Silvercrest KH 2357 Manuel utilisateur
KOMPERNASS GMBH · BURGSTRASSE 21 · D-44867 BOCHUM
www.kompernass.com
ID No.: KH2357-09/09-V2
3BC
KH 2357
Bluetooth®
Hands-Free Kit
Operating instructions
Bluetooth®-håndfrit sæt
til mobiltelefonen
Betjeningsvejledning
Εγκατάσταση ανοικτής
ακρόασης Bluetooth®
Οδηγίες χρήσης
CV_KH2357_DT37974_LB3BC 12.10.2009 13:31 Uhr Seite 1
1
3
4
5
6
2
CV_KH2357_DT37974_LB3BC 12.10.2009 13:31 Uhr Seite 4
CONTENT PAGE
Safety instructions 3
Correct Usage 5
Introduction 6
Items supplied 6
Technical data 7
Operating Elements 7
Installing the hands-free appliance in a vehicle 8
Switching the hands-free appliance on and off 9
Coupling the hands-free appliance with a
mobile telephone 9
Coupling the hands-free appliance with several
mobile telephones 11
Separating the connection 11
Re-establishing the connection 12
1
IB_KH2357_DT37974_GB.qxd 23.10.2009 9:36 Uhr Seite 1
Using the hands-free appliance 12
Troubleshooting 14
Cleaning and Care 15
Disposal 15
Warranty & Service 16
Importer 17
Information regarding the conformity declaration 18
2
IB_KH2357_DT37974_GB.qxd 23.10.2009 9:36 Uhr Seite 2
BLUETOOTH®HANDS-FREE KIT KH 2357
Safety instructions
Please read these operating instructions carefully and fold out the page with
illustrations when you do so. Closely heed this information when operating the
appliance. Should you have any further questions regarding use, please contact
the service department responsible for your country. Keep these operating instruc-
tions in a safe place and pass them on to whomsover might later acquire the
appliance.
Traffic safety has priority!
• Comply with all local laws. When driving, your hands must ALWAYS be free
to operate the vehicle safely. Traffic safety must ALWAYS take priority whilst
driving.
• Only manipulate the hands-free appliance on those occasions in which the
traffic situation permits it and in which you will not endanger, injure, obstruct or
cause annoyance to other road users.
• Do not permit your concentration on the road traffic to be compromised by the
manipulation and displays of the handsfree appliance!
• Become familiar with the operation of it before driving off and practice the
safe operation of the facility!
• Install the hands-free appliance in the vehicle such that your view is not
obstructed and that the appliance is not located in an impact zone in the
passenger compartment or in the inflation area of airbags.
3
IB_KH2357_DT37974_GB.qxd 23.10.2009 9:36 Uhr Seite 3
General safety instructions
• Do not attempt to open or repair the appliance. Should you do so, appliance
safety can no longer be assured and the warranty becomes void.
• Have the defective device repaired by customer service or an authorised
specialist only. No liability will be accepted for damage caused by misuse,
improper handling, use of force or unauthorized modification.
• Never subject the appliance to moisture, extreme temperatures or extreme
vibrations.
• Do not allow children and people subject to supervision play with the
appliance, they could injure themselves or cause damage to the appliance.
Connection to other mobile telephones
• If you wish to connect the appliance to another appliance, read the operating
instructions to obtain detailed safety instructions. Do not connect it to a product
that is not compatible.
High frequency signals in vehicles
HF signals can, under circumstances, negatively influence the function of not
properly installed or not sufficiently shielded electronic systems in vehicles,
e.g. electronic ABS, electronic tempo controllers and airbag systems. For further
information about your vehicle or its possible ancillaries make contact with the
respective manufacturer or their representative.
4
IB_KH2357_DT37974_GB.qxd 23.10.2009 9:36 Uhr Seite 4
Correct Usage
The Bluetooth®Hands-Free Kit KH 2357 is designed for use in vehicles with a
voltage of 12-24 V. The handsfree phone system uses both Bluetooth®radio tech-
nology as well as a digital signal processor (DSP) to carry out telephone functions.
This device may be used ONLY for private domestic purposes, not for industrial
or commercial applications. The product at hand is, by default, NOT intended
for use in medicinal, lifesaving or life support applications. All of the additional
connecting cables and external devices used MUST match the safety-related,
electromagnetic compatability and shielding quality standards of the device at
hand. With regard to CE Conformity, this device fulfills all of the relevant norms
and guidelines. In the event of modifications being made to the device without
agreement from the manufacturer, compliance with these norms and guidelines
can no longer be assured. Use only the accessories specified by the manufactu-
rer. If you are using the device outside the territory of the Federal Republic of
Germany you must pay heed to the national regulations resp. the laws of the
country in which it is being used.
5
IB_KH2357_DT37974_GB.qxd 23.10.2009 9:36 Uhr Seite 5
Introduction
Bluetooth®is a wireless communication system with a short range. It makes
possible wireless connections between Bluetooth®appliances, such as for example
mobile telephones, PDA and PCs. Bluetooth®relates itself to a worldwide stan-
dard for operation in the internationally recognised ISM Frequency Range
(Industrial, Scientific and Medical). Within the ISM Frequency Range
(2,402 - 2,480 GHz), a data transfer range of ca. 10 Meters (Klasse II) is
achieved. The disturbance susceptibility through other users of the ISM
Frequency Range, such as for example microwaves, WLAN (802.116) or
garage door openers, is minimised by so-called „Frequency-Hopping“.
With Frequency-Hopping, a change of frequency levels takes place at up to 1600
times per second, thereby Bluetooth®is also reckoned to be relatively tap-proof.
The HSP (Headset-Profil) makes possible standard functions such as voice
transference, as well as the acceptance and rejection of calls.
The HFP (Handsfree-Profil) makes possible the hands-free call functions of a
mobile telephone, for example with the help of voice commands.
Items supplied
Bluetooth®Hands-Free Kit KH 2357
Operating instructions
6
IB_KH2357_DT37974_GB.qxd 23.10.2009 9:36 Uhr Seite 6
Technical data
Operational voltage: 12-24 Volt DC / 500 mA
Bluetooth®Specification: Version 2.1 + EDR, 10 Meter range.
Supported Bluetooth®profiles: HSP and HFP
Dimensions (L x W x H): 15.5 x 5.5 x 3.2 cm
Weight: 67 g
Operational temperature: +5° to +40°C
Storage temperature: -10° to +60°C
Humidity: 5 to 90% (no condensation)
Operating Elements
1Vehicle connector plug
2Loudspeaker
3Volume control
4Multi-function button
5Microphone
6LED status display
7
IB_KH2357_DT37974_GB.qxd 23.10.2009 9:36 Uhr Seite 7
Installing the hands-free appliance in a vehicle
So that the hands-free appliance can function correctly, it is con-nected to the
vehicle cigar lighter socket and provided with electricity from there.
• Ensure that the hands-free appliance engages completely and that the
operation of the vehicle is not negatively influenced. The LED status indicator
6lights up every 3 seconds and a short high signl tone sounds once.
The appliance is in standby mode.
Note:
It is possible that the cigar lighter only functions when the vehicle ignition is
switched on. In cases of doubt, consult the operating instructions for the
particular vehicle.
CAUTION:
For vehicles in which the cigar lighter, resp. the vehicle circuit plug, also functions
when the ignition is switched off:
• Use the hands-free appliance only when the motor is running. Otherwise, the
vehicle batteries could become discharged over an extended period of time.
Note:
When you are not using the hands-free equipment remove it from the vehicles
cigarette lighter socket. Store it in a dry, dust free location protected from direct
sunlight.
8
