APPLICATION

TheseinstructionsapplytotheSimpsonDura-VentDirectVentSystem,Model

DV-GS.Thisventingsystem,incombinationwiththegasappliance,hasbeentested

andlistedasadecorativegasappliancesystem,orasadirectventheatersystem

byamajortestingagencysuchasUL,AGA,CGA,OmniorWarnockHersey.

Checkthemanufacturer'sratingplateandinstructionmanualtoconfirmthatthe

SimpsonDura-Ventdirectventsystemisapprovedforuseonthebrandname

applianceyouhaveselected.

IMPORTANT

Readallinstructionscarefullybeforestartingtheinstallation. Failuretofollowthese

instructionsmaycreateafireorothersafetyhazard,andwillvoidthewarranty. Be

suretochecktheappliancemanufacturer'sinstallationinstructionsforspecific

ventingandclearancetocombustiblerequirements,whichmayvaryfromone

appliance to another. Do not extend the venting system vertically or

horizontally in excess of the distance prescribed in the appliance

manufacturer'sinstallationinstructions.

INSTALLATIONPRECAUTIONS

TheSimpsonDura-VentDirectVentSystemisanengineeredproductthathasbeen

designedandtestedforusewithanapprovedlistofdirectventfireplaces. The

SimpsonDura-Ventwarrantywillbevoided,andseriousfire,health,orothersafety

hazardsmayresultfromanyofthefollowingactions:

•InstallationofanydamagedDirectVentcomponent.

•UnauthorizedmodificationoftheDirectVentSystem

•Installationofanycomponentpartnotmanufacturedorapprovedby

SimpsonDura-Vent.

•InstallationotherthanasinstructedbySimpsonDura-Ventandthe

appliancemanufacturer.

VENTING INSTRUCTIONS

FOR DIRECT VENT

FIREPLACES

Consultyourlocalbuildingcodesbeforebeginningtheinstallation.

WARNING

• Always maintain required clearances (air spaces) to nearby

combustiblestopreventafirehazard. Donotfillairspaceswithinsulation.

Besuretochecktheappliancemanufacturers'sinstallationinstructionsforminimum

clearancerequirementsbetweentheouterwallsof

the vent pipe and nearby combustible surfaces. Be sure to check the vent

terminationclearancerequirementsfromdecks,windows,soffits,gasregulators,

airsupplyinlets,andpublicwalkways,asspecifiedintheseinstallation

instructionsandlocalbuildingcodes.

• The fireplace and vent system must be vented directly to the

outsideofthebuilding. Eachdirectventfireplacemustuseit'sownseparatevent

system. Commonventsystemsareprohibited.

SAFETYPRECAUTIONSFORTHEINSTALLER

•Wearglovesandsafetyglassesforprotection.

•Exerciseextremecautionwhenusingladdersoronrooftops.

•Beawareofelectricalwiringlocationsinwallsandceilings.

PARTSLIST

TheSimpsonDura-VentDirectVentSystemoffersacompletelineofcomponent

partsforinstallationofbothhorizontalandverticalinstallations. Thegalvanizedpipe

and fittings are used for concealed locations such as attics, or spaces where

corrosionisafactor,suchasabovetheroofline. Snorkelterminationsareavailable

forapplicationswhichmayrequireverticalriseonthebuildingexterior.

PARTSLIST

Number Description

7" x 4" 8" x 5"

11008 1208 6"PipeLength

11007 1207 9"PipeLength

11006 1206 12"PipeLength

11004 1204 24"PipeLength

11003 1203 36"PipeLength

11002 1202 48"PipeLength

11017 1217 17"to24"Pipe,Adjustable

11045 1245 45°Elbow

11090 1290 90°Elbow

11043 1243 Flashing,0/12to6/12RoofPitch

11044 1243S Flashing,7/12to12/12RoofPitch

11053 1253 StormCollar

11063 1263 CeilingFirestop

11042 1242 WallFirestop

11088 1288 WallStrap

11081 1281 SnorkelTermination(36")

11082 1282 SnorkelTermination(14")

11084 1284 Horiz.SquareTermination

11030 1230 Horiz.RoundTermination

11080 1280 VerticalTermination

11091 1291 Vert.Termination,HighWind

11050 1250 VinylSidingStandoff

FIGURE 3

45° ELBOW

PIPE

SECTION

PIPE

SECTION

CEILING

FIRESTOP

FIGURE 1

ROUND

HORIZONTAL

TERMINATION

SQUARE HORIZONTAL

TERMINATION

45° ELBOW

PIPE SECTION

WALL

FIRESTOPS

WALL FIRESTOP

WALL

FIRESTOP

45° ELBOW

PIPE

SECTION

90° ELBOW

WALL

FIRESTOPS

ROUND

HORIZONTAL

TERMINATION

FIGURE 2

SQUARE

HORIZONTAL

TERMINATION

STORM

COLLAR

VERTICAL

TERMINA-

TION

FLASHING

PIPE

SECTION

PLANNINGYOURINSTALLATION

TherearetwobasictypesofDirectVentSysteminstallations. Checktheappliance

manufacturer'sinstallationinstructionstoconfirmwhattypesarepermitted,andalso

checkforanyventingrestrictionssuchasmaximumhorizontalrun,andmaximum

verticalrise. Thetwotypesofinstallationsare:

•Horizontal Termination(Fig1andFig2)

•Vertical Termination(Fig3)

Whenplanningyourinstallation,itwillbenecessarytoselecttheproperlengthof

ventpipeforyourparticularrequirements. Forhorizontalinstallations,checkthe

appliancemanufacturers'sinstallationsinstructionstodeterminetheminimum

clearancefromtherearoftheappliancetothewall. Itisalsoimportanttonotethe

wallthickness. Selecttheamountofverticalrisedesiredfor"vertical-to-horizontal"

type installations. To determine the length of vent pipe required for vertical

installations,measurethedistancefromtheapplianceflueoutlettotheceiling,the

ceilingthickness,theverticalriseinanatticorsecondstory, andallowforsufficient

ventheightabovetheroofline. Fortwo-storyapplications,firestopsarerequired

ateachfloorlevel. Ifanoffsetisneededintheattic,additionalpipeandelbowswill

berequired.

HORIZONTALINSTALLATION

Step1. Setthefireplaceinit'sdesiredlocation. Checktodetermineifwall

studsorroofraftersareinthewaywhentheventingsystemisattached. Ifthisis

thecase,youmaywanttoadjustthelocationoftheappliance.

Step2. DirectVentpipeandfittingsaredesignedwithspecialtwist-lock

connections. Toconnecttheventingsystemtotheapplianceflueoutlet,atwist-lock

applianceadaptorisrequired. Withsomebrandsofappliances,theSimpsonDura-

Ventadaptorwillbebuiltintotheapplianceatthefactory. Withotherbrands, it

willbesuppliedbythe appliancemanufacturer,forinstallationinthefield. Assemble

thedesiredcombinationofpipeandelbowstotheapplianceadaptorwithpipe

seamsorientedtowardsthewallorfloor,asmuchoutofviewaspossible. Ifthe

applianceadaptorisnotbuiltintotheapplianceatthefactory,itmaybepreferable

toassemblethepipeandelbowstotheadaptorpriortomountingtheadaptoronto

thefireplace. Inthismanner,thepipeand45°elbowassemblymaybeproperly

twist-lockedandrotatedtofacethewalltermination,withfinalpositioningofthe

ventpipeassemblydeterminedbythemountingorientationoftheapplianceadaptor

ontothefireplace. Figure4showssomeofthepossibleventpathwayoptions.

Consulttheappliancemanufacturerforanyrestrictions.

Notes:

(1)Twist-lockprocedure: Fourindentations,locatedonthefemaleends

ofpipesandfittings,aredesignedtoslidestraightontothemaleendsofadjacent

pipesandfittings,byorienting

thefourpipeindentationssothey

match and slide into the four

entryslotsonthemaleends.(Fig

5). Pushthepipesectionscom-

pletelytogether,thentwist-lock

onesectionclockwiseapproxi-

matelyone-quarterturn,untilthe

twosectionsarefullylocked.

SEALANT

(OPTIONAL

UNLESS

REQUIRED BY

APPLIANCE

MANUFACTURER)

FEMALE LOCKING

LUGS

MALE

LOCKING

LUGS

Fig 5

Fig 4

(2) Horizontal runs of

vent must be supported every

three feet. Wall Straps are

USE EITHER

SQUARE

HORIZONTALOR

ROUND

HORIZONTAL

TERMINATION

CAPS

availableforthispurpose.

(3) Sealant is optional, unless

specified by the appliance

manufacturer. Shouldyouelecttouse

sealant,itisonlynecessaryontheouter

tube of the GS Pipe. Run a 1/8-inch

widebeadofsealantaroundthemale

end of the outer sleeve, as shown in

Figure5, and twist-lockthe pipesor

fittingstogether.

Step 3. With the adaptor and

pipeattachedtothefireplace,slidethe

fireplaceintoit'scorrectlocation,and

markthewallforasquareholeofthe

appropriatesize. Usea10"x10" square

holefor7"x4"pipeandusean11"x11"

squareholefor8"x5"pipe. Thecenter

ofthesquareholeshouldlineupwith

thecenterlineofthehorizontalpipe,asshowninFigure6. Cutandframethesquare

hole in the exterior wall where the vent will be terminated. If the wall being

penetrated is constructed of noncombustible material, i.e. masonry block or

concrete,aholewithzeroclearancetothepipeisacceptable.

Notes:

(1) Thehorizontalrunofventmustbelevel, orhavea1/4-inchriseforevery

1footofruntowardsthetermination. Neverallowtheventtorundownward. This

couldcausehightemperaturesandmaypresentthepossibilityofafire.

(2)Thelocationofthehorizontalventterminationonanexteriorwallmust

meet all local and national building codes, and must not be easily blocked or

obstructed. Terminationclearancesareasfollows:

(a)Clearanceabovetheground, veranda,porch,deckorbalcony-12

inchesminimum.

(b) Clearanceto a window or doorthatmaybeopened-9inches

minimum.

terminationwithahorizontaldistanceof2feetfromthe

centerlineofthetermination-18inchesminimum.

(d) Clearancetoanunventilatedsoffit- 12inchesminimum.

CENTER

OF HOLE

Fig 6

(e) Clearance to an

outsidecorner-astested.

(f) Clearancetoaninside

corner-astested.

(g) Not to be installed

above a meter/regulator

assembly within 3 feet

horizontally from the

centerlineoftheregulator.

(h)Clearancetoaservice

regulatorventoutlet-6feet

minimum.

(i) Clearance to non-

mechanicalairsupplyinlet

to a building or the

combustionairinlettoany

otherappliance-12inches

minimum.

(j) Clearance to a

mechanicalairsupplyinlet-

6feetminimum.

(k) Clearance above a

paved sidewalk or paved

drivewaylocatedonpublic

property-refertolocalcode.

(l) Clearance under a

veranda, porch, deck or

balcony -12 inches

minimum.

Forinstallationsrequiringa

verticalriseontheexterior

ofthebuilding,14-inchand36-inchtallSnorkelTerminations,asshowninFigure

7 are available. Follow the same installation procedures as used for standard

SquareHorizontalTerminations. IftheSnorkelTerminationmustbeinstalled

belowgrade,(i.e.basementapplication),properdrainagemustbeprovidedto

preventwaterfromenteringtheSnorkelTermination. RefertoFigure8. Donot

attempttoenclosetheSnorkelwithinthewall,oranyothertypeofenclosure.

12 INCHES

MINIMUM

SNORKEL

SNORKLE

12 INCHES

MINIMUM

ADEQUATE

DRAINAGE

Fig 8

Fig 7

Step 4. For a Square Horizontal Vent

Termination,placetheventcap inthecenterof

thesquareholeand attachtotheexteriorwall

withthefourwoodscrewsprovided. Before

attachingtheVentTerminationtotheexterior

wall,runabeadofnon-hardeningsealantaround

it'soutsideedges,soastomakeasealbetween

it and the wall. If you are using a Round

HorizontalVentTermination,placeanexterior

WallFirestopoverthesquarehole. Runabead

ofnon-hardeningsealantaroundtheedgesof

theWallFirestop,andattachtheWallFirestop

tothewallwiththefourwoodscrewsprovided.

Thearrowontheventcapshouldbepointing

up. Insurethatproperclearancestocombustible

materialsaremaintained. (Fig9)

Notes:

(1) The four wood screws provided

shouldbereplaced withappropriatefastenersforstucco,brick,concrete,orother

typesofsidings.

(2)Forbuildings

withvinylsiding,aVinyl

SidingStandoff,should

beinstalledbetweenthe

vent cap and the wall.

(Fig10) AttachtheVi-

nylSidingStandofftothe

HorizontalVentTermi-

nation. TheVinylSiding

Standoffpreventsexces-

siveheatfrompossibly

melting thevinylsiding

material. Note that the

SquareHorizontalVent

Termination bolts onto

theflatportionoftheVi-

nyl Siding Standoff,

Fig 9

WOOD

SCREWS

WOOD

SCREWS

Fig 10

BOLT

(4) REQ

CUTVINYLSIDINGAWAY

TO FITSTANDOFF

NUT

(4) REQ

VINYL

SIDING

STANDOFF

ROUND

TERMINA-

TION CAP

WOOD SCREW

(4) REQ

(shadedareashowninFigure10),sothatan

airspacewillexistbetweenthewallandthe

Vent Termination. The Round Horizontal

VentTerminationdoesnotneedanexterior

WallFirestopwhenusingaVinylSidingStand-

off.Simplyslidetheroundtermination through

theVinylSidingStandoffinordertoconnect

totheventpiping. Besurethatallofthevent

capmeshistotheexteriorofthewall.

Step5. Beforeconnectingthehorizontal

runofventpipetotheventtermination,slidetheWallFirestopovertheventpipe

ontheinteriorsideofthewall.

Step6. Slidetheapplianceandventassemblytowardsthewall,carefully

insertingtheventpipeintotheventcapassembly. Itisimportantthattheventpipe

extendintotheventcapsufficientdistancesoastoresultinaminimumpipeoverlap

of 1-1/4inches. Securetheconnectionbetweentheventpipeandtheventcap.

Forsquarecaps,attachthe twosheetmetalstrips extendingfromtheventcap

assemblyinto the outerwall of thevent pipe. Use thetwo sheet metal screws

providedtoconnectthesheetmetalstripstothepipesection. Forroundcaps,use

threesheetmetalscrewsandattachcaptopipesection. (Fig11)

Step7. Slide the Wall Firestop up to the wall surface and attach with

screwsprovided. (Fig12)

Fig 11

STRAP

WOOD

SCREWS

Fig 12

SQUARE TERMINATION ROUND TERMINATION

WALL

FIRESTOP

SHEET

METAL

SCREW

WALL

FIRESTOP

WALL FIRESTOP

SHEET

METAL

SCREW

FOLD

STRAP

HERE

1-1/4 "

Table des matières

Autres manuels Simpson Cheminée intérieure

Simpson

Simpson Dura-Vent 5"x 8" Direct Vent System Manuel utilisateur

Manuels Cheminée intérieure populaires d'autres marques

Brigantia

Brigantia 35-DVRS31N-2 Manuel du propriétaire

Nordpeis

Nordpeis Bergen Manuel utilisateur

Superior

Superior BCT2536TMN Manuel utilisateur

Quadra-Fire

Quadra-Fire 5100I-GD-B Manuel utilisateur

Renaissance

Renaissance RUMFORD 1000 Manuel utilisateur

Lacunza

Lacunza IV-800 Manuel utilisateur

Baxi

Baxi 940 Instructions d'utilisation

Dru

Dru Maestro 60/2 Tall RCH Manuel utilisateur

Diamond Fireglass

Diamond Fireglass SS-O22 Manuel utilisateur

HearthStone

HearthStone Windsor Bay 8830 Manuel de programmation

Napoleon

Napoleon ASCENT B42 Manuel utilisateur

Enviro

Enviro E33GI Manuel utilisateur

Smeg

Smeg L30 FABE Instructions de montage

KEDDY

KEDDY K700 Manuel utilisateur

Godin

Godin 3451 Manuel utilisateur

Jøtul

Jøtul Jotul GI 535 DV IPI New Harbor Manuel utilisateur

Austro Flamm

Austro Flamm Heidi Back 2.0 945048 Manuel utilisateur

Desa

Desa CCFPDFT Manuel d'utilisation
