smart home SH-PPZW Manuel utilisateur
MODEL: SH - PPZW
Bkav SmartHome technology company limited
USER GUIDE
SMART SOCKET
SH - PPZW
1
Thank you for choosing Smart socket SH - PPZW of Bkav
SmartHome. By selecting Bkav SmartHome’s products,
you will get the best warranty service and installation
support from our technicians.
This document gives useful information during installation
and usage time. You should read and keep the manual
carefully in case of need.
Copyright © 2015 Bkav SmartHome Co., Ltd.
All rights reserved.
The smart socket SH - PPZW is the product of Bkav
SmartHome and has been registered regarding design,
utility solutions and quality certification. All violations such
as copies of design and product idea are subject to the
current copyright law of the Socialist Republic of Vietnam.
Usage notice
Electric shock may cause injuries or threats to
life. Before installing, repairing or cleaning the
device, you should check whether the device’s
power is disconnected.
This work should be done by technicians or
Customer Contact Center to avoid electric
related accidents.
Environmental regulations must be complied
when discarding or recycling the device or its
wrapping.
Warning
2
1
2
3
4
4
5
6
7
8
9
9
9
10
10
11
12
Usage notice
Table of contents
Safety instruction
Introduction
General introduction
Product package
Specifications
Installation instruction
How to replace the device’s fuse
Device usage
Device components
Function of direct control
Function of advanced control
How to restore default mode
How to install software
Contact
Table of contents
3
Warning
Do not disassemble the device if not necessary.
Do not clean the device with corrosive chemicals.
Safety instruction
Do not use voltage which is different from the
one stated in the device’s specifications.
Disconnect device’s power prior to any installa-
tion, disassembly or repair.
Do not leave the device in high-temperature
environment.
Safety instruction should be complied during the
device usage.
4
General introduction
The smart socket SH - PPZW(*) is integrated with remote
control via Wi-Fi or ZigBee from mobiles and tablets.
With capacitive touch technology applied to design,
anti-scratch Gorilla glass, ABS plastic cover, the device
will make your house luxurious and modern.
Besides, with Wi-Fi connection and control via mobile
devices connected to Wi-Fi/3G the devices connected to
the smart socket will be controlled anywhere even when
you are not at home.
When SH – PPZW is used in smart room system, it can
connect to other devices such as motion sensors or
switch sensors, etc. via Wi-Fi connection.
Users can set up and configure the device via Bkav
SmartDevice software. They can turn on/off, schedule
time, set up schedules for the device based on their need.
The smart socket is used to control home appliances
such as night lamps, fans, televisions, etc.
Introduction
(*) Model SH - PPW: The device uses Wi-Fi technology.
(*) Model SH - PPZ: The device uses ZigBee technology.
Notice
Bộ sản phẩm đóng gói
5
Product package
Smart pocket
3 straight pins 2 straight pins
2 cross pins 2 round pins
User guide (book)
Adapter plug
(Packing based on
product distribution
market)
MODEL: SH - PPZW
6
Specifications
Voltage
Wi-Fi 802.11b/g/n - 2.4GHz
100-240V 50/60Hz
55 x 31 x 105 mm
120 gram
Operating temperature
Dimensions (L x W x H)
Weight
60ºC max
Power rating Incandescent lamp - maximum 1000W
Fluorescent lamp - maximum 350W
ZigBee 2.4GHz
7
Connect the adapter plug to the smart socket
Installation instruction
Connect the smart socket to an available socket
Connect an electric device to the smart socket
10A-240VAC
Model
:SH - PPZW
Smart socket
Voltage: 100-240V50/60Hz
Loadpower: 10Amax
Operationtemperature: 60ºC max
Made in Vietnam
(+1)202 386 6779
10A-240VAC
Model
:SH - PPZW
Smart socket
Voltage: 100-240V50/60Hz
Loadpower: 10Amax
Operationtemperature: 60ºC max
Made in Vietnam
(+1)202 386 6779
Remove the fuse holder from the device
Remove the blown fuse from the fuse holder
Place the new fuse in the fuse holder
8How to replace the device’s fuse
10A-240VAC
Model
:SH - PPZW
Smart socket
Voltage: 100-240V50/60Hz
Loadpower: 10Amax
Operationtemperature: 60ºCmax
Made in Vietnam
(+1)202 386 6779
10A-240VAC
10A-240VAC
10A-240VAC
10A-240VAC
Model
:SH - PPZW
Smart socket
Voltage: 100-240V50/60Hz
Loadpower: 10Amax
Operationtemperature: 60ºCmax
Made in Vietnam
(+1)202 386 6779
Model
:SH - PPZW
Smart socket
Voltage: 100-240V50/60Hz
Loadpower: 10Amax
Operationtemperature: 60ºCmax
Made in Vietnam
(+1)202 386 6779
Model
:SH - PPZW
Smart socket
Voltage: 100-240V50/60Hz
Loadpower: 10Amax
Operationtemperature: 60ºCmax
Made in Vietnam
(+1)202 386 6779
Model
:SH - PPZW
Smart socket
Voltage: 100-240V50/60Hz
Loadpower: 10Amax
Operationtemperature: 60ºCmax
Made in Vietnam
(+1)202 386 6779
