SKS Germany INFINITY UNIVERSAL Manuel utilisateur
GERMANY
A 1x
F 1x
B 1x
C 1x
D 1x
E 1x
TX25
4.
1.
A
B
2.
3.
1. A
TOP
2.
1.
D
E
3 Nm
A
1.
2.
F
C
< 31,8 mm
3.
F
1.
B
2.
2x
2.
1 x 1 sec. = ON
1 x 1 sec. = OFF
1.
2,5 h
MANUAL ¬ INFINITY UNIVERSAL REARLIGHT ¬ 11948
ALLROAD ROAD MOUNTAIN
EN . Scope of delivery
EN . Tools
EN
Thread the short rubber band (B) into
the holder (A) and position it over
the tabs on the back. Finally, fold the
loops of the rubber band (B) up and
down on the front.
EN
Place the rear light bracket (A) on
the mounted luggage rack. The bolts
of the bracket (A) must engage in
the holes of the luggage rack.
Please note.
Note the alignment.
01
02
EN . Mounting the rear light
EN
Fix the rear light bracket (A) to the
luggage rack with the washer (D)
and screw (E).
EN
Alternatively, you can mount the rear
light (F) directly on the seat post
using the long rubber band (C).
Please note. Seat post
diameter max. 31.8 mm.
EN
Mount the rear light (F) on the luggage
rack using the loops from the rubber
band (B).
Please note.
Ensure that the rubber
band is correctly seated.
E
N
Operation. To switch on and off,
press the button on the side for
approx. one second. You need a
micro-USB cable (not included in
scope of supply) for charging. The
charging time is approx. 2.5 hours.
03 i
04 i
GERMANY
MANUAL ¬ INFINITY UNIVERSAL REARLIGHT ¬ 11948
ALLROAD ROAD MOUNTAIN
Carefully read the entire safety instructions and follow the
instructions.
Safety instructions.
• Ensure that the tensioning rubber is correctly seated.
If the rubber is not correctly guided behind the retaining lugs,
the rear light may fall off during cycling.
• Fully charge the rear light before using it for the first time.
• If the rear light is not used for a longer period of time,
we recommend charging the rear light every 6 months to prolong
the life of the installed battery.
Intended use.
The product is to be used as an accessory for the SKS Infinity Universal lug-
gage rack. Therefore, mount the SKS Infinity Universal luggage rack properly
beforehand.
Alternatively, the product can be mounted and used on the seat post with the
supplied rubber band.
Any other use or structural alteration is considered to be not in accordance with
the intended use and results in the expiry of the legal and contractual warranty.
Disposal.
Dispose of packaging material in accordance with the applicable national and
regional regulations.
The product contains batteries and must not be disposed of in hou-
sehold waste. You are legally obliged to return used batteries so that
proper disposal can be ensured. You can return used batteries to a
municipal collection point or to your local retailer. Alternatively, you
can also send the used batteries to us by post.
EN . Safety instructions
