Rotate™ and Big Turn™

Quick Reference Guide

See reverse side for additional instructions

Operating Instructions

1. Locate both power switches on left side of control unit.

2. Turn both switches to ON position.

Mattress Ination/Autorm

Press AUTOFIRM button to fully inate surface. Transfer

patient to surface. AUTOFIRM times out after 10 minutes

and resets to previous setting. To manually exit, press

AUTOFIRM a second time.

Rotation Therapy

1. Choose desired turn by pressing corresponding button:

• Right or Left Turn: maintains a turning cycle only to

the selected side

• Full Turn: provides left, center, and right rotational

therapy (CLRT)

2. After selecting desired turn, press CYCLE TIME -/+

buttons until desired time is reached. If using left or

right turn as a holding cycle, press RIGHT or LEFT

button until Hd shows on screen. Patient will be held

on desired side.

3. After selecting therapy, pressing TRAINING MODE

will slowly acclimate patient to therapy over a period

of 60 minutes.

Pulsation Therapy

1. Press PULSATE button until desired time is reached

(3, 5, or 10 min).

2. Set rmness using FIRM/SOFT buttons based on

patient comfort and clinical discretion.

Static Therapy

1. Press STATIC button.

2. Set rmness using FIRM/SOFT buttons

based on patient comfort and clinical discretion.

Fowler: Increases airow when head section of bed is

elevated. Newer models include an Auto Fowler feature.

Firm/Soft: Increases (FIRM) or decreases airow (SOFT)

creating a rmer or softer surface.

Lockout: Locks control panel (auto after 3 min).

To unlock, press and hold for 3 sec.

Alarm Reset: Light remains illuminated until problem is

corrected.

FOWLER

Other Features

CPR/Quick Deflation

Patient Transport

sizewise.com 800-814-9389

OPS-0044-0718 27650035 Rev. 1.0

1. CPR control is on front of control unit.

Depending on model, push red button

or turn dial clockwise to activate CPR.

Alarm will sound.

2. Locate red CPR valve at head of

mattress. Turn valve for quick air release.

-OR- Locate hose connection to control

unit (all models). Disconnect for quick

air release.

1. Activate Autorm mode for 3-5 minutes to ensure mattress

is completely inated.

2. Turn both power switches o (left side of control unit).

Unplug from wall.

3. Mattress will slowly deate. As patient sinks into mattress,

patient will rest on foam transport pad.

This card is not meant to replace product user

manual. For complete manual, contact Sizewise.
