Washing machine

WM16Y890ES WM16Y89XES

Your new washing machine

You have chosen a Siemens washing machine.

Please take a few minutes to read and become familiar with the

advantages of your washing machine.

To meet the high quality demands required by Siemens, every

washing machine that leaves our factory is carefully checked to

ensure that it functions correctly and is in perfect condition.

For more information on our products, accessories, replacement

parts and services, see our website www.siemens-home.com or

contact our after-sales service centres.

If the operating and installation instructions describe different

models, any differences will be pointed out at the relevant points

in the text.

Read these operating and installation instructions before

switching on the washing machine.

Display rules

mWarning!

This combination of symbol and signal word indicates a possibly

dangerous situation. Not heeding the warning can cause death

or injuries.

mCaution!

This signal word indicates a possibly dangerous situation. Not

heeding the caution can cause property and/or environmental

damage.

Information about the optimum use of the appliance/any other

useful information.

1. 2. 3. / a) b) c)

The steps are represented by numbers or letters.

Ø/ -

Lists are represented by a small box or a dash.

Contents

enWashing machineInstruction Manual and Installation Instructions

Before washing

ØIntended use 4

ØSafety instructions 5

ØProtection of the environment 7

ØThe main points in brief 8

ØGetting to know your appliance 9

ØDetergent drawer 10

ØOperating elements/Display elements 11

Operating the appliance

ØBefore each washing 12

ØWashing 18

ØAfter washing 21

ØProgramme overview 22

ØProgramme settings/options 29

ØAnti-stain system 32

ØIntelligent Dosing System 33

ØConsumption values 38

ØAppliance settings 39

ØSensors – Your washing machine is so intelligent 40

Cleaning and maintenance

ØCare and maintenance 41

ØEmergency release 47

ØInformation on the display panel 48

ØFaults, what to do? 49

ØCustomer service 51

Installing the appliance

ØStandard accessories 52

ØInstallation 54

ØRemove transportation protection devices 57

ØConnecting the water 59

ØAlignment 62

ØElectrical connection 63

ØBefore the 1st washing 64

ØTransportation, e.g. if moving house 65

Index 66

Before washing

Intended use

ØFor use in the household only.

ØThe washing machine is suitable for washing machine-

washable textiles and hand-washable wool in wash liquor.

ØThe washing machine is suitable to be operated with cold

drinking water and commercially available detergents and

care products which are suitable for use in washing

machines.

ØWhen dosing all detergents, cleaning aids, cleaning products

and cleaning agents, always follow the manufacturer's

instructions.

ØThe washing machine may be operated by children from 8

years of age, by persons who have limited physical, sensory

or mental abilities and by persons who have inadequate

experience or knowledge, provided they are supervised or

have been instructed by a responsible person.

ØKeep pets away from the washing machine!

Read and follow the operating and installation instructions and all

other information enclosed with the washing machine.

Retain documents for subsequent use.

Safety instructions

mWarning!

Danger of death from electric shock!

Danger of death if live parts are touched.

– Never pull out the mains plug by tugging the power cord.

– Insert/pull out the mains plug with dry hands only.

mWarning!

Risk to children!

– Do not leave children unsupervised near the washing machine.

– Children must not play with the washing machine.

– This will prevent children from locking themselves in and

suffocating.

On redundant appliances:

– Pull out the mains plug!

– Sever the power cord and discard together with the plug.

– Destroy the lock on the washing-machine door.

– Children must not perform any cleaning or maintenance work

without supervision.

– When playing, children may become entangled in the

packaging/film and packaging parts or pull them over their

heads and suffocate.

Keep packaging, plastic film and packaging parts out of the reach

of children.

– When washing at high temperatures, the glass of the washing

machine door becomes hot.

Prevent children from touching the hot washing machine door.

– Detergents and care products may cause intoxication if

consumed or eye and skin irritation if touched.

Keep detergents and care products out of the reach of children.

mWarning!

Risk of explosion!

Items of washing pretreated with solvent detergents, e.g. stain

remover/petroleum ether, may cause an explosion when the

washing machine has been loaded.

Before hand thoroughly rinse items of washing by hand.

mCaution!

Danger of scalding!

When washing at high temperatures, you may be scalded if you

touch the hot wash liquor (e.g. if draining hot wash liquor into a

washbasin or if draining the washing machine in an emergency).

Allow detergent solution to cool down.

mCaution!

Risk of damaging appliance!

–Cover plate may break!

Do not climb on the washing machine.

–Opened washing machine door may break off or washing

machine may overturn!

Do not lean on the open washing machine door.

mCaution!

Danger when reaching into/gripping the rotating drum!

If you reach into the rotating drum, you may injure your hands.

Do not grip the rotating drum. Wait until the drum stops rotating.

mCaution!

Risk of coming into contact with liquid detergents/care products!

If the detergent drawer is opened while the washing machine is

running, detergent/care product may spray out.

Caution when opening the detergent drawer.

In case of eye/skin contact, rinse thoroughly.

If accidentally swallowed, seek medical advice.

mCaution!

Hazard due to detergent/softener running out of the dispensers!

Leaking detergent/softener may impair the function of the appliance,

e.g. damage to electronics.

Before transporting the appliance, always drain dispensers.

Protection of the environment

Packaging/Old appliance

Hints and tips

ØUtilise the maximum amount of washing for the particular

programme.

ØWash normally soiled washing without Pre-wash.

ØDetergent dosage using the intelligent dosing system helps

save detergent and water.

ØEnergy saving mode: The display panel light goes out after

several minutes, inicio/pausa+carga

(Start/Pause+Reload) Üflashes. To activate the light, select

any button.

The energy-saving mode is not activated if a programme is

running.

ØThe selectable temperatures apply to the care labels on the

textiles. The temperatures in the machine may deviate from

this so that you get the optimum mix of energy-saving and

washing results.

ØAutomatic switch off: If the appliance is not operated for a

prolonged period, it automatically switches off before the

programme starts and when the programme has ended to

save energy. Switch on by pressing main switch # button.

ØIf the washing is then dried in the tumble dryer, select spin

speed according to the instructions of the dryer

manufacturer.

)Dispose of packaging in an environmentally friendly manner.

This appliance is labelled in accordance with European Directive

2012/19/EU concerning used electrical and electronic

appliances (waste electrical and electronic equipment - WEEE).

The guideline determines the framework for the return and

recycling of used appliances as applicable throughout the EU.

The main points in brief

1@@@

Insert mains plug.

Turn the tap on.

Open the washing

machine door.

To switch on, press

the #button.

Select the

programme, e.g.

algodón/algodão

(Cottons).

2@ @

Dosage: automatic ú

Please load laundry: max. 9kg

Sort the washing. Insert the washing. Do not exceed maximum load.

3@ @

Close the washing

machine door.

If required, change programme settings of the

selected programme and select programme

settings/options.

Select inicio/

pausa+carga Ü

(Start/

Pause+Reload).

FODFN

4@ @

vFinished, remove washing

End of the programme For switching the

machine on, press

the # button.

Turn off the mains

supply (for models

without Aqua-Stop).

Getting to know your appliance

2SHUDWLQJ

HOHPHQWV

'LVSOD\

HOHPHQWV

'UXPOLJKW

GHSHQGLQJ

RQPRGHO

'RRU

6HUYLFHIODS

'HWHUJHQWGUDZHU

2SHQLQJ DQGFORVLQJWKHGRRU 6HUYLFHIODS

FODFN

Detergent drawer

Intelligent Dosing System (i-Dos):

Your washing machine features an intelligent dosing system for liquid detergent and

softener. Dispensers i-Dos ô(1.3 l) and i-Dos iIô(0.5 l) in the detergent drawer are

used for this. You can select whether you want to use one liquid detergent and one

softener or two liquid detergents.

Depending on the selected programme and settings, the optimum amounts of detergent/

softener are dosed via the i-Dos containers.

At the factory the dosage has been preset for:

– i-Dos ô¨detergent for lightly soiled washing and

– i-Dos iIô©softener for normally soft washing.

Overview of the i-Dos settings starting on ~Page 22

¼ü 





½0ðð

Dispenser ôfor intelligent dosage: liquid detergent

Dispenser iôfor intelligent dosage: softener or liquid detergent

Dispenser ÀÁfor manual dosage. ~Page 37
