Smart Eye S-netx Manuel utilisateur

SMARTEYE

NETWORK READER

PRODUCTS

S-netx - Single Reader

T-netx - Dual Reader

Multi-netx - 8 Readers

Standard Ethernet or

Power over Ethernet Interface

802.3af (48v)

USER MANUAL

Revision 3

www.smarteyecorporation.com

related documents:

SMARTEYE Sender/Receiver Reader User Manual

The material in this manual is for informational purposes and is subject to

change without notice. Smarteye Corporation assumes no responsibility for any

errors which may appear in this manual.

SMARTEYE is a registered trademark of Smarteye Corporation.

BELDEN is a registered trademark of Belden CDT Inc.

Printed in U.S.A.

SMARTEYE contact information:

SMARTEYE Corporation

2637 Bond Street

Rochester Hills, MI 48309

Phone: (248) 853-4495 Fax: (248) 853-8539

www.smarteyecorporation.com

Email: [email protected]

SMARTEYE Netx Control Unit Manual Page i

TABLE OF CONTENTS

1.0 Introduction........................................................................................................... 1

2.0 Smarteye Netx Control Unit Features ................................................................ 2

3.0 Smarteye Netx Product Installation.................................................................... 2

4.0 Power/Wiring ........................................................................................................ 2

4.1 Power/Wiring for Power over Ethernet 802.3af (48v) – S-netx and T-netx only...............3

4.2 Power/Wiring for T-netx Model SP4051/03......................................................................3

4.3 Power/Wiring for Multi-netx Model SP4061/03 and SP4062/01......................................3

5.0 Communication Line Wiring............................................................................... 3

6.0 Reader Wiring and Mounting ............................................................................. 4

6.1 Reader Wiring.....................................................................................................................4

6.2 Local Reader Mounting (S-netx only) ................................................................................4

6.3 Remote Reader Mounting (S-netx, T-netx and Multi-netx) ...............................................4

7.0 Smarteye Netx Control Units CPU Configuration ............................................ 5

7.1 Configuration Legend .........................................................................................................5

7.2 S-netx Switch and Jumper Diagram....................................................................................6

7.2.1 S-netx Jumper Block J1 – Shield Termination Select............................................................. 7

7.2.2 S-netx Switches SW1 and SW2 – Auxiliary Port & Control Port Configuration .................. 7

7.2.3 S-netx Switches SW3, SW4 and SW5 – Not Used ................................................................ 8

7.2.4 S-netx Switch SW6 – Control Port Configuration - Receiver Select ..................................... 8

7.3 T-netx Switch and Jumper Diagram ...................................................................................9

7.3.1 T-netx Jumper Block J1 – Drain Termination ........................................................................ 9

7.3.2 T-netx Switch SW2 – Control Port Configuration ............................................................... 10

7.3.3 T-netx Switch SW6 – Control Port Configuration - Receiver Select ................................... 10

7.3.4 T-netx Power Select.............................................................................................................. 10

7.3.5 T-netx Jumper Block 2 ......................................................................................................... 11

7.4 Multi-netx Switch and Jumper Diagram...........................................................................12

7.4.1 Multi-netx Switch SW2 – Control Port Configuration......................................................... 12

7.4.2 Multi-netx Switch SW6 – Control Port Configuration - Receiver Select............................. 13

7.4.3 Multi-netx Jumper Block J1 – Port Ground Select............................................................... 13

7.4.4 Multi-netx Jumper Block J2 ................................................................................................. 14

7.5 RS485 Line Termination SW2..........................................................................................14

7.6 Terminating RS485 Point-To-Point (Handshake Mode) ..................................................14

7.7 Terminating RS485 Multi-drop (Poll Mode)....................................................................15

7.8 Shield (Drain) Terminations (J1) ......................................................................................16

8.0 Software Configuration...................................................................................... 16

8.1 Software Configuration Using the Network Port..............................................................17

8.1.1 Pre-Assignment of IP address............................................................................................... 18

Filename: netx Platform User Manual R3 .doc

…

In Control

SMARTEYE Netx Control Unit Manual Page ii

8.1.2 DHCP Automatic Assignment of IP address........................................................................ 18

8.1.3 Manual Assignment of IP address Using Smarteye Netx Setup Utility Program................. 18

8.1.4 Manual Assignment of IP address using a Web Browser..................................................... 25

8.2 Software Configuration Using the Auxiliary Port ............................................................29

8.2.1 Serial configuration Commands ........................................................................................... 31

8.2.1.1 General Configuration Example.................................................................................. 32

8.2.1.2 Network Port Configuration Example......................................................................... 32

8.2.1.3 Control Port Configuration Example .......................................................................... 33

8.2.1.4 Auxiliary Port Configuration Example ....................................................................... 33

8.3 Smarteye Netx Control Unit Configuration Parameters ...................................................34

8.3.1 Smarteye Netx Control Unit Configuration Parameters - General Configuration................ 34

8.3.2 Smarteye Netx Control Unit Configuration Parameters - Network Control Port ................. 35

Smarteye Netx Control Unit Configuration Parameters - Serial Control Port ................................... 36

8.3.3 Smarteye Netx Control Unit Configuration Parameters - Auxiliary Port ............................. 36

9.0 Monitoring........................................................................................................... 36

9.1 Monitor Commands: .........................................................................................................37

9.1.1 HELP – ‘h<cr>’.................................................................................................................... 38

9.1.2 MONITOR – ‘m<cr>’ .......................................................................................................... 38

9.1.3 INPUT – ‘i<cr>’ ................................................................................................................... 39

9.1.4 OUTPUT – ‘o<cr>’ .............................................................................................................. 39

9.1.5 BOTH – ‘b<cr>’ ................................................................................................................... 39

9.1.6 TIMESTAMP – ‘t<cr>’........................................................................................................ 39

9.1.7 PHOTOEYES – ‘p<cr>’....................................................................................................... 39

9.1.8 LABEL – ‘l<cr>’ .................................................................................................................. 40

9.1.9 ERROR – ‘e<cr>’.................................................................................................................40

9.1.10 DIAGNOSTIC – ‘d<cr>’...................................................................................................... 40

9.1.11 SHOW – ‘s<cr>’................................................................................................................... 40

9.1.12 VERSION – ‘v<cr>’............................................................................................................. 41

9.1.13 RUNTIME – ‘r<cr>’ ............................................................................................................ 41

9.1.14 EXIT – ‘exit<cr>’................................................................................................................. 41

10.0 Smarteye Netx Control Unit Web Pages........................................................... 42

10.1.1 Configuration webpage......................................................................................................... 43

10.1.2 Set Date & Time webpage.................................................................................................... 44

10.1.3 Read History webpage.......................................................................................................... 45

11.0 Power-Up ............................................................................................................. 46

12.0 Communication................................................................................................... 46

12.1 Ethernet Control Port Operation .......................................................................................46

12.2 Auxiliary Port Operation ..................................................................................................47

12.3 Message Protocols Classic (Original) & Full ASCII ........................................................47

12.4 Message Conventions for Classic Protocol.......................................................................47

12.4.1 Checksum Calculation Example ........................................................................................... 49

12.4.2 Received Poll........................................................................................................................ 50

12.4.3 Received Commands ............................................................................................................ 50

12.4.4 Messages Transmitted By The Smarteye Netx Control Unit................................................ 51

12.4.4.1 Online Idle Message.................................................................................................... 51

12.4.4.2 Offline Message .......................................................................................................... 51

12.4.4.3 Label Message............................................................................................................. 52

Filename: netx Platform User Manual R3 .doc

…

In Control

SMARTEYE Netx Control Unit Manual Page iii

12.4.4.4 Error Message ............................................................................................................. 52

12.4.4.5 Diagnostic Message .................................................................................................... 52

12.4.5 Poll Mode ............................................................................................................................. 52

12.4.5.1 Summary Of Responses - Poll Mode ......................................................................... 53

12.4.6 Handshake Mode ..................................................................................................................53

12.4.6.1 Summary Of Responses - Handshake Mode.............................................................. 54

12.4.6.2 Example #1 - Handshake Mode - Normal Operation.................................................. 55

12.4.6.3 Example #2 - Handshake Mode - Abnormal Operation.............................................. 56

12.5 Message Conventions for Full ASCII...............................................................................57

12.5.1 Checksum Calculation Example ........................................................................................... 58

12.5.2 Received Poll........................................................................................................................ 59

12.5.3 Received Commands ............................................................................................................ 59

12.5.4 Messages Transmitted By The Smarteye Netx Control Unit................................................ 60

12.5.4.1 Online Idle Message.................................................................................................... 60

12.5.4.2 Offline Message .......................................................................................................... 60

12.5.4.3 Label Message............................................................................................................. 61

12.5.4.4 Error Message ............................................................................................................. 61

12.5.4.5 Diagnostic Message .................................................................................................... 61

12.5.5 Poll Mode ............................................................................................................................. 61

12.5.5.1 Summary Of Responses - Poll Mode ......................................................................... 62

12.5.6 Handshake Mode ..................................................................................................................62

12.5.6.1 Summary Of Responses - Handshake Mode.............................................................. 63

12.5.6.2 Example #1 - Handshake Mode - Normal Operation.................................................. 64

12.5.6.3 Example #2 - Handshake Mode - Abnormal Operation.............................................. 65

13.0 Diagnostic Enable ............................................................................................... 66

14.0 Error Messages ................................................................................................... 66

Appendix A S-netx SP4002 Drawings................................................................... A-1

A.1 Sender/Receiver Cable Details for Local Mounting Applications – SP1054/01-417.....A-2

A.2 Sender/Receiver Cable Details for Remote Mount Applications –SP1054/01-418........A-3

A.3 S-netx Installation Details No-Power over Ethernet– SP4002/01-420...........................A-4

A.4 S-netx Connection Wiring Details No-Power over Ethernet– SP4002/01-410 ..............A-5

A.5 S-netx Installation Details Power over Ethernet – SP4002/02-420 ................................A-6

A.6 S-netx Connection Wiring Details Power over Ethernet – SP4002/02-410 ...................A-7

A.7 S-netx Auxiliary and Communication Port Wiring Details – SP4002/01-411 ...............A-8

Appendix B T-netx SP4050 Series Drawings....................................................... B-1

B.1 Sender/Receiver Cable Details – SP1054/01-419...........................................................B-2

B.2 T-netx Installation Details – SP4050/01-420..................................................................B-3

B.3 T-netx Connection Wiring Details No-Power over Ethernet– SP4050/01-410..............B-4

B.4 T-netx Connection Wiring Details Power over Ethernet – SP4050/02-410 ...................B-5

B.5 T-netx NEMA-12 Installation Details – SP4051/01-420................................................B-6

B.6 T-netx NEMA-12 Connection Wiring Details 110/220 VAC Power – SP4051/03-410 B-7

B.7 T-netx Auxiliary and Communication Port Wiring Details – SP4050/01-411...............B-8

Filename: netx Platform User Manual R3 .doc

…

In Control

SMARTEYE Netx Control Unit Manual Page iv

Appendix C Multi-netx SP4060 Series Drawings................................................ C-1

C.1 Sender/Receiver Cable Details – SP1054/01-424...........................................................C-2

C.2 Multi-netx Installation Details – SP4060/01-420 ...........................................................C-3

C.3 Multi -netx Connection Wiring Details 24VDC– SP4060/01-410 ................................. C-4

C.4 Multi-netx NEMA-12 Installation Details 24VDC– SP4061/01-420.............................C-5

C.5 Multi -netx NEMA-12 Connection Wiring Details 24VDC– SP4061/01-410 ...............C-6

C.6 Multi -netx NEMA-12 Installation Details 110/220VAC – SP4061/03-420..................C-7

C.7 Multi -netx NEMA-12 Connection Wiring Details 110/220VAC – SP4061/03-410.....C-8

C.8 Multi -netx Auxiliary and Communication Port Wiring Details – SP4060/01-411........C-9

C.9 Multi -netx Upgrade Kit Installation Details – SP4062/01-201 ..................................C-10

Filename: netx Platform User Manual R3 .doc

…

In Control

SMARTEYE Netx Control Unit User Manual Page 1

1.0 Introduction

Netx platform controller products are Smarteye’s latest, RoHS-compliant, reader interface units

used to interpret the patented Smarteye label pattern and direct the decoded data to central host

control systems or local PLC controllers. Although these new platform control units fully

support the RS-485 serial interface mechanism, the primary focus of this product platform is to

provide control connectivity over an Ethernet network. There are three offerings in Smarteye

Netx product line-up; the S-netx which is a single-reader control unit, the T-netx which provides

dual-reader capability, and the Multi-netx which supports up to 8 readers. To the system control

engineer, all three units function identically, the only difference being the number of Smarteye

readers supported and the corresponding physical footprint of the hardware. Besides the

physical mounting difference, due to power limitations, only the S-netx and T-netx can support

the 802.3af Power-over-Ethernet option at this time.

Wiring costs for Smarteye’s Netx Control Units are expected to be substantially less since most

plants now have their network infrastructure already in place. Utilizing power over Ethernet

further reduces the installation cost by eliminating the need for separate power wiring.

Reader(s) interface to Smarteye Netx Control Units through the reader port(s). The reader

senses a pattern of coded bars in the Smarteye label. As a label passes in front of a reader, the

coded information is passed along to the Smarteye Netx Control Unit. The Smarteye Netx

Control Unit then deciphers the coded information and makes the information available to the

control system(s). A typical control system would be a device such as a programmable

controller or computer.

Smarteye labels are typically constructed of 12-gauge steel and come in a variety of lengths to

suit specific application requirements.

The following is a list of Controller models covered by this manual:

• SP4002/01 – S-netx standard Ethernet interface, 24VDC power

• SP4002/02 – S-netx 802.3af compliant, power over Ethernet interface

• SP4050/01 – T-netx standard Ethernet interface, 24VDC power

• SP4050/02 – T-netx 802.3af compliant, power over Ethernet interface

• SP4051/01 – T-netx standard Ethernet interface, 24VDC power, NEMA-12

• SP4051/02 – T-netx 802.3af compliant, power over Ethernet interface, NEMA-12

• SP4051/03 – T-netx standard Ethernet interface, 110/220VAC power, NEMA-12

• SP4060/01 – Muti-netx standard Ethernet interface, 24VDC power

• SP4061/01 – Muti -netx standard Ethernet interface, 24VDC power, NEMA-12

• SP4061/03 – Muti -netx standard Ethernet interface, 110/220VAC power, NEMA-12

• SP4062/01 – Muti -netx SEA-8 Upgrade Kit, 110/220VAC power

Filename: netx Platform User Manual R3 .doc

…

In Control

SMARTEYE Netx Control Unit User Manual Page 2

2.0 Smarteye Netx Control Unit Features

For ease of installation the S-netx is designed to be mounted along with the Smarteye reader

assembly and can easily be mounted on the same bracket.

In general, Smarteye network products include the following major features:

• CPU circuit card with power indicators, two serial communication ports, and reader

interface circuitry. Cage or spring clamp connectors are provided for connection to

reader field wiring and the serial control port. A 9-pin DB-type connector is provided for

the auxiliary port.

• Panel Mount or NEMA-12 enclosures (S-netx available in NEMA-12 version only)

• RJ45 connector for Ethernet communication with link and activity LEDs

• Available in power over Ethernet 802.3af (48VDC) (S-netx and T-netx only)

3.0 Smarteye Netx Product Installation

The Smarteye Netx Control Units are designed to function in the environment found in most

industrial facilities. Smarteye Netx Control Units will operate properly in the same environment

as a programmable controller. They are rated for operation at temperatures from 0 to 60° C,

non-condensing.

Use of the specified cables for equipment interconnections with proper shield termination and

equipment grounding are recommended to minimize electromagnetic interference on signal lines.

Smarteye Netx Control Units should be mounted in such a way to allow complete access to the

unit. Adequate space must be left to insure that the covers can be opened for maintenance.

Mounting dimensions for each of the network products enclosures can be found in the appendix.

4.0 Power/Wiring

All Smarteye Netx Control Units operate on an input voltage of 24VDC. The S-netx uses 6

watts, the T-netx uses 9 watts, and the Multi-netx requires 28 watts of power. A polyswitch (self-

resetting) fuse link is used to protect the electronics on all models. See the appendix for detailed

drawings.

Smarteye Netx Control Units have been designed to be as tolerant to power fluctuations as is

practical. However, like most electronic equipment, they can be susceptible to 'brownouts' and

severe voltage 'spikes'. The AC line which drives the power supply for the Smarteye Netx

Control Units can supply other similar electronic equipment such as programmable controllers,

but should be isolated from any heavy industrial equipment that causes excessive line

fluctuations such as motors, motor starters, welders, variable frequency drives, etc.

All applicable codes and ordinances should be observed for wiring power and ground,

particularly the National Electrical Code published by the National Fire Protection Association

of Boston, Massachusetts.

Filename: netx Platform User Manual R3 .doc

…

In Control

SMARTEYE Netx Control Unit User Manual Page 3

4.1 Power/Wiring for Power over Ethernet 802.3af (48v) – S-netx and T-netx only.

The S-netx and T-netx both offer an optional power input module, which meets the 48VDC

Ethernet 802.3af specification. With this option, these units may be powered via an 802.3af

compliant power source through the Ethernet communication cable. This provides power for

both the CPU circuit card and the reader(s) connected to the unit. An RJ45 connector is

provided on the S-netx and T-netx for delivering both power and data. See the appendix for

detailed drawings.

4.2 Power/Wiring for T-netx Model SP4051/03

The T-netx SP4051/03 unit is designed to be powered from 110 to 240 VAC 50-60 Hz. This unit

includes an AC circuit breaker and internal 24VDC power supply. See the appendix for detailed

drawings.

4.3 Power/Wiring for Multi-netx Model SP4061/03 and SP4062/01

The Multi-netx SP4061/03 and SP4062/01 are designed to be powered from 110 to 240 VAC 50-

60 Hz. These units include an AC circuit breaker and internal 24VDC power supply. See the

appendix for detailed drawings.

5.0 Communication Line Wiring

All Smarteye network products have three communication ports: the Ethernet control port, the

serial control port, and the auxiliary port. The S-netx is supplied with an RJ45 connector on the

inside of the box and a single-hole Ethernet cable grommet on the outside of the box. The T-

netx and Multi-netx have an RJ45 connector on the outside of the unit. The RJ45 connector

provides communication for all products and optional power connections for the S-netx and T-

netx. Diagrams of the Ethernet connection can be found in the appendix.

The serial control port connector for an S-netx is a cage clamp type and is located at the bottom

of the CPU circuit card. The T-netx and Multi-netx use a spring clamp connector for the serial

control port that protrudes through the bottom of the case. The auxiliary port connection is a 9-

pin DB connector on all Netx products. The auxiliary port is factory configured for RS232

communications (57600 baud, 8 data bits, parity none, 1 stop bit, flow control none).

Belden 8723 or equivalent (2 shielded pairs, 22 gauge) is recommended for RS232 connections.

A detailed wiring drawing can be found in the appendix.
