Skid Pro WX410-SKD Manuel utilisateur

OPERATOR'S MANUAL

Skid Steer Wood Splitter

410-SKD

430-SKD

470-SKD

Document Number: Z97151_EnRev Feb-2020

Skid Pro Wood Splitter Manual Rev Feb-2020

SKID STEER MOUNTED Log Splitter

DELIVERY INSPECTION REPORT

(please print)

INSPECTION REPORT SAFETY

____ All Decals Installed

____ Guards and Shields Installed

____ Review Operating and Safety Instructions

____ Check that Cylinder Extends Freely

____ Fasteners Tight

____ Hydraulic Fittings Tight - No Leaks

____ Hydraulic Lines Free and in Good Condition

____ Lubricate Wood splitter

____ Frame Anchored to Face Plate

The product manuals have been received by me and I

have been thoroughly instructed as to care, adjustments,

safe operation, and applicable warranty policy.

Customer

Address

City, State/Province, ZIP/Postal Code

( )

Phone Number

Contact Name

Model

Serial Number

Delivery date

I have thoroughly instructed the buyer on the equipment

care, adjustments, safe operation and applicable

warranty policy and reviewed the manuals.

Guru

Address

City, State/Province, ZIP/Postal Code

( )

Phone Number

Skid Pro Wood Splitter Manual Rev Feb-2020

TABLE OF CONTENTS

DELIVERY INSPECTION REPORT..........................2

WARRANTY................................................................4

SERIAL NUMBER LOCATION..................................5

1 INTRODUCTION................................................6

1.1 PRODUCT DECAL INFORMATION ............... 7

2 SAFETY..............................................................8

2.1 SAFETY ALERT SYMBOL .............................. 8

2.2 SIGNAL WORDS ............................................. 8

2.1 GENERAL SAFETY......................................... 9

2.2 EQUIPMENT SAFETY GUIDELINES .......... 10

2.3 SAFETY TRAINING....................................... 11

2.5 PREPARATION.............................................. 11

2.6

OPERATING SAFETY............................................12

2.7 TRANSPORT SAFETY.................................. 13

2.8 MAINTENANCE SAFETY ............................. 14

2.9 HYDRAULIC SAFETY................................... 14

2.10 STORAGE SAFETY ...................................... 14

2.11 SIGN-OFF FORM .......................................... 15

3 SAFETY SIGN LOCATIONS ..........................16

3.1 SAFETY SIGNS............................................. 16

3.2 SAFETY SIGN EXPLANATIONS.................. 17

3.3 REPLACING DAMAGED SAFETY SIGNS .. 18

4 OPERATION.....................................................19

4.1 TO THE NEW OPERATOR OR OWNER ..... 19

4.2 WOOD SPLITTER COMPONENTS ............. 20

4.3 WOOD SPLITTER BREAK-IN ...................... 21

4.4 PRE-OPERATION CHECKLIST ................... 21

4.5 EQUIPMENT MATCHING ............................. 22

4.6 CONTROLS.................................................... 23

4.7 ATTACHING / UNHOOKING SKID STEER . 24

4.8 FIELD OPERATION....................................... 26

4.10 TRANSPORTING .......................................... 31

4.11 STORAGE ...................................................... 32

4.11.1 PLACING IN STORAGE............................ 32

4.11.2 REMOVING FROM STORAGE ................. 32

5 SERVICE AND MAINTENANCE ....................33

5.1 FLUIDS AND LUBRICANTS ......................... 33

5.2 GREASING..................................................... 33

5.3 SERVICING INTERVALS.............................. 33

5.4 SERVICE ILLUSTRATION............................ 34

5.5 SERVICE RECORD TABLE.......................... 35

6. TROUBLESHOOTING ....................................36

7 SPECIFICATIONS ...........................................37

7.1 MACHINE SPECIFICATIONS....................... 37

7.2 BOLT TORQUE.............................................. 38

7.3 HYDRAULIC FITTING TORQUE.................. 38

Skid Pro Wood Splitter Manual Rev Feb-2020

WARRANTY

rev. Feb -2020

LIMITED WARRANTY

Skid Pro products are warranted to be free of defects in materials and

workmanship under normal use and service, for a period of

One Year

from the date of purchase, when operated and maintained in accordance with the operang

and maintenance instrucons supplied with the unit. Warranty is limited to the repair of the

product and/or replacement of parts.

This warranty is extended only to the original purchaser and is not transferable.

Repairs must be done by an authorized Guru. Products will be returned to the Guru at the

customer’s expense. Include the original purchase receipt with any claim.

This warranty does not cover the following:

1) Normal maintenance or adjustments

2) Normal replacement of wearable and service parts

3) Consequen damage, indirect damage, or loss of prots

4) Damages resulng from:

• Misuse, negligence, accident, theor re

•Use of improper or insucient fuel, uids or lubricants

•Use of parts or aermarket accessories other than genuine OEM parts

• Modicaons, alteraon, tampering or improper repair performed by pares other

than an authorized Guru

• Any device or accessories installed by pares other than an authorized Guru

5) Engines. Engines are covered by the manufacturer of the engine for the warranty period

they specify. For the details of your engine warranty, see your engine owner’s manual.

Skid Pro Wood Splitter Manual Rev Feb-2020

SERIAL NUMBER LOCATION

Always give your Guru the serial number of your Skid Pro Skid Steer Mounted Log Splitter when order-

ing parts or requesting service or other information.

The wood splitter is equipped with a serial plate where indicated. Please mark the number in the space

provided for easy reference.

Model Number ____________________________________________________

Serial Number ____________________________________________________

WX410-SKD

WX430-SKD

WX470-SKD

Skid Pro Wood Splitter Manual Rev Feb-2020

1 INTRODUCTION

Congratulations on your choice of a Skid Pro Skid Steer Mounted Log Splitter to compliment your log splitting

operation. This equipment has been designed and manufactured to meet the needs of a discriminating buyer for

the e󰀩cient splitting of wood.

Safe, e󰀩cient and trouble free operation of your Skid Pro Log Splitter requires that you and anyone else who will

be operating or maintaining the wood splitter, read and understand the Safety, Operation, Maintenance and Trou-

ble Shooting information contained within the Operator's Manual.

If you require replacement parts, call your Guru to order.

This manual covers the WX410-SKD, WX430-SKD and WX470-SKD Skid Steer Mounted Log Splitter.

Keep this manual handy for reference and to pass on to new operators or owners. Call your Skid Pro Guru or the

Distributor if you need assistance, information or additional copies of the manuals.

OPERATOR ORIENTATION – The directions left, right, front and rear, as mentioned throughout this manual, are

determined when sitting in the operator seat and facing the splitter.

WX410-SKD / WX430-SKD

WX470-SKD Horizontal

WX470-SKD Vertical

Skid Pro Wood Splitter Manual Rev Feb-2020

1.1 PRODUCT DECAL

INFORMATION

When getting familiar with the Skid Pro product, notice

that there are numerous decals located on the machine.

There are di󰀨erent types of decals for safety, information,

and product identication. The following section explains

what they are for and how to read them.

Safety Decals are pictorial with a yellow background and

generally two panel. The top panel shows the safety alert

(the potential hazard) and the bottom panel shows the

message (how to avoid the hazard).

Safety alert

Message

Safety Notice Decals are pictorial with a blue background

and generally rectangular with single or multiple symbols.

This decal informs what Personal Protective Equipment is

required for safe operation.

Informative Decals are generally pictorial with a white

background and can vary in the number of panels. This

type of decal provides additional information to the

operator or explains the operation of a control.

Product Decals indicate machine model and serial

number, and other important information.

Maintenance Decals have a green background and can

vary to the number of panels. This decal shows a type

maintenance required and frequency interval.

See the section on safety signs for safety decal

explanations.

Skid Pro Wood Splitter Manual Rev Feb-2020

2 SAFETY

2.1 SAFETY ALERT SYMBOL

This Safety Alert Symbol means:

ATTENTION! BE ALERT!

YOUR SAFETY IS INVOLVED!

The Safety Alert Symbol identies important safety

messages on the Wood Splitter and in the manual.

When you see this symbol, be alert to the possibility

of personal injury or death. Follow the instructions in

the safety message.

2.2 SIGNAL WORDS

The signal words DANGER, WARNING and CAUTION

determine the seriousness level of the warning messages

in this manual. The appropriate signal word for each

message in this manual has been selected using the

following guidelines:

DANGER –

Indicates an imminently hazardous situation that, if not

avoided, will result in death or serious injury. This signal

word is to be limited to the most extreme situations

typically for machine components which, for functional

purposes, cannot be guarded.

WARNING –

Indicates a potentially hazardous situation that, if not

avoided, could result in death or serious injury, and

includes hazards that are exposed when guards are

removed. It may also be used to alert against unsafe

practices.

CAUTION –

Indicates a potentially hazardous situation that, if not

avoided, may result in minor or moderate injury. It may

also be used to alert against unsafe practices.

IMPORTANT – To avoid confusing equipment

protection with personal safety messages, a signal word

IMPORTANT indicates a situation that if not avoided,

could result in damage to the machine.

Skid Pro Wood Splitter Manual Rev Feb-2020

YOU are responsible for the SAFE operation and

maintenance of your Skid Pro Skid Steer Mounted Log

Splitter. YOU must ensure that you and anyone else

who is going to use, maintain or work around the Log

Splitter be familiar with the using and maintenance

procedures and related SAFETY information contained

in this manual. This manual will take you step-by-step

through your working day and alerts you to all good

safety practices that should be used while using the

Log Splitter.

Remember, YOU are the key to safety. Good safety

practices not only protect you but also the people

around you. Make these practices a working part of

your safety program. Be certain that EVERYONE using

this equipment is familiar with the recommended using

and maintenance procedures and follows all the safety

precautions. Most accidents can be prevented. Do not

risk injury or death by ignoring good safety practices.

• Skid Steer Mounted Log Splitter owners must give

operating instructions to operators or employees

before allowing them to operate the wood splitter,

and at least annually thereafter.

• The most important safety device on this equip-

ment is a SAFE operator. It is the operator’s re-

sponsibility to read and understand ALL Safety and

Operating instructions in the manual and to follow

these. Most accidents can be avoided.

• A person who has not read and understood all

using and safety instructions is not qualied to use

the wood splitter. An untrained operator exposes

himself and bystanders to possible serious injury or

death.

• Do not modify the equipment in any way. Unau-

thorized modication may impair the function and/

or safety and could a󰀨ect the life of the equipment.

• Think SAFETY! Work SAFELY!

1. Read and understand the Operator’s Manual and

all safety signs before operating, maintaining, ad-

justing or servicing the Log Splitter.

2. Have a rst-aid kit available for use should the

need arise and know how to use it.

2.1 GENERAL SAFETY

3. Have a re extinguisher available for use should

the need arise and know how to use it.

4. Do not allow riders.

5. Wear appropriate protective gear. This list includes

but is not limited to:

- A hard hat

- Protective shoes with slip resistant soles

- Protective glasses, goggles or face shield

- Heavy gloves

- Wet weather gear

- Hearing Protection

-Respirator or lter mask

6. Install and secure all guards before starting.

7. Wear suitable ear protection for prolonged expo-

sure to excessive noise.

8. Lower splitter frame, place all controls in neutral,

stop engine, remove ignition key and wait for all

moving parts to stop before servicing, adjusting,

repairing or maintaining.

9. Clear the area of people, especially small children,

before using the unit.

10. Review safety related items annually.

Skid Pro Wood Splitter Manual Rev Feb-2020

2.2 EQUIPMENT SAFETY GUIDELINES

1. Safety of the operator and bystanders is one of the

main concerns in designing and developing equip-

ment. However, every year many accidents occur

which could have been avoided by a few seconds

of thought and a more careful approach to handling

equipment. You, the operator, can avoid many

accidents by observing the following precautions

in this section. To avoid personal injury or death,

study the following precautions and insist those

working with you, or for you, follow them.

2. In order to provide a better view, certain photo-

graphs or illustrations in this manual may show an

assembly with a safety shield removed. However,

equipment should never be used in this condi-

tion. Keep all shields in place. If shield removal

becomes necessary for repairs, replace the shield

prior to use.

3. Replace any safety sign or instruction sign that is

not readable or is missing. Location of such safety

signs is indicated in this manual.

4. Never use alcoholic beverages or drugs which can

hinder alertness or coordination while using this

equipment. Consult your doctor about using this

wood splitter while taking prescription medications.

5. Under no circumstances should young children

be allowed to work with this equipment. Do not

allow persons to use or assemble this unit until

they have read this manual and have developed

a thorough understanding of the safety precau-

tions and of how it works. Review the safety

instructions with all users annually.

6. This equipment is dangerous to children and

persons unfamiliar with its operation. The opera-

tor should be a responsible, properly trained and

physically able person familiar with wood splitting

and trained in this equipment's operations. If the

elderly are assisting with work, their physical limita-

tions need to be recognized and accommodated.

7. Never exceed the limits of a piece of wood split-

ting. If its ability to do a job, or to do so safely, is in

question - DON'T TRY IT.

8. Do not modify the equipment in any way.

Unauthorized modication may result in serious

injury or death and may impair the function and life

of the equipment.

9. Use a Skid Steer that is equipped with a Roll Over

Protective Structure (ROPS) and a seat belt.

10. In addition to the design and conguration of this

implement, including Safety Signs and Safety

Equipment, hazard control and accident prevention

are dependent upon the awareness, concern, pru-

dence, and proper training of personnel involved in

the operation, transport, maintenance, and storage

of the wood splitter. Refer also to Safety Messages

and operation instruction in each of the appropriate

sections of the engine and wood splitter manuals.

Pay close attention to the Safety Signs a󰀩xed to

the skid steer and the wood splitter.

Ce manuel convient aux modèles suivants

Table des matières

Manuels fendeuse de bûches populaires d'autres marques

Bell

Bell Pickpine VS S9 Manuel d'instructions

ATIKA

ATIKA ASP 5 N-UG Instructions de fonctionnement

Posch

Posch Schälprofi 500 Manuel utilisateur

Champion

Champion 91520 Manuel

Fieldmann

Fieldmann FZLS 1008V-E Manuel utilisateur

Craftsman

Craftsman 247.28775 Manuel utilisateur

Scheppach

Scheppach OX 3-1000 Instructions de montage

Swisher

Swisher 21200 Manuel utilisateur

Elem Garden Technic

Elem Garden Technic FBHT65-22TCH Manuel utilisateur

Champion Power Equipment

Champion Power Equipment 90720 Manuel

Boss Industrial

Boss Industrial ES5T20 Manuel utilisateur

Villager

Villager LSP 12 T Manuel utilisateur

MTD

MTD 242-642A Manuel utilisateur

Rok

Rok 150-51-50255 Manuel utilisateur

Hakki Pilke

Hakki Pilke Raven Manuel utilisateur

Swisher

Swisher LSRB11534 Manuel utilisateur

Hyundai

Hyundai HYLS7TE Manuel utilisateur

Scheppach

Scheppach HL1500M Guide de l'utilisateur
