Antenna users:
The typical antenna configuration is:
Antenna -> Amplifier -> 4-way Splitter -> TVs/Devices
For larger antenna based syste s:
Antenna -> Amplifier -> 2-way Splitter -> 4-way Splitter -> TVs/Devices
-> 4-way Splitter -> TVs/Devices
It is generally a good idea to balance the splitter layout, as shown above. A balanced
configuration eans all devices go through the sa e configuration of splitters back to the
antenna; balancing in this way will result in si ilar signal levels at each device.
Avoid cascading a 4-way splitter after another 4-way splitter without careful design consideration
- each cascaded splitter reduces the signal level considerably.
Antenna:
We reco end using an outdoor antenna for best perfor ance.
Amplifier:
When splitting to ultiple devices, a prea plifier or distribution a plifier ay be required.
The a plifier should be placed before any splitters.
Digital Cable users:
Typical cable TV configuration:
Street -> 2-way Splitter -> 2/4-way Splitter -> TVs/Devices
-> 2/4-way Splitter -> TVs/Devices
It is generally a good idea to balance the splitter layout, as shown above. A balanced
configuration eans all devices go through the sa e configuration of splitters back to the
antenna; balancing in this way will result in si ilar signal levels at each device.
Avoid cascading a 4-way splitter after another 4-way splitter without careful design consideration
- each cascaded splitter reduces the signal level considerably.
Amplifier:
If a distribution a plifier is used it should be rated for bi-directional cable use and placed before
any splitters.
