Siemens KF..L SERIES Manuel utilisateur

fr Notice d'utilisation

Réfrigérateur / Congélateur combiné

KI..L.. / KF..L..

Fridge-freezer

User manual

en Table of Contents

Safety and warning information ............ 3

Information concerning disposal .......... 5

Scope of delivery .................................... 5

Observe ambient temperature

and ventilation ......................................... 6

Installation location ................................. 6

Connecting the appliance ..................... 7

Getting to know your appliance ........... 7

Switching the appliance on ................... 8

Setting the temperature ......................... 8

Usable capacity ....................................... 8

Refrigerator compartment ..................... 9

The freezer compartment ...................... 9

Max. freezing capacity ........................... 9

Freezing and storing food .................. 10

Freezing fresh food ............................. 10

Thawing frozen food ............................ 11

Interior fittings ....................................... 11

Sticker “OK” .......................................... 11

Switching off and disconnecting

the appliance ........................................ 12

Defrosting .............................................. 12

Cleaning the appliance ....................... 13

Tips for saving energy ........................ 14

Operating noises ................................. 14

Eliminating minor faults yourself ....... 15

Customer service ................................. 17

fr Table des matières

Prescriptions-d'hygiène-alimentaire .. 18

Consignes de sécurité

et avertissements ................................. 19

Conseil pour la mise au rebut ........... 21

Étendue des fournitures ..................... 22

Contrôler la température ambiante

et l'aération ............................................ 22

Lieu d'installation .................................. 23

Branchement de l’appareil ................. 23

Présentation de l’appareil ................... 24

Enclenchement de l’appareil ............. 24

Réglage de la température ................ 24

Contenance utile .................................. 25

Le compartiment réfrigérateur ........... 25

Le compartiment congélateur ............ 26

Capacité de congélation maximale .. 26

Congélation et rangement ................. 26

Congélation de produits frais ............ 26

Décongélation des produits .............. 28

Equipement ........................................... 28

Autocollant « OK » ............................... 28

Arrêt et remisage de l'appareil .......... 28

Si vous dégivrez l'appareil ................. 29

Nettoyage de l’appareil ...................... 30

Economies d’énergie .......................... 31

Bruits de fonctionnement ................... 31

Remédier soi même aux

petites pannes ...................................... 32

Service après-vente ............................. 34

enTable of Contents

enInstruction for Use

Safety and warning

information

Before you switch ON

the appliance

Please read the operating

and installation instructions carefully.

They contain important

information on how to install, use

and maintain the appliance.

Retain all documents for subsequent use

or for the next owner.

Technical safety

This appliance contains a small quantity

of environmentally-friendly but flammable

R600a refrigerant. Ensure that the tubing

of the refrigerant circuit is not damaged

during transportation and installation.

Leaking refrigerant may cause eye

injuries or ignite.

If damage has occurred

■Keep naked flames and/or ignition

sources away from the appliance,

■thoroughly ventilate the room for

several minutes,

■switch off the appliance and pull out

the mains plug,

■inform customer service.

The more refrigerant an appliance

contains, the larger the room must be in

which the appliance is situated. Leaking

refrigerant can form a flammable gas-air

mixture in rooms which are too small.

The room must be at least 1 m³ per 8 g

of refrigerant. The amount of refrigerant

in your appliance is indicated on the

rating plate inside the appliance.

If the power cord of this appliance is

damaged, it must be replaced by the

manufacturer, customer service or a

similarly qualified person. Improper

installations and repairs may put the user

at considerable risk.

Repairs may be performed by the

manufacturer, customer service or a

similarly qualified person only.

Only original parts supplied by the

manufacturer may be used. The

manufacturer guarantees that only these

parts satisfy the safety requirements.

A power cable extension may be

purchased from customer service only.

Important information when

using the appliance

■Never use electrical appliances inside

the appliance (e.g. heater, electric ice

maker, etc.). Risk of explosion!

■Never use a steam cleaner to defrost

or clean the appliance! The steam

may penetrate electrical parts

and cause a short-circuit. Risk of

electric shock!

■Do not use pointed or sharp-edged

implements to remove frost or layers

of ice. You could damage

the refrigerant tubing. Leaking

refrigerant may ignite or cause eye

injuries.

■Do not store products which contain

flammable propellants (e.g. spray

cans) or explosive substances in

the appliance. Risk of explosion!

■Do not stand on or lean heavily

against base of appliance, drawers or

doors, etc

■Before defrosting and cleaning

the appliance, pull out the mains plug

or switch off the fuse. Do not pull out

the mains plug by tugging the cable.

■Bottles which contain a high

percentage of alcohol must be sealed

and stored in an upright position.

■Keep plastic parts and the door seal

free of oil and grease. Otherwise,

parts and door seal will become

porous.

■Never cover or block the ventilation

openings for the appliance.

■People (children incl.) who have

limited physical, sensory or mental

abilities or inadequate knowledge

must not use this appliance unless

they are supervised or given

meticulous instructions.

■Do not store bottled or canned drinks

(especially carbonated drinks) in

the freezer compartment. Bottles

and cans may explode!

■Never put frozen food straight from

the freezer compartment into your

mouth.

Risk of low-temperature burns!

■Avoid prolonged touching of frozen

food, ice or the evaporator pipes, etc.

Risk of low-temperature burns!

Children in the household

■Keep children away from packaging

and its parts.

Danger of suffocation from folding

cartons and plastic film!

■Do not allow children to play with the

appliance!

■If the appliance features a lock:

keep the key out of the reach of

children!

General regulations

The appliance is suitable

■for refrigerating and freezing food,

■for making ice.

This appliance is intended for use in

the home and the home environment.

The appliance is suppressed according

to EU Directive 2004/108/EC.

The refrigeration circuit has been

checked for leaks.

This product complies with the relevant

safety regulations for electrical

appliances (EN 60335-2-24).

Informationconcerning

disposal

*Disposal of packaging

The packaging protects your appliance

from damage during transit. All utilised

materials are environmentally safe and

recyclable. Please help us by disposing

of the packaging in an environmentally

friendly manner.

Please ask your dealer or inquire at your

local authority about current means of

disposal.

*Disposal of your old

appliance

Old appliances are not worthless

rubbish! Valuable raw materials

can be reclaimed by recycling old

appliances.

m Warning

Redundant appliances

1. Pull out the mains plug.

2. Cut off the power cord and discard

with the mains plug.

3. Do not take out the trays

and receptacles: children are

therefore prevented from climbing in!

4. Do not allow children to play

with the appliance once it has spent

ist useful life. Danger of suffocation!

Refrigerators contain refrigerant

and gases in the insulation. Refrigerant

and gases must be disposed of

professionally. Ensure that tubing of the

refrigerant circuit is not damaged prior

to proper disposal.

Scope of delivery

After unpacking all parts, check for any

damage in transit.

If you have any complaints, please

contact the dealer from whom you

purchased the appliance or our

customer service.

The delivery consists of the following

parts:

■Built-in appliance

■Interior fittings (depending on model)

■Operating instructions

■Installation manual

■Customer service booklet

■Warranty enclosure

■Information on the energy

consumption and noises

■Bag containing installation materials

This appliance is identified

according to the European

guideline 2002/96/EC on waste

electrical and electronic

equipment – WEEE. The directive

specifies the framework

for an EU-wide valid return

and re-use of old appliances.



Observe ambient

temperature

and ventilation

Ambient temperature

The appliance is designed for a specific

climatic class. Depending on the climatic

class, the appliance can be operated at

the following room temperatures.

The climatic class can be found on

the rating plate, Fig. ).

Room temperature switch

If the room temperature drops

below 16 °C, the freezer compartment

of appliances belonging to climatic

class SN may become too warm.

In an extreme case the frozen food may

thaw. To prevent this from happening,

switch on the room temperature switch.

As a result, the refrigerating unit

operates more frequently. The appliance

can now be operated at a room

temperature of +10 °C to +16 °C.

To switch on, press the room

temperature switch, Fig. "/B. Mark “0”

is no longer visible. The light inside

the appliance is lit at a reduced

luminosity.

To save energy, switch off the room

temperature switch as soon as the room

temperature exceeds +16 °C.

Ventilation

The air on the rear panel of

the appliance heats up. Conduction of

the heated air must not be obstructed.

Otherwise, the refrigeration unit must

work harder. This increases power

consumption. Therefore: Never cover

or block the ventilation openings!

Installation location

Install the appliance in a dry, well

ventilated room. The installation location

should neither be exposed to direct

sunlight nor near a heat source, e. g.

a cooker, radiator, etc. If installation next

to a heat source is unavoidable, use

a suitable insulating plate or observe

the following minimum distances to a

heat source:

■3 cm to electric or gas cookers.

■30 cm to an oil or coal-fired cooker.

Climatic class Permitted ambient

temperature

SN +10 °C to 32 °C

N+16 °C to 32 °C

ST +16 °C to 38 °C

T+16 °C to 43 °C

Connecting

the appliance

After installing the appliance, wait at least

1 hour until the appliance is switched on.

During transportation the oil in

the compressor may have flowed into

the refrigeration system.

Before switching on the appliance for

the first time, clean the interior of

the appliance (see chapter “Cleaning

the appliance”).

Electrical connection

The socket must be near the appliance

and also freely accessible following

installation of the appliance.

The appliance complies with the

protection class I. Connect the appliance

to 220–240 V/50 Hz alternating current

via a correctly installed socket with

protective conductor. The socket must

be fused with a 10 to 16 A fuse.

For appliances operated in non-

European countries, check whether the

stated voltage and current type match

the values of your mains supply match

the values of the mains supply. This

information can be found on the rating

plate. Fig. )

Getting to know your

appliance

Please fold out the illustrated last page.

These operating instructions refer

to several models.

The features of the models may vary.

The diagrams may differ.

Fig. !

1 Temperature controller/light

2 Light switch

3 Glass shelf in the refrigerator

compartment

4 Vegetable container

5 Door shelf

6 Shelf for large bottles

A Freezer section

B Refrigerator compartment

Switching

the appliance on

Turn temperature controller, Fig. "/A,

from position “0”. The appliance begins

to cool. Light is switched on when

the door is open.

Operating tips

The refrigerator compartment

temperature rises:

■if the appliance door is opened

frequently,

■if large quantities of food are placed in

the refrigerator compartment,

■if the ambient temperature is high.

Setting

the temperature

Turn temperature controller, Fig. "/A, to

the required setting.

When the controller is at a medium

setting, the temperature drops

to approx. +4 °C in the coldest zone.

Fig. #.

Higher settings lower the temperature in

the refrigerator and freezer

compartments.

We recommend:

■Perishable food should not be stored

above +4 °C.

■Low setting for short-term

storage of food (energy-saving mode).

■Medium setting for long-term storage

of food.

■Select a higher setting only

temporarily, when the door is

frequently opened or large quantities

are placed in the refrigerator

compartment.

Refrigeration capacity

The temperature in the refrigerator

compartment may rise temporarily if

large amounts of food or a lot of drinks

are placed inside.

Therefore the temperature controller

should be set to a higher setting for

approx. 7 hours.

Freezer compartment

The temperature in the freezer

compartment

depends on the temperature

in the refrigerator compartment.

Usable capacity

Information on the usable capacity

can be found inside your

appliance on the rating plate.

Refrigerator

compartment

The refrigerator compartment is the ideal

storage location for ready meals, cakes

and pastries, preserved food, condensed

milk, hard cheese, fruit and vegetables

sensitive to cold as well as tropical fruit.

Note when loading products:

Wrap or cover food before placing in

the appliance. This will retain the aroma,

colour and freshness of the food. In

addition, flavours will not be transferred

between foods and the plastic parts will

not become discoloured.

Note

Avoid contact between food and rear

panel. Otherwise the air circulation will

be impaired.

Food or packaging could freeze to

the rear panel.

Note the chill zones in

the refrigerator compartment!

The air circulation in the refrigerator

compartment creates different chill

zones:

■Coldest zone is between the arrow

stamped on the side and the glass

shelf situated below. Fig. #

Note

Store perishable food (e.g. fish,

sausage, meat) in the coldest zones.

■Warmest zone is at the very top of

the door.

Note

Store e.g. cheese and butter in

the warmest zone. When served,

the cheese will not have lost its flavour

and the butter will be easy to spread.

The freezer

compartment

Using the freezer compartment

■To store deep-frozen food.

■To make ice cubes.

■To freeze small quantities of food.

Note

Ensure that the freezer compartment

door has been closed properly. If

the door is open, the frozen food will

thaw. The freezer compartment will

become covered in thick ice. Also: waste

of energy due to high power

consumption!

The freezer compartment door engages

audibly.

Max. freezing capacity

Information about the max. freezing

capacity within 24 hours can be found

on the rating plate (see chapter

“Customer service”).

Freezing and storing

food

Purchasing frozen food

■Packaging must not be damaged.

■Use by the ”use by” date.

■Temperature in the supermarket

freezer must be –18 °C or lower.

■If possible, transport deep-frozen food

in a cool bag and place quickly in

the freezer compartment.

Freezing fresh food

Freeze fresh and undamaged food only.

To retain the best possible nutritional

value, flavour and colour, vegetables

should be blanched before freezing.

Aubergines, peppers, zucchini and

asparagus do not require blanching.

Literature on freezing and blanching

can be found in bookshops.

Note

Keep food which is to be frozen away

from food which is already frozen.

■The following foods are suitable for

freezing:

Cakes and pastries, fish and seafood,

meat, game, poultry, vegetables, fruit,

herbs, eggs without shells, dairy

products such as cheese, butter and

quark, ready meals and leftovers such

as soups, stews, cooked meat and

fish, potato dishes, soufflés and

desserts.

■The following foods are not suitable

for freezing:

Types of vegetables, which are usually

consumed raw, such as lettuce or

radishes, eggs in shells, grapes,

whole apples, pears and peaches,

hard-boiled eggs, yoghurt, soured

milk, sour cream, crème fraîche and

mayonnaise.

Note

When freezing fresh food, the

refrigeration unit runs for longer. As a

result, the refrigerator compartment

temperature may drop too low. Increase

the temperature in the refrigerator

compartment.

Packing frozen food

To prevent food from losing its flavour

or drying out, place in airtight containers.

1. Place food in packaging.

2. Remove air.

3. Seal the wrapping.

4. Label packaging with contents

and date of freezing.

Suitable packaging:

Plastic film, tubular film

made of polyethylene, aluminium foil,

freezer containers.

These products are available

from specialist outlets.

Unsuitable packaging:

Wrapping paper, greaseproof paper,

cellophane, bin liners and used

shopping bags.

Ce manuel convient aux modèles suivants

Table des matières

Langues :

Autres manuels Siemens Réfrigérateur

Siemens

Siemens KI81RAD30 Manuel utilisateur

Siemens

Siemens KT..R Series Guide de configuration

Siemens

Siemens KG28UA290K Manuel utilisateur

Siemens

Siemens KG36NHI32 Manuel utilisateur

Siemens

Siemens KG series N Manuel utilisateur

Siemens

Siemens KF96NVPEAL Manuel utilisateur

Siemens

Siemens iQ300 KS V Series Manuel utilisateur

Siemens

Siemens KU15RAFF0 Manuel utilisateur

Siemens

Siemens KS**V SERIES Manuel utilisateur

Siemens

Siemens iQ500 KF96N Series Fiche technique

Siemens

Siemens IQ700 KI52F Series Manuel utilisateur

Siemens

Siemens KG56NHX3P Guide de configuration

Siemens

Siemens KA62DV00GB Manuel utilisateur

Siemens

Siemens KI24LNSF3 Manuel utilisateur

Siemens

Siemens KI52L series Manuel utilisateur

Siemens

Siemens KA..N Feuille d'instructions

Siemens

Siemens KG..U SERIES Manuel utilisateur

Siemens

Siemens KS V Series Manuel utilisateur

Siemens

Siemens KI..N series Manuel utilisateur

Siemens

Siemens KG36NSW30 Manuel utilisateur

Siemens

Siemens KD46NVI20N Manuel utilisateur

Siemens

Siemens KI87SAF30 Manuel utilisateur

Siemens

Siemens KA58NA75 Guide de configuration

Siemens

Siemens S36IT70NNP Manuel utilisateur

Manuels Réfrigérateur populaires d'autres marques

Bonnet Neve

Bonnet Neve SKYVIEW PLUS Manuel utilisateur

Zanussi Electrolux

Zanussi Electrolux ZERB 8441 Manuel utilisateur

Sharp

Sharp SJ-BA31IEXW2-EU Manuel utilisateur

CORBERO

CORBERO CC2300MCW Manuel utilisateur

KitchenAid

KitchenAid 2205264 Manuel utilisateur

Stengel

Stengel KU 1101 A++ Manuel utilisateur

NEFF

NEFF KI181 Series Manuel utilisateur

Hoshizaki

Hoshizaki Reach-In Manuel utilisateur

Amana

Amana ASD2524VES00 Manuel utilisateur

BOMANN

BOMANN KGC 213 Manuel utilisateur

Danby

Danby DAR044A1SLDD Instructions de montage

Samsung

Samsung RF323TE Manuel utilisateur

Beko

Beko CSA31022 Manuel utilisateur

IKEA

IKEA FROSTIG C 185 E Manuel utilisateur

Electrolux

Electrolux ER 6821 D Manuel utilisateur

True

True TS-28 Manuel utilisateur

Frigidaire

Frigidaire FSC23R5DW9 Manuel utilisateur

Beko

Beko LSP4579W Manuel utilisateur
