Singsation CENTER STAGE FREESTYLE Manuel utilisateur

QUICK START

GUIDE

Instructions en français..................................... 10

Instrucciones en español....................................19

CENTER STAGE FREESTYLE

A L L- I N - O N E K A R A O K E S Y S TEM

For Video Setup

Instructions, Scan Here!

FPO

Step 1: Unpack

Make sure the following items came in this package:

Center Stage base

Microphone stand

Device cradle and

locking knob

AC power adapter

2 Wireless

Microphones

Step 2: Remove the remote

battery tab

Pull the battery tab out of the bottom of the

remote. The battery will start powering the remote

so you can use it.

Remote control

with pre-installed

battery

Step 3: Put it together

Insert the microphone stand into the

center of the Center Stage base as

shown here.

Screw the microphone stand clockwise

into the base until it’s fastened tight.

Adjust the height of the stand by

turning each clutch counterclockwise

and lifting the pole to the desired

length.

Make sure to tighten each clutch (turn

clockwise) before you proceed.

Party

system base

Microphone

stand

Clutches

Microphone

stand

Attach the device cradle to the stand

using the locking knob. Place the

cradle on the top of the stand. Then

insert the locking knob in the hole

on the back of the device cradle and

tighten it until the cradle feels secure.

Do not overtighten!

Microphone

stand

Locking

knob

Device

cradle,

side

IMPORTANT: Make sure the

microphone stand is tightened as

much as it can be before proceeding.

Press and hold the button on

the top of the Center Stage base

(or on the remote) to turn it on.

The Center Stage plays its startup

sound and the indicator below the

button starts blinking slowly.

After 15–30 seconds, the Center

Stage announces “Pairing” and goes

to Bluetooth pairing mode to set

up with your Bluetooth device. The

indicator below the button starts

blinking faster.

Step 4: Plug in

Step 5: Turn on

Attach one end of the AC adapter to the DC jack on the left side of the

Center Stage base.

Plug the other end of the adapter into a working outlet or surge protector.

Base

Enable Bluetooth on your smartphone or other

Bluetooth device.

Step 6: Pair + Connect

Wi-Fi

Bluetooth

Bluetooth Settings

VPN Settings

Wi-Fi Settings

8:45PM

Make sure the indicator below the button on

the top of the Center Stage is blinking rapidly.

(If it isn’t, give a short double-press on the

button. The Center Stage announces “Pairing.”)

If you’ve previously paired your phone or other Bluetooth device with

the Center Stage, it will automatically attempt to reconnect to that

device when you switch it on. If you want to pair to a new device, give

a short double-press to the button. The Center Stage announces

“Pairing” and the indicator below the button starts blinking.

Choose SINGSATION CENTER STAGE from the

pairing options on your Bluetooth device. (If it’s

not in the list, choose “Scan” from your device’s

Bluetooth menu.)

The Center Stage announces “Device Connected” when it’s ﬁnished pairing

and connecting to your Bluetooth device. The indicator below the button

turns solid blue.

Note: The process of enabling Bluetooth and connecting varies from device to device. See your device’s owners

manual for more information and speciﬁc instructions.

Bluetooth Wireless Connection Tips

• Make sure the Bluetooth capability of your device is turned on.

• Make sure there’s nothing plugged into the Center Stage’s (line in) jack when you’re

trying to use Bluetooth.

• The Bluetooth wireless connection works up to a range of roughly 33 feet (10 meters).

This range may vary, however, based on other factors, such as room layout, wall

material, obstacles, your device’s Bluetooth performance, etc. If you’re having problems

connecting to the speaker, move closer to it.

• If your device asks you for a password to connect, use “0000”.

Base

Step 8: Sing along!

Center Stage, Front

Step 7: Install wireless mic batteries

The Center Stage comes with 2 wireless

microphones you can use to sing along or make

announcements! Each microphone requires 2 AA

batteries (not included).

To install batteries in each microphone: Open

the battery door on the back of the microphone by

sliding it down. Insert 2 AA batteries in the battery

compartment (make sure you follow the + and

– diagrams in the compartment). Then slide the

battery door back up until it clicks back into place.

Microphone,

back

Battery

door

Microphone,

front

To turn on a mic: Press the power button

on its front. The mic automatically connects

wirelessly to the Center Stage and its power

button illuminates. (These buttons illuminate

in dierent colors for each mic when you turn

them on.) IMPORTANT: Make sure the mic’s

volume slider is all the way up!

To adjust the volume of your mic: Slide your

mic’s volume slider up or down.

To adjust the volume of both mics: Use the

dial on the front of the Center Stage.

To adjust the volume of your music: Use the

volume controls on your Bluetooth device.

To adjust the volume of everything: Use the

knob on the front of the Center Stage, or

press + or –on the remote.

Power

button

Volume

slider

Using Voice/Sound Eects and EQ

To change voice eects: Press the button on

the Center Stage or remote. Keep pressing to try

all the eects!

To add/adjust voice echo: Use the dial

on the front of the Center Stage

To use sound eects: Press the button on

the Center Stage or remote. A single press plays

the same eect again. Press and hold to change

eects.

To adjust sound EQ: Press the button on the

Center Stage or remote to cycle through the EQ

settings (rock, vocals, and ﬂat).

Top

Using Dynamic Lighting

The (lighting) and (color) buttons on top of

the Center Stage give you control over the built-in

dynamic lighting, as do the same buttons on the

remote. Press the button to cycle through the

multiple lighting modes.

Top

continues on the next page...

Tour of the Center Stage

button cycles through the dierent EQ settings

for the Center Stage (rock, vocals, and ﬂat).

button turns the Center Stage on/o (press and

hold) and puts it into pairing mode (short double-

press when the Center Stage is on).

indicator illuminates when the Center Stage is on

and shows the Bluetooth status of the Center Stage

(solid is connected; fast ﬂashing means pairing, and

slow ﬂashing means not connected). This indicator

turns solid white when something is connected to

the Center Stage’s jack (line in).

button controls the speaker’s multi-mode lighting.

Press to cycle through the light modes. Press and

hold to turn lighting o.

button cycles through the available voice eects.

button changes the color of the light in light

modes where you can select color.

button plays one of the available sound eects.

Press once to play the current eect. Press and hold

to change eects.

dial adjusts the amount of voice echo eect.

dial adjusts the Center Stage’s volume.

Remote control sensor receives the commands from

the remote control.

dial adjusts the volume of the

microphone(s).

Performer Center Stage Base

Remote control sensor

Top

Front

DC jack connects to the included power adapter to

power the Center Stage.

jack lets you connect to an external audio device

with a 3.5mm audio cable. The speaker switches

automatically to this input when you insert the cable.

jack lets you connect to an external ampliﬁed

speaker.

Left

Remote

button turns the Singsation Center Stage on/o

(press and hold) and puts it into pairing mode (short

double-press when the Singsation Center Stage is on).

+ and — buttons increase/decrease the master volume.

button cycles through the dierent EQ settings for

the Center Stage (rock, vocals, and ﬂat).

button changes light eects.

button changes voice eects.

button changes light colors.

button plays one of the available sound eects.

Press once to play the current eect. Press and hold to

change eects.

Wireless Microphone

Power

button

Volume

slider

Volume slider adjusts the volume of each microphone.

Power button turns the wireless microphone on and

connects it wirelessly with the Center Stage. This

button illuminates when the mic is on.

If you have any questions about this product,

visit SingsationKaraoke.com

Pour toute question concernant ce produit,

visiter le site SingsationKaraoke

Si tiene preguntas sobre este producto,

visite SingsationKaraoke.com

3502 Woodview Trace, Suite 220

Indianapolis, IN 46268

www.SingsationKaraoke.com SPKAW740M2 NA QSG 00
