SilverOnyx S7 Manuel utilisateur

S7 CORDLESS STICK VACUUM

Instruction Manual

- Version 1.0 -

Please keep in a safe place for reference.

Important Safety Instructions

IMPORTANT: READ ALL INSTRUCTIONS BEFORE USE.

RETAIN INSTRUCTIONS FOR FUTURE REFERENCE.

Do not use in rain or leave outdoors while raining.

WARNING: Basic safety precautions should always be observed when using an

electrical appliance, including the following to reduce the risk of re, electrical

shock, or injury.

Personal Safety:

1. Store indoors in a dry place out of the reach of children.

2. Always use responsibly. This appliance can be used by children age 10 years and older.

Persons with reduced physical, sensory or mental capabilities, or lack of experience and

knowledge may use this appliance if they have been given supervision or instruction

concerning the safe use of the appliance and understand the hazards involved.

3. Don’t let children play with the appliance; supervise children using or maintaining the

appliance.

4. Use only manufacturer’s recommended attachments as described in this manual; misuse

or use of any accessory or attachment other than those recommended, may present a risk

of personal injury.

5. Take extra care when cleaning stairs.

6. Keep the appliance and accessories away from hot surface.

7. Do not block the appliances openings or hinder air ow, keep openings free of any

objects including clothing and ngers (and all parts of the body).

Electrical Safety:

1. Only use batteries and chargers supplied by the manufacturer.

2. Never modify the charger in any way.

3. The charger has been designed for a specic voltage. Always check that the mains

voltage is the same as that stated on the rating plate.

4. A charger that is suitable for one type of battery pack may create a risk of re when used

with another battery pack.

5. Before use, check the charger cord for signs of damage or ageing. A damaged or

entangled charger cord increases the risk of re and electric shock.

6. Do not abuse the charger cord.

7. Never carry the charger by the cord.

8. Do not pull the cord to disconnect from a socket, grasp the plug and pull to disconnect.

9. Don’t wrap the cord around the charger when storing.

10. Keep the charger cord away from hot surfaces and sharp edges.

11. The supply cord cannot be replaced. If the cord is damaged the charger should be

discarded and replaced.

12. Do not handle the charger or the appliance with wet hands.

13. Do not store or charge the appliance outdoors.

14. The charger must be removed from the socket before removing the battery, cleaning or

maintaining the appliance.

Important Safety Instructions

Battery safety:

1. This appliance includes Li-ion batteries, do not incinerate batteries or expose to high

temperatures, as they may explode.

2. Liquid ejected from the battery may cause irritation or burns.

3. In an emergency situation contact professional help immediately.

4. Leaks from the battery cells can occur under extreme conditions. Do not touch any liquid

that leaks from the battery. If the liquid gets on skin wash immediately with soap and

water. If the liquid gets into the eyes, ush them immediately with clean water for a

minimum of 10 minutes and seek medical attention. Wear gloves to handle the battery

and dispose of immediately in accordance with local regulations.

5. Shorting the battery terminals may cause burns or re.

6. When the battery pack is not in use, keep it away from paper clips, coins, keys, nails,

screws or other small metal objects that could make a connection from one terminal to

another.

7. When you dispose of the appliance remove the battery and dispose of the battery safely

in accordance with local regulations.

Service:

1. Before using the appliance and after any impact, check for signs of wear or damage and

repair as necessary.

2. Do not use the appliance if any part is damaged or defective.

3. Repairs should be carried out by a service agent or a suitably qualied person in

accordance with relevant safety regulations. Repairs by unqualied persons could be

dangerous.

4. Never modify the appliance in any way as this may increase the risk of personal injury.

5. Only use replacement parts or accessories provided or recommended by manufacturer.

Intended use:

1. This appliance has been designed for domestic dry vacuum cleaning only.

2. Do not pick up liquids or use on wet surfaces.

3. Do not pick up anything that is ammable, burning, or smoking.

4. Use only as described in this manual.

5. Don’t use on concrete, asphalt, or other rough surfaces.

WARNING:

1. Do not use water, solvents, or polishes to clean the outside of the appliance; wipe clean

with a dry cloth.

2. Never immerse the unit in water and do not clean in a dish washer.

Important Safety Instructions

Components

HANDHELD/

MOTOR

HANDLE

POWER Switch

HANDHELD

RELEASE

CHARGING SEAT BACK

BRUSH Accessory

CREVICE TOOL

CHARGER

CHARGING SEAT BASE

LED Lamp

FLOOR BRUSH

WHEELS

ROTATING

BRUSH

CHARGING

Port

DUST Collector

POWER Button

CHARGING

Indicator

HANDLE

SUCTION Inlet

AIR Outlet

DUST Collector

Release Button

ACCESSORIES

1 2

Insert power adapter into

power input on bottom of

charging base, then feed

through groove in base.

First Use

Place nose of handheld unit

in groove on base, and push

handle until it snaps in place.

Slide charging back into charging

base and snap into place.

1 2

1) Remove screw from back of

handle;

2) Slide handle over base;

3) Insert and

tighten screw to

secure handle

to base.

Plug power

supply adapter

into wall outlet.

When charging

begins the

indicator will turn

red. Charging will

be complete in

about 5 hours, at

which time the

indicator will turn

off.

ASSEMBLE CHARGER

ASSEMBLE HANDLE

Place vacuum

on charging

base, aligning

the charging

port with the

adapter on

the base.

CHARGING

Charging

Port

Operating the Vacuum

1 2

3 4

When in operation, the

charging indicator will be

solid green.

Slide the POWER swich

down once to turn on the

appliance in low speed.

Slide again for high speed,

and slide up to turn off.

The vacuum is

equipped with

an LED lamp to

see dark corners,

under furniture,

etc.

Press the

RELEASE

lock button

to remove

the handheld

unit from the

vacuum.

5Insert CREVICE tool into

suction end of handheld

unit for cleaning in tight

areas.

Low

High

6Insert BRUSH tool into

suction end of handheld

unit for cleaning

of fabrics, glass,

electronics, etc.

Care & Maintenance

1 2

Press the dust collector

release button to remove

from the body of the

handheld unit.

Empty dust collector into

trash bin.

Gently knock debris and

dust from the lter ele-

ment and lter screen.

6Reassemble lter and dust

collector, then attach to

body (see diagram below) -

you will hear a click sound

when connected properly.

Lift off dust collector and

remove the lter.

Remove lter element

from lter screen.

DUST COLLECTOR

EMPTY DUST CUP

Care & Maintenance

1 2

3 4

Remove the driving belt from

the brush.

Use a coin

to unlock

the brush

compartment

on the

underside

of the brush

head as

shown here.

Pull brush to remove from

brush head.

Carefully cut away any

hair, yarn, or other debris

entangled in the brush.

CLEAN BRUSH HEAD

5Clean the brush by running

under water. NOTE: be

sure to let the brush dry

thoroughly before replacing.

6Remove any trapped debris

from the underside of the

brush head, and wipe down

with a damp cloth.

Driving

Belt

Care & Maintenance

1 1

2 3

After removing the

dust collector from

the body, remove

the lter screen and

lter element. The

dust collector may

then be washed

with a mild soap

and soft cloth/

sponge.

Filter screen and lter

element may be washed with

a mild soap and soft brush/

cloth. Rinse lter

element under

running water

to remove any

polluntants.

NOTE: be sure to

let all parts dry

thoroughly before

reassembly.

1 2

Use a screwdriver to access the

battery on the underside of the

handheld unit.

Pull battery to remove, then

while pressing down on the

tab, pull the battery connec-

tor apart to disconnect. Insert

new battery in reverse order.

CLEAN DUST CUP CLEAN FILTER

Before washing the lter screen and

lter element, carefully knock out

any dust or debris.

REPLACE BATTERY

Troubleshooting

Problem Battery

Indicator

Possible Cause Solution

Appliance

cannot be

recharged.

Charging

indicator does

not light.

1. The charging plug may

be loose in the socket.

2. Power adapter is not

securely attached to the

appliance.

Attach the power adapter

securely to the appliance.

Battery

indicator stays

on longer than

6 hours.

The internal PCB board

may be defective or

damaged.

This problem can only be

xed by a professionally

trained person. Please

send or take appliance to

an after-service depot.

Floor brush

does not work,

and handheld

unit does not

work either.

Battery

indicator does

not light up.

1. Power is off.

2. Brush is totally blocked

by hair or other debris.

3. There may be a short on

the circuit inside the brush.

1. Recharge the appliance.

2. Remove blockage from

brush.

3. This problem can only

be xed by a professionally

trained person. Please

send or take appliance to

an after-service depot.

Brush does

not work, but

handheld

unit works

normally.

Battery

indicator is

normal.

The rubber belt inside the

brush head may be loose.

Check the drive belt (see

cleaning instructions

on Page 7). If belt is

connected properly, please

send or take appliance to

an after-service depot.

Appliance

does not pick

up debris /

suction power

is weak.

Batter indicator

is normal.

1. Dust cup is full.

2. Dust cup lter needs to

be cleaned or replaced.

3. Brush is blocked by hair

or other debris.

1. Clean the dust cup.

2. Clean the lter

according to the

instructions.

3. Remove blockage from

brush.
