HomePlug AV Ethernet Adapter User’s Manual
1
1. Introduction
The HP200PT 4 HomePlug AV Powerline Ethernet Adapter (called HP200PT64, hereafter)
provides the fast data and video transmission through your existing Powerline environment.
It’s simple to plug into your power socket to every room in your home and easy to extend your
network without any extra wires and configuration. The integrated female power socket with
AC filter design is convenience of not losing your single power outlet. HP200PT 4 provides
high speed transmit data rates of up to 200Mbps and the QoS support let you enjoy the HD
videos, IPTV /VoIP services, online game and other multimedia contents transmission
smoothly. The built-in AES-128 bit data encryption algorithms can achieve a secure and
safety Powerline network. HP200PT 4 enable you to a high speed home networking
experience!.
1.1 General Features
High speed transfer PHY rate up to 200 Mbps for HD/IPTV and VOD services and whole
triple-play connectivity.
Easy to build or extend home networking environment use the existing power outlet, no
extra wire required.
Simple plug-and-play and zero configuration between the routers, computers, and your
gaming console.
Integrated Quality of Service (QoS) and low power consumption.
128-bit AES data encryption algorithm.
Co-existence with HomePlug 1.0 nodes.
Integrated AC Power Socket with AC filter design.
1.2 Package Contents
2 x HP200PT 4 HomePlug AV Powerline Ethernet Adapters. (dual pack)
2 x Ethernet RJ-45 Cat5.Cables.
1 x Printed Quick Start Guide.
1 x CD-ROM. (Contains Power Packet utility software / User’s Manual / Quick start guide )
1.3 System Requirement
In order to use the HomePlug AV Ethernet Adapters to establish the network connection in
your home, you must have the following:
ADSL or Cable service with at least one public Internet address for your LAN
if you want to use Powerline devices to get on to the internet.
One or more computers each containing an Ethernet network interface card (NIC)
Operating system:
Windows 98/SE,Me,2000,XP,Vista for install/configure/remove Power Packet utility.
