Siemens RWB27Si Manuel utilisateur

RWB27Si Timeswitch

Daily Programming

RWB27Si Controls

MENU/SELEC

RESE

WHEN LI

EX END

ADVANCE

BACK/EXI

UP & DOWN

Introduction

This booklet gives you easy to follow instructions allowing you to

set your RWB27Si Timeswitch to the Daily, (same ON/OFF times

each day) program.

Contents

How do I change/set the ON/OFF times?

How do I review the current ON/OFF times?

What do the switching options mean?

How do I select my Switching Options?

How do I set my holiday program?

How do I activate my holiday program?

What do the buttons do?

What does the Boiler Service Interval Reminder do?

Notes on RWB27Si settings.

To make it easier to follow, the buttons you should be using

are coloured grey.

RWB27Si Daily

At first installation

display will show as

above unless reset is

activated.

At first installation

display will show as

above when reset is

activated.

3:37

CH OFF MAN

10:32

Mon Tue Wed

How do I change/set the

ON/OFF times?

• Press left hand button MENU

• Press top middle button

until SET PROGRAM is shown

• Press left hand button SE ECT

display will show

(continued on next page)

3:37

CH OFF MAN

SET PROGRAM

SELECT EXIT

CH OFF MAN

3:37

SET 1st ON

SELECT BACK

8:30

3:37

To change 1st ON time press

SE ECT,time will flash, change

times by using +/- , when

desired time is in the display press

ENTER display will show

• Repeat as above until last OFF

time is entered

display will show

press EXIT to return to MENU

SET THE TIME

ENTER +/- BACK

12:00

SET PROGRAM

SELECT EXIT

10:30

3:37

SET 1st OFF

SELECT BACK

10:30

3:37

How do I review the current

ON/OFF times?

• Press left hand button MENU

• Press top middle button

until REVIEW PROG is shown

• Press left hand button SE ECT

• 1st ON time will be shown

(continued on next page)

REVIEW PROG

SELECT EXIT

VIEW 1st ON

BACK

3:37

CH OFF MAN

3:37

8:30

3:37

• Press top middle button

1st OFF will be shown

• Continue above two actions until

last OFF is shown

• Press right hand button BACK

then press again EXIT

(this will return you to MENU)

VIEW 1st OFF

BACK

10:30

3:37

VIEW 2 d OFF

BACK

11:30

3:37

REVIEW PROG

SELECT EXIT

3:37

What do the switching options mean?

AUTO

This means that the RWB27Si will switch ON and OFF according to

the programmed times

MANUA OFF

This means that the RWB27Si will be permanently OFF

MANUA ON

This means that the RWB27Si will be permanently ON

ONCE

This means that the RWB27Si will switch ON at the first ON time

and switch OFF at the last OFF time you have programmed

ignoring any ON/OFF times in between. This is also referred to as

All Day.

How do I select my four

switching options?

• Press left hand button MENU

Display shows

• Press left hand button SE ECT

twice, Display shows

• Press top middle button until

your switching option is displayed

AUTO*

MANUA OFF*

MANUA ON*

ONCE*

*see previous page for details

• Choose desired option by pressing

ENTER

(continued on next page)

AUTO

ENTER BACK

MANUAL OFF

ENTER BACK

SET STATUS

SELECT EXIT

CH OFF MAN

3:37
