Building Technologies

Fire safety and security products

FDT181 Heat Detector

Product Manual

Overview

The heat detector FDT181 is an intelligent detector. It is used for early fire detection

inside a building.

Characteristics

– With built-in CPU, signals received are processed by intelligent algorithm

– Two operation modes: A2S/A2R

– Automatically address setting without encoder setting or DIP switch

– All-around visible alarm indicator

– Resistant to environment and interference factors such as humidity, corrosive and

vibration, with immunity against electro-magnetic interference.

– Communication via FD18-BUS, polarity free connection

– “Sticker Method” easy for commissioning

Functions

– The detection behavior of the detectors is influenced by the operation mode, so that

it can be specifically adjusted according to the environment to be monitored

– Unique ID of each detector, controller can identify the detector type according to the

ID and assign address

Building Technologies

A6V10326261_d_en_--

Fire safety and security products

07.2012

Application

– Suitable for use in places where the ambient temperature can change rapidly or

smoke detector are not suitable

– Dust cap protects the detector from being contaminated by construction work

Indicator

The detector is provided with an internal alarm indicator to show its operating status.

Status

Indicator

Normal

Off

Flashing when connected with FC1840-A3 (for Russian).

Locate/Test

Flashing

Alarm

Steady on

Installation

Easy and time-saving mounting

Install the base and finish the wiring during the construction phase.

1. Point the retaining nest to the positioning pointer and insert it into the base.

2. Turn it clock wisely until it stops.

Uninstallation:

1. Turn it counterclockwisely until it stops.

2. Pull the detector out.

After all the construction is finished, the dust cap must be taken away!

Dimensions

In：mm（with base）

Detector

Retaining nest

Base

Positioning pointer

Building Technologies

A6V10326261_d_en_--

Fire safety and security products

07.2012

Connection diagram

51a

6 1b

To next base

Terminal resistor

is not necessary

To controller

FDB181 Base

Maintenance

Performance test

Recommendation:

– Submit all detectors to an annual visual check. Detectors that are strongly soiled or

mechanically damaged must be replaced.

– Any detectors should be replaced after 7 to 10 years of service, independent from

the environmental conditions.

– Long term auxiliary detectors should be stored with plastic bag.

– Carry out heat test each year.

Technical data

Operating voltage

12 … 32 VDC

Operating current (quiescent)

0.26 mA

Activation current

1.2 mA

Operating temperature

–10 ... +50 °C

Storage temperature

–20 ... +75 °C

Humidity

≤96% (40±2 ℃)

Communication protocol

FD18-BUS

Load factor

Color

White, RAL 9010

Protection category EN60529 / IEC529/GB4208-93

IP44

Approval (for Russian) TR RF N123-FZ

Details for ordering

Type

Material No.

Part No.

Designation

Weight

FDT181

S54320-F3-A1

100856212

Heat detector

0.064Kg

FDB181

S54320-F1-A1

100856213

Detector base

0.027Kg

A5Q00022001

100566011

FDT181 dust cap

Beijing Siemens Cerberus Electronics Limited

No.1,Fengzhidonglu, Xibeiwang, HaiDian District,

Beijing, 100094, China

Tel: +10 6476 8806

Fax: +10 6476 8899

Doc No.

A6V10326261_d_en_--

Manual FD18

Edition

07.2012

100858265
