SKC Quick Take 15 Manuel utilisateur
Operating Instructions
Catalog No. 228-9515
SKC Inc.
863 Valley View Road
Eighty Four, PA 15330 USA
Form #40076—Rev 0710
Table of Contents
Quick Guide................................................................................1
Description..................................................................................2
Performance Prole....................................................................3
Operation....................................................................................5
Mounting Sampling Media..........................................................7
Calibration and Setting Flow.......................................................8
Setup ..........................................................................................9
Sampling...................................................................................11
Advanced Setup .......................................................................13
Maintenance.............................................................................17
Battery Operation .....................................................................19
Cautions and Warnings ............................................................19
Service Policy...........................................................................20
Warranty...................................................................................21
Ordering Information.................................................................22
Notice: This operating instruction may not address all safety concerns (if any) associated
with this product and its use. The user is responsible for determining and following the
appropriate safety and health practices and regulatory limitations (if any) before using
the product. The information contained in this document should not be construed as legal
advice, opinion, or as a nal authority on legal or regulatory procedures.
1
QuickTake 15 Quick Guide
Terms »
Star Button
Turns on LED, toggles between displays, and exits without saving
Up and Down Arrow Buttons
Scroll through presets, increase or decrease sampling parameters, and toggle
between setup options
Button Sequence
or = Press individually.
[] = Press both simultaneously.
= Security code, press in sequence
Programming Sequences »
• To activate pump LED:
Press and hold for 2 seconds.
• To check battery status:
Press .
• To choose a run time preset:
Press or to scroll through presets. Once desired preset displays,
press [] to start sampling.
• To Run or Hold:
Press [].
• To repeat a sample run:
From Done, reset (rSEt), or sampling error (SErr), press [] to return to
run time preset. Press [] to sample.
• To change or calibrate ow:
Note: Flow rate does not appear on LED.
Press or and scroll to a run time preset. Press and hold CAL for 2 seconds.
(Does not require a security code.) Press or to change ow rate until desired
ow appears on calibrator. Press . When Stor displays, press [] to save
setting or to ignore changes to ow setting.
• To interrupt run, terminate a sample, or reset pump:
While in Hold, press . Sample reset (rSEt) will display. Press [] to reset
pump or to ignore reset and return to Hold.
www.skcinc.com
SKC Inc., 863 Valley View Road, Eighty Four, PA 15330
2
Description
The QuickTake® 15 is a portable, baery-powered air sampling pump designed
specically to provide constant airow for the short sampling times required for mold
screening. QuickTake 15 allows timed samples to be taken within the ow range of
5 to 15 L/min. A diaphragm pump operating with a closed loop ow control
system, the QuickTake 15 maintains constant ow and is suitable for use with
spore trap cassees such as VersaTrap, wall cavity samplers, the BioStage 200
impactor, and lter cassees including microvacuum cassees. The QuickTake
15 features a programmable timer that provides up to eight programmable
run time presets of 1 to 999 minutes, continuous run with manual shut-o, or
intermient sampling. A rechargeable lithium-ion baery pack provides run
times up to four hours.
Charging jack
(on side of case,
not shown)
High-contrast LED
display for readout
of presets, run time,
and battery status
Calibration mode
button
Up arrow
increases ow
and time and
scrolls through
presets
Inlet
(shown without adapter)
LED indicates
active battery
charging
Down arrow
decreases ow
and time and
scrolls through
presets
Star button
activates LED and
toggles between
displays
Speaker for end of
timed run alarm
Printed Quick Guide
Tubing Adapter
Cassette Adapter
Ring for shoulder
strap attachment
3
QuickTake 15 Performance Prole
Flow range: 5 to 15 L/min
Flow compensation
accuracy: ± 5% of set ow
Compensating ow
back pressure range: 15 L/min at 8 inches water back pressure
10 L/min at 15 inches water back pressure
5 L/min at 20 inches water back pressure
Power: Rechargeable 7.2-volt lithium-ion (Li-Ion) battery (see Li-Ion Battery
Shipment on page 4), or battery with standard AC charger/adapter
(115 V), or battery with deluxe AC charger/adapter (100-240 V)
Battery recharge time: Approximately 5 hours
Typical Run time: VersaTrap Cassette: 4 hours at 15 L/min
Results when tested with a new pump and new fully charged
battery. Pump performance may vary.
The AC charger/adapter can be used to extend baery run
time, but it is not a baery eliminator. Therefore, it will
not provide indenite run times.
Temperature: Operating: 32 - 113 F (0 - 45 C)
Storage: -4 - 113 F (-20 - 45 C)
Charging: 32 - 113 F (0 - 45 C)
Protect sample pump from weather when in use outdoors.
Run time features: User-selectable features, user-adjustable presets (see Advanced
Setup)
Preset timed runs: 1, 2, 5, 10, or 15 min
Manually set continuous
run with manual shut-off: 1 to 999 min (repeats 1 to 999-min
runs indenitely until user stops
pump or power supply is depleted)
Intermittent sampling: See Advanced Setup
Flow fault features: If the pump is unable to compensate due to excessive back pressure,
the pump will go into ow fault mode (see page 12 for details). Flow
fault features are enabled as the default setting. Flow fault may be
disabled at the user’s option. See Advanced Setup.
Flow fault: Flow fault displays immediately.
Pump shuts off after 5 seconds
Fault restart: Pump attempts restart every
10 seconds up to ve times
Compare the information in this table to pump compensation range to determine appropriate applications.
Typical Back Pressure of Sampling Media (inches water)
Flow Rate (L/min) 5.0 8.0 10.0 12.0 15.0
Filter/Pore Size (µm)
37-mm MCE/0.8 11 18 22 28 36
37-mm PVC/5.0 4 7 9 11 15
4
Media compatibility: VersaTrap and other bioaerosol cassettes, wall cavity samplers,
BioStage® 200 impactor, and other lter cassettes including
microvacuum cassettes
Housing: ABS plastic
Dimensions: 10.3 x 4.6 x 2.4 in (26.2 x 11.7 x 6.1 cm)
Weight: 32 oz (907 g)
Approvals: CE (models with 223-245 charger only)
Li-Ion Battery Shipment
Rechargeable, lithium-ion batteries for use with SKC sampling pumps have been
tested in accordance with the UN Manual of Tests and Criteria and are designated as
UN3091.
For air shipments:
Rechargeable lithium-ion batteries in SKC pumps are subject to the A-45 exemption to
the IATA regulations and are not regulated for air shipments. This information must be
written on the shipping document when shipping by air.
For ground shipments:
US DOT regulations specify a limit of 24 or fewer battery cells in one shipping box. If
you exceed 12 QuickTake 15 pumps with battery packs in one shipping box, specic
shipping requirements must be followed. Contact SKC for more information or refer to
the regulatory authority in your area.
Indicates a warning, caution, or note.
www.skcinc.com
See http://www.skcinc.com/instructions/1721.pdf for more information
on maintaining, disposing, and shipping Li-Ion batteries.
5
Operation
Button Sequence
Buons must be pressed in the sequence
shown.
or = Press individually
[] = Press both simultaneously
= Security code, press in sequence
Operating the Pump
• To activate LED:
Press and hold for 2 seconds.
• To check battery status:
With the LED on, press .
Battery Status Indicators
Full charge; approximately 75% to 100% baery capacity
remaining.
Baery is charged enough to operate the pump;
approximately 25% to 75% baery capacity remaining.
Baery charge is low (charge baery); approximately
1% to 25% baery capacity remaining.
Low Baery Fault. Pump will stop running, beep, and
go to sleep in 10 seconds.
• To operate from AC power:
The QuickTake 15 may be run using AC power with the AC charger/
adapter with baery. Insert the charger plug into the jack on the pump
and the charger into a standard wall outlet. Operate the pump.
The charge light on the LED will ash if the battery is charging during AC
operation.
The AC charger/adapter can be used to extend battery run time, but it is not a
battery eliminator. Therefore, it will not provide indenite run times.
