IMPORTANT: Read Before Using

Operating/ afety

Instructions

Call Toll Free for Consumer

Information & ervice Locations

1-877- KIL999 (1-877-754-5999)

www.skil.com

2356

SM 1619X07542 08-12_SM 1619X07542 08-12.qxp 8/27/12 1:59 PM Page 1

Read all safety warnings

and all instructions. Failure

to follow the warnings and instructions may

result in electric shock, fire and/or serious injury.

SAVE ALL WARNINGS AND

INSTRUCTIONS FOR FUTURE

REFERENCE

The term “power tool” in the warnings refers to

your mains-operated (corded) power tool or

battery-operated (cordless) power tool.

Work area safety

Keep work area clean and well lit. Cluttered

or dark areas invite accidents.

Do not operate power tools in explosive

atmospheres, such as in the presence of

flammable liquids, gases or dust. Power

tools create sparks which may ignite the dust

or fumes.

Keep children and bystanders away while

operating a power tool. Distractions can cause

you to lose control.

Electrical safety

Power tool plugs must match the outlet.

Never modify the plug in any way. Do not use

General Power Tool Safety

Warnings

WARNING

SM 1619X07542 08-12_SM 1619X07542 08-12.qxp 8/27/12 1:59 PM Page 2

any adapter plugs with earthed (grounded)

power tools. Unmodified plugs and matching

outlets will reduce risk of electric shock.

Avoid body contact with earthed or grounded

surfaces such as pipes, radiators, ranges and

refrigerators. There is an increased risk of

electric shock if your body is earthed or

grounded.

Do not expose power tools to rain or wet

conditions. Water entering a power tool will

increase the risk of electric shock.

Do not abuse the cord. Never use the cord for

carrying, pulling or unplugging the power tool.

Keep cord away from heat, oil, sharp edges or

moving parts. Damaged or entangled cords

increase the risk of electric shock.

When operating a power tool outdoors, use

an extension cord suitable for outdoor use.

Use of a cord suitable for outdoor use reduces

the risk of electric shock.

If operating a power tool in a damp location is

unavoidable, use a Ground Fault Circuit

Interrupter (GFCI) protected supply. Use of an

GFCI reduce the risk of electric shock.

Personal safety

Stay alert, watch what you are doing and use

common sense when operating a power tool.

Do not use a power tool while you are tired or

SM 1619X07542 08-12_SM 1619X07542 08-12.qxp 8/27/12 1:59 PM Page 3

under the influence of drugs, alcohol or

medication. A moment of inattention while

operating power tools may result in serious

personal injury.

Use personal protective equipment. Always

wear eye protection. Protective equipment

such as dust mask, non-skid safety shoes, hard

hat, or hearing protection used for appropriate

conditions will reduce personal injuries.

Prevent unintentional starting. Ensure the

switch is in the off-position before connecting

to power source and / or battery pack, picking

up or carrying the tool. Carrying power tools

with your finger on the switch or energizing

power tools that have the switch on invites

accidents.

Remove any adjusting key or wrench before

turning the power tool on. A wrench or a key

left attached to a rotating part of the power tool

may result in personal injury.

Do not overreach. Keep proper footing and

balance at all times. This enables better

control of the power tool in unexpected

situations.

Dress properly. Do not wear loose clothing or

jewelry. Keep your hair, clothing and gloves

away from moving parts. oose clothes,

jewelry or long hair can be caught in moving

parts.

SM 1619X07542 08-12_SM 1619X07542 08-12.qxp 8/27/12 1:59 PM Page 4

If devices are provided for the connection of

dust extraction and collection facilities,

ensure these are connected and properly

used. Use of dust collection can reduce dust-

related hazards.

Power tool use and care

Do not force the power tool. Use the correct

power tool for your application. The correct

power tool will do the job better and safer at the

rate for which it was designed.

Do not use the power tool if the switch does

not turn it on and off. Any power tool that

cannot be controlled with the switch is

dangerous and must be repaired.

Disconnect the plug from the power source

and/or the battery pack from the power tool

before making any adjustments, changing

accessories, or storing power tools. Such

preventive safety measures reduce the risk of

starting the power tool accidentally.

Store idle power tools out of the reach of

children and do not allow persons unfamiliar

with the power tool or these instructions to

operate the power tool. Power tools are

dangerous in the hands of untrained users.

Maintain power tools. Check for misalignment or

binding of moving parts, breakage of parts

and any other condition that may affect the

power tool’s operation. If damaged, have the

SM 1619X07542 08-12_SM 1619X07542 08-12.qxp 8/27/12 1:59 PM Page 5

power tool repaired before use. Many

accidents are caused by poorly maintained

power tools.

Keep cutting tools sharp and clean. Properly

maintained cutting tools with sharp cutting

edges are less likely to bind and are easier to

control.

Use the power tool, accessories and tool

bits etc. in accordance with these instructions,

taking into account the working conditions

and the work to be performed. Use of the

power tool for operations different from those

intended could result in a hazardous situation.

Battery tool use and care

Recharge only with the charger specified by

the manufacturer. A charger that is suitable

for one type of battery pack may create a risk

of fire when used with another battery pack.

Use power tools only with specifically

designated battery packs. Use of any other

battery packs may create a risk of injury and

fire.

When battery pack is not in use, keep it

away from other metal objects like paper

clips, coins, keys, nails, screws, or other

small metal objects that can make a

connection from one terminal to another.

Shorting the battery terminals together may

cause burns or a fire.

SM 1619X07542 08-12_SM 1619X07542 08-12.qxp 8/27/12 1:59 PM Page 6

Under abusive conditions, liquid may be

ejected from the battery, avoid contact. If

contact accidentally occurs, flush with

water. If liquid contacts eyes, additionally

seek medical help. iquid ejected from the

battery may cause irritation or burns.

Service

Have your power tool serviced by a qualified

repair person using only identical

replacement parts. This will ensure that the

safety of the power tool is maintained.

Use auxiliary handle(s) if supplied with the

tool. oss of control can cause personal injury.

Hold power tool by insulated gripping

surfaces, when performing an operation

where the fastener may contact hidden

wiring. Fasteners contacting a "live" wire may

make exposed metal parts of the power tool

"live" and could give the operator an electric

shock.

Use clamps or another practical way to secure

and support the workpiece to a stable

platform. Holding the work by hand or against

your body leaves it unstable and may lead to

loss of control.

SAFETY RULES FOR CORDLESS

SCREWDRIVERS

SM 1619X07542 08-12_SM 1619X07542 08-12.qxp 8/27/12 1:59 PM Page 7

Do not drill, fasten or break into existing

walls or other blind areas where electrical

wiring may exist. If this situation is

unavoidable, disconnect all fuses or circuit

breakers feeding this worksite.

Battery tools are always in an operative

condition. Be aware of the possible hazards.

Always wear safety goggles or eye

protection when using this tool.

Secure the workpiece, never hold it in your

hand or across legs. The drilling action may

cause you to lose control of the

workpiece and injury may occur.

Do not insert two bits into a

single Bit Magazine slot. The

second bit may eject forcefully when the Sliding

Switch is pushed to the forward position.

When installing a bit, insert the shank of the bit

well within the collet. If the bit is not inserted

deep enough, the grip of the collet over the bit is

reduced and the loss of control is increased.

Do not run the tool while carrying it at your

side. A spinning bit could become entangled

with clothing and injury may result.

Do not use dull or damaged bits and

accessories. Dull or damaged bits have a

greater tendency to bind in the workpiece.

Some dust created by

power sanding, sawing,

WARNING

SM 1619X07542 08-12_SM 1619X07542 08-12.qxp 8/27/12 1:59 PM Page 8

grinding, drilling, and other construction

activities contains chemicals known to

cause cancer, birth defects or other

reproductive harm. Some examples of

these chemicals are:

• ead from lead-based paints,

• Crystalline silica from bricks and cement and

other masonry products, and

• Arsenic and chromium from chemically-

treated lumber.

Your risk from these exposures varies,

depending on how often you do this type of

work. To reduce your exposure to these

chemicals: work in a well ventilated area, and

work with approved safety equipment, such as

those dust masks that are specially designed to

filter out microscopic particles.

Battery/Charger

Before using battery charger,

read all instructions and

cautionary markings on (1) battery charger,

(2) battery pack, and (3) product using battery.

Do not disassemble charger or operate the

charger if it has received a sharp blow, been

dropped or otherwise damaged in any way.

Replace damaged cord or plugs immediately.

Incorrect reassembly or damage may result in

electric shock or fire.

Do not recharge battery in damp or wet

environment. Do not expose charger to rain or

snow. If battery case is cracked or otherwise

WARNING

SM 1619X07542 08-12_SM 1619X07542 08-12.qxp 8/27/12 1:59 PM Page 9

damaged, do not insert into charger. Battery

short or fire may result.

Charge battery pack in temperatures above

+32 degrees F (0 degrees C) and below +113

degrees F (45 degrees C). Store tool and

battery pack in locations where temperatures

will not exceed 120 degrees F (49 degrees C).

This is important to prevent serious damage to

the battery cells.

Place charger on flat non-flammable surfaces

and away from flammable materials when re-

charging battery pack. The charger and

battery pack heat during charging. Carpeting

and other heat insulating surfaces block proper

air circulation which may cause overheating of

the charger and battery pack. If smoke or

melting of the case are observed unplug the

charger immediately and do not use the battery

pack or charger.

Use of an attachment not recommended or

sold by Skil may result in a risk of fire, electric

shock or injury to persons.

Battery Care

When batteries are not in

tool or charger, keep them

away from metal objects. For example, to

protect terminals from shorting DO NOT place

batteries in a tool box or pocket with nails,

screws, keys, etc. Fire or injury may result.

WARNING

SM 1619X07542 08-12_SM 1619X07542 08-12.qxp 8/27/12 1:59 PM Page 10

Table des matières

Langues :

Autres manuels Skil Tournevis électrique

Manuels Tournevis électrique populaires d'autres marques

Makita

Makita DFT085F Manuel utilisateur

Parkside

Parkside 345138 2004 Manuel utilisateur

Makita

Makita DFL650F Manuel utilisateur

AEG

AEG BST 18BLX2-0 Manuel utilisateur

Ingersoll-Rand

Ingersoll-Rand D5000 Series Manuel utilisateur

BGS technic

BGS technic 956 Manuel utilisateur

Hilti

Hilti SD 6000 Manuel utilisateur

Parkside

Parkside PEPS 3 A1 Manuel utilisateur

Festool

Festool TI 15 Manuel utilisateur

Makita

Makita DWT190 Manuel utilisateur

Matatakitoyo Torque Tools

Matatakitoyo Torque Tools MTD Manuel utilisateur

DeWalt

DeWalt XR LI-ION DCD931 Manuel utilisateur

Festool

Festool DWC 18-2500 Manuel utilisateur

EINHELL

EINHELL TE-CD 12/1 Li Series Manuel utilisateur

Makita

Makita BFT043F Manuel utilisateur

Stanley

Stanley SCD2 Manuel utilisateur

Atlas Copco

Atlas Copco LUM12 SR Feuille d'instructions

FAR

FAR TECNUM Manuel d'utilisation et d'entretien
