SMART-AVI QWALL-HD Manuel utilisateur

4X4 HDMI Matrix & WALL System 1

1-800-284-2131

www.smartavi.com

USER MANUAL

4X4 HDMI Matrix & WALL System

QWALL-HD 4X4 HDMI Matrix & WALL System

QWALL-HD

4X4 HDMI Matrix & WALL System 2

TECHNICAL SPECIFICATIONS_____________________________________________________________ 3

WHAT’S IN THE BOX?_____________________________________________________________________ 4

QWALL-HD FRONT AND REAR___________________________________________________________ 4

INSTALLATION____________________________________________________________________________ 5

APPLICATION DIAGRAM__________________________________________________________________ 5

AVAILABLE CONFIGURATION_____________________________________________________________ 6

CONTROL USING THE FRONT PANEL_____________________________________________________ 7

CONTROL USING IR REMOTE CONTROL__________________________________________________ 8

CONTROL USING RS-232__________________________________________________________________ 9-10

RS-232 INTEGRATION WITH THIRD PARTY SOFTWARE____________________________________11

CONTROL USING TCP/IP__________________________________________________________________ 12-14

WEB CONFIGURATION___________________________________________________________________ 15

FIRMWARE UPDATE______________________________________________________________________ 15

TROUBLESHOOTING______________________________________________________________________16

TECHNICAL SUPPORT_____________________________________________________________________ 16

LIMITED WARRANTY STATEMENT________________________________________________________ 17

Table of content

4X4 HDMI Matrix & WALL System 3

VIDEO

Video Bandwidth Single-link 340MHz [10.2Gbps]

Resoluon HDTV Up to 1080p

PC Resoluon Up to 1920 x 1080

Input Video Signal 1.2 volts

Input DDC Signal 5 volts

Single Link Range 1080p

Format HDMI 1.4

DVI Compliance Single-link DVI-D 2.0

Output Cable Length Up to 20 .

HDCP Compliance 1.0/2.0

Input Interface (4) HDMI

Output Interface (4) HDMI

Connector Type A [19-pin female]

Technical Specifications

AUDIO

Format HDMI Digital Audio

Output Interface 3.5 mm Stereo Audio

Frequency Response 20Hz ~ 20KHz

CONTROL

Front Panel Push Buons with LED Indicators

RS-232 DB9 (female) Via Control @ 9600 bps

Hot Keys Via Keyboard

Remote IR

Web Web Interface

OTHER

Power Internal 100-240 VAC

Dimensions 17.0” W x 2.0” H x 10.75” D

Weight 4.4 lbs

Approvals UL, CE, ROHS Compliant

Operang Temp. +32 to +104°F (0 to +40°C)

Storage Temp. -4 to 140°F (-20 to +60°C)

Humidity Up to 80% (No Condensaon)

4X4 HDMI Matrix & WALL System 4

What’s in the box?

Qwall-hd rear

Qwall-hd front

PART NO. QTY DESCRIPTION

QWALL-HD 14x4 HDMI Matrix & WALL System.

PS12VD3A-WLLMNT 112V DC, 3A (minimum) power adapter with center-pin posive polarity.

SAVI-RMT 1IR Remote Control

User Manual

4X4 HDMI Matrix & WALL System 5

1. Make sure QWALL-HD is turned o.

2. Connect up to 4 HDMI inputs (i.e. PC, Blu-Ray Player, Digital Signage, etc.) to the HDMI

INPUT ports of QWALL-HD using HDMI cables.

3. Connect up to 4 HDTVs to the HDMI OUTPUT ports of QWALL-HD using HDMI cables

or HDMI-to-DVI adapters for DVI displays.

4. Connect a CAT5/CAT6 cable to the RJ45 connector.

5. Oponally connect an RS232 cable from PC to the RS-232 port of the unit for addional

control.

6. Turn on QWALL-HD

7. Wait for the unit to inialize. This should take less than a minute.

installation

Application diagram

4X4 HDMI Matrix & WALL System 6

Available configuration

Video Wall Mode: User can select any of the four HD inputs and project the image across

four HD screens (2x2 conguraon).

Clone Mode: User can select any of the four HD inputs and project the image individually on

all four HD screens, with supported resoluon up to 1920x1080 on each screen.

Matrix Mode: User can quickly assign inputs to their desired output.

Splicing Mode: User can splice the input to do dierent matrix arrays (i.e. 1x2, 2x1, 1x3, 3x1,

1x4, 4x1).

1x2

2x1

1x3

3x1

1x4

4x1

4X4 HDMI Matrix & WALL System 7

CONTROL USING THE FRONT PANEL

The front panel supports changing between several modes, Matrix, Wall, and the preset

saved onto Macro 1 and Macro 2.

To use Matrix Mode, select this mode and then select the desired Output and Input

respecvely. For example to set Input 1 on Output 3, the user must press Buon 5 -> Buon

3 (Output) -> Buon 1 (Input).

To use Wall Mode, select this mode and the select the desired Input.

To use the Macro buons, user must access the web page of QWALL-HD and set each

buon to a specic preset. Once the user saves the Macro buon from the web, QWALL-HD

will always change to the specic preset with the selected input unl the user updates

QWALL-HD to perform a new macro.

BUTTON DESCRIPTION

1Input 1

2Input 2

3Input 3

4Input 4

5Matrix Mode

6Wall Mode

7Macro 1

8Macro 2

There are a total of 8 buons used for the front panel of QWALL-HD.

4X4 HDMI Matrix & WALL System 8

CONTROL USING IR REMOTE CONTROL

COMMAND FUNCTION

IN -> # -> WALL -> OK Set Input ‘#’ to Wall Mode

IN -> # -> CLONE -> OK Set Input ‘#’ to Clone Mode

IN -> # -> QUAD -> OK Set Input ‘#’ to quickly set up matrix array of all

4 inputs, with ‘X’ on Output 1

IN -> # -> OUT -> 1 -> OK Set Input ‘#’ to Output 1

IN -> # -> OUT -> 2 -> OK Set Input ‘#’ to Output 2

IN -> # -> OUT -> 3 -> OK Set Input ‘#’ to Output 3

IN -> # -> OUT -> 4 -> OK Set Input ‘#’ to Output 4

IN -> # -> F1 -> OK Set Input ‘#’ to do 1x2 splicing on Output 1 + 2

IN -> # -> F1 -> F1 -> OK Set Input ‘#’ to do 1x2 splicing on Output 3 + 4

IN -> # -> F2 -> OK Set Input ‘#’ to do 2x1 splicing on Output 1 + 3

IN -> # -> F2 -> F2 -> OK Set Input ‘#’ to do 2x1 splicing on Output 2 + 4

IN -> # -> F3 -> OK Set Input ‘#’ to do 1x4 splicing

IN -> # -> F4 -> OK Set Input ‘#’ to do 4x1 splicing

Note: # will only use 1, 2, 3, or 4

4X4 HDMI Matrix & WALL System 9

CONTROL USING RS-232

The QWALL-HD may also be controlled via RS-232 commands. This feature requires

an RS-232 card installed on your computer or a USB to RS-232 adapter. Below are

instrucons on how to properly create an RS-232 connecon between a PC the QWALL-HD.

Establish a connecon to QWALL-HD:

1. Connect a straight- through male-to-female RS-232 cable to the RS-232 connector

on the PC.

2. Connect the other end of the cable to the RS-232 port of the QWALL-HD.

3. Power on the device.

If you are using a USB to COM port adapter and need to idenfy the COM port used do the

following:

1. Click on the start buon.

2. Click on Control Panel.

3. Click on Device Manager.

4. Click on the arrow next to Ports (COM & LPT).

You should see the name of your adapter and the COM port number in use.

Seng up the Terminal Applicaon:

Run the terminal client of your choice such as HyperTerminal or PuTTY. Select the correct

COM port on the PC. Use the following connecon sengs: 9600, N, 8, 1, no ow control.

Once the connecon is established type ? And hit enter. The QWALL-HD should respond

with a version number and a list of commands.

When you connect to the QWALL-HD to a computer via an RS-232 connecon, you will see

an opening screen on startup. Below are some examples of RS-232 commands.

4X4 HDMI Matrix & WALL System 10

CONTROL USING RS-232 (continued)

Type ? To see the Main Menu list

of commands.

QWALL-HD v1.23.10 main menu

i - system information

v - display mode and video options

e - edid/hotplug

a - audio

o - osd navigator and parts load

? - help

Type –v to switch to the Video Menu.

-v

main -> video menu

Type -i to view System Informaon.

-i

Port src res EDID HPD audio

1 HDMI 1920x 540 CAT-6066 ON 0

2 HDMI 1920x 540 CAT-6066 ON 1

3 HDMI 1920x1080 CAT-6066 ON 2

4 DVI 1920x 540 CAT-6066 ON 3

Current Output: 1080P

Then Type ? to view the Video Menu.

QWALL-HD v1.23.10 video menu

f -set [Input] to [Output] in full screen

q -set [Input] to quadrant 1

p -set [Input] to main screen of pip mode

v -set [Input] as a videowall

fl -flip [channel] [ 1:flip | 2:unflip ]

o -[1-1080P60|2-1080P30]

ex -exit to main menu

? -help
