Parts Manual

Rev. 04/2003

Regent

Series Lawn Tractors & Mower Decks

TP 400-3829-00-RG-S

. No. Descri

tion

HP Tractors

1694310 Regent, 15HP Hydro (CE)

1694314 Regent, 15HP Hydro

. No. Descri

tion

Mower Decks

1693920 38" Mower Deck

1693930 38" Mower Deck (CE)

Table Of Content

Torque Specification Chart ..................................................................... Inside Back Cover

TRACTOR / MOWER DECK COMPONENTS PAGES

Frame Group ......................................................................................................................... 4

Steering Group ...................................................................................................................... 6

Engine Group - 15HP Briggs & Stratton ................................................................................ 8

Engine Group - 15HP Briggs & Stratton ................................................................................ 10

Transmission Group .............................................................................................................. 14

Transmission SERVICE PARTS - Tuff Torq K51 Transaxle Group ....................................... 18

Controls Group ...................................................................................................................... 22

Electrical Group ..................................................................................................................... 24

Hood, Dash & Fuel Tank Group ............................................................................................ 28

Hood, Dash & Fuel Tank Group ............................................................................................ 30

Seat & Seat Deck Group ....................................................................................................... 32

Wheels & Tires Group ...........................................................................................................34

Decals Group - Brand & Model ............................................................................................. 36

Decals Group - Safety & Common ........................................................................................ 38

38" Mower Deck - Belt, Idler Arm & Hitch .............................................................................. 40

38" Mower Deck - Height Adjustment & Roller Bar ............................................................... 42

38" Mower Deck - Height Adjustment & Roller Bar Group .................................................... 46

38" Mower Deck - Housing, Arbors & Blades ........................................................................ 48

38" Mower Deck - Housing, Arbors & Blades ........................................................................ 52

Frame Group

NOTE: Unless noted otherwise,

use the standard hardware torque

specification chart.

Insert Must

Face Out

986202

The above parts group applies to the following Mfg. Nos.:

2003 4

1694310 - Re

ent

1694314 - Regent

TP 400-3829-00-RG-S

PART NO. DESCRIPTIONREF NO QTY.

Frame Group

Footnotes

1 1724393 1 FRAME ASSEMBLY

2 1715015 1 PLUG, Hole

3 1715016 1 PAD, Footrest RH

4 1714417 1 PAD, Footrest LH

5 1704351 12 FASTENER, Panel

6 1935255 4 NUT, Speed 5/16-18

7 1719869 1 "J" HOOK, Hitch

8 1930591 4 SCREW, Hex Head Flange Lock, 5/16-18 x 3/4

9 1723021 1 WRAPPER ASSEMBLY

10 1930591 2 CAPSCREW, Hex Head Flange Whiz Lock, 5/16-18 x 3/4

11 1719951 1 BRACKET

12 1920328 2 CAPSCREW, Hex Head, 1/2-13 x 1/2

13 1918431 3 WASHER

14 1709235 1 SPACER

15 1930644 2 NUT, Hex Head, 1/2-13

16 1717189 1 CARRIER ASSEMBLY

17 1717286 1 SPACER

18 1717424 1 BAR, Torsion

19 960641 1 NUT, Hex Head Aluninum Insert, 3/8-16

20 1924356 1 WASHER

21 176440 6 BUSHING

22 1719868 1 SPACER

23 1960614 1 CAPSCREW, Hex Head, 3/8-16 x 3, G8

The above parts group applies to the following Mfg. Nos.:

2003 5

1694310 - Re

ent

1694314 - Regent

TP 400-3829-00-RG-S

Steering Group

NOTE: Unless noted otherwise,

use the standard hardware torque

specification chart.

Note: See

Wheels & Tires

Group

Torque to

36-44 ft/lbs

(47-60) Nm

Torque to

28-36 ft/lbs

(35-48) Nm

Torque to

36-44 ft/lbs

(47-60) Nm

Torque to

17 ft/lbs

(23) Nm

985576A

The above parts group applies to the following Mfg. Nos.:

2003 6

1694310 - Re

ent

1694314 - Regent

TP 400-3829-00-RG-S

PART NO. DESCRIPTIONREF NO QTY.

Steering Group

Footnotes

1 1722738 1 STEERING WHEEL

2 1722319 1 CAP, Steering Wheel

3 1714400 1 TUBE, Cover

4 1960540 1 PIN, Spring

5 1723051 1 SHAFT & PINION ASSEMBLY

6 1931350 2 CARRIAGE BOLT, 3/8-16 x 1

7 1703508 1 PLATE, Mounting

8 1928352 2 NUT, Hex Whiz Lock, 3/8-16

9 176440 1 BUSHING, 3/4, Nylon

10 1960114 5 WASHER, 3/4

11 1919438 1 NUT, Hex Lock, 5/16-18

12 1933468 2 WASHER, 5/16

13 1666001 2 BUSHING, 3/4, Powered Metal

14 1611710 4 RING, Klipring Extension

15 1920415 1 CAPSCREW, Hex Head, 3/8-16 x 1-1/4

16 1922611 1 WASHER, 3/8

17 1723072 1 SHAFT & GEAR ASSEMBLY

18 1713469 1 LINK, 19.66" Long

19 1930645 3 NUT, Hex Flange Lock, 3/8-16

20 1931335 1 CARRIAGE BOLT, 5/16-18 x 1

21 1721472 1 ARM & SPACER ASSEMBLY, LH Splined

22 1960160 2 WASHER, 3/4

23 1919314 1 PIN, Cotter

24 1721542 2 SPINDLE & CUP ASSEMBLY

25 1713791 2 SPACER

26 1722484 1 ROD, Tie

27 1721473 1 ARM & SPACER ASSEMBLY, RH Splined

28 1664847 2 CAPSCREW, Hex Head Taptite, 5/16-18 x 3/4

29 1960268 2 CARRIAGE BOLT, 3/8-16 x 1-1/4

30 1921221 1 CAPSCREW, Hex Head, 5/16-18 x 1-1/2

31 1673796 1 SPACER

32 1710437 1 SPACER

33 1935048 1 NUT, Hex Flange Lock, 5/16-18

The above parts group applies to the following Mfg. Nos.:

2003 7

1694310 - Re

ent

1694314 - Regent

TP 400-3829-00-RG-S

Engine Group - 15HP Briggs & Stratton

NOTE: Unless noted otherwise,

use the standard hardware torque

specification chart.

Note:

Orientation

of Key

Torque to

19-23 ft/lbs

(26-31) Nm

Torque to

19-23 ft/lbs

(26-31) Nm

Torque to

19-23 ft/lbs

(26-31) Nm

Torque to

45-50 ft/lbs

(61-68) Nm

26 25

986029

The above parts group applies to the following Mfg. Nos.:

2003 8

1694314 - Re

ent

TP 400-3829-00-RG-S

PART NO. DESCRIPTIONREF NO QTY.

Engine Group - 15HP Briggs & Stratton

Footnotes

1 1708405 1 VALVE-SHUT OFF

2 920427 1 LOCKWASHER, External Tooth 3/8

3 916950 1 NUT, Hex 3/8-16

4 1723212 1 SEAL, Foam

5 1723213 1 SEAL, Foam

6 173206 1 FILTER, Fuel

7 960112 2 CLAMP, Hose Type E

8 1718678 1 HOSE, 12" Long

9 1715897 1 KNOB, Slot

10 1960498 2 CAPSCREW, Hex Washer Head 1/4-14 x 5/8

11 1707388 1 CABLE, Throttle Control, 14" Long

12 * 1 ENGINE-15/16/17HP B&S INTEK SINGLE

13 1930598 3 CAPSCREW, Hex Washer Head, Taptite, 3/8-16 x 1-1/2

14 171241 1 KEY

15 1723497 1 PULLEY

16 1933263 3 WASHER

17 960361 1 CAPSCREW, Hex Washer Head, Taptite, 3/8-16 x 2

18 1918199 1 LOCKWASHER, 7/16

19 1920594 1 CAPSCREW, 7/16-20 x 2

20 1719456 1 PULLEY, 5.40 O.D.

21 1719460 1 GUIDE-BELT

22 1935255 4 NUT, Speed 5/16-18

23 1723735 1 DUCT, Muffler

24 1930595 2 CAPSCREW, Hex Flange Lock, 5/16-18 x 1-1/4

25 1705248 2 PIVOT

26 1705249 2 SPACER

27 1930591 2 CAPSCREW, Hex Flange Lock, 5/16-18 x 3/4

28 1723086 1 DUCT, Muffler, Upper

29 1917356 2 LOCKWASHER, 5/16

30 1924856 4 CAPSCREW, Hex Washer Head, Taptite, 5/16-18 x 1/2

31 1927428 2 CAPSCREW, Hex Washer Head, Taptite, 1/4-20 x 3/8

32 1723408 1 MUFFLER

33 1936228 2 CAPSCREW, 5/16-18 x 3/4, G8

34 1720567 1 PIPE, Exhaust

35 1650670 1 GASKET

36 1723320 1 WIRE ASSEMBLY, Briggs & Stratton

See your local Briggs & Stratton distributor for parts.

The above parts group applies to the following Mfg. Nos.:

2003 9

1694314 - Re

ent

TP 400-3829-00-RG-S

Engine Group - 15HP Briggs & Stratton

NOTE: Unless noted otherwise,

use the standard hardware torque

specification chart.

Note:

Orientation

of Key

Torque to

19-23 ft/lbs

(26-31) Nm

Torque to

19-23 ft/lbs

(26-31) Nm

Torque to

19-23 ft/lbs

(26-31) Nm

Torque to

45-50 ft/lbs

(61-68) Nm

26 25

986077

The above parts group applies to the following Mfg. Nos.:

2003 10

1694310 - Re

ent

TP 400-3829-00-RG-S
