Parts Manual

522E / 522EX

22" Single Stage Snowthrowers

. No. Descri

tion

Attachment

1695468522E, 22" Single Stage Snow Thrower

1695514522EX, 22" Single Stage SnowThrower

Not

for

Reproduction

Rev. 11/2008

TP 400-5004-00-ST-S

Part No.: 1737494

Not for

Reproduction

Table Of Content

Torque Specification Chart ..................................................................... Inside Back Cover

PRODUCT COMPONENTS PAGES

Frame and Fuel Tank ........................................................................................................................................... 4

Engine Drive System ............................................................................................................................................ 6

Electric Starter ...................................................................................................................................................... 8

Body Covering ...................................................................................................................................................... 10

Wheel Assembly .................................................................................................................................................. 12

Decals .................................................................................................................................................................. 14

Auger and Housing .............................................................................................................................................. 16

Chute System ....................................................................................................................................................... 18

Handle Assembly ................................................................................................................................................. 20

Not for

Reproduction

Frame and Fuel Tank

NOTE: Unless noted otherwise,

use the standard hardware torque

specification chart.

0005

The above parts group applies to the following Mfg. Nos.:

Briggs and Stratton Yard Power Products Group

1695468 - 522E

1695514 - 522EX

TP 400-5004-00-ST-S

Not for

Reproduction

PART NO. DESCRIPTIONREF NO QTY.

Frame and Fuel Tank

Footnotes

SCREW, 1/4 - 20 x 3/41 302628MA 9

WASHER2 71067MA 18

BRACKET, Fuel Tank3 1741771HYP 1

CAP, Fuel Tank4 1715917SM 1

TANK, Fuel5 1716634SM 1

NUT, Hex 1/4 - 206 73826MA 20

NUT, Hex 5/16 - 187 71391MA 6

HOSE, Fuel Line, Low Perm, 9" (Cut to length)8 7200111YP 1

CLAMP, Fuel Line9 323387MA 1

FILTER, Fuel Line10 298090S 1

CRADLE ASSEMBLY, Engine12 1741989HYP 1

FRAME, L.H.13 1501872E701MA 1

SCREW, 5/16-18 x 5/814 48901MA 1

SCREW, 1/4 - 20 x 215 180044MA 5

PLATE, Mounting Support16 335351MA 1

SUPPORT, Frame17 1501851MA 1

FRAME, R.H.18 1741988AYP 1

SCREW, 5/16-18 x 3/419 180077MA 2

RING, Foam20 1740032MA 1

CLAMP, Fuel Line21 47345MA 1

SCREW, 1/4 - 20 x 5/822 310169MA 2

The above parts group applies to the following Mfg. Nos.:

Briggs and Stratton Yard Power Products Group

1695468 - 522E

1695514 - 522EX

TP 400-5004-00-ST-S

Not for

Reproduction

Engine Drive System

NOTE: Unless noted otherwise,

use the standard hardware torque

specification chart.

0003

The above parts group applies to the following Mfg. Nos.:

Briggs and Stratton Yard Power Products Group

1695468 - 522E

1695514 - 522EX

TP 400-5004-00-ST-S

Not for

Reproduction

PART NO. DESCRIPTIONREF NO QTY.

Engine Drive System

Footnotes

ENGINE, 5.25GT 4CY B&S Electric Start * (Model # 09A4130202E1, Domestic Only)1 ----- 1

ENGINE, 5.25GT 4CY B&S Electric Start * (Model # 09A4130203E1, CE/Export Only)1 ----- 1

CRADLE ASSEMBLY, Engine2 1741989HYP 1

FRAME, L.H.3 1501872E701MA 1

ANTI-VIBRATION MOUNT, Engine4 1502027MA 1

BOLT, Hex, 5/16 - 1851X216MA 1

BOLT, Hex, 5/16 - 2466X118MA 1

WASHER, Flat7 71071MA 3

NUT, Hex Center Lock, 5/16 - 188 71391MA 6

GUIDE, Belt9 334079MA 1

BOLT10 333594MA 2

PAD, Brake11 333970MA 1

SCREW, 1/4 - 20 x 5/812 579052MA 3

IDLER, Arm Pivot13 313444MA 1

SPRING14 313473MA 1

NUT, Hex 1/4 - 2015 73826MA 20

BOLT16 333594MA 2

WIRE, Brake17 1501009MA 1

SPRING18 313471MA 1

PIN, Cotter19 121223MA 1

ARM, Idler20 1741727YP 1

ROD, Clutch Linkage21 313436MA 1

PULLEY, Idler22 48924MA 1

SCREW, 3/8 - 16 x 1-5/823 1741500MA 1

PULLEY, Engine24 1501908MA 1

BOLT, Engine Pulley25 1501907MA 1

WASHER, Flat26 71067MA 18

SCREW, 1/4 - 20 x 227 180044MA 5

PINCH ROLLER28 1501010MA 1

SPACER, Idler29 1741499MA 1

NUT, Hex30 590MA 1

BELT, Drive31 33721MA 1

BOLT, Hex, 5/16 - 1832 001X81MA 1

SCREW, 3/8 - 16 x 133 47792MA 3

WASHER, Flat34 414106MA 3

LOCKWASHER, Split35 71060MA 3

NUT, 5/16 - 1836 71037MA 6

Note* For information on Replacement Parts contact the engine

The above parts group applies to the following Mfg. Nos.:

Briggs and Stratton Yard Power Products Group

1695468 - 522E

1695514 - 522EX

TP 400-5004-00-ST-S

Not for

Reproduction

Electric Starter

NOTE: Unless noted otherwise,

use the standard hardware torque

specification chart.

0009

The above parts group applies to the following Mfg. Nos.:

Briggs and Stratton Yard Power Products Group

1695468 - 522E

1695514 - 522EX

TP 400-5004-00-ST-S

Not for

Reproduction

PART NO. DESCRIPTIONREF NO QTY.

Electric Starter

Footnotes

SCREW, # 8 - 32 x 31 311633MA 2

WASHER2 414106MA 2

NUT, Keps3 271163MA 2

LEVER, Choke *4 791534 1

Muffler *5-1 699565 1

GASKET, Muffler *5-2 691880 1

SCREW, Torx, Socket-Head, Muffler *5-3 699554 1

WASHER, Split Lock5-4 71060MA 1

NUT, Hex, 5/16 - 185-5 71037MA 1

BOLT, Hex, 5/16 - 185-6 001X81MA 1

CORD, Extension (Domestic Only)6 6219MA 1

CORD, Extension (CE/Export Only)6 761332MA 1

GRIP, Mitten7 699334 1

Note* For information on Replacement Parts contact the engi

The above parts group applies to the following Mfg. Nos.:

Briggs and Stratton Yard Power Products Group

1695468 - 522E

1695514 - 522EX

TP 400-5004-00-ST-S

Not for

Reproduction

Body Covering

NOTE: Unless noted otherwise,

use the standard hardware torque

specification chart.

0015

The above parts group applies to the following Mfg. Nos.:

Briggs and Stratton Yard Power Products Group

1695468 - 522E

1695514 - 522EX

TP 400-5004-00-ST-S

Not for

Reproduction
