Silicon Graphics SGI 1200 Series Manuel utilisateur

SGI™1200-Family of Servers

Quick Start Guide

Guide de démarrage rapide de la famille des serveurs SGI 1200

SGI 1200-Serverfamilie – Schnelleinstieg

Manuale di installazione rapida - Linea Server SGI 1200

Família de servidores SGI 1200 - Instruções iniciais

Guía de inicio rápido de la familia de servidores SGI 1200

Document Number 007-4233-002ML

SGI™1200-Family of Servers Quick Start Guide

Document Number 007-4233-002ML

CONTRIBUTORS

Writen by Mark Schwenden and Carlin Otto

Illustrated by Dan Young

Production by Joe Kish

The contents of this document may not be copied or duplicated in any form, in whole

or in part, without the prior written permission of Silicon Graphics, Inc.

This equipment has been tested and found to comply with the limits for a Class A

digital device, pursuant to Part 15 of the FCC Rules. This equipment generates, uses,

and can radiate radio frequency energy and, if not installed and used in accordance

with the instructions, may cause harmful interference to radio communications.

LIMITED AND RESTRICTED RIGHTS LEGEND

Use, duplication, or disclosure by the Government is subject to restrictions as set

forth in the Rights in Data clause at FAR 52.227-14 and/or in similar or successor

clauses in the FAR, or in the DOD, DOE, or NASA FAR Supplements. Unpublished

rights reserved under the Copyright Laws of the United States.

Contractor/manufacturer is Silicon Graphics, Inc., 1600 Amphitheatre Pkwy.,

Mountain View, CA 94043-1351.

SGI and the Silicon Graphics logo are trademarks of Silicon Graphics, Inc. Adobe,

Acrobat, and PostScript are registered trademarks of Adobe Systems Incorporated.

iii

SGI 1200-Family of Servers Quick Start Guide . . . . . . . . . . . . . . . 1

Guide de démarrage rapide de la famille des serveurs SGI 1200. . . . . . . . . . 7

SGI 1200-Serverfamilie – Schnelleinstieg . . . . . . . . . . . . . . . . 13

Manuale di installazione rapida - Linea Server SGI 1200 . . . . . . . . . . . . 19

Família de servidores SGI 1200 - Instruções iniciais . . . . . . . . . . . . . 25

Guía de inicio rápido de la familia de servidores SGI 1200 . . . . . . . . . . . 31

. . . . . . . . . . . . . . . . . . . . . . . . . . . . 37

. . . . . . . . . . . . . . . . . . . . . . . . . . . . 43

. . . . . . . . . . . . . . . . . . . . . . . . . . . . 49

. . . . . . . . . . . . . . . . . . . . . . . . . . . . 55

0. Introducing the SGI 1200 Servers

This document is intended to help you get your new SGI server unpacked, connected,

and powered on. Although there are a number of models in the SGI 1200-family of

servers, this document will refer to the products generically as SGI 1200 servers. After

completing the steps in this guide, you may wish to continue with additional

configuration, or read more about your server’s capabilities. Reference the SGI

1200-Family of Servers User’s Guide for more detailed information on your system.

Warning: To avoid personal injury when unpacking the server, use two people

and/or a mechanical assist unit to lift it out of the shipping carton. The server

configuration weighs a maximum of 42.0 lbs (19.1 kg). The server, options, and

packaging combination can weigh up to 70.0 lbs (31.8 kg). Use a hand-truck or other

mechanical assist unit to move the server from one location to another. Before

operating this server, read the additional cautions in “Product Warnings” on page 6.

Physical and Environmental Requirements

The SGI 1200 server can be mounted in most industry-standard racks. Contact your sales

or service provider if you need to change the mounting configuration of your server after

receiving the unit. Table 1 provides information on environmental requirements for the

server. For instructions on mounting your server in a 19-inch equipment rack, see the SGI

1200-Family of Servers User’s Guide.

Table 1 Cooling and Power Requirements

Specification Value Per Server

Cooling Requirements:

Minimum configuration

Maximum configuration

730 BTU/hour heat dissipation

859 BTU/hour heat dissipation

Air Conditioning Load 0.0718 tons maximum

Introducing the SGI 1200 Servers

Setting Up Your SGI 1200 Server

Use the information in this section to set up and turn on your SGI 1200 server.

1. Select a proper operational site for your server. Complete instructions for selecting a

safe and appropriate site are provided in the SGI 1200-Family of Servers User’s Guide.

2. Unpack the server from its shipping carton.

3. Remove the drive protection card (if present) from the diskette drive. Figure 1

shows the drive locations on the front of the server (plastic front cover removed).

Power Consumption:

Minimum configuration

Maximum configuration

214 watts

252 watts

Chassis Dimensions 3.48 in. high (2U) x 17.1 in. wide x 23.92 in. long

(8.85 cm high (2U) x 43.43 cm wide x 60.76 cm long)

Weight:

Installed

In packaging

42.0 lb (19.1 kg) maximum

70.0 lb (31.8 kg) maximum

Installation Orientation Any, with 2 inches (5.1 cm) clearance at back

Table 1 (continued) Cooling and Power Requirements

Specification Value Per Server

Setting Up Your SGI 1200 Server

Figure 1 SGI 1200 Front View With Cover Removed

4. If you plan to use any options (for example, PCI boards, additional memory, and so

on), follow the instructions in the SGI 1200-Family of Servers User’s Guide to install

these items.

Caution: Electrostatic discharge (ESD) can damage disk drives, add-in boards, and

other parts. This server can withstand normal levels of environmental ESD.

However, SGI recommends doing all procedures in this guide only at an

ESD-protected workstation. If one is not available, you can provide some ESD

protection by wearing an antistatic wrist strap attached to chassis ground of the

server—any unpainted metal surface—when handling components.

5. As applicable, follow the detailed procedures in Chapter 3 of the User’s Guide to

install the unit into a rack.

6. Attach any of the following common peripherals that you intend to use at the

connectors shown in Figure 2:

•Keyboard: plug the keyboard into the keyboard port

•Mouse: plug the mouse into the mouse port

•Terminal: plug the display terminal into the video connector port on the rear of

the server and also into a power source, and turn the terminal on

Blue AC power LED

Amber global failure LED

Green Ethernet activity LED

Green disk activity LED

Introducing the SGI 1200 Servers

Figure 2 SGI 1200 Server Rear Connectors and Controls

7. Attach the power cord to the AC power plug at the back of the unit and plug the

other end into a power source.

Caution: Make sure that the power service connection is through a properly

grounded outlet. In geographic regions that are susceptible to electrical storms, using

a surge suppressor is highly recommended.

8. Turn on the rear rocker power switch (on the power supply).

9. Push the front on/off power switch.

Warning: The front on/off power switch does not turn off all internal power. To

completely remove power from the server, you must turn off the rear rocker switch

on the power supply and unplug the AC power cord from the supply or wall

outlet.

Verify that the power-on LED (illustrated in Figure 1 on page 3) on the front panel is

lit. A complete description of these LEDs is provided in the server’s User’s Guide.

After a few seconds, the power-on self-test (POST) begins. To view the POST results,

the terminal must be connected to the rear of the server and turned on.

10. If the server’s operating system (OS) is not pre installed, you should install it using

the instructions in the documentation that shipped with the OS.

AC on/off

rocker switch

AC power

connector

USB

connectors

Parallel port

connector

Optional PCI board

(RAID controller board shown)

Mouse

connector

Optional external

SCSI connector

Network

connector

Video

connector

Additional optional

PCI board slot Amber LED

Green LED

COM2/EMP

connector

COM1

connector

Keyboard

connector

Getting Manuals

11. At power on the system displays a CPU description, runs a memory test, displays

several additional screen messages, and then prompts you with the following:

Press <F2> to enter Setup

12. If you do not immediately press F2, the boot process continues. Then this message

appears:

Press <Ctrl><A> for SCSI Utility

•If you press Ctrl+A you enter the SCSI Utility screen. After you make any

changes, press Esc to exit the utility. Note that if there are no SCSI devices

connected to the system you cannot enter the SCSI Utility.

•If you do not press Ctrl+A the system continues the boot process, offers you

another chance to Press <F2> to enter Setup and then proceeds to the

power-on self tests (POST). If the OS is not available you see the message:

Operating System not found

13. While the POST runs, you can press Esc to access a boot menu. From this menu, you

can choose a new boot device or enter BIOS Setup.

After POST completes, the OS loads, then the login screen appears.

Getting Manuals

SGI provides manuals online and on CDs in various formats.

The SGI Technical Publications Library

If you would like to access manuals on the SGI 1200 server using the World Wide Web,

SGI makes its manuals available in a variety of formats via the Web. Using your Web

browser, open the following URL:

http://techpubs.sgi.com/library

Enter a keyword search, or search by title to find the information or manual you need.

Introducing the SGI 1200 Servers

Manuals on CD

SGI provides manuals on the CD that arrived with your SGI 1200 server. The manuals are

in the following viewable and printable formats:

•PDF files: read and print .pdf files using an Adobe Acrobat Reader; note that the

reader is not pre installed with every operating system shipped. The Acrobat

Reader application files are supplied on the documentation CD.

•HTML files: view or print HTML files using your Web browser (English only).

Product Warnings

Please be aware of these safety precautions and information when using SGI 1200

servers:

•The power supply in this product contains no user-serviceable parts; refer servicing

only to qualified personnel.

•Do not attempt to modify the supplied AC power cord.

•Do not use the supplied AC power cord if it is not the exact type required for your

power source.

•The SGI 1200 server’s front on/off switch does not turn off all system power. To

completely remove power from the system, you must turn the power supply switch

to off and unplug the AC power cord from the wall outlet or power supply.

Table des matières

Langues :

Autres manuels Silicon Graphics Serveur

Silicon Graphics

Silicon Graphics UV 3000 Manuel utilisateur

Silicon Graphics

Silicon Graphics Rackable C1000 Manuel utilisateur

Silicon Graphics

Silicon Graphics Altix XE340 Manuel utilisateur

Silicon Graphics

Silicon Graphics 1200 Manuel utilisateur

Silicon Graphics

Silicon Graphics Rackable C2112-4KL1 Manuel utilisateur

Silicon Graphics

Silicon Graphics UV 30 Manuel utilisateur

Silicon Graphics

Silicon Graphics Rackable C1104-GP2 Manuel utilisateur

Silicon Graphics

Silicon Graphics 1450 Manuel utilisateur

Silicon Graphics

Silicon Graphics Rackable C2112-4G3 Manuel utilisateur

Silicon Graphics

Silicon Graphics Altix XE320 Manuel utilisateur

Silicon Graphics

Silicon Graphics Rackable C2112-4RP9 Manuel utilisateur

Silicon Graphics

Silicon Graphics Origin 3900 Manuel utilisateur

Silicon Graphics

Silicon Graphics 1400 Manuel d'installation et d'exploitation

Silicon Graphics

Silicon Graphics UV 20 Manuel utilisateur

Silicon Graphics

Silicon Graphics POWER CHALLENGE Manuel utilisateur

Silicon Graphics

Silicon Graphics Rackable C2005 Family Manuel utilisateur

Silicon Graphics

Silicon Graphics Rackable C2110G-RP5 Manuel utilisateur

Silicon Graphics

Silicon Graphics 1400 Manuel utilisateur

Silicon Graphics

Silicon Graphics Rackable C2005 2U Manuel utilisateur

Silicon Graphics

Silicon Graphics UV 300H Manuel utilisateur

Silicon Graphics

Silicon Graphics InfiniteStorage C1104-GP6 Manuel utilisateur

Silicon Graphics

Silicon Graphics Rackable C1110-RP6 Manuel utilisateur

Silicon Graphics

Silicon Graphics Origin200 Manuel utilisateur

Silicon Graphics

Silicon Graphics Altix XE250 Manuel utilisateur

Manuels Serveur populaires d'autres marques

HP AlphaServer ES47 Manuel utilisateur

Dell

Dell PowerEdge R410 Manuel utilisateur

PowerNAS

PowerNAS CMA Manuel utilisateur

Supero

Supero FatTwin F617R3-FT Manuel utilisateur

MSI

MSI P1-109N-L70 Manuel utilisateur

Dell

Dell PowerEdge XE9640 Manuel

Dell

Dell PS4100 Instructions de montage

EtroVISION

EtroVISION EV3151 Manuel utilisateur

NEC

NEC Express5800/T110j Manuel utilisateur

HP ProLiant Gen9 Manuel utilisateur

Compaq

Compaq ProLiant 3000 Manuel

Dell

Dell PowerEdge 3YPMN Manuel utilisateur

iRobo

iRobo IPC2U Manuel utilisateur

Nortel

Nortel 1000 Con?guration guide Manuel utilisateur

Asus

Asus AP7500 Manuel d'utilisation et d'entretien

Avid Technology

Avid Technology AirSpeed 5000 Manuel utilisateur

HP Integrity rx2600 Guide d'installation

Milestone

Milestone Husky IVO 350T Manuel utilisateur
