Silhouette DBC2760BLS Manuel utilisateur

OWNER’S MANUAL

GUIDE DU PROPRIÉTAIRE

MANUALDELUSUARIO

CAUTION:

Read and Follow All Safety Rules and

Operating Instructions Before First

Use of This Product.

ATTENTION :

Avant de faire fonctionner cette

machine, lisez et suivez toutes les

consignes de sécurité de ce guide en

premier lieu.

ATENCIÓN:

Lea y Siga Todas las Indicaciones de

Seguridad y de Operación Antes de

Utilizar Este Producto.

Table of Contents . . . . . . . . . . . . . . . . . . . . 1

Table des matières . . . . . . . . . . . . . . . . . . . 12

Índice. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23

Danby Products Limited, Guelph, Ontario Canada N1H 6Z9

Danby Products Inc., Findlay, Ohio USA45839-0669

Version 1.09.05

DBC2760BLS

Important Safety Information

Safety Precautions 4

Grounding Instructions 5

Operating Instructions

Features of Your Beverage Center 6

The Controls of Your Beverage Center 7

Setting the Temperature 7

Wine Storage 8

Shelf Instructions 8

Installation Instructions

Tools You Will Need 9

Preparing the Enclosure 9

Care and Cleaning

Helpfull Hints 10

How to Clean the Inside 10

How to Clean the Outside 10

Trouble Shooting

Before You Call For Service 11

TABLE OF CONTENTS

WELCOME

NEED HELP?

Welcome to the

Danby family. We’re

proud of our quality

products and we

believe in dependable

service.

You’ll see it in this

easy-to-use manual

and you’ll hear it in the

friendly voices of our

consumer service

department.

Tel:1-800-26-

Best of all, you’ll

experience these

values each time you

use your Beverage center.

That’s important,

because your new

appliance will be part

of your family for a

longtime.

Before you call for service,

there are a few things you

can do to help us serve

you better...

Read this manual

It contains instructions to

help you use and maintain

your Beverage center properly.

If you received a

damaged appliance

Immediately contact the

dealer (or builder) that sold

you the Beverage center.

Save time and money

Check the TroubleShooting

section before calling. This

section helps you solve

common problems thatmay

occur.

If you do need service, you

can relax knowing help is

only a phone call away.

Tel: 1-800-26-

Write down the model and serial

numbers here. They are on a label

located on the back of the Beverage

Center.

Model numberDBC2760BLS

Serial number ______________

Date purchased ____________

Staple your receipt to the inside

back cover of this manual. You will

need it to obtain service under

warranty.

Start Here!…Before using your Beverage Center

READ ALL SAFETY INFORMATION BEFORE USING

IMPORTANT SAFETY INFORMATION

WARNING

SAFETY

PRECAUTIONS

•This appliance must be

grounded. Connect only to a

properly grounded outlet.

See “Grounding Instructions”

section on page 4.

•Do not operate this appliance

if it has a damaged power cord

or plug, if it is not working

properly, or if the appliance has

been damaged or dropped.

•Do not splice the power cord

that is equipped with this appli-

ance.

•Keep power cord away from

heated surfaces.

•Do not immerse power cord,

plug or the appliance itself in

water.

•Do not use this product near

water-for example, in a wet

basement, near a swimming

pool or near a sink.

•Do not use corrosive

chemicals or vapors inthis

appliance.

•Use this appliance only for

it’s intended use, asdescribed

in this manual.

•Do not store perishable food

items such as (but not limited

to) meats and dairy products

in your Beverage Center .

•Store wine in sealed bottles

only.

•See door surface cleaning

instructions in the Care and

Cleaning section(s) of this

manual.

•Do not cover or block any

openings on the appliance.

•This appliance is intended for

household use only. Do not

attempt to operate or store this

appliance outdoors.

•This appliance should be

serviced only by qualified serv-

ice personnel. Contact the

nearest authorized service

facility for examination, repair

or adjustment.

SAVE THESE INSTRUCTIONS

DANGER, RISK OF CHILD ENTRAPMENT!

An empty Beverage Center is a very dangerous attraction to children. Remove either the gasket,

latches, lids, lock and/or doors from unused or discarded appliances, or take some other action

to guarantee it harmless. DON’T WAIT, DO IT NOW!

To reduce the risk of fire, burns, electric shock, or injury to persons when using your appliance,

follow basic precautions, including the following sections;

This appliance must be

grounded. In the event of an

electrical short circuit, ground-

ing reduces the risk of electric

shock by providing an escape

wire for the electric current.

This appliance is equipped

with a power cord having a

grounding wire with a ground-

ing plug. The plug must be

plugged into an outlet that is

properly installed and ground-

ed.

Consult a qualified electrician

or service technician if the

grounding instructions are not

completely understood, or if

doubt exists as to whether the

appliance is properly ground-

ed.

If the outlet is a standard 2-

prong wall outlet, it is your per-

sonal responsibility and obliga-

tion to have it replaced with a

properly grounded 3-prong

wall outlet.

For best operation, plug this

appliance into its own electri-

cal outlet to prevent flickering

of lights, blowing of fuse or

tripping of circuit breaker.

Do not under any circum-

stances cut or remove the

third (ground) prong from the

power cord.

Do not use an adapter plug

with this appliance.

Do not use an extension

cord with this appliance. If the

power cord is too short, have

a qualified electrician or serv-

ice technician install an outlet

near the appliance.

GROUNDING

INSTRUCTIONS

IMPORTANT SAFETY INFORMATION

WARNING

Improper use of the

grounding plug can result

in a risk of electric shock.

Operating Instructions

Features of your

Beverage Center

1. Twin Door Design:Divided compart-

ments allow for separate storage of different

types of wines.

2. Dual Electronic Controls:For indi-

vidually regulating the temperature for both

compartments of the Beverage Center .

3. Magnetic Door Gaskets:Tight fitting

seals retain all the cooling power and humid-

ity levels.

4. Stainless Steel Trim Shelves

5. Child Proof Locks with Key

6. Front Mounted Exhaust:Allows for

integrated (built-in) applications.

7. Tempered Glass Doors:Tinted for

UV protection while still allowing for easy

interior viewing.

8. Leveling Legs

9. Interior Lights (not shown): Cool Blue -

LED lighting illuminates the interior without the

heat of an incandescent bulb.

10. Interior Light Toggle Switch: To

manually illuminate/extinguish both interior

lights, while doors remain closed.

Operating Instructions

Setting the

Temperature

•Toswitch the display

between the Fahrenheit (°F)

and Celsius (°C) scale,

depress the UPandDOWN

control buttons simultaneouslyfor

approximately five (5) sec-

onds

•The temperature range for

both compartments can be

set as low as 39°F(4°C) or

as high as 64°F (18°C) to suit

your specific wine storage

requirements. Each depres-

sion of the UPor DOWN but-

ton will allow you adjust the

temperature in 1°degree

increments within the afore-

mentioned range.

•You may view your ‘set’

temperature at any time by

briefly depressing either the

‘UP’or‘DOWN’button. The

settemperature will flash in

the display area for 5 sec-

onds before the display

resumes showing the current

cabinet temperature.

Please note:In the event of

a power failure or interrup-

tion, all modified settings are

lost and the default settings

are used once power

resumes.

The Controls of

your Beverage Center

1.Run

Indicator light illuminates to signify the

cooling mode is currently in operation.

2.Electronic Display

Dispay screen shows current cabinet

temperature and set temperature. (see

‘Setting the Temperature’below)

3. C° / F°

Adjacent indicator light denotes which

scale of temperature is displayed.

4. ‘UP’Button

Used to raise (warm) the temperature

in 1° degree increments.

‘DOWN’Button

Used to lower (cool) the

temperature in 1° degree increments.

When you plug in your

Beverage Center for the first

time, the temperatures

will automatically be set

to 45°F (7°C) and 54°F

(12°C)in the left and right

compartmentsrespectively

and will be displayed in

the Fahrenheit scale (°F).

Operating Instructions

In order to achieve the maxi-

mum storage capacity of

27 bottles, it will be

necessary to position the bot-

tles alternately on the upper

six shelves, as shown in Fig

A. This will allow for the stor-

age of four (4) 750 ml bottles

per rack in each of the top six

shelves, and three (3) bottles

on the bottom shelf for a total

storage capacity of 27 wine

bottles.

Wine

Storage

The *maximum capacity of

the DBC2760BLS is 27

(750ml)wine bottles.

*When stocked as per

instructions

Fig A

Shelf Instructions To remove a shelf from it’s

locked position, tilt the shelf

as shown in Fig C and pull

outward.

To re-install, ensure the shelf

is resting securely on the sup-

port brackets and push shelf

inward until it locks into place.

Please Note: The bottom

shelf in both sections of the

cabinet are not secured in

place (locked). Do not attempt

to pull on the shelf when

either it is stocked with wine.

IMPORTANT!

Do not cover shelves with

aluminum foil or any other

material that will prevent

adequate air circulation

within the cabinet.

Fig C

Installation Instructions - Intergrated Application

Preparing the

Enclosure

FOR YOUR SAFETY:

While performing

installations described in

this section, gloves, safety

glasses or goggles should

be worn.

Tools You Will

Need

Carpenters

Square

Measuring

Tape

Level

Drill & Hole Saw set

Gloves

Safety Glasses

Flashlight

Electrical Requirements:

The appliance must be

connected to an individual

properly grounded electrical

outlet, protected by a 15 or

20 ampere circuit breaker or

time delay fuse.

•It is recommended that you do

not install the Beverage Center into a

corner (i.e. directly beside a

wall). This is to allow the door(s)

to have a greater then 90° open-

ing swing. A limited door swing

will prevent the shelves from

sliding out as intended, and may

lead to damaging the door gas-

ket(s).

•The rough cabinet opening

must be on a level floor area

and at least 24” deep*by 24”

wide. The opening should also

have a height of at least 34-1/2”.

• The electrical outlet may be

positioned from within either

side of the adjacent cabinetry, or

the rear of the shaded area (as

shown in Fig C.).

Important: If the electrical out-

let is surface mounted (not flush)

within the enclosure, the depth

requirment for the installation be

affected.

•If the electrical outlet is located

inside the adjacent cabinetry, cut

a 1-1/2” diameter hole to admit

the power cord.

Electrical Access

Fig C

Cabinets

Square

and

Plumb

34-1/2” From

Underside of

Countertop to

Floor

24”

6”

2”

24”

Min*

1-1/2” dia. hole

*if electical outlet

is in adjacent

cabinetry

*The listed depth requirment for the installation is assuming that the electrical outlet is located in the adja-

cent cabinetry or is flush mounted in the rear wall, not surface mounted in the enclosure.

HelpfullHints

Allow the Beverage Center door to

remain open for a few minutes

after manual cleaning to air out

and dry the inside of the wine

cooler cabinet

NOTE: Be certain the

power is off before

cleaning any part of

this appliance.

How to Clean

the Inside Walls, Floor, Inside

Window, and Shelves

Water deposits and dust can

should be removed with a

damp cloth.

Care and Cleaning

How to Clean

the Outside Outer Case

It’s important to keep the area

clean where the door seals

against the cabinet. Clean this

area with a sudsy cloth. Rinse

and then dry.

Door surface

Use only mild, non-abrasive

detergents applied with a

clean sponge or soft cloth.

Rinse well.

Control Panel and

Door

Wipe with a damp cloth and

dry thoroughly. Do not use

cleaning sprays, large

amounts of soap and water,

abrasive or sharp objects on

the panel, they can damage it.

Some paper towels may also

scratch the control panel and

door glass.

Do not use cleaners con-

taining ammonia or alcohol

on the Beverage center.

Ammonia or alcohol can

damage the appearance of

the appliance.

Never use any commercial or

abrasive cleaners or sharp

objects on any part of wine

cooler.

Autres manuels pour DBC2760BLS

Table des matières

Langues :

Autres manuels Silhouette Appareils de cuisine

Silhouette

Silhouette Veneto DPC042D1BSSPR Instructions de montage

Silhouette

Silhouette Professional SPRBC056D1SS Manuel utilisateur

Silhouette

Silhouette Professional DBC056D3BSSPR Instructions de montage

Silhouette

Silhouette Professional SPRBC031D1SS Manuel utilisateur

Silhouette

Silhouette SPRBC047D1SS Manuel utilisateur

Silhouette

Silhouette Professional SPRWC031D1SS Manuel utilisateur

Silhouette

Silhouette DELUXE WINE COOLER DWC512BLS-1 Manuel utilisateur

Silhouette

Silhouette DBC047D3BSSPR Manuel utilisateur

Silhouette

Silhouette Silhouette DWC283BLS Manuel utilisateur

Silhouette

Silhouette SPRAR055D1SS Manuel utilisateur

Silhouette

Silhouette Professional DBC047D1BSSPR Manuel utilisateur

Silhouette

Silhouette DWC047D1BSSPR Instructions de montage

Silhouette

Silhouette DWC053D1BSSPR Manuel utilisateur

Silhouette

Silhouette DWC1534BLS Manuel utilisateur

Silhouette

Silhouette Select DOBC7070SSST Manuel utilisateur

Silhouette

Silhouette DBC031D4BSSPR Instructions de montage

Silhouette

Silhouette PROFESSIONAL SPRWC140D1SS Manuel utilisateur

Silhouette

Silhouette DWC140D1BSSPR Manuel utilisateur

Manuels Appareils de cuisine populaires d'autres marques

Tayama

Tayama TYG-35AF Manuel utilisateur

AEG

AEG 43172V-MN Manuel utilisateur

REBER

REBER Professional 40 Guide de l'utilisateur

North American

North American BB12482G / TR-F-04-B-NCT-1 Manuel utilisateur

Presto

Presto fountain popper Manuel utilisateur

Westmark

Westmark 1035 2260 Manuel utilisateur

Zanussi

Zanussi ZCG64396XA Manuel utilisateur

HOFFEN

HOFFEN SM-9302M Manuel utilisateur

Philips

Philips HD3133 Manuel utilisateur

Ronco

Ronco Beef Jerky Manuel utilisateur

Hendi

Hendi 470411 Manuel utilisateur

Livoo

Livoo MEN386 Manuel utilisateur

Vogue

Vogue D446 Manuel utilisateur

croydon

croydon WR-10313-700 Manuel utilisateur

ADE

ADE AUTOMATIC-L Manuel utilisateur

Chefman

Chefman RJ43-SQ Series Manuel utilisateur

Vacmaster

Vacmaster VP680 Manuel utilisateur

Jetmaster

Jetmaster 900HG Manuel utilisateur
