Warning! Please read and understand this entire manual before attempting to
assemble or operate this product.
Caution!
Weight Limitations
•Choking hazard – This product contains small parts. Keep all hardware out of reach of children.
•Two people are recommended for assembly.
•Unpack on a soft, smooth surface and inventory all parts.
•DO NOT overtighten any connectors.
•Philips head screwdriver (not provided) required for assembly.
Do not use power tools.
Maximum top weight: 68.9 kg/152lb
Important Safety Instructions
This accent
console is intended for use only with products and maximum weights shown on this
label. Use with other products or products heavier than maximum weights shown below may
result in instability causing possible injury.
Country of Origin: China
3/ 22
Label Part Number Description Qty Part Image
01 P00210030001 Table Top 1
02 P00040116401 Cross Beam for
Table Top 1
03 P00380054601 Upper Side Panel 2
Exploded Drawing
Parts List
Country of Origin: China
4/ 22
04 P00420005101 Shelf 1
05 P00560045201 Decoration Panel
1 1
06 P00560045301 Decoration Panel
2 2
07 P00380054701 Lower Side Panel 2
08 P00010024501 Base 1
09 P00390012901 Lower Right Front
Panel 1
10 P00040116501 Cross Beam for
Shelf 1
11 P00390013001 Lower Left Front
Panel 1
12 P099900008
23” Electric
Fireplace
Insert( Packed In
a Separate Box)
1
13 P005300069 Adjust Foot Pad
(preassembled) 4
Country of Origin: China
5/ 22
Label Part Number Description Qty Part Image
H1 H100010064 Cam Bolt D6*35 16
H2 H100020003 Cam Lock Ø15*12 16
H3 H010030522 Bolt M6*10 40
H4 H010030021 Bolt M6*25 9
HH1 P00050155501 Plastic Connector 20
HH2 H060030003 Dowel Ø8*30 4
HH3 H100030004 Wall Anchor Kit 1
HW H090030002 Allen Key M6 1
Hardware Pack
Country of Origin: China
6/ 22
Cam Bolt + Cam Lock Hidden Connector System
Assembly Technique
Screw the cam bolt into the threaded inserts on the panel.
Connect both panels together, making sure the cam bolt goes into the pre-drilled
hole on the end of panel and is visible so the cam lock can be attached.
Insert the cam lock into the pre-drilled large hole on the panel, making sure the
arrow on the face of the cam lock faces out and points toward to cam bolt.
Take a Phillips head screwdriver and rotate cam lock clockwise to lock the cam bolt
into place.
HIDDEN CONNECTOR……ASSEMBLY TECHNIQUES
Before beginning assembly of product, make sure all parts are present. Assemble
on a soft surface.
(4)
(1) (2)
(3)
Country of Origin: China
7/ 22
STEP 1
1x
8x
Country of Origin: China
8/ 22
STEP 2
2x
2x
2x
Country of Origin: China
9/ 22
STEP 3
4x
4x
1x
1x
Country of Origin: China
10 / 22
STEP 4
14x
14x
2x
Country of Origin: China
