Simplicity WONDER Manuel utilisateur

www.SimplicityVac.com

Straight Suction Canister

(The chances are you’re

never going to read me)

Owner’s Manual

IMPORTANT SAFETY INSTRUCTIONS

When using an electrical appliance, basic precautions should always be followed, including

the following:

READ ALL INSTRUCTIONS BEFORE

USING THIS APPLIANCE

The manufacturer cannot accept responsibility for damage

caused when the appliance is not used according to the

instructions or for uses other than those for which it

was intended.

To reduce the risk of fire, electric shock or injury:

• Do not leave appliance when plugged in.

Unplug from outlet when not in use and

before servicing.

• WARNING: ELECTRIC SHOCK COULD

OCCUR IF USED OUTDOORS OR ON

WET SURFACES.

• Do not allow to be used as a toy. Close

attention is necessary when used by or

near children.

• Use only as described in this manual.

Use only manufacturer’s recommended

attachments.

• Do not use with damaged cord or plug. If

appliance is not working as it should, has

been dropped, damaged, left outdoors,

or dropped into water, return it to your

Authorized Retailer for service.

• Do not pull or carry by cord, use cord as

a handle, close a door on the cord, or pull

cord around sharp edges or corners. Do

not run appliance over cord. Keep cord

away from heated surfaces.

• Do not unplug by pulling on cord. To

unplug, grasp the plug, not the cord.

• Hold plug when retracting the power cord

to prevent the cord from whipping.

• Do not handle plug or appliance with

wet hands.

• Do not put any object into openings. Do

not use with any opening blocked; keep

free of dust, lint, hair and anything that

may reduce air ﬂow.

• Keep hair, loose clothing, ngers and all

parts of body away from openings and

moving parts.

• Do not pick up anything that is burning or

smoking, such as cigarettes, matches or

hot ashes.

• Do not use without vacuum bag in place.

• Turn off all controls before unplugging.

• Use extra care when cleaning on stairs.

• Do not use to pick up ammable or

combustible liquids such as gasoline or

use in areas where they may be present.

• Do not attempt to service the unit while

appliance is plugged in.

• Do not use vacuum to pick up water or

any wet materials.

SAVE THESE INSTRUCTIONS.

WARNING:

Contents

Safety Precautions 4

Replacing the Vacuum Bag and Filters 5

Description and Operation of the Canister 6-7

Troubleshooting Guide 8

Key Replacement Parts 8

Owner’s Information 9

Warranty 10

Safety Precautions

This vacuum cleaner should be used for normal, dry household dust and dirt. The manufacturer

cannot be held responsible for any damage caused by use or operation of the vacuum contrary

to these instructions. If the vacuum is wrongly operated for a purpose other than that for which

it is intended, no liability can be accepted for any possible damage.

• Do not vacuum areas which contain moisture or water, flammable matter, needles, pins,

razor blades, matches, cigarettes, etc., since they may damage the vacuum or vacuum bag.

• When retracting the power cord, hold the plug to prevent the cord from whipping.

• Make sure a vacuum bag and filters are always in place.

• This product is equipped with a polarized alternating current line plug (a plug having one

blade wider than the other). This plug fits into the power outlet only one way. This is a safety

feature. If you are unable to insert the plug fully into the outlet, try reversing the plug. If the

plug should still fail to fit, contact an electrician to replace the obsolete outlet. Do not defeat

the safety purpose of the polarized plug.

State of California Proposition 65 Warnings:

WARNING: This product contains one or more chemicals known to the State of California to

cause cancer.

WARNING: This product contains one or more chemicals known to the State of California to

cause birth defects or other reproductive harm.

Replacing the Vacuum Bag and Filters

Replacing the Vacuum Bag

Change the vacuum bag when the full bag indicator

changes from green to red or when the suction power

is weak. The bag compartment will not close without a

bag in the vacuum or if the bag is not properly installed.

1. Open the bag compartment.

2. Pull the tab on the bag collar, which closes the

bag while removing it from the bag holder.

3. Remove and discard the used bag.

NOTE: The HEPA media bag cannot be reused.

4. Slide a new bag into the bag holder until it

clicks into place.

5. Close the bag compartment.

Replacing the Secondary Filter

1. Open the bag compartment and locate

the filter behind the vacuum bag. For

better access to the secondary filter,

remove the bag.

2. Pull the filter holder up.

3. Remove the used filter and replace it with

a new filter.

4. Slide the filter holder back into place and

replace the bag.

Replacing the HEPA Media Filter

1. Open the bag compartment and locate the

filter behind the vacuum bag. For better access

to the HEPA media filter, remove the bag.

2. Grasp the tab with two fingers and pull the filter

out towards you. Replace with a new filter by sliding

the filter in and pushing down on the top of the tab

until it clicks into place.

NOTE: The HEPA media filter cannot be washed

and reused.

At a minimum, it’s recommended to replace the HEPA media and secondary filters after

using 12 vacuum bags.

If someone in your household is sensitive to airborne allergens, it is recommended to

change the filter set after every six vacuum bags.

When to Change the Filters

State of California Proposition 65 Warnings:

WARNING: This product contains one or more chemicals known to the State of California to

cause cancer.

WARNING: This product contains one or more chemicals known to the State of California to

cause birth defects or other reproductive harm.

Description and Operation of the Canister

Wand

Storage

• The tab on the neck of the wand or

the neck of the floor tool can be

inserted into either groove on the

canister for easy storage.

Power Cord Management

• Pull cord out of vacuum to desired length.

Do not pull cord out past the yellow

safety tape.

• Insert cord into the cord holder to lock

into place.

• To retract the cord, remove it from the

holder and tug on the cord until it retracts

into the vacuum.

2-n-1 Tool

• This tool converts from a

premium dusting brush to

a deluxe upholstery tool by

inserting the hose handle

or wand end into the

indicated openings.

Hose Inlet

• To separate the hose

from the canister body,

press the buttons on

the hose inlet and

pull it away from the

canister.

• Use to clean and

polish tile, hard wood

and linoleum floors.

Floor It! Tool with

Microfiber Pad

Insert here for

Deluxe Upholstery Tool

Insert here for

Premium Dusting Brush

Description and Operation of the Canister

Crevice

Tool

2-n-1 Tool

Full Bag Indicator

• If the green indicator changes to red:

- Change the vacuum bag.

- If the vacuum bag is not full, but the full bag indicator is

red, check the hose for a clog.

- If you are vacuuming fine dust like flour or drywall dust,

the pores of the bag may become clogged reducing

suction before the bag is full. If this happens, change

the bag and resume vacuuming.

• When cleaning with a tool (2-n-1 tool or crevice tool), the red

indicator may appear. In this case, continue cleaning.

On/Off Switch

• Lift here to access the

vacuum bag and filters.

Bag Compartment Latch

Power Control

Cleaning Tools

Handle

Release

Button

Wand

Extension

Button

Suction Relief Dial

• Slide to increase or decrease

the power of the motor.

• Turn dial to open air stream

and reduce suction for

delicate jobs like cleaning

sheer curtains.

POWER

Troubleshooting Guide

Please check each item below if you have trouble with your vacuum.

Unplug the vacuum from the power supply before servicing.

Problem Check Point Possible Solution

Suction power is weak. Vacuum bag If vacuum bag is

full, replace it.

Wand, tools, or hose If clogged or blocked,

remove the object.

The vacuum does not work. Is the hose adapter inserted Insert it completely.

into the suction opening of the

vacuum completely?

When the vacuum bag is full Turn the vacuum off and

or any of the accessories are unplug the vacuum.

blocked, the over-heating Check the vacuum

protection for the motor bag and accessories

is activated. and remove any

blockages. The

vacuum can be turned

on again after approximately

20 minutes.

Power cord does not retract. Power cord Tug the power cord a

little until it starts to retract.

Power cord won’t pull out of Power cord Do not pull it out by force.

the vacuum. Visit an Authorized Simplicity

Vacuum Retailer.

Model: WONDER

Rating: 120V/60Hz

Amps: 10

Key Replacement Parts

• Genuine HEPA Media Vacuum Bags 6 pack: SCH-6

• Genuine HEPA Media Filter Set: SF19

• Mircober Pad 3 pack: HFIP-3

Speciﬁcations

Owner’s Information (keep this for your records)

The model and serial number of this product may be found on the back side of the unit.

You should note the model and serial number of your unit in the spaces provided below,

and retain this book as a permanent record of your purchase.

Date of purchase ____________________________________________________

Serial number _______________________________________________________

Model number ______________________________________________________

Purchased from:

Store name _______________________________________________________

Address _______________________________________________________

City, State, Zip ______________________________________________________

Telephone _______________________________________________________

For Best Performance:

• Keep your canister clean and in good operating condition.

• Change vacuum bags once a month or when the the full bag indicator changes from

green to red to maximize cleaning performance.

• Always use genuine vacuum bags and replacement parts. Use of other products may

result in poor cleaning performance, potential vacuum cleaner damage and may void

vacuum warranty. Genuine products are designed for maximum cleaning performance.

• Have your canister checked periodically by your Authorized Simplicity Vacuum Retailer.

• Use only Authorized Simplicity Vacuum Retailers for parts or service.

• Store your canister carefully in a dry area.

• For optimum cleaning performance and safety, follow your owner’s manual instructions.

www.SimplicityVac.com

Warranty

What is Covered:

This warranty covers any defects in material and workmanship in your new

Simplicity vacuum and applies exclusively to the original purchaser.

How Long Coverage Lasts:

Warranty coverage for the Simplicity Wonder canister lasts three years.

Household models used commercially are only warranted for 90 days.

What is Not Covered:

• Damage to the vacuum which occurs from neglect, abuse, alterations,

accident, misuse or improper maintenance.

• Normal replacement items: lters and disposable bags.

What Simplicity Vacuums Will Do:

This warranty provides, at no cost to you, all labor and parts to place this vacuum

in correct operating condition during the warranted period.

How to Get Service:

Warranty service can only be obtained by presenting the vacuum to an Authorized

Simplicity Retailer. A proof-of-purchase and product serial number will be required

before service is rendered. To locate your nearest Simplicity Retailer,

please call 1-888-9-SIMPLY or visit the Simplicity website at

www.SimplicityVac.com.

THIS WARRANTY IS EXCLUSIVE AND IN LIEU OF ANY AND ALL OTHER

WARRANTIES WHETHER WRITTEN, ORAL, EXPRESSED OR IMPLIED,

(INCLUDING ANY WARRANTY OF MERCHANTABILITY OR FITNESS FOR

A PARTICULAR PURPOSE). THIS WARRANTY DISCLAIMS LIABILITY FOR

INCIDENTAL OR CONSEQUENTIAL DAMAGES.

How State Law Applies:

This warranty gives you specic legal rights, and you may also have other rights

which vary from state to state.

www.SimplicityVac.com

Autres manuels pour WONDER

Table des matières

Autres manuels Simplicity Aspirateur

Simplicity

Simplicity S38 Manuel utilisateur

Simplicity

Simplicity Symmetry S20S Manuel utilisateur

Simplicity

Simplicity Synergy X9 Manuel utilisateur

Simplicity

Simplicity Symmetry Manuel utilisateur

Simplicity

Simplicity Jessie Vacuum Bag and Filters Manuel utilisateur

Simplicity

Simplicity Central Vacuum Power Units Manuel utilisateur

Simplicity

Simplicity 7 Series Manuel utilisateur

Simplicity

Simplicity WONDER Manuel utilisateur

Simplicity

Simplicity S65D Manuel utilisateur

Simplicity

Simplicity S18 Manuel utilisateur

Simplicity

Simplicity S65S Manuel utilisateur

Simplicity

Simplicity Synchrony S30P Manuel utilisateur

Simplicity

Simplicity HEAVY DUTY SHD-1T Manuel utilisateur

Simplicity

Simplicity Jill Manuel utilisateur

Simplicity

Simplicity Freedom S10CV Manuel utilisateur

Simplicity

Simplicity Freedom F3300 Manuel utilisateur

Simplicity

Simplicity Whoosh Manuel utilisateur

Simplicity

Simplicity S24 Manuel utilisateur

Simplicity

Simplicity Jack Manuel utilisateur

Simplicity

Simplicity S20E Manuel utilisateur

Simplicity

Simplicity S5 Manuel utilisateur

Simplicity

Simplicity S20 Manuel utilisateur

Simplicity

Simplicity Scout Plus Manuel utilisateur

Simplicity

Simplicity Synergy X9 Manuel utilisateur

Manuels Aspirateur populaires d'autres marques

Bissell

Bissell LittleGreen Proheat 1425 Series Manuel utilisateur

Panasonic

Panasonic MC-YL637S147-AE Manuel utilisateur

NEFF

NEFF N17XH10 0 Series Manuel utilisateur

LG A9 Series Manuel utilisateur

Oreck

Oreck Cordless Captura BK51700 Series Manuel utilisateur

Kogan

Kogan KAVACROBVWA Manuel utilisateur

Kränzle

Kränzle VENTOS 50 ID Guide de l'utilisateur

EVVO

EVVO Ai35 Manuel utilisateur

DeWalt

DeWalt DWH200D Manuel utilisateur

Pontec

Pontec Pondomatic Vacuum Cleaner Manuel utilisateur

Cleanmaxx

Cleanmaxx PC-P007E Manuel utilisateur

Exido

Exido 240-114 Manuel utilisateur

RIDGID

RIDGID WD1685AU0 Manuel utilisateur

Ezviz

Ezviz RE4P Manuel utilisateur

STG global

STG global TANVAC HDV3000 Manuel utilisateur

Shark

Shark ROTATOR PRO COMPLETE NV550 Series Manuel utilisateur

Factory

Factory M3340 Manuel utilisateur

Shop-Vac

Shop-Vac VN92 SERIES Manuel utilisateur
