Siemens CRM-4 Manuel utilisateur

P/N 315-090853-7

The Model CRM-4 Controllable Relay Module

from Siemens Industry, Inc. provides

auxiliary

control of building functions such as door holder

release, elevator capture, smoke control, lock

release, etc.

OPERATION

Each CRM-4 module provides four fully program-

mable relays. Each relay contains one set

SPDT contacts rated at 2A, 30 VDC/120 VAC

resistive. All relay coils are supervised in a de-

energized state to provide proper operation.

Individual relays can be automatically activated

or deactivated through control by event and time

based logic contained in the MXL. Each relay

may also be either manually controlled or may

be disarmed through the MXL keypad. When

any relay is disarmed, the LCD annunciator

indicates the affected relay, and the PARTIAL

SYSTEM DISABLE and TROUBLE indicators

light until the relay is returned to an armed

condition.

Four LEDs are provided on the CRM-4. Two

diagnostic LEDs provide positive indication of

the CRM-4’s network communication. The

other two are user programmable through the

MXL software.

For additional information, refer to the

MXL/MXLV Manual, P/N 315-092036.

Figure 1

MOM-4 Slots for the CRM-4

Installation Instructions

Model CRM-4

Controllable Relay Module

Siemens Industry, Inc.

Building Technologies Division

Florham Park, NJ

Siemens Building Technologies, Ltd.

Fire Safety & Security Products

2 Kenview Boulevard

Brampton, Ontario

L6T 5E4 Canada

INSTALLATION

Remove all system power before installation,

first battery and then AC. (To power up, con-

nect the AC first and then the battery.)

The CRM-4 module plugs into one slot on the

MOM-4 Expansion module. There are four avail-

able slots for the CRM-4 on the MOM-4 (See

Figure 1).

Selecting which position on the MOM-4

to use for a CRM-4 determines which contacts

are available: TB1, TB2, TB3, or TB4.

Setting the Address

Before the CRM-4 is installed in the MOM-4, set

the network address on dipswitch S1 (See Figure

2). Set the network address to the address

selected in the CSG-M. Refer to Table 1 on the

back for the correct switch settings for that address.

Device Addresses on Module

The device addresses on the module are as follows:

Relay 1 01

Relay 2 02

Relay 3 03

Relay 4 04

LED 1 05

LED 2 06

Terminal Block Cover

The CRM-4 is shipped with a protective cover for

the MOM-4 terminal block used for that CRM-4

installation. To install this cover, remove the screw

and clamp assembly from position 8 on the MOM-4

terminal block used. Place the cover over the

terminal block and fasten it into position 8 with the

nylon thumb screw provided.

Mounting the CRM-4

The CRM-4 module has a card guide that must be

installed into the MOM-4 (See Figure 4). To install

the card guide:

1. Loosen the appropriate screw in the center

of the MOM-4 and set the card guide in place.

2. Make sure that the locating pin on the bottom

of the card guide is in the hole on the MOM-4.

3. Tighten the screw on the MOM-4 to secure

the card guide.

Then install the CRM-4 in the MOM-4, being sure

that the module is firmly seated in the card edge

connector.

ELECTRICAL INFORMATION

Electrical connections and ratings for the four

relays are shown in Figure 3.

Figure 2

CRM-4 PC Board

tnerruCeludoMCDV5evitcAAm01

tnerruCeludoMCDV42evitcA Am81 yalerevitcarep

tnerruCeludoMCDV42ybdnatS Am5

)

syalerevitcaon(

Figure 4

Installing a Card Guide

Figure 3

CRM-4 Relay Wiring

NOTE: RELAYS K1 - K4 ARE PROGRAMMABLE.

P/N 315-090853-7

TABLE 1

NETWORK ADDRESS PROGRAMMING

ADDR 87654321 ADDR 87654321 ADDR 87654321 ADDR 87654321

000 ILLEGAL 064 OXOOOOOO 128 XOOOOOOO 192 XXOOOOOO

001 ILLEGAL 065 OXOOOOOX 129 XOOOOOOX 193 XXOOOOOX

002 ILLEGAL 066 OXOOOOXO 130 XOOOOOXO 194 XXOOOOXO

003

004

005

006

007

008

009

010

011

012

013

014

015

016

017

018

019

020

021

022

023

024

025

026

027

028

029

030

031

032

033

034

035

036

037

038

039

040

041

042

043

044

045

046

047

048

049

050

051

052

053

054

055

OOOOOOXX

OOOOOXOO

OOOOOXOX

OOOOOXXO

OOOOOXXX

OOOOXOOO

OOOOXOOX

OOOOXOXO

OOOOXOXX

OOOOXXOO

OOOOXXOX

OOOOXXXO

OOOOXXXX

OOOXOOOO

OOOXOOOX

OOOXOOXO

OOOXOOXX

OOOXOXOO

OOOXOXOX

OOOXOXXO

OOOXOXXX

OOOXXOOO

OOOXXOOX

OOOXXOXO

OOOXXOXX

OOOXXXOO

OOOXXXOX

OOOXXXXO

OOOXXXXX

OOXOOOOO

OOXOOOOX

OOXOOOXO

OOXOOOXX

OOXOOXOO

OOXOOXOX

OOXOOXXO

OOXOOXXX

OOXOXOOO

OOXOXOOX

OOXOXOXO

OOXOXOXX

OOXOXXOO

OOXOXXOX

OOXOXXXO

OOXOXXXX

OOXXOOOO

OOXXOOOX

OOXXOOXO

OOXXOOXX

OOXXOXOO

OOXXOXOX

OOXXOXXO

OOXXOXXX

067

068

069

070

071

072

073

074

075

076

077

078

079

080

081

082

083

084

085

086

087

088

089

090

091

092

093

094

095

096

097

098

099

100

101

102

103

104

105

106

107

108

109

110

111

112

113

114

115

116

117

118

119

OXOOOOXX

OXOOOXOO

OXOOOXOX

OXOOOXXO

OXOOOXXX

OXOOXOOO

OXOOXOOX

OXOOXOXO

OXOOXOXX

OXOOXXOO

OXOOXXOX

OXOOXXXO

OXOOXXXX

OXOXOOOO

OXOXOOOX

OXOXOOXO

OXOXOOXX

OXOXOXOO

OXOXOXOX

OXOXOXXO

OXOXOXXX

OXOXXOOO

OXOXXOOX

OXOXXOXO

OXOXXOXX

OXOXXXOO

OXOXXXOX

OXOXXXXO

OXOXXXXX

OXXOOOOO

OXXOOOOX

OXXOOOXO

OXXOOOXX

OXXOOXOO

OXXOOXOX

OXXOOXXO

OXXOOXXX

OXXOXOOO

OXXOXOOX

OXXOXOXO

OXXOXOXX

OXXOXXOO

OXXOXXOX

OXXOXXXO

OXXOXXXX

OXXXOOOO

OXXXOOOX

OXXXOOXO

OXXXOOXX

OXXXOXOO

OXXXOXOX

OXXXOXXO

OXXXOXXX

131

132

133

134

135

136

137

138

139

140

141

142

143

144

145

146

147

148

149

150

151

152

153

154

155

156

157

158

159

160

161

162

163

164

165

166

167

168

169

170

171

172

173

174

175

176

177

178

179

180

181

182

183

XOOOOOXX

XOOOOXOO

XOOOOXOX

XOOOOXXO

XOOOOXXX

XOOOXOOO

XOOOXOOX

XOOOXOXO

XOOOXOXX

XOOOXXOO

XOOOXXOX

XOOOXXXO

XOOOXXXX

XOOXOOOO

XOOXOOOX

XOOXOOXO

XOOXOOXX

XOOXOXOO

XOOXOXOX

XOOXOXXO

XOOXOXXX

XOOXXOOO

XOOXXOOX

XOOXXOXO

XOOXXOXX

XOOXXXOO

XOOXXXOX

XOOXXXXO

XOOXXXXX

XOXOOOOO

XOXOOOOX

XOXOOOXO

XOXOOOXX

XOXOOXOO

XOXOOXOX

XOXOOXXO

XOXOOXXX

XOXOXOOO

XOXOXOOX

XOXOXOXO

XOXOXOXX

XOXOXXOO

XOXOXXOX

XOXOXXXO

XOXOXXXX

XOXXOOOO

XOXXOOOX

XOXXOOXO

XOXXOOXX

XOXXOXOO

XOXXOXOX

XOXXOXXO

XOXXOXXX

195

196

197

198

199

200

201

202

203

204

205

206

207

208

209

210

211

212

213

214

215

216

217

218

219

220

221

222

223

224

225

226

227

228

229

230

231

232

233

234

235

236

237

238

239

240

241

242

243

244

245

246

247

XXOOOOXX

XXOOOXOO

XXOOOXOX

XXOOOXXO

XXOOOXXX

XXOOXOOO

XXOOXOOX

XXOOXOXO

XXOOXOXX

XXOOXXOO

XXOOXXOX

XXOOXXXO

XXOOXXXX

XXOXOOOO

XXOXOOOX

XXOXOOXO

XXOXOOXX

XXOXOXOO

XXOXOXOX

XXOXOXXO

XXOXOXXX

XXOXXOOO

XXOXXOOX

XXOXXOXO

XXOXXOXX

XXOXXXOO

XXOXXXOX

XXOXXXXO

XXOXXXXX

XXXOOOOO

XXXOOOOX

XXXOOOXO

XXXOOOXX

XXXOOXOO

XXXOOXOX

XXXOOXXO

XXXOOXXX

XXXOXOOO

XXXOXOOX

XXXOXOXO

XXXOXOXX

XXXOXXOO

XXXOXXOX

XXXOXXXO

XXXOXXXX

XXXXOOOO

XXXXOOOX

XXXXOOXO

XXXXOOXX

XXXXOXOO

XXXXOXOX

XXXXOXXO

XXXXOXXX

056 OOXXXOOO 120 OXXXXOOO 184 XOXXXOOO 248 ILLEGAL

057 OOXXXOOX 121 OXXXXOOX 185 XOXXXOOX 249 ILLEGAL

058 OOXXXOXO 122 OXXXXOXO 186 XOXXXOXO 250 ILLEGAL

059 OOXXXOXX 123 OXXXXOXX 187 XOXXXOXX 251 ILLEGAL

060 OOXXXXOO 124 OXXXXXOO 188 XOXXXXOO 252 ILLEGAL

061 OOXXXXOX 125 OXXXXXOX 189 XOXXXXOX 253 ILLEGAL

062 OOXXXXXO 126 OXXXXXXO 190 XOXXXXXO 254 ILLEGAL

063 OOXXXXXX 127 OXXXXXXX 191 XOXXXXXX 255 ILLEGAL

O = OPEN (or OFF) X = CLOSED ( or ON

)
