Simfer FS7300A+ Manuel utilisateur
UPRIGHT FREEZER
USER MANUAL
Models
FS7300A+
FS6210A+
FS5210A+
2
Dear Customer,
Thank you for choosing Simfer products. We aim to allow you to op-
timally and eciently use this environment-friendly product produced
in our modern facilities under precise conditions with respect to sense
of quality in total.
We advise you to read these operating manual thoroughly before
using the deep freeze and keep it permanently so that the features of
the Simfer deep freeze you have purchased will stay the same as the
rst day for a long time and serve in an optimum ecient way.
NOTE:
This User Manual is prepared for multiple models. Your appliance may
not feature some functions specied in the manual. These functions
are marked by the sign *. Your product must be installed and intro-
duced by Simfer authorized service.
Our appliances are intended for domestic use. They are not intended for
commercial use.
"PLEASE READ THE MANUAL BEFORE INSTALLING
OR USING THIS PRODUCT."
This product has been produced in modern environment-friendly fa-
cilities without adversely aecting nature.
"Complies with AEEE Regulation"
3
CONTENTS
1. SECTION
Safety Warnings....................................................................
2. SECTION
Overview and Technical Specications...................................
Technical Table......................................................................
3. SECTION
Installing Your Deep Freeze and First Operation.....................
Operating the Device and Temperature Setting .....................
4. SECTION
Using Your Deep Freeze........................................................
Packing Food........................................................................
Placing the Food...................................................................
5. SECTION
Cleaning, Maintaining and Transporting Your Deep Freeze ....
What To Do Before Leaving For Holiday ...............................
6. SECTION
What To Do Before Calling For Authorized Service.................
7. SECTION
Compliance With AEEE Regulations And Waste Disposal
and Packaging Information ...................................................
4
8
9
11
13
14
14
15
17
19
20
22
4
SAFETY WARNINGS
1. Your deep freeze is set for 220-240 V 50 Hz mains
power. Use of incompatible voltage may cause your
deep freeze to become inoperable or re.
2. Do not place your deep freeze under direct sun-
light or within inuence area of a stove, radiator, fur-
nace, oven, heater or infrared. Otherwise, your deep
freeze may perform poorly, get damaged or become
inoperable.
3. Choose a place without moisture but with air cir-
culation allowed.
4. Clean inside of your product prior to rst use.
5. Do not allow children to get into the product or
play around it.
6. Do not place your hand under your deep freeze,
a sharp corner or an edge may cause injury.
7. For your safety, in order to eliminate the risk
of electric shock and re there must certainly be a
breaker system with a residual current device in your
electrical wiring. Our rm is not responsible for fail-
ures and losses which might occur as a result of us-
ing the product in an ungrounded mains.
8. Do not place explosive or ammable material in
your deep freeze.
9. Do not use any object except ice scraping appa-
ratus provided with your product to scrape ice o.
Otherwise, use of sharp, pointed and metallic objects
may damage the inner surface of your deep freeze.
5
This kind of improper use may also cause gas leak-
age.
10. After putting your deep freeze into place, allow
at least 2 hours without moving it before starting to
use.
11. Your deep freeze is designed for indoor use. Do
not use your product outdoor.
12. Installation, placement, maintenance and clean-
ing of your deep freeze shall be performed as pre-
scribed in the manual. In case of damage to your
deep freeze due to misuse, the warranty of the prod-
uct shall be invalid.
13. After closing the your deep freeze door, you may
need to wait up to a minute to re-open it. Due to the
vacuum eect by the cooling, opening the door may
prove dicult.
14. In order to avoid your appliance from sliding or
overturning, place the appliance on a non-tilted at
surface.
15. In caseof a failure within your product, taking
measures for food preserved within the deep freeze
is fully under responsibility of the user. Our company
is not responsible for spoilt food due to any failure or
misuse.
16. Never use extension cord or multi-plug with your
deep freeze.
17. Never use pressured water to clean. Pressured
water may damage live-current parts.
6
18. Place the packaging material of the appliance
where children cannot reach. Some packaging mate-
rial (such as nylon, styrofoam, etc.) may be danger-
ous for children.
19. The appliance should not be used by physically,
visually, audibly or mentally handicapped ones, chil-
dren, non-experienced or non-informed ones without
surveillance of a person responsible for the safety of
such people.
20. Open the freezer cover only when necessary.
Please make sure that the lid is sealed properly when
it is not necessary.
21. In the event of a sudden power outage unplug
your product. Plug back in 20 minutes after you make
sure that the mains become normal.
22. Do not put domestic and wild animals inside
your product and do not allow them to enter into
your product. These kind of living creatures might
damage the electrical system and cause re.
23. Loading food in pieces, making additions as
food starts to freeze instead of lling your freezer to
its full capacity is an healthier freezing method. Since
sucient air ow can not be provided in loadings to
the full capacity in one time, cooling process of your
freezer might not be sucient.
24. Do not allow food newly put into your freezer to
contact with frozen food.
7
Attention!
• This appliance includes R600a or in-
ammable and explosive gas. The ventilation
holes on the casing and the body of the appli-
ance should not be blocked.
• Do not use mechanical tools or other assem-
blies except the models recommended by the
manufacturer to make defrosting quicker.
• The cooling circuit should not be damaged.
• Except materials recommended by the man-
ufacturer, no electric appliances should be used
within food preserving partition of the appli-
ance.
• In order to decrease the risk of aming, this
appliance should be installed and maintained
only by Simfer services.
8
2. SECTION
OVERVIEW AND TECHNICAL SPECIFICATIONS
1. Control Panel
2. Upwards Opening Covers*
3. Glass Rack
4. Large Drawer
5. Standard Drawer
6. Small Drawers
7. Adjustable Leg
2
3
6
1
4
x
a
M
5
2
5
7
9
TECHNICAL TABLE
Brand Simfer Simfer Simfer
Model FS7300A+ FS6210A+ FS5210A+
Product Category Household
vertical deep
freeze
Household
vertical deep
freeze
Household
vertical deep
freeze
Coolant R600a R600a R600a
Energy Class A+ A+ A+
Annual energy consumption
(kWh/year) 295 249 249
Total Gross Volume (lt) 288 210 210
Total Net Volume (lt) 285 200 200
Star Class
Cooling System Static Static Static
Temperature Increase
Duration (hours) 23 20 20
Freezing Capacity
(kg/24 hours) 10 10 10
Ice Making Capacity
(kg/24 hours) 1.3 1.1 1.1
*Climate Class SN-T SN-T SN-T
Noise Level
(dB(A)) 41 41 41
Height (mm) 1765 1470 1470
Width (mm) 595 540 540
Depth (mm) 600 600 600
Net Weight ()kg 66 55 53
Electric Input (V/Hz) 220-240V/
50Hz
220-240V/
50Hz
220-240V/
50Hz
Total Power (W) 200 150 150
10
FREEZER RACK AND DRAWERS
Upwards Opening Covers*
The upper covers provides convenience when
placing or removing food. To place or remove
food, hold the cover handle and lift upwards.
(The amount of upper covers or their position
may dier based on the model.)
Removing the drawers
Pull out the drawer completely, lift the front side
upward and remove.
Ice Container
To produce ice cubes, use only drinking water.
• Remove the ice container (1) ll it with drink-
ing water up to the mark.
• Place the container in the ice tray (2).
• To remove the ice cubes from the ice con-
tainer, place the container under running warm
water and twist it.
1
2
