OpenAir™

Air damper actuators

GEB..1E

Electronic rotary actuators for 2-position, 3-position, and modulating control

●Nominal torque 20 Nm

●Operating voltage AC 24 V ~ / DC 24…48 V ⎓or AC 100…240 V ~

●Mechanically adjustable span between 0…90°

●Pre-wired with standard 0.9 m connection cables

●Type-specific variations with adjustable offset and span for

the positioning signal

●Position indication: Mechanical and electrical

●Feedback potentiometer

●Self-adaption of the rotation angle range and adjustable auxiliary switches

for supplemental functions

Siemens

A6V11449860_en--a

Smart Infrastructure

2019-09-10

Use

Rotary actuators are used in ventilation and air conditioning plants to regulate and shut off

air dampers:

●For damper areas up to approximately 4 m2 (Guideline: Always comply with the damper

manufacturer's specifications).

●Suitable for use with 2-position and 3-position controllers as well as modulating

controllers (DC 0/2…10 V) to control air dampers.

●We recommend a minimum pulse length of 500 ms on rotary actuators operated with 3-

point control to ensure continuous and accurate operation.

Functions

GEB..

AC 24 V ~ /

DC 24…48 V ⎓

141.1E / 142.1E / 146.1E

161.1E / 163.1E / 164.1E / 166.1E

AC 100…240 V ~

341.1E / 346.1E

361.1E

Control type

2-position / 3-position

Modulating control (0/2…10 V)

Rotary movement,

rotary direction

Clockwise or counterclockwise direction depends …

… on the type of control

… on the setting of the rotary direction

switch.

cw ccw

The actuator remains in the respective

position with no power applied.

… on the setting on the DIL switch

clockwise / counterclockwise

00...

selfadapt

2...

selfadapt

00...

2...

ccw

… on the positioning signal.

The actuator remains in the deployed

position:

…if the positioning signal is maintained at a

constant value

…in the event of power loss

cw = Clockwise

ccw = Counterclockwise

Position indication

Mechanical

Rotation angle position indication using a position indicator.

Position indication

Electric

By connecting the feedback potentio-

meter to external voltage, output voltage

is generated proportional to rotation

angle.

Position indicator: Output voltage

U = DC 0/2…10 V is generated proportional

to rotation angle.

The direction of rotation (inverted or non-

inverted) for output voltage U is based on

the DIL switch position.

Auxiliary switch

The switching points for auxiliary switches A and B can be set independently in

increments of 5° from 0 to 90°.

Self-adaptation of the

rotation angle range

The actuator automatically determines the

mechanical end positions of the rotation

angle range.

The characteristic function (Uo, ΔU) is

mapped to the calculated rotation angle

range.

Power must be connected to DIL switch 2

(self-adaptation) for the function to operate.

Manual adjustment

The actuator can be manually adjusted by pressing the gear train disengagement

button.

Rotation angle limitation

A set screw can limit the rotation angle to between 0° and 90°.

Siemens

A6V11449860_en--a

Smart Infrastructure

2019-09-10

Technical design

Housing

●Robust and light cast aluminum housing. The housing guarantees long life, even under

harsh ambient conditions.

Actuator / gears

●Brushless, robust DC motors ensure reliable operation regardless of load. The damper

actuators do not require an end position switch, are overload proof, and remain in place

upon reaching the end stop.

●The gears are maintenance free and low noise.

Type summary

Type

Stock number

Open-loop

control

Operating

voltage

Positioning

signal input Y

Position

indicator

U = DC

0…10 V ⎓

Feedback

potentio-

meter

5 kΩ

Self-adapting

rotation angle

ranges

Auxili-

ary

switch

Rotation

direction

switch

GEB141.1E

S55499-D329

2- or 3-

position

AC 24 V ~ /

DC 24…48 V ⎓

Yes

GEB142.1E

S55499-D330

Yes

GEB146.1E

S55499-D331

GEB341.1E

S55499-D336

AC 100…240 V ~

GEB346.1E

S55499-D337

GEB161.1E

S55499-D332

Modulating

AC 24 V ~ /

DC 24…48 V ⎓

DC 0/2…10 V ⎓

Yes

GEB163.1E

S55499-D333

DC 0…35 V ⎓

GEB164.1E

S55499-D334

GEB166.1E

S55499-D335

DC 0/2…10 V ⎓

GEB361.1E

S55499-D338

AC 100…240 V ~

Accessories/spare parts

See data sheet N4697

Product documentation

Topic

Title

Document ID

Data sheet

Air damper actuators

A6V11449860

Technical principles

Non-spring rotary actuators GEB…1

Z4621

Mounting Instructions

GEB..1E

A6V11476940

Data sheet

Accessory and spare parts for air damper actuators

N4697

Related documents such as environmental declarations, CE declarations, etc., can be

downloaded at the following Internet address:

http://siemens.com/bt/download

Siemens

A6V11449860_en--a

Smart Infrastructure

2019-09-10

Notes

Safety

CAUTION

National safety regulations

Failure to comply with national safety regulations may result in personal injury and property

damage.

●Observe national provisions and comply with the appropriate safety regulations.

●Mounting, commissioning, and service by properly trained personnel only.

Engineering

Auxiliary switch and potentiometer

Cannot be integrated after the fact.

Mounting

See Mounting instructions M4621

Shaft connection

When mounting, comply with the notes on shaft diameters and damper surface areas in

Technical data (page 8) and use only quality materials typical to the sector for the damper

shaft.

Installation

WARNING

No internal line protection for supply lines to external consumers

Risk of fire and injury due to short-circuits!

●Adapt the line diameters as per local regulations to the rated value of the installed fuse.

Maintenance

The GEB..1E actuators are maintenance-free.

Siemens

A6V11449860_en--a

Smart Infrastructure

2019-09-10

Disposal

The device is considered an electronic device for disposal in accordance

with the European Guidelines and may not be disposed of as domestic

garbage.

●Dispose of the device through channels provided for this purpose.

●Comply with all local and currently applicable laws and regulations.

Siemens

A6V11449860_en--a

Smart Infrastructure

2019-09-10

Technical data

Power supply (GEB1..1E)

Operating voltage (SELV/PELV)

AC 24 V ~ ± 20 % (19.2…28.8 V ~)

DC 24…48 V ⎓± 20 % (19.2…57.6 V ⎓) 1)

Frequency

50/60 Hz

Power consumption: During

operation

GEB14..1E

GEB16..1E

2.3 VA / 1,1 W

2.5 VA / 1.2 W

Holding

GEB14..1E

GEB16..1E

0.5 W

0.65 W

Power supply (GEB3..1E)

Operating voltage (SELV/PELV)

AC 100…240 V ~ ± 10 % (90…264 V ~)

Frequency

50/60 Hz

Power consumption: During

operation

GEB34..1E

GEB36..1E

4 VA / 1.6 W

3.4 VA / 1.3 W

Holding

GEB34..1E

GEB36..1E

0.9 W

0.6 W

Function data

Nominal torque

Maximum torque (when blocked)

Minimum holding torque

20 Nm

35 Nm 2)

20 Nm

Nominal rotation angle (with position indication)

Maximum rotation angle (mechanically limited)

90°

95° ± 2°

Runtime at nominal rotation angle 90°

150 s

Actuator sound power level (at a positioning time of 150 s)

<35 dB(A)

Inputs

Positioning signal for GEB14..1E

Operating voltage

AC 24 V ~ / DC 24…48 V ⎓

(wires 1-6/G-Y1)

(wires 1-7/G-Y2)

Clockwise

Counterclockwise

Positioning signal for GEB34..1E

Operating voltage

AC 100…240 V ~

(wires 1-6/G-Y1)

(wires 1-7/G-Y2)

Clockwise

Counterclockwise

Positioning signal for GEB16..1E

Input voltage

Power consumption

Input resistance

(wires 8-2/Y-G0)

DC 0/2…10 V ⎓

0.1 mA

>100 kΩ

Max. permissible input voltage

Protected against faulty wiring

DC 35 V ⎓limited internally to DC 10 V ⎓

Max. AC 24 V ~/ DC 24…48 V ⎓

Hysteresis

for non-adjustable characteristic function

for adjustable characteristic function

60 mV

0.6 % of ΔU

Adjustable characteristic (GEB163.1E, GEB164.1E)

Adjustable with 2 potentiometers:

Offset Uo

Span ΔU

DC 0…5 V ⎓

DC 2…30 V ⎓

Max. input voltage

Protected against faulty wiring

DC 35 V ⎓

Max. AC 24 V ~ / DC 24…48 V ⎓

1) cUL: Only to DC 30 V ⎓permissible

2) See notes on page 4 and page 8

Siemens

A6V11449860_en--a

Smart Infrastructure

2019-09-10

Outputs

Position indicator

Output signal (GEB16..1E)

Output signal (GEB36..1E)

Output voltage U

Max. output current

(wires 9-2/U-G0)

(wires 9-2/U-G-)

DC 0…10 V ⎓

DC ± 1 mA

Protected against faulty wiring

Max. AC 24 V ~/ DC 24…48 V ⎓

Aux. power supply (G-/G+)

GEB36..

DC 24 V ⎓± 20 %, max. 10 mA

Feedback potentiometer (for GEB142.1E)

Change in resistance

(wires P1-P2)

0…5000 Ω

Load

Max. contact current

Permissible voltage at potentiometer (SELV/PELV)

Insulation resistance between potentiometer and

housing

<0.25 W

<0.1 mA

AC 24 V ~ / DC 24…48 V ⎓

AC 500 V ~

Auxiliary switches (GEB146.1E, GEB166.1E, GEB346.1E)

Switching voltage

Contact loading

Electric strength auxiliary switch against housing

Switching range for auxiliary switches / setting

increments

AC 24…250 V ~ / DC 12…30 V ⎓

6 A resistive, 2 A inductive, min. 10 mA @ AC

4 A resistive, 2 A inductive, min. 10 mA @ DC 30 V ⎓

0.8 A resistive, 0.5 A inductive, min. 10 mA @ DC 60 V⎓

AC 4 kV

5°…90° / 5°

Factory switch setting:

Switch A

Switch B

5°

85°

Connection cables

Cable length

0.9 m

Cross-section

0.75 mm2

Permissible length for signal wires

300 m

Safety class and degree of protection

Protection class

AC 24 V ~ / DC 24…48 V ⎓, feedback

potentiometer

AC 100…240 V ~, auxiliary switches

EN 60730

III

Degree of protection of housing

IP54 as per EN 60529 (see "Mounting", page 4, and

Mounting instructions A6V11476940)

Environmental conditions

Operation

Climatic conditions

Mounting location

Temperature

Humidity, non-condensing

IEC 60721-3-3

Class 3K5

interior, weather-protected

-32…55 °C

<95 % r.h.

Transportation

Climatic conditions

Temperature

Humidity, non-condensing

IEC 60721-3-2

Class 2K3

-32…70 °C

<95 % r.h.

Storage

Climatic conditions

Temperature

Humidity, non-condensing

IEC 60721-3-1

Class 1K3

-32…50 °C

<95 % r.h.

Mechanical conditions

Class 2M2

Siemens

A6V11449860_en--a

Smart Infrastructure

2019-09-10

Standards, directives and approvals

Product standards

EN60730

Part 2-14: Particular requirements for electric

actuators

Electromagnetic compatibility (field of use)

For residential, commercial, and industrial

environments

EU conformity (CE)

A5W00051707 3)

RCM conformity

A5W00051708 3)

EAC compliance

Eurasian conformity

Federal Communications Commission

UL as per 60730 http://ul.com/databse

cUL as per CSA-C22.2 No. 24-93

Environmental compatibility

The product environmental declaration A5W00055607 3) contains data on environmentally compatible product

design and assessments (RoHS compliance, materials composition, packaging, environmental benefit, disposal).

Dimensions

Actuator (W x H x D)

See "Dimensions" (page 11)

Damper shaft

Round

Square (diagonal)

Min. length

Max. shaft hardness

8…20.5 mm

8…14.5 mm

20 mm

<300 HV

Weight

Excl. packaging

Max. 1.1 kg, without auxiliary switches

Max. 1.3 kg, with auxiliary switches

3) Documents can be downloaded at http://siemens.com/bt/download.

NOTICE

Shaft connection –Important notes for the manufacturer / installer

Use of unsuitable damper shafts may damage the damper or damper shaft.

●Use only damper shafts with diameters suitable for the damper surface.

●Use only quality materials typical for the sector for damper shafts/rods.

Siemens

A6V11449860_en--a

Smart Infrastructure

2019-09-10

Connection diagrams

Internal Diagrams

GEB14..1E

(open-close, 3-position control)

GEB34..1E

(open-close, 3-position control)

AC 24 V ~ / DC 24…48 V ⎓

AC 100…240 V ~

100%

(a)

(Q12)

(Q14)

(Q24)

(Q22)

(Q11)

(Q21)

(b)

(c)

SELV/PELV AC 24...2 0 V / 6 (2)A5 ~

DC 12...30 V / 2 A

0...5000

III

AC 24 V ~

DC 24...48 V

5° 85°

(Q12)

(Q14)

(Q24)

(Q22)

S2 S3 S5 S6

S1 S4

(Q11)

(Q21)

AC 24...2 0 V / 6 (2) A5 ~

DC 12...30 V / 2 A

5° 85°

AC 0 V100...24 ~

GEB16..1E

(modulating, Y = DC 0/2…10 V ⎓)

GEB16..1E

(modulating, Y = DC 0…35 V ⎓)

GEB361.1E

(modulating, Y = DC 0/2…10 V ⎓)

AC 24 V ~ / DC 24…48 V ⎓

AC 100…240 V ~

III

100%

DC 0 ...10 V/2

/2DC0 ...10V

G0 U

(Q12)

(Q14)

(Q24)

(Q22)

2 9

1 8

(Q11)

(Q21)

AC 24...2 0 V / 6 (2) A5 ~

DC 12...30 V / 2 A

AC 24 V~

DC 24...48 V

III

100%

DC 0 ... V/2 10

35DC0... V

G0 U

(Q12)

(Q14)

(Q24)

(Q22)

2 9

1 8

(Q11)

(Q21)

AC 24...2 0 V / 6 (2) A5 ~

DC 12...30 V / 2 A

AC 24 V~

DC 24...48 V

G-

M100%

1 8

AC 0 V10 ...240 ~

SELV/PELV

D 24C V C VD 0/2...10

DC 0/2...10 V

Connection diagrams

Control on GEB1..1E (AC 24 V ~ / DC 24…48 V ⎓)

Open-close, single wire control

Single pole single throw (SPST)

Open-close, double wire control

Single pole double throw (SPDT)

3-position control

Modulating control

Y1 Y2

AC 24 V ~

DC 24...48 V

Y1 Y2

AC 24 V ~

DC 24...48 V

Y1 Y2

AC 24 V ~

DC 24...48 V

G Y

AC 24 V ~

DC 24...48 V

AC 24 V ~

DC 24...48 V

Y1 Y2

AC 24 V ~

DC 24...48 V

Y1 Y2

AC 24 V ~

DC 24...48 V

Y1 Y2

Siemens

A6V11449860_en--a

Smart Infrastructure

2019-09-10

Control on GEB3..1E (AC 100…240 V ~)

Open-close, single wire control

Single pole single throw (SPST)

Open-close, double wire control

Single pole double throw (SPDT)

3-position control

Modulating control

Y1 Y2

AC 100...240 V ~

Y1 Y2

AC 100...240 V ~

Y1 Y2

AC 100...240 V ~

LYUG+

G-

AC 100...240 V ~

Cable designations

Connecting thread

Code

No.

Color

Abbreviation

Meaning

Actuators

AC 24 V ~ / DC 24…48 V ⎓

red

black

violet

orange

gray

pink

System potential AC 24 V ~ / DC 24…48 V ⎓

System zero

Positioning signal AC/DC 0 V, clockwise (GEB14..1E)

Positioning signal AC/DC 0 V, counterclockwise (GEB14..1E)

Signal input (GEB16..1E)

Signal output (GEB16..1E)

Actuators

AC 100…240 V ~

G+

G-

brown

light blue

black

white

red

black

gray

pink

Phase, AC 100…240 V ~

Neutral conductor

Positioning signal AC 100…240 V ~, clockwise (GEB34..1E)

Positioning signal AC 100…240 V ~, counterclockwise (GEB34..1E)

System potential DC 24 V (auxiliary power) (GEB361.1E)

System neutral (auxiliary power) (GEB361.1E)

Signal input (GEB361.1E)

Signal output (GEB361.1E)

Feedback potentiometer

white/red

white/blue

white/pink

WH RD

WH BU

WH PK

Potentiometer 0…100 % (P1-P2)

Potentiometer pick-off

Potentiometer 100…0 % (P3-P2)

Auxiliary switch

Q11

Q12

Q14

Q21

Q22

Q24

gray/red

gray/blue

gray/pink

black/red

black/blue

black/pink

GY RD

GY BU

GY PK

BK RD

BK BU

BK PK

Switch A input

Switch A NC contact

Switch A NO contact

Switch B input

Switch B Normally closed contact

Switch B NO contact

Autres manuels pour GEB-1E Series

Table des matières

Autres manuels Siemens Contrôleurs

Siemens

Siemens SIMATIC S5-115F Manuel utilisateur

Siemens

Siemens Simatic S7-300 Manuel utilisateur

Siemens

Siemens REV200 Series Manuel utilisateur

Siemens

Siemens SIMATIC HMI TP700 Comfort Manuel utilisateur

Siemens

Siemens UP 227 Manuel de service

Siemens

Siemens RWD44U Guide de l'utilisateur

Siemens

Siemens SIRIUS 3RW50 Manuel utilisateur

Siemens

Siemens OpenAir GIB13.1 Series Manuel utilisateur

Siemens

Siemens ICP-B6 Manuel de service

Siemens

Siemens OpenAir GDE131.1U Manuel utilisateur

Siemens

Siemens LME39 Series Manuel utilisateur

Siemens

Siemens S7-1200 TELECONTROL Manuel utilisateur

Siemens

Siemens RLU2 Series Manuel utilisateur

Siemens

Siemens Climatix S300 HRV Guide de l'utilisateur

Siemens

Siemens SINAMICS V90 Manuel utilisateur

Siemens

Siemens SIMATIC S7 F Manuel utilisateur

Siemens

Siemens Simatic S7 Series Guide de l'utilisateur

Siemens

Siemens Powermite 599 MT Series Manuel du propriétaire

Siemens

Siemens RDX33.21 Manuel utilisateur

Siemens

Siemens 72G Series Manuel utilisateur

Siemens

Siemens 3VA9 Series Manuel utilisateur

Siemens

Siemens SIMATIC S7-1200 Manuel utilisateur

Siemens

Siemens RVP540 Manuel de l'opérateur

Siemens

Siemens OpenAir GIB132.1P Manuel du propriétaire

Manuels Contrôleurs populaires d'autres marques

Digiplex

Digiplex DGP-848 Mode d'emploi

YASKAWA

YASKAWA SGM series Manuel utilisateur

Sinope

Sinope Calypso RM3500ZB Manuel utilisateur

Isimet

Isimet DLA Series Style 2 Manuel d'installation

LSIS

LSIS sv-ip5a Manuel utilisateur

Rockwell Automation

Rockwell Automation 1769-L31 Manuel utilisateur

Airflow

Airflow Uno hab Manuel utilisateur

ABB

ABB ACS580-01 drives Manuel utilisateur

Panasonic

Panasonic GM1 Series Manuel utilisateur

Emerson

Emerson SW93 Manuel utilisateur

AutoAqua

AutoAqua Smart ATO micro SATO-120P Manuel utilisateur

Panasonic

Panasonic FP? Positioning Unit RTEX Manuel utilisateur

Samson

Samson Type 5824 Manuel de service

Alpha IP

Alpha IP MIOB 21001 Manuel utilisateur

Surecom

Surecom SR-629 Manuel utilisateur

Fishman

Fishman TriplePlay Manuel utilisateur

Regulus

Regulus SRS1 T Manuel utilisateur

3M MicroTouch EX113 Manuel utilisateur
