KH 700

FOOD PROCESSOR

Food Processor

Operating instructions

CV_KH700_38172_LB6.qxd 27.10.2009 16:22 Uhr Seite 1

KH 700

III

CV_KH700_38172_LB6.qxd 27.10.2009 16:23 Uhr Seite 4

- 1 -

CONTENT PAGE

1. Appliance description / Items supplied 2

2. Intended Use 2

3. Technical data 2

4. Safety instructions 2

5. Before starting the appliance 3

6. Assembling the food processor 3

6.1 Fitting the mixing bowl..............................................................................................................3

6.2 Fitting the lid...............................................................................................................................3

6.3 Insert the ingredient by filling shaft and pusher .....................................................................4

7. Working with the mixing bowl 4

7.1 Working with the cutting blade................................................................................................4

7.2 Remove the cutting and grating blades from the accessory clip..........................................5

7.3 Insert the cutting and grating discs back into the accessory clip.........................................5

7.4 Working with the cutting and grating discs............................................................................5

7.5 Working with the kneading blade...........................................................................................6

8. Working with the blender 7

9. Cleaning & Care 8

10. Malfunctioning 9

11. Disposal 9

12. Warranty and service 9

13. Importer 10

14. Table for ingredients 10

Read these operating instructions carefully before using the appliance for the first time and preserve this

maual for later reference. Pass this manual on to whoever might acquire the appliance at a future date.

IB_KH700_38172_LB6 27.10.2009 10:30 Uhr Seite 1

- 2 -

FOOD PROCESSOR

KH 700

1. Appliance description /

Items supplied

1Splash protection cap

2Blender lid

3Accessory clip

4Blender jug max. 1.5 l

5Motor block cover

6Motor block

7Speed controller

8Drive shaft

9Mixing bowl max. 1.5 l

0Lid for mixing bowl

qFilling shaft

wPusher

eMeasuring cup

rRetainer

tKneading blade

zBlade

uProtective case for blades

I. Potato slurry disc

II. Fine cutter

III. Coarse cutter

IV. Coarse shredder

V. Fine shredder

VI. Potato-chips disc

iDisc holder

oSpatula

Operating Instructions

2. Intended Use

This appliance is intended for the processing of

foodstuff in household quantities and only for priva-

te use in closed rooms protected from rain. This ap-

pliance is not intended for commercial or industrial

use or for operation in the open.

3. Technical data

Power supply: 230 V / 50 Hz

Power consumption: 700 Watt

Protection class: II /

Capacity blender jug: 1.5 l

KB-time blender jug: 3 miutes

Capacity mixing bowl: 1.5 l

KB-time mixing bowl: 1 minute

CO Time

The CO Time (Continuous Operation Time) details

how long an appliance can be operated without

the motor overheat-ing and becoming damaged.

After the appliance has run for this period it must be

switched off until the motor has cooled itself down.

4. Safety instructions

• Please read all safety instructions carefully.

• Make sure that the power cord never becomes

wet or damp during operation. Lay the cord such

that it cannot be pinched or otherwise damaged.

Do not leave it dangling from the working surface.

• Arrange for defective power plugs and/or

cables to be replaced as soon as possible by a

qualified technician or by our Customer Service

Department to avoid the risk of injury.

• Pull the plug from the socket when you do not use

the appliance, before changing the attachments

and before cleaning the appliance. Switching off

the appliance is not sufficient because the applian-

ce receives power as long as the power plug is

connected to the socket. In this way you will also

prevent inadvertent switching on of the appliance.

• This appliance is not intended for use by persons

(including children) with reduced physical, senso-

rial or mental cabilities, or lack of experience and

knowledge, unless they have been given supervi-

sion or instruction concerning use of the applian-

ce by a person responsible for their safety.

• Children should be supervised to ensure that they

do not play with the appliance.

IB_KH700_38172_LB6 27.10.2009 10:30 Uhr Seite 2

- 3 -

• Use only the supplied original accessories since

these have been optimised for interaction with the

appliance.

• Do not operate the appliance without ingredients.

Overheating hazard!



Caution:

The blade zis very sharp! Exercise special care when

inserting and removing or cleaning the blade z!



Caution:

While the machine is in use, only put those ingre-

dients in the mixing bowl 9or blender jug 4,

which are to be processed. Do not put hands and fo-

reign objects in the filling shaft qor blender jug 4

to avoid the risk of injury or damage to the machine.

• Do not attempt to open the lid 0of the mixing

bowl 9while in operation.

5. Before starting the appliance

• Before starting the device ensure that...

- the device and all accessories and the power plug

and the power cord are in perfect condition and...

– all packaging materials have been removed

from the appliance.

• Prior to initial use clean all device components as

described in the “Cleaning” chapter.

• Assemble the food processor and note that…

- The food processer is in a firm and stable posi-

tion. Secure the food processor on the working

surface with the four suction cups.

- the mixing bowl 9works only when the cover

5for the motor block 6, the mixing bowl 9

and the lid 0for the mixing bowl 9have

been properly fitted and engaged.

- the blender works only when the blender jug

4and the blender lid 2have been correctly

fitted and engaged.

- when blender jug 4, mixer lid 2, mixing bowl

9and the lid 0of the mixing bowl 9have

been fitted, only the blender will work.

6. Assembling the food processor

6.1 Fitting the mixing bowl

• Place the cover 5on the motor

block 6so that the arrow on

the cover 5points towards the

open lock on the motor block

6. Turn the cover 5anti-

clockwise until it is firmly seated.

The arrow now points towards

the closed lock.

• Position the mixing bowl 9

so that the arrow on the mi-

xing bowl 9points towards

the open lock on the motor

block 6. Take hold of the mi-

xing bowl 9with the handle

and turn it clockwise as far as

it will go. The arrow now po-

ints towards the closed lock.

6.2 Fitting the lid



Note:

Always ensure that the lid 0is properly engaged

before switching on the appliance! Otherwise,

foodstuffs could be sprayed out during usage.

• Fit the lid 0on the mixing

bowl 9so that the recesses

of the lid 0match the slots of

the bowl 9. The marks on

the lid 0and the bowl 9

must match.

• Turn the lid 0clockwise until

you hear an impact. The lug

of the lid 0now rests on the

handle of the mixing bowl 9.

IB_KH700_38172_LB6 27.10.2009 10:30 Uhr Seite 3

- 4 -

6.3 Insert the ingredient by

filling shaft and pusher



Caution:

Never use your fingers, spatula, spoon handles or

similar objects for pushing foodstuff through the

filling shaft q! Risk of injury!

• You can add liquid and solid

foodstuffs to the mixing bowl

9through the filling shaft q.

You can close the filling shaft

qwith the pusher wwhile

the appliance is in use, in or-

der to avoid splashing or

flour (e.g. while kneading

flour) from coming out.

• Use the pusher wto force

food stuffs through the filling

shaft q.

• The pusher wis equipped

with a measuring cup e. If

you remove it you can reduce

size of the filling shaft q. This

can be useful when cutting or

grating foodstuffs.

7. Working with the mixing

bowl

The supplied accessories for the mixing bowl 9

consist of 6 grating and cutting discs (I-VI), a

kneading blade tand a chopping blade z. The

mixing bowl 9is very versatile to use: grating or

cutting, mixing or cutting, kneading or stirring.

7.1 Working with the cutting blade



Caution! Risk of injury!

• The cutting edges are very sharp! Exercise speci-

al care when inserting and removing or cleaning

the cutting blade z!

• The bowl 9must first be properly locked in posi-

tion before inserting the cutting blade z. Risk of

injury!

• Never use your fingers, spatula, spoon handles

or similar objects for pushing foodstuff through

the filling shaft q!

The cutting blade zcan be used to mix, chop or

knead dough. Use the cutting blade z, for instance,

for chopping meat, cheese, onions, herbs and nuts.

• Remove the cutting blade z

from the protective case u.

• Fit the mixing bowl 9to the

food processor.

• Fit the cutting blade zon the

retainer rand place the lat-

ter on the drive shaft 8.

• Place the lid 0on the mixing

bowl 9.

• Insert the ingredients into the

mixing bowl 9through the

loading shaft q.

• Place the stodger win the lo-

ading shaft q.

• Now switch on the appliance by setting the

speed controller 7to the level recommended in

the table.

If you are uncertain about the speed, use the fastest

level (3).

IB_KH700_38172_LB6 27.10.2009 10:30 Uhr Seite 4

- 5 -

Hints:

• Cut the ingredients into approx. 3 cm size pieces

before adding them to the bowl 9.

• The appliance chops the ingredients very fast,

therefore allow the appliance to run only briefly.

• Do not allow the appliance to run for more than

1 minute at a time.

• Should the ingredients get caught up in the bowl

9or between the blades z:

- Switch off the appliance.

- Remove the lid 0from the mixing bowl 9.

- Remove the ingredients with a spatula o.

7.2 Remove the cutting and grating

blades from the accessory clip

• Remove the blender lid 2

from the blender jug 4by

turning it clockwise.

• Grasp the accessory clip 3

on the handle at the centre of

the retainer 3with the thumb

and index finger.

• Pull the accessory clip 3with the cutting and

grating discs (I-VI) out of the blender jug 4.

• Remove the cutting and

grating discs (I-VI) from the

holder 3.

7.3 Insert the cutting and grating discs

back into the accessory clip

• Insert the cutting discs (II/III)

in the retainer slots. Begin

with the inner retainer

slots.The lateral flaps with the

elevation in the middle must

point upwards.

Make sure that all the cutting edges are pointing in-

wards.

• Place the shredder (IV/V),

grater (I) and potato-chips

disc (VI) in the storage slot on

the outside.

• Place the accssory clip 3

back in the blender jug 4.

Ensure that the rails on the ac-

cessory mounting 3grip

firmly into the shoulders of the

mixing container 4.

• Place the cover 2on the li-

quidiser 4so that the arrows

on the handle of the liquidiser

4and on the cover 2point

towards each other. Turn the

cover 2anti-clockwise until it

sits firmly.

7.4 Working with the cutting and gra-

ting discs



Caution:

• The cutting edges are very sharp! Exercise inser-

ting and removing or cleaning the discs!

• Never use your fingers, spatula, spoon handles

or similar objects for pushing foodstuff through

the filling shaft q!

IB_KH700_38172_LB6 27.10.2009 10:30 Uhr Seite 5

- 6 -

The cutting (II/III) and grating discs (IV/V) can be

used to slice or grate food stuffs quickly. The special

potato-chip disc (VI) enables you to make uniform

potato-chips at home. With the potato grater disc (I)

you can finely chop raw potatoes for the mixture,

and finely grate other vegetables or fruits as well.

• Place the mixing bowl 9on

the food processor. Select the

appropriate disc.

• Place the disc with the lea-

ding edge (the side without

the ring marking on the cor-

ners) in the disc holder i.

• Push the other side (marked

with two circles at the cor-

ners) down until the disc

engages with a “click”.

• Fit the retainer rto the drive

shaft 8. Insert thumb and in-

dex finger in the holes of the

disc holder iand place it on

the retainer r.

• Place the lid 0on the bowl

• You can now fill ingredients

through the filling shaft q.

• Set the speed controller 7to level 3 (maximum

speed) for cutting and grating. Should you wish

to process soft fruit or vegetables you can also

select a lower speed.

• Slowly and gradually push the ingredients in the

filling shaft qusing the pusher w.

• To remove the disc from the

disc holder i, remove the

disc from the disc holder i

by pushing on the marked

side in an upward direction.

Hints:

• Cut the food into pieces so that they fit through

the filling shaft q.

• Fill the filling shaft qevenly and do not exert ex-

cessive pressure.

• If you wish to process large quantities of food do

it in small batches and empty the mixing bowl 9

inbetween.

7.5 Working with the kneading blade

With the kneading blade tyou can knead bread

dough and mix batter or cake mixture.

• Place the mixing bowl 9on

the food processor.

• Place the kneading blade t

on the retainer rand fit on

the drive shaft 8.

• Add the ingredients to the

mixing bowl 9.

IB_KH700_38172_LB6 27.10.2009 10:30 Uhr Seite 6

- 7 -

• Place the lid 0on the bowl

9and the pusher win the

filling shaft q.

• Set the speed controller 7to the level recom-

mended in the table.

Hints:

• Put liquid ingredients into the bowl 9last and

start mixing at low speed to avoid splashing.

• Never fill the mixing bowl 9above the

MAX.mark (1.5l).

• For mixing “water like” liquids only use the speed

1 with maximum volume of 1 l to avoid liquid

spilling out.

8. Working with the blender



Caution:

• Never switch on the blender when empty.

• Never insert the plug in the socket before the

blender jug 4and the blender lid 2have been

correctly assembled.

• Always pull the plug from the socket before

removing the blender jug 4.

• Do not fill ingredients hotter than 80°C in the

blender jug 4.

• To avoid splashing, never add more than 1.5l of

liquid in the blender jug 4.

• Never remove the blender lid 2during opera-

tion.

• Never run the blender continuously for more than

3 minutes.

You can use the blender to finely puree and mix in-

gredients. You can use the blender for preparing

soups, sauces, milkshakes, baby food or process ve-

getables and fruit into a puree

• First remove the cover 5for

the motor block 6by turning

it clockwise.

• Now place the liquidiser 4in

the opening, so that the arrow

marking on the liquidiser 4po-

ints towards the open lock on

the motor block 6. Turn the li-

quidiser 4anti-clockwise until it

is firmly seated. Ensure that the

arrow marking is pointing to-

wards the closed lock.

• Fill the ingredients in the blender jug 4. Cut them

into smaller pieces beforehand if required.

• Place the cover 2on the li-

quidiser 4so that the arrows

on the handle of the liquidiser

4and on the cover 2point

towards each other. Turn the

cover 2anti-clockwise until it

sits firmly.

• If required, insert the splash

protection cap 1and turn it

anti-clockwise to secure.

• Switch on the blender by setting the speed

controller 7to the desired level.

IB_KH700_38172_LB6 27.10.2009 10:30 Uhr Seite 7

- 8 -

• When you have finished,

switch off the blender and re-

move the blender jug 4by

turning it clockwise.

• Remove the blender lid 2

from the blender jug 4by

turning it clockwise.

Hints:

• You can add your ingredients to the blender jug

4through the opening in the lid 2during ope-

ration. To do so, simply remove the splash protec-

tion cap 1.

• If you process hot liquids, remove the splash

protection cap 1to allow the steam to escape.

• Should ingredients be trapped in the blender jug

4during operation, proceed as follows:

- Switch off the device (speed controller 7to le-

vel 0) and pull the plug from the socket.

- Remove the splash protection cap 1and the

lid 2.

- Remove the trapped ingredients in the blender

jug 4using the spatula o. Ensure you do not

damage the spatula owith the blade z!

9. Cleaning & Care



Caution:

Never immerse the device in water or other

liquids. There could be potential hazard of

life-threatening electric shock, if moisture en-

ters the voltage conducting parts upon opera-

ting the appliance again.

• Exercise special care when cleaning the blades

z, the blender jug 4with installed blade and

the cutting discs (I-VI). The blades and cutting ed-

ges are extremely sharp! Risk of injury!

• Wipe the housing with a clean, damp cloth after

each use.



Warning regarding appliance

damage:

NONE of the appliance components are designed

for cleaning in a dishwashing machine! Additional-

ly, do not use abrasive cleansers for cleaning appli-

ance components.

• You can clean the mixing bowl 9and the lid 0

in hot soapy water.

• Always remove the plug from the socket before

cleaning the appliance. Otherwise, you are at

risk of receiving an electric shock!

• Clean all appliance components that have come

in contact with foodstuff with detergent and hot

water after use.

• Use an appropriate dishwashing brush for places

that are difficult to access.

IB_KH700_38172_LB6 27.10.2009 10:30 Uhr Seite 8

Table des matières

Autres manuels Silvercrest Robot culinaire

Silvercrest

Silvercrest SKM 500 A1 Manuel utilisateur

Silvercrest

Silvercrest SMZ 260 I4 Manuel utilisateur

Silvercrest

Silvercrest SKMP 1300 B3 Manuel utilisateur

Silvercrest

Silvercrest SKM 550 EDS A1 Manuel utilisateur

Silvercrest

Silvercrest 390051 2201 Manuel utilisateur

Silvercrest

Silvercrest SMZ 260 B1 Manuel utilisateur

Silvercrest

Silvercrest SMZT 500 A1 Manuel utilisateur

Silvercrest

Silvercrest SKM 350 A1 Manuel utilisateur

Silvercrest

Silvercrest MONSIEUR CUISINE SKMH 1100 A1 Manuel utilisateur

Silvercrest

Silvercrest SKMP 1200 A2 Manuel utilisateur

Silvercrest

Silvercrest SMZS 260 G1 Manuel utilisateur

Silvercrest

Silvercrest MONSIEUR CUISINE SKMH 1100 A1 Manuel utilisateur

Silvercrest

Silvercrest KM 250 B1 Manuel utilisateur

Silvercrest

Silvercrest SKM 500 B1 Manuel utilisateur

Silvercrest

Silvercrest SKV 1200 A1 Manuel utilisateur

Silvercrest

Silvercrest MONSIEUR CUISINE SKMH 1100 A1 Manuel utilisateur

Silvercrest

Silvercrest SMZS 260 E3 Manuel utilisateur

Silvercrest

Silvercrest SMZ 260 H1 Feuille d'instructions

Silvercrest

Silvercrest SKM 550 B1 Manuel utilisateur

Silvercrest

Silvercrest SMZ 260 C2 Manuel utilisateur

Silvercrest

Silvercrest 105261 Manuel utilisateur

Silvercrest

Silvercrest 281064 Manuel utilisateur

Silvercrest

Silvercrest SKM 550 B2 Manuel utilisateur

Silvercrest

Silvercrest SMZ 400 A1 Manuel utilisateur

Manuels Robot culinaire populaires d'autres marques

INNOLIVING

INNOLIVING INN-727 Manuel utilisateur

Berkel

Berkel C32 Manuel utilisateur

Beko

Beko CHP5554W Manuel utilisateur

KitchenAid

KitchenAid 5KFP0719 Manuel utilisateur

QUIGG

QUIGG KM 2017Wi.20 Manuel utilisateur

Lakeland

Lakeland PRESS AND CHOP 31557 Manuel utilisateur

Bosch

Bosch MMR08 GB Series Manuel utilisateur

HOFFEN

HOFFEN Chef Express T9532 Manuel utilisateur

Garland

Garland 852 ZG Manuel utilisateur

Robot Coupe

Robot Coupe CL50 Gourmet Manuel utilisateur

SAPIRHOME

SAPIRHOME SP-1111-K Manuel utilisateur

Moulinex

Moulinex DJ3051 Manuel utilisateur

Bosch

Bosch MUM5 Manuel utilisateur

cecotec

cecotec Mambo Touch Manuel utilisateur

KitchenAid

KitchenAid 9KFC0516 Manuel utilisateur

Black & Decker

Black & Decker hc 300 Instructions d'installation

Gorenje

Gorenje SBR 1000 DV Manuel utilisateur

Arzum

Arzum AR 1128 Manuel utilisateur
