Skope ActiveCore TMF650N Series Manuel utilisateur

TMF / SKFT-N ActiveCore

SKOPE Top Mount Freezer

Hydrocarbon

Service Manual

MAN80227 Rev. 1.0 Dec. 2021

TMF / SKFT-N ActiveCore

SKOPE Top Mount Freezer

Hydrocarbon

Service Manual

MAN80227

Rev. 1.0 Dec. 2021

SKOPE Industries Limited reserve the right to alter specifications without notice.

is a registered trademark of SKOPE Industries Limited.

SKOPE INDUSTRIES LIMITED

Head Office

PO Box 1091, Christchurch

New Zealand

NZ: 0800 947 5673

E-mail: [email protected]

Website: www.skope.com

Trademark Infringement

The SKOPE trademark on this product is infringed if the owner, for the time being, does

any of the following:

• Applies the trade mark to the product after their state, condition, get-up or packaging

has been altered in any manner

• Alters, removes (including part removal) or obliterates (including part obliteration) the

trade mark on the product

• Applies any other trade mark to the product

• Adds to the product any written material that is likely to damage the reputation of the

trade mark

Notice of the above contractual obligations passes to:

• Successors or assignees of the buyer

• Future owners of the product

SKOPE TMF-N ActiveCore Series

Service Manual iii

CONTENTS

1Servicing Hydrocarbon

Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6

SKOPE HC Service Requirements . . . . . . . . . . . . . . . . . . . . . . . . . . .7

2Specifications

Models. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8

3Electronic Controller

Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9

Apps . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9

SCS Connect Field App . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

SCS Connect Track App . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

SKOPE Connect App . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

Controller Faceplate . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10

Buttons and Display . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

Service Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

SCS Connect Field App and Track App. . . . . . . . . . . . . . . . . . . . . . .12

Connecting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12

App Categories . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13

Faults and Alarms . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .15

4Wiring

Model: TMF/SKFT650N/1000N . . . . . . . . . . . . . . . . . . . . . . . . . .19

Notes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .21

5Spare Parts

Main Assembly - TMF/SKFT650N Series . . . . . . . . . . . . . . . . . . . . .22

Parts — Main Assembly TMF650N Series . . . . . . . . . . . . . . . . . .22

Main Assembly - TMF/SKFT1000N Series . . . . . . . . . . . . . . . . . . . .23

Parts — Main Assembly TMF1000N Series . . . . . . . . . . . . . . . . .23

Cabinet Assembly - TMF650N Series . . . . . . . . . . . . . . . . . . . . . . . .24

Parts — Cabinet Assembly TMF650N Series . . . . . . . . . . . . . . .24

Cabinet Assembly - TMF1000N Series. . . . . . . . . . . . . . . . . . . . . . .25

Parts — Cabinet Assembly TMF1000N Series . . . . . . . . . . . . . .25

Glass Door Assembly . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .26

Parts — Glass Door Assembly . . . . . . . . . . . . . . . . . . . . . . . . . . .26

Sign Assembly. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .27

Parts — Sign Assembly TMF650N . . . . . . . . . . . . . . . . . . . . . . .27

Parts — Sign Assembly TMF1000N . . . . . . . . . . . . . . . . . . . . . .27

Unit Assembly UTHDNI-0043 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .28

Parts — Unit Assembly . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .29

Electronic Controller Assembly . . . . . . . . . . . . . . . . . . . . . . . . . . . . .30

Parts — Electronic Controller . . . . . . . . . . . . . . . . . . . . . . . . . . . .30

Unit Junction Box Assembly . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .31

Parts — Unit Junction Box . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .31

6Installation

Installation Guidelines. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .32

Ventilation Requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .33

Door Handles . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .34

Fitting Door Handles . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34

Removing Door Handles . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35

Shelves . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .36

Shelf Clips . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36

SKOPE TMF-N ActiveCore Series

Service Manual

Repositioning Shelves . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36

7Operation

Loading Product . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .37

Light Switch. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .37

Cabinet Heat Control. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .38

Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38

Dew Point Sensor . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38

Temp Sensor . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38

Hot Gas Defrost . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .39

Refrigeration System Diagnostics - Function Test . . . . . . . . . . . . . .40

Refrigeration System Table. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .41

Cabinet Heat Control. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .42

Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42

Trouble Shooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42

Adjusting Heater Power . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43

Procedure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43

Dew Point Sensor . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43

Temp Sensor . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44

Compressor and Inverter Information . . . . . . . . . . . . . . . . . . . . . . . .45

Inverter LED Indication . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45

Trouble Shooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45

Compressor . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46

Compressor Inverter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47

8Replacement Procedures

Lighting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .48

Sign Light . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 51

Doors. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .52

Alignment Adjustment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 52

Height Adjustment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 52

Replacing the Gasket . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 52

Removing and Refitting the Door . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 52

Adjusting Door Tension . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 54

Replacing the Torsion Bar . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 54

Refrigeration Unit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .55

Before Servicing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 55

Refrigeration Unit Assembly . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 56

Gas Detector . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 57

Leak Detector . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 57

On-Site Work . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 57

Not Cooling Fault . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 57

Hydrocarbon Workshop . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 57

Removing the Unit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 59

Replacing the Unit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 60

Unit Electrics Box Assembly . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 61

Unit Cover . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 62

Condenser Fan . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 62

Evaporator Fan . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 64

Replacing the Controller . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 67

Door Switch . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 68

Control Probe . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 68

Evaporator Probe . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 69

Condenser Probe . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 70

Ambient Probe . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 71

Oxygen Free Nitrogen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 72

Cleaning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .73

Cabinet . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 73

Condenser Coil . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 73

Probe Resistance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .74

SKOPE TMF-N ActiveCore Series

Service Manual

Probe Resistance (continued) . . . . . . . . . . . . . . . . . . . . . . . . . . . 75

9Troubleshooting

Electronic Controller . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 76

Cabinet and Refrigeration Unit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 76

On-site work procedure by authorised service person . . . . . . . . 78

On-site work procedure (continued) . . . . . . . . . . . . . . . . . . . . . . 79

6Servicing Hydrocarbon

Service Manual

SKOPE TMF-N ActiveCore Series

1Servicing Hydrocarbon

Overview

This ActiveCore freezer range utilises hydrocarbon (HC) R290 as its

refrigerant. R290 is a natural refrigerant that has a very low environmental

impact.

Special service requirements are needed as R290 is a flammable

refrigerant.

Safety hazards

The main hydrocarbon safety hazards are:

Flammable refrigerant.

Venting of hydrocarbon and compressor oil.

Asphyxiation.

Do not interfere with the refrigeration system. All refrigeration maintenance

and repairs must be undertaken according to the SKOPE HC Service

Requirements below.

See “SKOPE HC Service Requirements” on page 7 for more information

including examples of hazardous activities.

Electrical safety precautions

Correct wiring routing is as important as use of correct components for

compliance with safety and radio interference regulations. In order to

maintainsafety andcompliancewith regulations,any wiringthatis disturbed

during servicing must be replaced and secured in its original position.

SKOPE TMF-N ActiveCore Series

Servicing Hydrocarbon

Service Manual

SKOPE HC Service Requirements

Servicing must only be performed byApproved SKOPE Service Technicians, and must meet all

requirements in the SKOPE HC Service Policy (available from SKOPE), including the following:

Hydrocarbon work – SKOPE Service Policy

It is the responsibility of the service technician to follow SKOPE’s Hydrocarbon equipment service policy

and by accepting a service work order they agree to the following (where applicable):

xMUST – Ensure all workers are trained in the SAFETY of hydrocarbon products to the appropriate

level for the work required.

xMUST – Follow all Local Safety Regulations relevant to flammable refrigerant gases.

oAustralia should reference - AIRAH Flammable Refrigerants – Safety Guide

oNew Zealand should reference – Flammable Refrigerant Safety Documentation

(Refrigerant License NZ)

xMUST – Adhere to all on-site (workplace) Health and Safety requirements

xMUST – Not modify or alter the design of SKOPE equipment in any way

xMUST – In cases where the refrigeration system is not readily removable from the cabinet; then the

entire cabinet MUST be sent to the Hydrocarbon workshop for repair.

xMUST – ONLY use SKOPE OEM Spare Parts; or identical replacement parts. Any variation in

replacement part may render the system non-compliant and unsafe.

xMUST – Follow all best practice work activities for servicing hydrocarbon refrigerants (SKOPE

recommend attending specific hydrocarbon refrigeration handling training courses). Nitrogen must

be used for purging system before commencing “Hot Work” – brazing.

xMUST – Adhere to relevant SKOPE Service Manual. If any contradiction, the local Regulations take

precedence over SKOPE requirements

xMUST – Work only in suitable, safe and compliant work spaces. Personal Protective Equipment

must always be used when working on Hydrocarbon equipment.

xMUST – Service people diagnosing refrigeration faults must always carry and utilise Flammable Gas

detectors when working on Hydrocarbon equipment.

xMUST – Prior to any service work; know where and how to safely and quickly isolate power supply

to cabinet

xMUST – Not perform any Hot Work (brazing etc.) in the field. These are to be completed in a suitable

service depot / workshop (in a dedicated specific Hazardous Work Area compliant to local

flammable gas regulations)

xMUST – Not transport a refrigeration system with a known active leak. If there is an active leak the

refrigerant must be safely removed (with use of Bullet Piercing Valve or Line Tap valves) before

transporting. Valves must be removed at the hydrocarbon service depot once repair is completed.

xMUST – All hydrocarbon workshop areas must have emergency plans; that includes suitable

evacuation and fire control plans and equipment.

xMUST – Only use refrigerant grade hydrocarbon, to precise mass specified on removable

refrigeration system serial label.

xMUST – Be accurate refrigerant charge; The refrigerant mass is ultra-low charge and must only be

measured in by accurate scales to +/- 1.0gram. Refrigerant MUST not be overcharged; or added to

an already charged system.

xMUST – Use identical drier replacement; as any change will affect gas charge volume; and effect

reliability compliance and safety.

xMUST – Any pipework replacement, must be identical to genuine SKOPE parts.

xMUST – Not introduce a sparking device inside a cabinet or inside a removable refrigeration system.

Battery drills should not be used.

xMUST – Not perform any activity that could stress a refrigeration pipe (unless in a workshop).

xMUST – Get customer authorisation to permanently swap a removable refrigeration system.

xMUST – Have the Wellington Drive SCS Field app installed on a Bluetooth enabled device carried by

the service technician (exception is for cabinets that do not utilise the Wellington Drive Controller).

The app should be utilised for safe, accurate diagnosis of the system and it is required to complete

a controller replacement in the field.

xRECOMMENDED – Have the Wellington Drive SCS Track app installed on a Bluetooth enabled device

carried by the service technician. This passive app collects system data from the Wellington Drive

SCS Connect Controller and transmit it to the cloud.

xLogistics companies may be used to transport a complete refrigerator where no separation of the

refrigeration system occurs. Logistics companies are not required to be contracted to this SKOPE

Service Policy.

8Specifications

Service Manual

SKOPE TMF-N ActiveCore Series

2Specifications

Models

This freezers service manual is applicable to the SKOPE TMF ActiveCore

top mount freezers detailed in the table below. Refer to the relevant product

specification sheet (available on the SKOPE website: www.skope.com) for

specifications.

Series Model SKOPE ID Unit

TMF650N ActiveCore TMF650N-A LTH65GYN

UTHDNI-0043

TMF650N-AC LTH65BYN

TMF1000N ActiveCore TMF1000N-A LHT10GYN

TMF1000N-AC LTH10BYN

SKFT650N ActiveCore SKFT650N-A LT65GYN

SKFT650N-AC LT65BYN

SKFT1000N ActiveCore SKFT1000N-A LT10GYN

SKFT1000N-AC LT10BYN

SKOPE TMF-N ActiveCore Series

Electronic Controller

Service Manual

3Electronic Controller

Overview

The freezer is fitted with a Wellington Drive SCS Connect electronic

controller. The controller is located above the door/s and visible from the

outside of the freezer.

Controller servicing can be performed via the controller faceplate, or the

SCS Connect Field app.

This does not control the cabinet body and door heater elements

Apps

SCS Connect

Field App The SCS Connect Field app is designed for service techs, and provides

access to the controller from mobile devices with Bluetooth capability. The

app provides information on data logging, alarm notification and diagnostic

control.

See “SCS Connect Field App and Track App” on page 12 for information on

setting up and using the app.

SCS Connect

Track App The SCS Connect Track app is used to upload data from freezers fitted with

a Wellington SCS Connect electronic controller.

SKOPE

Connect App The SKOPE-connect app is designed for end-users and provides wireless

access to the controller from mobile devices with Bluetooth capability.

The app allows end users to adjust some electronic controller settings

including energy saving modes, open/close hours and preset temperature

set points for specific product.

The app may be useful for diagnostics. Download from

the Google Play Store, or Apple App Store.

10 Electronic Controller

Service Manual

SKOPE TMF-N ActiveCore Series

Controller Faceplate

Buttons and

Display The controller faceplate includes the front display panel and interface

buttons.

Service Mode Service mode can be accessed and used via the SCS Connect Field app

(see “SCS Connect FieldApp and TrackApp” on page 12), or the controller

faceplate (see below).

Note:A9 digit pin code is required to access service mode via the controller

buttons. Contact your User Manager to receive your activation code.

To enable and use service mode via the controller faceplate

12 3 4 5

8 7

No. Description

1Night Mode: Indicator. On during cooler night mode.

Display: Indicator. Digital display of cabinet air temperature or messages.

The temperature is what the sensor inside the cooler detects, and not

necessarily the product temperature. However, they may be very close

depending on how the controller is set to sense temperature.

3Light Switch - Night Mode (back/abort): Button. Press to switch the lights

on or off. Press and hold to switch cooler between day and night mode. Used

during programming.

4Up: Button. Used for programming.

5Bluetooth: Indicator. Flashing when connected to a device.

6Defrost Cycle (next/enter): Button. Press and hold to initiate manual defrost.

Used during programming.

7Down: Button. Used for programming.

8Fault - Alarm: Indicator. On during fault or alarm. Note: Alarm message is

also shown on the display during alarm.

9Compressor: Indicator. On when the compressor is running.

10 Defrost Mode: Indicator. On during defrost cycle.

11 Fan: Indicator. ON when evaporator fan running.

1. Press and hold the up and down buttons simultaneously until prompted to

enter the 9 digit pin code.

2. Enter service mode pin code.

3. Use the up, down, back/abort and next/enter buttons to navigate to the

desired category.

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels Skope Congélateur

Skope

Skope ActiveCore SKFT1500N-A-WG Manuel utilisateur

Skope

Skope TMEF Series Manuel utilisateur

Skope

Skope ProSpec Series Manuel utilisateur

Skope

Skope SERENE SC430N Manuel utilisateur

Skope

Skope BC070-CB Manuel utilisateur

Skope

Skope PG Series Manuel utilisateur

Skope

Skope PG Series Manuel utilisateur

Skope

Skope VF Series Manuel utilisateur

Skope

Skope Centaur Series Manuel utilisateur

Skope

Skope VF650 Manuel utilisateur

Skope

Skope ActiveCore Manuel utilisateur

Skope

Skope PG600VF Manuel utilisateur

Manuels Congélateur populaires d'autres marques

Siemens

Siemens GU..D SERIES Manuel utilisateur

Omcan

Omcan FR-CN-0155 Manuel utilisateur

Beko

Beko FNE290E24W Manuel utilisateur

Electrolux

Electrolux ARCTIS G 8 60 50-6I Manuel utilisateur

Electrolux

Electrolux EUF2042AOX Manuel utilisateur

Dometic

Dometic CoolFreeze CFX95DZ Manuel utilisateur

Electrolux

Electrolux EUF7000W1 Manuel utilisateur

Polar Electro

Polar Electro CT330 Manuel utilisateur

MPM

MPM MPM-145-SK Series Manuel utilisateur

SAF

SAF PRESTOTIG 200AC/DC Guide rapide

Zanussi

Zanussi ZFT11407WA Manuel utilisateur

AEG

AEG A63190GT Manuel utilisateur

AEG

AEG A81000TNW0 Manuel utilisateur

Matsui

Matsui MUC50S15E Manuel utilisateur

NEFF

NEFF G4344X8 Manuel utilisateur

Frigidaire

Frigidaire FV 1246 H Manuel utilisateur

Frigidaire

Frigidaire FFC13K1AW Manuel utilisateur

Electrolux

Electrolux EU 2400C Manuel utilisateur
