Singer Quantum XL-6000 Instructions de fonctionnement

Workbook

QUANTUM XL-6000

0639_SS_XL6000_WRKBK 6/9/04, 3:47 PM1

Quantum®XL-6000

Table of Contents

SEWING MACHINE SECTION of Quantum®XL-6000 0

Principal Parts of the Machine....……………………………………………. 1

Operation Keys..……………….………….………………………………………. 2

Pattern Category Screens...…….…………………………………………….. 3

Help Screens………………………….......…………………………………….… 4

Pictograms and Color-coded Screens……………………………………….. 5

Operation Pictograms……………………………………………………………. 6

Knee Lifter and Screen Brightness…..……………………………………… 7

Automatic Threading………………………………...…………………………. 8

Manual Threading……………....……………………………………………….. 9

Wind-In-Place Bobbin System™…………....…………………………………. 10

Manual Bobbin Winding…....…………………………………………………… 12

Machine Thread Exchanger…………………………………….………….….. 13

Tension, Odometer, Needles…………………………………………………… 15

Standard Machine Operation…..……………..………………………………. 16

Large and Small Decorative Patterns.…...…………………………………. 19

Built-in Lettering...……………………………………………………………….. 21

Memory in Regular Sewing Machine Mode.……………………………….. 22

EMBROIDERY SECTION of Quantum® XL-6000 23

Categories of Built-in Embroideries...………………………………………. 24

Auto Thread Exchanger™..……………………………………………………… 25

Endless Bobbin™..………………………………………………………………… 26

Pictograms on the Embroidery Screen..…………………………………… 28

Smart Cards..………………………………………………………………………. 29

Combination Embroidery..…………………………………………………….. 30

Multiple Hoop Embroidery.……………………………………………………. 40

Memory in Embroidery…………………………………………………………. 48

Continuous Hoop Attachment………....……………………………………... 49

Conversion Software……………………………………………………………… 51

**Thank you to Singer USA Education Department and Singer Sourcing for developing this Workbook**

Singer®, Quantum®,Wind-In-Place Bobbin System™, Auto Thread Exchanger™, and

Endless Bobbin™are registered trademarks of The Singer Company Limited.

Part # 640 5052550GE

Quantum®XL-6000

SEWING MACHINE SECTION

Quantum®XL-6000

Principal Parts of the Machine

- 1 -

Quantum®XL-6000

Operation Keys

- 2 -

When this key is pressed “stitching procedure” is shown on LCD

Screen

Used to save and recall patterns and letter strings

Used to change thread tension, stitch length, needle position and

zigzag width

Used to automatically thread sewing machine

Used to automatically wind a bobbin

Used to pause to take a break during embroidery sewing. The

machine may be turned off and the current status will be saved to be

used when returning to the machine and turning on the power.

Quantum®XL-6000

Pattern Category Screens

- 3 -

The Quantum®XL-6000 has a 256 color 3-D appearance LCD screen. All

commands are input with a light touch on the LCD Screen.

Do not press on the screen*.

The Utility Patterns are provided on four different screens.

Touch the file folder pictograms to access the four “Utility” screens (green).

Touch the numbered arrows to access

the “Continuous Pattern” screens (rose).

Initial Screen First Utility Screen

Touch lightly on

screen

* If the Pictograms do not line up

directly under your finger please

refer to the 4-Point Adjustment

Procedure detailed on Page 25 of

your Instruction Book.

Quantum®XL-6000

Help Screens

- 4 -

The Help Screens give different types of guidance including Machine Usage,

Advice, and Sewing Methods. Each “guidance” category gives detailed

information and easy-to-understand graphics.

Turn the machine on and touch anywhere on the screen.

Stitching Procedure (Obtain information on “how to sew” methods)

Select STRAIGHT STITCH.

Touch advice key.

Touch the ‘forward page turning” pictogram, and it will advance to the next

screen. Touch the “backward page turning” pictogram, and it will return to

the previous screen.

To return to Utility Pattern screen, touch Return Arrow pictogram.

Use of sewing machine (Help in machine set up and for customizing

options) (Pink pictograms)

Example: Get information on how to perform “Manual Needle Threading”:

Touch advice key. Advice screen comes up.

Touch pictogram.

Touch Hand pictogram. This brings up screen showing

“Manual Needle Threading”.

To return to Utility Pattern screen, touch Return Arrow pictogram 3

times.

Tips (Obtain sewing tips) (Yellow pictograms)

Example: For information about “Inadequate Thread Tension”:

Touch advice key. Advice screen comes up.

Touch pictogram.

Quantum®XL-6000

Pictograms and Color-coded Screens

- 5 -

Now is the time to scroll through the vast assortment of Stitch Patterns available on the

Quantum®XL-6000. The Stitch Selection Process of the Quantum®XL-6000 is a simple touch

of the Pictograms which is all it takes to change groupings and select Stitch Patterns. All Stitch

Patterns are grouped by general function and are color coded for easy identification.

Utility Patterns are grouped on 4 screens and are color-coded green.

Continuous, Functional and Decorative Patterns are grouped on 10

screens and are color-coded rose.

Large [X-Y Feed] Decorative Patterns are grouped on 6 screens and

are color-coded orange. Note: To access the Large Decorative

Patterns first touch the Pictogram.

Small Decorative Patterns are grouped on 4 screens and are color-

coded purple.

Alphabet and Numeric Screens are grouped by fonts on 25 screens

and are color-coded blue.

Quantum®XL-6000

Operation Pictograms

-6-

Used to vertically invert - turn over - a pattern

Used to mirror image a pattern

Used to select straight stitch and to return quickly to “Utility

Stitch Pattern” screen (green)

Used to activate “Large Decorative Pattern” screen (orange]

and leads to Small Decorative Patterns and Alphabets

Pattern Elongation - Change visible on screen

Pattern Positioning

Enlarge Size Pictogram

Regular Size Pictogram

Reduce Size Pictogram

Used for sewing with Twin Needle

Used to activate Two-Color Sewing

Used to make single pattern designs sew continuously

Used to clear patterns stored in memory

Used to scroll and check patterns stored in memory

Quantum®XL-6000

Knee Lift and Screen Brightness

- 7 -

LCD Screen Brightness / Contrast

Adjustment

Knee Lift

The Knee Lift attachment fits

into the slot, located at the front

of the machine just below the

LCD screen. It is used to raise

and lower the presser foot, when

the presser foot is down.

Fit the smallest part of the

screwdriver into the

brightness adjustment

hole.

To increase the screen

brightness (make lighter)

turn the screwdriver

clockwise.

To decrease the screen

brightness (make darker)

turn the screwdriver

counter clockwise.

hter

Darker
