Singer 2662 Manuel utilisateur

BUYER'S MODEL NO. 2662 FACTORY MODEL ORIGINAL ISSUE MARCH, 2003 SECTION ----

REFER TO IMPORTANT NOTICE BELO

P.NO.77327

PARTS LIST

FOR

IMPORTANT:

WHEN ORDERING THE PARTS

LWAYS CHECK THE SERIAL

NUMBER OF THE MACHINE.

FIRST DIGIT OF THE SERIAL

NUMBER MUST MATCH WITH

THE LAST DIGIT OF THE FACTOR

MODEL ABOVE.

FIRST DIGIT

CA97861

SERIAL

NO.

FACTORY

MODEL

×××××××

Model 2662

BUYER'S MODEL NO. 2662 SECTION PAGE REVISION REMARKS PART NO. DESCRIPTION

BUYER'S MODEL NAM

43390 THRUST WASHE

FACTORY MODEL CA97861 61227 E6 PHILLIPS SCRE

ORIGINAL ISSU

March

2003 64203 TAPPING SCRE

64367 M8 SCRE

66124 RUBBER FOOT

67533 RUBBER CUSHION

72807 M4 STUD SCRE

73299 M4 TORQUE NUT

76015 LEG

76429 EXTENSION TABLE

76444 BOTTOM COVE

76445 LEG COVE

76446

CCESSORY BOX

77042 M4 PHILLIPS SCRE

SERIAL NO.

BUYER'S MODEL NO. 2662 SECTION PAGE REVISION REMARKS PART NO. DESCRIPTION

BUYER'S MODEL NAM

8400 E5 CLIP-ON-WASHE

FACTORY MODEL CA97861 10963 E6 CLIP-ON-WASHE

ORIGINAL ISSU

March

2003 33223 WASHER

39542 CLIP-ON-WASHE

40091 THRUST WASHE

43390 THRUST WASHE

43930 SPRING PIN

56807 TIMING BELT

58431 FIBER WASHE

61771 TENSION ROLLE

66235 SECURING PLATE

66437 BUSH

66474 M5 SCRE

67447 M5 SCRE

72858 WASHER

73371 M6 SCRE

73434 M4 PHILLIPS SCRE

75046 BELT PULLE

75047 CLUTCH

75060 TAKE-UP LEVER CRAN

75072 BALL BUSHING

75139 WASHER

75158 COLLAR

75179 M5 SCRE

75182 COLLAR

75194 TORSION SPRING

75207 GRIP RING

76050 TENSIONING PULLEY BASE

76135 BELT PULLE

76164 NEEDLE BAR CRAN

76165 BALANCER

76182 TAKE-UP LEVE

76184 MAIN SHAFT

76366 CRANK SHAFT

76494 HAND WHEEL

76688 SHAFT

77035 M4 PHILLIPS SCRE

77042 M4 PHILLIPS SCRE

77070 SPRING GEA

SERIAL NO.

BUYER'S MODEL NO. 2662 SECTION PAGE REVISION REMARKS PART NO. DESCRIPTION

BUYER'S MODEL NAM

1520 E3 CLIP-ON-WASHE

FACTORY MODEL CA97861 8058 NEEDLE CLAMP SCRE

ORIGINAL ISSU

March

2003 26934 #8 SCREW

28917 HOOK FOR SPRING

43658 THRUST WASHE

53740 SPRING WASHE

61222 M4 PHILLIPS SCRE

62215 M4 TORQUE NUT

66005 M2 PHILLIPS SCRE

66052 M4 SCRE

66259 M4 SCRE

66725 M4 SCRE

66727 M4 SCRE

67232 NEEDLE

68343 PIN

73304 M4 SCRE

74050 EXTENSION SPRING

75024 STOPPER

75025 GUIDE BLOC

75027 COMPRESSION SPRING

76163 THREADER SHAFT SE

76170 SUPPORT BRACKE

76179 NEEDLE BAR SUPPOR

76181 SUPPORT CENTER PIN

76183 NEEDLE BA

76189 SUPPORT PIN

76190 SUPPORT CENTER PIN

76196 THREAD GUIDE

76333 SUPPORT THREAD GUIDE

76347 SUPPORT BASE PIN

76349 CAP

77037 NEEDLE BAR CLAMP

77421 THREADER ASSEMBL

80003 NEEDLE CLAMP SE

SERIAL NO.

BUYER'S MODEL NO. 2662 SECTION PAGE REVISION REMARKS PART NO. DESCRIPTION

BUYER'S MODEL NAM

1513 E4 CLIP-ON-WASHE

FACTORY MODEL CA97861 8400 E5 CLIP-ON-WASHE

ORIGINAL ISSU

March

2003 32316 WASHER

44894 WASHER

53740 SPRING WASHE

58741 CORD GUARD

61222 M4 PHILLIPS SCRE

66052 M4 SCRE

66259 M4 SCRE

66725 M4 SCRE

66727 M4 SCRE

67315 PRESSER BA

68299 #7 SCREW FOR SHAN

72326 WASHER

75191 COMPRESSION SPRING

76167 DARNING CONTROL PLATE

76168 DARNING CONTROL BASE

76169 STRAIGHT PIN

76171 PRESSER BAR BRACKE

76250 PRESSER FOOT HOLDE

76251 ZIGZAG PRESSER FOO

76340 PRESSER BAR BLOC

76348 STRAIGHT PIN

76432 PRESSER CONTROL DIAL

77042 M4 PHILLIPS SCRE

SERIAL NO.

BUYER'S MODEL NO. 2662 SECTION PAGE REVISION REMARKS PART NO. DESCRIPTION

BUYER'S MODEL NAM

1504 E7 CLIP-ON-WASHE

FACTORY MODEL CA97861 39817 M4 PHILLIPS SCRE

ORIGINAL ISSU

March

2003 43390 THRUST WASHE

43392 THRUST WASHE

50994 RETAINER SET

60162 KNOCK PIN

61221 M4 PHILLIPS SCRE

63501 WASHER

66235 SECURING PLATE

66725 M4 SCRE

66727 M4 SCRE

67444 COLLAR

67447 M5 SCRE

73208 M4 PHILLIPS SCRE

73434 M4 PHILLIPS SCRE

76027 SHUTTLE RACE BASE

76116 BALL METAL GUIDE

76118 BOBBIN CASE STOPPE

76130 LOWER SHAFT

76134 SCREW

76136 BELT METAL

76137 SHUTTLE RACE SHAF

76138 SECURING PLATE

76140 FEED REGULATING

76141 BALL METAL

76200 COLLAR

76203 OILING CORD

76204 PIN

76205 TORSION SPRING

76211 BEVEL GEA

76212 BOBBIN CASE

76317 M3 PHILLIPS SCRE

76487 LOWER SHAFT GUIDE BRACKE

76488 LOWER SHAFT GUIDE

77042 M4 PHILLIPS SCRE

85128 BOBBIN

86005 SHUTTLE RACE

86133 FEED LIFTING CAM

SERIAL NO.

BUYER'S MODEL NO. 2662 SECTION PAGE REVISION REMARKS PART NO. DESCRIPTION

BUYER'S MODEL NAM

10963 E6 CLIP-ON-WASHE

FACTORY MODEL CA97861 37515 WASHER

ORIGINAL ISSU

March

2003 39817 M4 PHILIPS SCRE

43658 THRUST WASHE

43858 WASHER

61381 CRINKLE WASHE

66052 M4 SCRE

64653 M3 SCRE

66481 M4 STUD SCRE

66725 M4 SCRE

67445 COLLAR

67447 M5 SCRE

68891 WASHER

72791 M4 SCRE

72821 COLLAR

72826 EXTENSION SPRING

73299 M4 TORQUE NUT

76025 FEED DOG BASE

76026 FEED REGULATING BRACKE

76088 FEED CONTROL LIN

76104 FEED DOGS

76109 FEED REGULATING LINK R.

76110 FEED REGULATING LINK L.

76111 HEADED PIN

76112 PIN

76121 FEED REGULATING ARM

76122 FEED BASE ADJUSTMEN

76125 SPRING HOOK PLATE

76131 HORIZONTAL FEED SHAF

76132 SHAFT

76133 FEED REGULATING SHAF

76197 HEADED PIN

76199 PIN

76206 TORSION SPRING

76215 SPRING

76324 M4 SCRE

77035 M4 PHILLIPS SCRE

77042 M4 PHILLIPS SCRE

77056 WASHER

SERIAL NO.

BUYER'S MODEL NO. 2662 SECTION PAGE REVISION REMARKS PART NO. DESCRIPTION

BUYER'S MODEL NAM

1513 E4 CLIP-ON-WASHE

FACTORY MODEL CA97861 8400 E5 CLIP-ON-WASHE

ORIGINAL ISSU

March

2003 28735 CRINKLE WASHE

32316 WASHER

32949 WASHER

53321 WASHER

58431 FIBER WASHE

59221 WASHER

61221 M4 PHILLIPS SCRE

61222 M4 PHILLIPS SCRE

66725 M4 SCRE

66727 M4 SCRE

73299 M4 TORQUE NUT

73304 M4 SCRE

73458 M4 STUD SCRE

74841 SEAL

75169 HEADED PIN

75207 GRIP RING

76029 PINION SHAFT

76069 SECURING SHAFT PLATE

76076 PIN

76087 R. CONNECTING ROD C

76089 FEED CONTROL ARM

76282 S.S. CHANGING LINK ASSEMBL

76344 STITCH LENGTH CONTROL CAM

76350 BH TUNING SETTING PLATE

76351 BH FINE TUNING PLATE

76354 FEED CONTROL LINK

76355 FEED CONTROL LINK B

76356 TORSION SPRING

76357 LEAF SPRING

76363 BH WIRE ROD

76439 STITCH LENGTH CONTROL

76453 DIAL INDICATO

76462 ECCENTRIC CAM

76529 R. FUNCTION PLATE

76530 CONNECTING ROD

76531 R. LINK PLATE

76532 R. CONNECTING ROD B

77042 M4 PHILLIPS SCRE

SERIAL NO.

BUYER'S MODEL NO. 2662 SECTION PAGE REVISION REMARKS PART NO. DESCRIPTION

BUYER'S MODEL NAM

1513 E4 CLIP-ON-WASHE

FACTORY MODEL CA97861 8400 E5 CLIP-ON-WASHE

ORIGINAL ISSU

March

2003 25436 E2 CLIP-ON-WASHE

53321 WASHER

67447 M5 SCRE

74819 INDICATOR

76052 SHAFT

76085 SPRING

76096 ROLLER

76097 INDICATOR DRIVER PULLE

76150 BEVEL GEA

76226 SEAL

76228 STRING

(

TETRON

)

76235 STRAIGHT PIN

76371 INDICATOR GUIDE PLATE

76438 PATTERN SELECTING DIAL

77042 M4 PHILLIPS SCRE

SERIAL NO.

BUYER'S MODEL NO. 2662 SECTION PAGE REVISION REMARKS PART NO. DESCRIPTION

BUYER'S MODEL NAM

1424 WASHER

FACTORY MODEL CA97861 10963 E6 CLIP-ON-WASHE

ORIGINAL ISSU

March

2003 43390 THRUST WASHE

50938 PATTERN SELECTING CAM

55894 TAPPING SCRE

58269 SPRING PIN

61225 M4 PHILLIPS SCRE

61588 WASHER

63501 WASHER

66235 SECURING PLATE

66725 M4 SCREW

67444 COLLAR

67447 M5 SCRE

73434 M4 PHILLIPS SCRE

75125 LEAF SPRING

75217 WORM GEA

76028 BH NOTCH

76033 PATTERN CAM

76034 CAM SHAFT

76035 PINION

76036 BH WIDTH CAM

76038 BH RING PLATE

76042 BH CAP

76044 COMPRESSION SPRING

76055 RING STOPPE

76141 BALL METAL

76142 STRETCH STITCH CAM

76161 BH CAM

76222 SPRING

76321 BRACKET

77042 M4 PHILLIPS SCRE

SERIAL NO.
