Parts Manual

Rev. 12/2008

Conquest / 1700 / 2700

2WD Series Garden Tractors & Mower Decks

. No. Descri

tion

23HP Product

1694818 1723H, 23HP Hydro RMO

1694819 Conquest, 23HP Hydro RMO

1694820 2723H, 23HP Hydro RMO

1695153 Conquest, 23HP Kohler Hydro RMO

1695154 1723H, 23HP B&S Hydro w/PS RMO

1695155 2723H, 23HP B&S Hydro w/PS RMO

1695226 Conquest, 23HP B&S Hydro (CE/Export)

2690745 Conquest, 23HP Hydro 2WD w/PS and 50" Mower Deck

2690746 Conquest, 23HP Hydro 2WD RMO and 50" Mower Deck

2690747 Conquest, 23HP Hydro 2WD RMO and 44" Mower Deck

2690748 1723H, 23HP Hydro 2WD RMO and 50" Mower Deck

2690749 1723H, 23HP Hydro 2WD w/PS RMO and 50" Mower Deck

2690750 2723H, 23HP Hydro 2WD RMO and 50" Mower Deck

2690751 2723H, 23HP Hydro 2WD w/PS RMO and 50" Mower Deck

2690753 Conquest, 23HP 2WD RMO and 44" Mower Deck

(CE/Export)

2690799 Conquest, 23HP Hydro and 54" Mower Deck (CE/Export)

. No. Descri

tion

Mower Decks

1695399 44" Mower Deck

1695400 44" Mower Deck

1695397 50" Mower Deck

1695589 50" Mower Deck

TP 400-4803-C-CQ-SMA

1735722

Part No.:

Not for

Reproduction

Not for

Reproduction

Table Of Content

Torque Specification Chart ..................................................................... Inside Back Cover

PRODUCT COMPONENTS PAGES

Frame Group - Manual Steering .......................................................................................................................... 4

Frame Group - Power Steering ............................................................................................................................ 8

Power Steering & Hydraulic Lift Group ................................................................................................................ 12

Steering Group - Manual Steering ....................................................................................................................... 14

Steering Group - Tilt Steering .............................................................................................................................. 16

Engine Group - 20HP, 22HP & 23HP Briggs & Stratton, Vanguard Twin ........................................................... 18

Engine Group - 23HP Kohler, Courage Twin ...................................................................................................... 20

Transmission Group ............................................................................................................................................. 22

Controls Group ..................................................................................................................................................... 26

Cruise Control Group ........................................................................................................................................... 28

Electrical Group .................................................................................................................................................... 30

Hood, Grille & Dash Group .................................................................................................................................. 34

Seat & Seat Deck Group ...................................................................................................................................... 36

Lift Group - Manual Lift ......................................................................................................................................... 38

Wheels & Tires Group .......................................................................................................................................... 40

Decals Group - Brand & Model ............................................................................................................................ 42

Decals Group - Safety & Common ...................................................................................................................... 44

44" & 50" Mower Deck - Clutch & Support Group ............................................................................................... 46

44" Mower Deck - Height Adjustment & Roller Group ......................................................................................... 48

44" Mower Deck - Housing, Arbors & Blades Group ........................................................................................... 52

50" Mower Deck - Height Adjustment & Roller Bar Group .................................................................................. 56

50" Mower Deck - Housing, Arbors & Blades Group ........................................................................................... 58

54" Mower Deck - Height Adjustment & Roller Bar Group .................................................................................. 62

54" Mower Deck - Housing, Arbors & Blades Group ........................................................................................... 66

Not for

Reproduction

Frame Group - Manual Steering

NOTE: Unless noted otherwise,

use the standard hardware torque

specification chart.

986747

The above parts group applies to the following Mfg. Nos.:

2008

1694818 - 1723H

1694819 - Conquest

1694820 - 2723H

1695153 - Conquest

1695226 - Conquest

2690746 - Conquest

2690747 - Conquest

2690748 - 1723H

2690750 - 2723H

2690753 - Conquest

2690799 - Conquest

TP 400-4803-C-CQ-SMA

Not for

Reproduction

PART NO. DESCRIPTIONREF NO QTY.

Frame Group - Manual Steering

Footnotes

TOWER & SUPPORT ASSEMBLY1 1733139ASM 1

CAPSCREW, Hex Washer Head Taptite, 3/8-16 x 3/42 1923683SM 4

CAPSCREW, Hex Washer Head Taptite, 5/16-18 x 3/43 1960541SM 4

SUPPORT, Seat Deck4 1723528ASM 1

NUT, Hex Flange 3/8-16 Whiz Lock, Large5 1928352SM 2

NUT, Hex Flange Two-Way Lock, 1/2-136 1930644SM 2

BACKPLATE7 1722602ASM 1

CAPSCREW, Hex Head 1/2-13 x 1, Black8 1923114SM 2

CAPSCREW, Hex Head 3/8-16 x 1, Black9 1921210SM 2

FRAME ASSEMBLY, Front & Rear10 1726989ASM 1

NUT, Hex Flange Two-Way Lock, 3/8-1611 1930645SM 7

WASHER, 3/8, Black12 1922755SM 1

WASHER, 3/8, Black13 1960103SM 2

LINK, Drag14 1722541SM 1

NUT, Hex Jam 1/2-2015 1919262SM 1

JOINT, Ball16 1702779SM 1

SPACER, 3/8 x 1/2 x 5/817 1708236SM 1

CARRIAGE BOLT, 3/8-16 x 118 1931350SM 2

ROD, Tie19 1722626ASM 1

AXLE ASSEMBLY w/LH Spindle (Includes Ref. Nos. 22, 24, 41, 42 & 43)20 1722200ASM 1

SPACER, 25/64 x 5/8 x 5/16, Powder Metal21 1611705SM 2

BUSHING, 31/32 x 1-1/4 x 3/4, Powder Metal22 1721682SM 6

NUT, Hex Flange Two-Way Lock, 7/16-1423 1930650SM 2

FITTING, Lube24 2821133SM 3

SPINDLE REPLACEMENT KIT, LH (Includes Ref. Nos. 22, 26, 27, 28, 29 & 30)25 1686985SM 1

CAPSCREW, 3/8-16 x 7/8, GR826 2823485SM 1

WASHER, Spring, 3/827 1663151SM 1

HUB & ARM ASSEMBLY28 1725112SM 1

KEY, Woodruff29 2830671SM 1

SPINDLE, LH30 1724264SM 1

CARRIAGE BOLT, 3/8-16 x 1-1/231 1931352SM 1

SPACER, 11/16 x 21/32 x 2 3/3232 1721752SM 1

CAPSCREW, Hex Head, 7/16-14 x 2 G833 1927531SM 2

HOOK, "J"34 1721918ASM 1

BUMPER, Black35 1721805ASM 1

BUMPER, Chrome35 1723502SM 1

SCREW, Truss Head Torque Drive, 5/16-18 x 7/836 1960086SM 4

CAPSCREW, Hex Whiz Lock, 5/16-18 x 3/437 1930591SM 2

PLATE, Axle Wear38 1724801ASM 1

NUT, Hex Flange Whix Lick, 5/16-1839 1931277SM 2

SPINDLE, RH40 1722199SM 1

WASHER41 1919394SM 1

RETAINING RING42 2832577SM 1

The above parts group applies to the following Mfg. Nos.:

2008

1694818 - 1723H

1694819 - Conquest

1694820 - 2723H

1695153 - Conquest

1695226 - Conquest

2690746 - Conquest

2690747 - Conquest

2690748 - 1723H

2690750 - 2723H

2690753 - Conquest

2690799 - Conquest

TP 400-4803-C-CQ-SMA

Not for

Reproduction

Frame Group - Manual Steering

NOTE: Unless noted otherwise,

use the standard hardware torque

specification chart.

986747

The above parts group applies to the following Mfg. Nos.:

2008

1694818 - 1723H

1694819 - Conquest

1694820 - 2723H

1695153 - Conquest

1695226 - Conquest

2690746 - Conquest

2690747 - Conquest

2690748 - 1723H

2690750 - 2723H

2690753 - Conquest

2690799 - Conquest

TP 400-4803-C-CQ-SMA

Not for

Reproduction

PART NO. DESCRIPTIONREF NO QTY.

Frame Group - Manual Steering

Footnotes

CAPSCREW, Hex Flange Whiz Lock, 3/8-16 x 3/443 1933260SM 4

FITTING, Grease for Wear Plate44 2821133SM 2

WASHER, 5/845 1960035SM 2

CAPSCREW, Hex Head, 5/8-11 x 3-1/246 2860645SM 1

NUT, Hex Flange Two-Way Lock, 5/8-1147 2860646SM 1

PLATE, Axle48 1722212ASM 1

The above parts group applies to the following Mfg. Nos.:

2008

1694818 - 1723H

1694819 - Conquest

1694820 - 2723H

1695153 - Conquest

1695226 - Conquest

2690746 - Conquest

2690747 - Conquest

2690748 - 1723H

2690750 - 2723H

2690753 - Conquest

2690799 - Conquest

TP 400-4803-C-CQ-SMA

Not for

Reproduction

Frame Group - Power Steering

NOTE: Unless noted otherwise,

use the standard hardware torque

specification chart.

987426

The above parts group applies to the following Mfg. Nos.:

2008

1695154 - 1723H

1695155 - 2723H

2690745 - Conquest

2690749 - 1723H

2690751 - 2723H

TP 400-4803-C-CQ-SMA

Not for

Reproduction

PART NO. DESCRIPTIONREF NO QTY.

Frame Group - Power Steering

Footnotes

FRAME ASSEMBLY, Front & Rear1 1733765ASM 1

TOWER & SUPPORT ASSEMBLY2 1733139ASM 1

SUPPORT, Seat Deck3 1723528ASM 1

BACKPLATE, Hitch4 1722602ASM 1

PLATE, Axle Support5 1722212ASM 1

BUMPER6 1721805ASM 1

AXLE, SPINDLES & BUSHINGS ASSEMBLY (Includes Ref. Nos. 19, 21, 44, 45, 46, 47,

48, 49 & 50)

7 1732937ASM 1

HOOK, "J"8 1721918ASM 1

ROD, Tie, Flat Ends9 1732759ASM 1

SUPPORT, Steering Unit10 1733044ASM 1

SPACER, Powdered Metal11 1721752SM 1

SPACER12 1611705SM 2

JOINT, Ball, 1/2-20 Thread13 1702779SM 1

SPACER14 1719725SM 1

NUT, Hex Jam, 1/2-2015 1919262SM 1

NUT, Hex Flange, 3/8-16 Two-Way Lock16 1930645SM 4

CYLINDER, Hydraulic Steering17 1732439SM 1

CARRIAGE BOLT, 3/8-16 x 1 G518 1931350SM 2

FITTING, Lube 1/4 Drive19 1704314SM 3

NUT, Hex Flange 7/16-14 Two Way Lock20 1930650SM 2

SPACER, Powdered Metal21 1732208SM 1

CAPSCREW, Hex Head 7/16-14 x 2 G822 1927531SM 2

CAPSCREW, Hex Head 5/8-11 x 3-1/2 G523 2860645SM 1

WASHER, 5/824 1960035SM 2

SCREW, Hex Whiz Lock Flange 3/8-16 x 3/425 1933260SM 4

SCREW, Hex Washer Head Taptite 5/16-18 x 3/426 1664847SM 4

NUT, Hex Flange 5/8-11 Two Way Lock27 2860646SM 1

SCREW, Hex Washer Head Taptite 3/8-16 x 3/428 1923683SM 4

NUT, Hex Flange 1/2-13 Whiz Lock29 2860668SM 2

NUT, Hex Flange 3/8-16 Whiz Lock Large30 1928352SM 2

CAPSCREW, Hex Head 1/2-13 x 1 G531 1923114SM 2

CAPSCREW, Hex Head 3/8-16 x 1 G532 1921210SM 2

SCREW, Truss Head Torx Drive 5/16-18 x 7/833 1960086SM 4

PLATE, Axle "U" Form34 1724801ASM 1

SCREW, Hex Whiz Lock Flange 5/16-18 x 3/435 1930591SM 2

NUT, Hex Flange 5/16-18 Whiz Lock36 1931277SM 2

FITTING, Lube 1/4 Drive37 2821133SM 2

SCREW, Hex Washer Head Taptite 5/16-18 x 1/238 1924856SM 4

SPACER39 1733912ASM 1

WASHER, 5/840 1924366SM 2

CAPSCREW, Hex Head41 1960713SM 1

NUT, Hex Toplock42 1960714SM 1

NUT, Hex Flange, Machine Lock 3/8-1643 1960339SM 2

The above parts group applies to the following Mfg. Nos.:

2008

1695154 - 1723H

1695155 - 2723H

2690745 - Conquest

2690749 - 1723H

2690751 - 2723H

TP 400-4803-C-CQ-SMA

Not for

Reproduction

Frame Group - Power Steering

NOTE: Unless noted otherwise,

use the standard hardware torque

specification chart.

987426

The above parts group applies to the following Mfg. Nos.:

2008

1695154 - 1723H

1695155 - 2723H

2690745 - Conquest

2690749 - 1723H

2690751 - 2723H

TP 400-4803-C-CQ-SMA

Not for

Reproduction

Autres manuels pour CONQUEST Conquest / 2700

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels Simplicity Tondeuse à gazon

Simplicity

Simplicity REVITALIZER 629 Manuel utilisateur

Simplicity

Simplicity LANDLORD 1700 Manuel utilisateur

Simplicity

Simplicity Landlord 569-3210 Manuel utilisateur

Simplicity

Simplicity 5900707 Manuel utilisateur

Simplicity

Simplicity 1695296 Manuel utilisateur

Simplicity

Simplicity Wonder-Boy 600 Manuel utilisateur

Simplicity

Simplicity 1550ES Manuel utilisateur

Simplicity

Simplicity Regent 1693264 Manuel utilisateur

Simplicity

Simplicity Stallion Series Manuel utilisateur

Simplicity

Simplicity 1021 Manuel utilisateur

Simplicity

Simplicity 1319 Manuel utilisateur

Simplicity

Simplicity Colt ZT2148T Manuel utilisateur

Simplicity

Simplicity ZT3000 Manuel utilisateur

Simplicity

Simplicity Colt ZT2148 Manuel utilisateur

Simplicity

Simplicity Massey Ferguson 2690487 Manuel utilisateur

Simplicity

Simplicity 17GTH-L48 Manuel utilisateur

Simplicity

Simplicity Champion Manuel utilisateur

Simplicity

Simplicity Champion 2690449 Manuel utilisateur

Simplicity

Simplicity 500 Series Manuel utilisateur

Simplicity

Simplicity Citation 2690445 Citation Manuel utilisateur

Simplicity

Simplicity ZT4000 Manuel utilisateur

Simplicity

Simplicity SunRunner 1691198 Manuel utilisateur

Simplicity

Simplicity FB Manuel utilisateur

Simplicity

Simplicity ZT2000 Series Manuel utilisateur

Manuels Tondeuse à gazon populaires d'autres marques

RHINO

RHINO 1958 Manuel utilisateur

Wolf Garten

Wolf Garten Compact plus 40 B Manuel utilisateur

Cub Cadet

Cub Cadet LTX 1045 Manuel utilisateur

Craftsman

Craftsman 917.378461 Manuel utilisateur

GGP ITALY SPA

GGP ITALY SPA CR/CS 434 SERIES Manuel utilisateur

Challenge

Challenge CH18V2 Instructions de fonctionnement

TALEN TOOLS

TALEN TOOLS AVR HGM30 Manuel utilisateur

DEWEZE

DEWEZE ATM-725 Manuel d'utilisation

Weed Eater

Weed Eater 180083 Manuel utilisateur

Husqvarna

Husqvarna Poulan Pro PP185A42 Manuel utilisateur

Better Outdoor Products

Better Outdoor Products Quick Series Manuel utilisateur

Cub Cadet

Cub Cadet 23HP Z-Force 60 Manuel d'utilisation

MTD

MTD 795, 792, 791, 790 Manuel utilisateur

Toro

Toro Groundsmaster 3505-D Manuel utilisateur

Dennis

Dennis FT 610 Manuel utilisateur

AIRFORCE

AIRFORCE F-15 Gen 3 Manuel utilisateur

MTD

MTD 126-220-000 Manuel utilisateur

Toro

Toro 74806 Manuel utilisateur
