MarineSol-ThinFilm-12V30W
Amorphous Silicon Solar Panel
Charges 12V batteries with sunlight.
Maintenance Free / Easy installation, comes with aluminum frame, junction box, 6.5 feet of cable,
and 10 feet of thin wire
Built-in blocking diode protects battery discharge at night.
Glass laminated, completely weatherproof.
Works in all-weather condition.
Dimensions: 24” x 36”
Weight: 23 lbs.
How do the solar panel work
This solar panel converts light energy from the sun into 12 volt DC electricity which is then
transported to the rechargeable batteries through lead wire and connector of choice.
The THIN FILM technology this panel use allow them to absorb a wider spectrum of the natural light,
and therefore can work under cloudy winter conditions, and this technology also enable the solar
panel to handle the intense heat of the summer sun, its power loss due to the rising temperature is
obviously less when compare to other type of solar panel.
How to use
When operates, face the front (black) side of the solar panel to the sun, and make sure there
is no shadow cast on the solar panel. Best place the long side of solar panel at South to
North direction.
Tilt the solar panel at a suitable angle. The
right angle should be same as your local
latitude.
Attach the solar panel to battery using the
battery clamps and cable provided. Please
note that the black lead indicates negative (-)
and the red lead indicates positive (+).
Ensure you connect to the correct battery
terminals.
Innovative Solar Solutions| 2917 State Hwy 7, Bainbridge, N.Y. 13733 | Ph: 800.786.0329 | www.SiliconSolar.com
Caution
Always keep the glass surface clean with a soft cloth. In order to ensure its maximum
output.
The solar panel uses glass substrate, please handle with care.
Avoid contact with acid and alkali.
