Fridge-freezer

KU..R..

en Table of Contents

Safety and warning information ........... 3

Information concerning disposal ......... 6

Scope of delivery ................................... 6

Ambient temperature

and ventilation ........................................ 7

Installation location ................................ 7

Connecting the appliance .................... 8

Getting to know your appliance .......... 8

Switching the appliance on .................. 9

Setting the temperature ........................ 9

Usable capacity ...................................... 9

Refrigerator compartment .................... 9

Interior fittings ....................................... 10

Sticker “OK” .......................................... 11

Switching off and

disconnecting the appliance ............. 11

Defrosting .............................................. 11

Cleaning the appliance ....................... 11

Tips for saving energy ........................ 12

Operating noises ................................. 13

Eliminating minor faults yourself ....... 13

Customer service ................................. 14

enTable of Contents

enInstruction for Use

Safety and warning

information

Before you switch ON the

appliance

Please read the operating and

installation instructions carefully!

They contain important

information on how to install,

use and maintain the appliance.

The manufacturer is not liable if

you fail to comply with the

instructions and warnings.

Retain all documents for

subsequent use or for the next

owner.

Technical safety

The appliance contains a small

quantity of environmentally

friendly but flammable

refrigerant R600a. Ensure that

the tubing of the refrigerant

circuit is not damaged during

transportation and installation.

Leaking refrigerant may cause

eye injuries or ignite.

If damage has occurred

■Keep naked flames and/or

ignition sources away from the

appliance,

■thoroughly ventilate the room

for several minutes,

■switch off the appliance and

pull out the mains plug,

■inform customer service.

The more refrigerant an

appliance contains, the larger

the room must be in which the

appliance is situated. Leaking

refrigerant can form a

flammable gas-air mixture in

rooms which are too small.

The room must be at least 1 m³

per 8 g of refrigerant. The

amount of refrigerant in your

appliance is indicated on the

rating plate inside the appliance.

If the power cord of this

appliance is damaged, it must

be replaced by the

manufacturer, customer service

or a similarly qualified person.

Improper installations

and repairs may put the user

at considerable risk.

Repairs may be performed by

the manufacturer, customer

service or a similarly qualified

person only.

Only original parts supplied by

the manufacturer may be used.

The manufacturer guarantees

that only these parts satisfy the

safety requirements.

A extension cable may be

purchased from customer

service only.

Important information when

using the appliance

■Never use electrical

appliances inside the

appliance (e.g. heater, electric

ice maker, etc.). Explosion

hazard!

■Never defrost or clean the

appliance with a steam

cleaner! The steam may

penetrate electrical parts and

cause a short-circuit. Risk

of electric shock!

■Do not use pointed or sharp-

edged implements to remove

frost or layers of ice. You

could damage the refrigerant

tubes. Leaking refrigerant may

cause eye injuries or ignite.

■Do not store products which

contain flammable propellants

(e.g. spray cans) or explosive

substances in the appliance.

Explosion hazard!

■Do not stand on or lean

heavily against base

of appliance, drawers

or doors, etc

■For defrosting and cleaning,

pull the mains plug out or

switch off the fuse. Do not pull

out the mains plug by tugging

on the power cord.

■Store high-percentage alcohol

tightly closed and standing up.

■Keep plastic parts and the

door seal free of oil and

grease. Otherwise, parts and

door seal will become

porous.

■Never cover or block the

ventilation openings of the

appliance!

■Avoiding placing children

and vulnerable people at

risk:

At risk are children, people

who have limited physical,

mental or sensory abilities, as

well as people who have

inadequate knowledge

concerning safe operation of

the appliance.

Ensure that children and

vulnerable people have

understood the hazards.

A person responsible for

safety must supervise or

instruct children and

vulnerable people who are

using the appliance.

Only children from 8 years

and above may use the

appliance.

Supervise children who are

cleaning and maintaining the

appliance.

Never allow children to play

with the appliance.

Children in the household

■Keep children away from

packaging and its parts.

Danger of suffocation from

folding cartons and plastic

film!

■Do not allow children to play

with the appliance!

■If the appliance features a

lock:

keep the key out of the reach

of children!

General regulations

The appliance is suitable for

refrigerating food.

This appliance is intended for

use in the home and the home

environment.

The appliance is suppressed

according to EU Directive

2004/108/EC.

The refrigeration circuit has

been checked for leaks.

This product complies with

the relevant safety regulations

for electrical appliances

(EN 60335-2-24).

This appliance is intended for

use up to a maximum height of

2000 metres above sea level.

Information concerning

disposal

*Disposal of packaging

The packaging protects your appliance

from damage during transit. All utilised

materials are environmentally safe and

recyclable. Please help us by disposing

of the packaging in an environmentally

friendly manner.

Please ask your dealer or inquire at your

local authority about current means of

disposal.

*Disposal of your old

appliance

Old appliances are not worthless

rubbish! Valuable raw materials can be

reclaimed by recycling old appliances.

m Warning

Redundant appliances

1. Pull out the mains plug.

2. Cut off the power cord and discard

with the mains plug.

3. Do not take out the trays

and receptacles: children are

therefore prevented from climbing in!

4. Do not allow children to play with

the appliance once it has spent its

useful life. Danger of suffocation!

Refrigerators contain refrigerant

and gases in the insulation. Refrigerant

and gases must be disposed

of professionally. Ensure that tubing

of the refrigerant circuit is not damaged

prior to proper disposal.

Scope of delivery

After unpacking all parts, check for any

damage in transit.

If you have any complaints, please

contact the dealer from whom you

purchased the appliance or our

customer service.

The delivery consists of the following

parts:

■Built-under appliance

■Interior fittings (depending on model)

■Bag containing installation materials

■Operating instructions

■Installation manual

■Customer service booklet

■Warranty enclosure

■Information on the energy

consumption and noises

This appliance is labelled in

accordance with European

Directive 2012/19/EU concerning

used electrical and electronic

appliances (waste electrical and

electronic equipment - WEEE).

The guideline determines the

framework for the return and

recycling of used appliances as

applicable throughout the EU.



Ambient temperature

and ventilation

Ambient temperature

The appliance is designed for a specific

climate class. Depending on the climate

class, the appliance can be operated at

the following temperatures.

The climate class can be found on

the rating plate. Fig. -

Note

The appliance is fully functional within

the room temperature limits

of the indicated climatic class. If

an appliance of climatic class SN

is operated at colder room temperatures,

the appliance will not be damaged up to

a temperature of +5 °C.

Ventilation

Fig. !/6

The refrigeration unit is ventilated only via

the ventilation grille in the base. Never

cover the ventilation grille or place

anything in front of it. Otherwise

the refrigeration unit must work harder,

increasing the power consumption.

Installation location

Install the appliance in a dry, well

ventilated room. The installation location

should neither be exposed to direct

sunlight nor near a heat source,

e. g. a cooker, radiator, etc. If installation

next to a heat source is unavoidable, use

a suitable insulating plate or observe

the following minimum distances to a

heat source:

■3 cm to electric or gas cookers.

■30 cm to an oil or coal-fired cooker.

Undercounter

An attachment under certain worktops,

e.g. stone, glass or stainless steel, is

frequently not possible. You can order

accessories from customer service for

installation on the side walls.

Climate

class

Permitted ambient

temperature

SN +10 °C to 32 °C

N+16 °C to 32 °C

ST +16 °C to 38 °C

T+16 °C to 43 °C

Connecting

the appliance

After installing the appliance, wait at least

1 hour until the appliance is switched on.

During transportation the oil in

the compressor may have flowed into

the refrigeration system.

Before switching on the appliance for

the first time, clean the interior of

the appliance (see chapter “Cleaning

the appliance”).

Electrical connection

The socket must be near the appliance

and also freely accessible following

installation of the appliance.

The appliance complies with the

protection class I. Connect the appliance

to 220–240 V/50 Hz alternating current

via a correctly installed socket with

protective conductor. The socket must

be fused with a 10 to 16 A fuse.

For appliances operated in non-

European countries, check whether the

stated voltage and current type match

the values of your mains supply. This

information can be found on the rating

plate. Fig. -

Getting to know your

appliance

Please fold out the illustrated last page.

These operating instructions refer

to several models.

The features of the models may vary.

The diagrams may differ.

Fig. !

1 Light switch

2 Temperature controller/light

3 Glass shelf in the refrigerator

compartment

4 Pull-out container

5 Vegetable container

6 Ventilation opening

7 Shelf for butter and cheese

8 Egg rack

9 Shelf for large bottles

Switching

the appliance on

Turn temperature controller, Fig. "/A,

from position “0”. The appliance begins

to cool. Light is switched on when

the door is open.

Operating tips

The refrigerator compartment

temperature rises:

■if the appliance door is opened

frequently,

■if large quantities of food are placed in

the refrigerator compartment,

■if the ambient temperature is high.

Setting

the temperature

Turn temperature controller, Fig. "/A, to

the required setting.

When the controller is at a medium

setting, the temperature drops

to approx. +4 °C in the coldest zone.

Fig. #

Higher settings lower the temperature in

the refrigerator compartment.

We recommend:

■Perishable food should not be stored

above +4 °C.

■Low setting for short-term

storage of food (energy-saving mode).

■Medium setting for long-term storage

of food.

■Select a higher setting only

temporarily, when the door is

frequently opened or large quantities

are placed in the refrigerator

compartment.

Refrigeration capacity

The temperature in the refrigerator

compartment may rise temporarily if

large amounts of food or a lot of drinks

are placed inside.

Therefore the temperature controller

should be set to a higher setting for

approx. 7 hours.

Usable capacity

Information on the usable capacity can

be found inside your appliance on

the rating plate. Fig. -

Refrigerator

compartment

The refrigerator compartment is the ideal

storage location for ready meals, cakes

and pastries, preserved food, condensed

milk, hard cheese, fruit and vegetables

sensitive to cold.

Note when loading products

Wrap or cover food before placing

in the appliance. This will retain

the aroma, colour and freshness

of the food. In addition, flavours will not

be transferred between foods

and the plastic parts will not become

discoloured.

Note

Avoid contact between food and rear

panel. Otherwise the air circulation will

be impaired.

Food or packaging could freeze

to the rear panel.

Note the chill zones

in the refrigerator

compartment

The air circulation in the refrigerator

compartment creates different chill

zones:

■Coldest zone is in the pull-out

container. Fig. #

Note

Store perishable food (e.g. fish,

sausage, meat) in the coldest zone.

■Warmest zone is at the very top

of the door.

Note

Store e.g. hard cheese and butter

in the warmest zone. Cheese can then

continue to release its flavour and the

butter will still be easy to spread.

Interior fittings

You can reposition the shelves inside

the appliance and the door shelves as

required:

■Lift the glass shelves, pull forwards,

lower and swivel out to the side.

Fig. $

■Reposition stoppers and re-insert

shelf. Fig. %

■Lift the door shelf and remove. Fig. &

Special features

(not all models)

Pull-out container

Fig. '

The pull-out container is especially

suitable for the storage of foods which

contain meat. It can be taken out for

loading, unloading and cleaning.

Vegetable container with cover

Fig. (

The vegetable container can be taken

out for loading, unloading and cleaning.

Bottle holder

Fig. )

The bottle holder prevents bottles from

falling over when the door is opened

and closed.

Autres manuels pour KU..R.. series

Table des matières

Autres manuels Siemens Réfrigérateur

Siemens

Siemens KG49NH90GB Manuel utilisateur

Siemens

Siemens KD46NVI20N Manuel utilisateur

Siemens

Siemens KI38LA50GB Manuel utilisateur

Siemens

Siemens KI81RAF31I Manuel utilisateur

Siemens

Siemens KG39NLB35 Manuel utilisateur

Siemens

Siemens KG..N.. Manuel utilisateur

Siemens

Siemens KA58NP95 Feuille d'instructions

Siemens

Siemens iQ300 KI85NH Series Fiche technique

Siemens

Siemens KI42F Manuel utilisateur

Siemens

Siemens KG series N Manuel utilisateur

Siemens

Siemens S18ID Series Guide d'installation

Siemens

Siemens KI32L series Manuel utilisateur

Siemens

Siemens KI81RAFE0 Manuel utilisateur

Siemens

Siemens KS**V SERIES Manuel utilisateur

Siemens

Siemens iQ100 KG N Series Manuel utilisateur

Siemens

Siemens iQ300 KS36VVWEP/01 Manuel utilisateur

Siemens

Siemens KI86V Series Manuel utilisateur

Siemens

Siemens iQ300 KA90N Series Manuel d'utilisation

Siemens

Siemens KI96NV Series Fiche technique

Siemens

Siemens KI81FHDD0 Manuel utilisateur

Siemens

Siemens KI..L38 SERIES Manuel utilisateur

Siemens

Siemens iQ500 KF96N Series Fiche technique

Siemens

Siemens KI81FH Series Manuel utilisateur

Siemens

Siemens IQ700 KA N Series Guide de configuration

Manuels Réfrigérateur populaires d'autres marques

Bonnet Neve

Bonnet Neve SKYVIEW PLUS Manuel utilisateur

Zanussi Electrolux

Zanussi Electrolux ZERB 8441 Manuel utilisateur

Sharp

Sharp SJ-BA31IEXW2-EU Manuel utilisateur

CORBERO

CORBERO CC2300MCW Manuel utilisateur

KitchenAid

KitchenAid 2205264 Manuel utilisateur

Stengel

Stengel KU 1101 A++ Manuel utilisateur

NEFF

NEFF KI181 Series Manuel utilisateur

Hoshizaki

Hoshizaki Reach-In Manuel utilisateur

Amana

Amana ASD2524VES00 Manuel utilisateur

BOMANN

BOMANN KGC 213 Manuel utilisateur

Danby

Danby DAR044A1SLDD Instructions de montage

Samsung

Samsung RF323TE Manuel utilisateur

Beko

Beko CSA31022 Manuel utilisateur

IKEA

IKEA FROSTIG C 185 E Manuel utilisateur

Electrolux

Electrolux ER 6821 D Manuel utilisateur

True

True TS-28 Manuel utilisateur

Frigidaire

Frigidaire FSC23R5DW9 Manuel utilisateur

Beko

Beko LSP4579W Manuel utilisateur
