Installation Instructions
Skiguard Touring Model 200608 ENG R0
Installation Instructions Skiguard Touring Models:
Included inside Skiguard Touring
Models:
•Pair of quick-release tie-downs and
mounting hardware
•Pair of cargo organizers (ski-rack)
•Set of keys (tied to the strap in the
rear)
You will need:
•1 strong friend
•13mm or ½’’deep socket or wrench
•Knife or something with a sharp
point
•Tape measure (not required, but
recommended)
•In some cases, Allen and/or Torx
wrenches may be required for
disassembly/reassembly of
crossbars.
Video Instructions:
Scan QR code below or visit www.skiguard.com/faq
NB: There are many different types of roof racks/crossbars using various methods of mounting
techniques. Make sure that you know and follow the manufacturer's instructions and guidelines
before installing your Skiguard.
Installation Instructions
Skiguard Touring Model 200608 ENG R0
Step 1: Preparing the roof rack/crossbars and Skiguard
On your cross bars, remove the feet from the load bars on one side on both bars. Pass the load
bars through the tunnels in the lower half of your Skiguard roof box. Make sure the U-bolts are
loosened on the inside of the Skiguard so the load bars can pass through without difficulty.
Step 2: Reassemble the crossbars
Reattach the feet to the load bars, but do not fully tighten as adjustments will be needed later.
Step 3: Lift the Skiguard with crossbars onto the roof of the car
Lift the Skiguard onto the roof of the car. Ensure that it is moved sufficiently forward so that it
does not interfere with the rear hatch in open position. It is recommend leaving at least 1cm or
½’’ of clearance between the Skiguard and the rear hatch.
Step 4: Adjust crossbars and Skiguard position
Adjust the position of the roof box so that it is centered on the middle of the roof and the roof
rack. A good way to this without using a tape measure is to gauge it using the antenna, if center
mounted, in the rear, and the rear-view mirror in the windshield in the front. Also make sure that
the ends of the load bars stick out the same distance on both sides, if applicable.
Step 5: Tighten all screws, nuts and bolts on crossbars and Skiguard.
Tighten all nuts, bolts, and fasteners on the cross bars and inside the Skiguard. Now the cross
bars should be securely attached to the car, and the Skiguard tightly and securely fastened to
the load bars.
Step 6: Double check fitment and recheck screws, nuts and bolts
Make sure to go back and recheck that all nuts, bolts, straps etc. on cross bars and inside
Skiguard are properly tightened on a regular basis.
NB:
You are solely responsible for the safety of you and others by safely installing the cross
bars and Skiguard Ski & Cargo Box. Skiguard USA, Inc. is not responsible or liable for
any misfortune caused by the failure to properly secure the roof box to the vehicle, as set
forth in the Warranty and Disclaimer information.
Skiguard USA, Inc
E-mail: info@skiguard.com
Phone: (720) 223-5459
Mail: 1630, 30th St. #272, Boulder, CO 80301, USA
