Silvercrest KH 2031 Manuel utilisateur
KH 2031
KOMPERNASS GMBH
BURGSTRASSE 21 · D-44867 BOCHUM
www.kompernass.com
ID-Nr.: KH2031-08/09-V2
PLL WORLD RECEIVER
4C
PLL World Receiver
Operating instructions
Svetovni PLL-sprejemnik
Navodila za uporabo
PLL-Svjetski prijemnik
Upute za upotrebu
CV_KH2031_DT35253_LB4C.qxd 09.09.2009 9:41 Uhr Seite 1
KH 2031
Aq w e
r
t
y
u
i
oasdfg
2);lk
j
h
B
CV_KH2031_DT35253_LB4C.qxd 09.09.2009 9:41 Uhr Seite 4
- 1 -
CONTENTS PAGE
Intended use 2
Technical Data 2
Symbols used 4
Safety information 5
Operating elements 9
Starting up 10
General functions 12
Time functions 13
Time, date, time zone and world time ............................................13
Select display mode .........................................................................17
Alarm function ...................................................................................18
Stop watch function ..........................................................................20
Countdown function..........................................................................20
Radio operation 22
Setting the station..............................................................................23
Fine tuning..........................................................................................24
Aerial..................................................................................................24
Memory functions .............................................................................25
Cleaning 27
Disposal 28
Importer 28
Warranty & Service 29
IB_KH2031_DT35253_LB4C 09.09.2009 12:56 Uhr Seite 1
PLL WORLD RECEIVER KH2031
Before using the device for the first time, read these operating instructions
carefully and keep them for later reference. Hand the instructions over
when transferring the device to a third party.
Intended use
This device is designed to receive generally approved radio transmissions
in all countries (world receiver) and only for domestic use.
It has not been designed to receive transmissions that are not generally
approved, nor as part of safety radio systems, e.g. on board sports boats,
nor for industrial or commercial use. It has also not been designed for use
in temperatures beyond those stated in the Technical Data.
Technical Data
This appliance is in full compliance with the fundamental requirements and
relevant stipulations of the EMC Directive 2004/108/EC, as well as the
guidelines of the Low Voltage Directive 2006/95/EC.
Power consumption: 5 watts
Power consumption Standby: 1.4 W
Operating temperature: +5 ~+35°C
Humidity: 5 ~90% (no condensation)
- 2 -
IB_KH2031_DT35253_LB4C 09.09.2009 12:56 Uhr Seite 2
Dimensions (W x H x D): 177 x 110 x 40 mm
Appliance weight: 380 g approx.
Power transformer weight: 185 g approx.
Batteries
4x 1.5 V, Type AA/LR6/Mignon (not supplied)
Frequency range radio:
VHF (FM): 87 – 109 MHz
SW: 5.85 – 17.90 MHz
MW (AM) Europe 522 – 1656 kHz
MW (AM) USA 520 – 1710 kHz
LW 144 – 299 kHz
The technical features of the device enable the frequency ranges stated
above to be set. Various countries may have different national rules on the
radio frequency ranges assigned. Please note that you may not sell, transfer
to third parties or abuse information received outside the assigned radio
frequency ranges.
Tuning ranges (NORMAL/FINE):
FM (VHF) 100 kHz /50 kHz
SW 5 kHz /1 kHz
MW (AM) Europe 9 kHz /1 kHz
MW (AM) USA 10 kHz /1 kHz
LW 1 kHz
Sensitivity: SW can be set to 2 intervals
- 3 -
IB_KH2031_DT35253_LB4C 09.09.2009 12:56 Uhr Seite 3
General
Memory positions : 1600 (400 for each frequency range)
Headphones
Model: E105
Impedance: 32 Ω
Wideband characteristic
Voltage (WBCV): approx. 150 mV
Headphone socket
max. Output voltage: approx. 200 mV
Power transformer
Manufacturer: S&S MFG. LTD.
Model: A400-75
Primary: 230 V ~50 Hz / 30 mA
Secondary: 7.5 V DC 400 mA / 3VA
Symbols used
These symbols bring to your attention that here a warning notice
follows in regard to one of the following matters:
- Risk of injury,
- Risk of electric shocks,
- Risk of fire,
- Risk of explosion,
plus bringing your attention to important matters such as:
- Information regarding the handling of batteries,
- Information about voltage surges,
- Information about mains-power disconnection.
- 4 -
IB_KH2031_DT35253_LB4C 09.09.2009 12:56 Uhr Seite 4
This symbol warns about submersing the appliance in water or
other liquids.
This symbol warns you about hearing damage.
Note:
With this symbol you are given tips about interaction with the appliance.
Safety information
• This device has not been designed for use by people (including children)
with restricted physical, sensory or intellectual abilities or lack of expe-
rience and/or knowledge, unless they are supervised by a responsible
person (for their own safety) or have received instructions on how to
use the device.
• Children should be supervised to ensure that they do not play with
the device.
• In order to avoid the device being switched on unintentionally, remove
the adapter from the mains socket after each use and before cleaning.
• Check the device and all parts for visible damage. The device’s safety
concept can only work if the device is in perfect condition.
• A mains adapter connected to the device must always be easily
accessible so that the device can be quickly disconnected from the
mains power in an emergency.
- 5 -
IB_KH2031_DT35253_LB4C 09.09.2009 12:56 Uhr Seite 5
Risk of electric shock!
• Connect the mains-power adapter only to correctly installed and eart-
hed mains sockets. Ensure that the rating of the local power supply tal-
lies completely with the details given on the rating plate of the appliance.
• Damaged adapters or mains cables should be exchanged immediately
by an authorised technician or the Customer Service in order to
avoid risks.
• Connection cables or devices that do not work perfectly or have been
damaged should be repaired or exchanged immediately by Customer
Services.
Never immerse the device in water! Simply wipe it with a slightly
damp cloth.
• Do not expose the wall wart to rain or use it in a damp or wet
environment.
• Ensure that the connection cable is never wet or damp when in use.
• You must not open or repair the device’s housing. This can be dangerous
and renders the warranty null and void.
• Protect the device from moisture and sprayed water. Therefore do not
place any objects filled with water (e.g. vases) on or near the device.
Risk of fire!
• Do not use the device near hot surfaces.
• Do not set the device up where it is exposed to direct sunlight.
This could cause it to overheat and damage it beyond repair.
• Never leave the device unattended during operation.
• Never cover the device’s ventilation slots when it is switched on.
• Do not place open flames, such as candles, on or near the device.
- 6 -
IB_KH2031_DT35253_LB4C 09.09.2009 12:56 Uhr Seite 6
Risk of injury
• Keep children away from the connection cable and device.
Children frequently underestimate the danger of electrical devices.
• If the device has fallen down or is damaged it must no longer be used.
Have the device checked by a qualified specialist and, if necessary,
repaired.
• Batteries must not be handled by children.
Children can put batteries in their mouths and swallow them.
If a battery has been swallowed, obtain medical assistance immediately.
Thunder storms!
Devices connected to mains power can be damaged during a thunder
storm. If there is a thunder storm, always remove the mains plug from
the socket.
Information on voltage surges (EFT/electrical fast
transient) and electrostatic discharges:
If the product does not work properly due to electrical fast transient
processes (voltage surges) or electrostatic discharge, it must be
reset to restore normal operation. If necessary, remove the plug from
the power socket and insert it again. The batteries (if used) must be
removed and reinserted.
Information on separating the device from
mains power
The POWER button on this device does not completely separate it from
the mains network. In addition, the device uses power when in stand-
by mode. In order to completely separate the device from the mains
supply the plug must be removed from the mains socket.
- 7 -
IB_KH2031_DT35253_LB4C 09.09.2009 12:56 Uhr Seite 7
Notes on handling batteries
The device uses batteries. Please note the following on handling batteries:
Risk of explosion!
Do not throw batteries into a fire. Do not recharge batteries.
• Never open, solder or weld batteries. There is a risk of explosion and injury!
• Check batteries regularly. Leaking batteries can damage the device.
• If the appliance is not going to be used for long periods, remove the
batteries.
• If batteries leak, put on protective gloves.
• Clean the battery compartment and contacts with a dry cloth.
Caution!
No liability/warranty applies to damage to the device caused by
moisture due to water penetrating the device or overheating!
- 8 -
