Siemens TRIANO 3 Manuel utilisateur

US Coast Guard Approved

Certificate No. (Cert No:161.002/17/8)

Marine Fire Detection

System Manual

System 3™ Control Panel

Refef

efef

eferer

erer

erencenc

encenc

encee

ULI FULI F

ULI File Nile N

ile Nile N

ile Noo

o..

.S522S522

S522S522

S522

P/N 315-086283-9

Building Technologies Division

8 Fernwood Road

Florham Park, NJ 07932

Siemens Industry, Inc.

Phone (973) 593-2600

Fax (973) 593-6612

www.sbt.siemens.com/fis

Table of Contents

TABLE OF CONTENTS

I INTRODUCTION...................................................................................................................1

Typical Wiring Lists .......................................................................................................2

II POWER REQUIREMENTS...................................................................................................4

III EQUIPMENT DESCRIPTIONS AND FUNCTIONS ..............................................................5

1. Modules.........................................................................................................................5

2. Supplementary Modules................................................................................................7

3. Enclosures.....................................................................................................................8

4. Remote Annunciation ..................................................................................................11

5. Audible Alarms ............................................................................................................ 11

6. Initiating Devices - Automatic ......................................................................................13

7. Initiating Devices - Manual ..........................................................................................15

IV CONTROL PANEL CONFIGURATION...............................................................................16

V DETECTORAPPLICATIONAND SPACING ......................................................................17

1. Smoke Detectors.........................................................................................................17

2. Thermal Detectors.......................................................................................................17

3. Planning a Fire Detection System ...............................................................................18

4. Detector Installation.....................................................................................................21

5. System Maintenance and Testing ...............................................................................22

VI POWER CALCULATIONS..................................................................................................23

1. Power Calculation Sheet .............................................................................................24

2. Determining Current Requirements for a Given System Configuration ......................25

3. Batttery Backup Power................................................................................................25

4. Determining Battery Size Necessary for Backup Power .............................................28

Table of Contents

APPENDIX

Coast Guard System 3 Typical Drawing..............................................................................30

Drawing No. 315-085585

US Coast Guard Approved Equipment List .........................................................................31

PTR-1 Connections, Cover, and Enclosure (Mounting) ......................................................39

Part No. 315-086284

DM-31 ModuleAssembly.....................................................................................................40

Part No. 515-021941

System 3 from Siemens Industry, Inc. was

developed as a flexible, wide range fire detection

and control system. System 3 uses a modular

concept: Only those functions desired in each

system are built into that system. Any number of

various input and output circuits may be custom-

assembled in various size enclosures.

This manual contains information regarding

only System 3 equipment and detectors that

are US Coast Guard approved under

Certificate No. 161.002/17/8. The use of any

other equipment in systems required by US

Coast Guard regulations, but not US Coast

Guard approved, should only be considered

when absolutely necessary. Special US Coast

Guard one time approval would be required.

SECTION I

INTRODUCTION

Drawing No. 315-085585 (Coast Guard Sys-

tem 3 Specification) is considered a part of

this manual (See print in Appendix, page 30).

In addition, the typical internal module to

module wiring of two control panels is shown

on pages 2 and 3 in the form of typical Wire

Lists. Either a wiring list of this type or a

complete point to point wiring diagram should

be furnished with every system and should be

kept as on-board documentation for future

reference in system service and maintenance.

NOTE: When designing Fire Control Systems

for various types of vessels, the designer

should be aware of the required vessel type,

domestic and SOLAS regulations applicable

for that vessel.

9-20 DWG E 315-085585 Sheet of

Name TYPICAL LARGE SYSTEM Job No.

Section I — Introduction

WIRE LIST

FROM TO FROM TO FROM TO

CP-36 C3-1 B5-7 D3-36

C3-1 C3-2 B6-1 D3-40

C3-2 C1-1 B6-7 D3-44

C3-3 C1-2 B7-1 D5-1

C2-5 C1-3 B7-7 D5-4

C1-3 CP-39 B8-1 D5-9

P5-5 D1-1 B8-7 D5-36

D1-1 C2-1 C8-1 D5-44

C2-1 C4-1 C7-1 D7-1

P5-6 D1-2 C7-7 D7-4

D1-2 C2-2

C2-2 C4-1

C6-1 C5-1

C5-1 C5-2

C5-2 D1-5

B2+ BATT+

B2- BATT-

C8-PIN5 CP-41

B4-1 D3-1

B4-7 D3-5

B5-1 D3-7

87654 3 21

A53-PC53-SP

BUZ53ST

UZ53ST

MM53 53-CB

CUZ53ST

UZ53ST

SZ03 MS03 MR U03 LT U03 EAU03 CM03

DEAU03

23-RS23-RS23-RS

E33-KB

Module Space

EK -

CP -

PS -

JP -

JS -

JS-

BM -

No. of BP - 30

Section I — Introduction

WIRE LIST

FROM TO FROM TO FROM TO

CP-41 BB-5

NOTE: RC-30U CONTROLS B6 THRU B8

87654 3 21

53-PC53-SP

UZ53ST

CR U03

UZ53ST

9-20 DWG E 315-085585 Sheet of

Name TYPICAL SMALL SYSTEM Job No.

Module Space

EK -

CP -

PS -

JP -

JS -

BM -

No. of BP - 30

It is a US Coast Guard requirement that the

fire detection system have two sources of

power. Most large ships have both main

generators and emergency generators;

therefore, they can satisfy this requirement

by arranging to have power supplied to the

fire detection system by both the main and

emergency generators.

A US Coast Guard approved Power

Transfer Relay must be used for the

automatic transfer from main power to

secondary power when the main power

source has 15% to 20% potential variation.

The transfer to secondary power creates a

visual and audible trouble signal on the CP-

35 Control Panel. The Model PTR-1 Power

Transfer Relay from Siemens Industry, Inc.

has been designed for this purpose and is

US Coast Guard approved.

In cases where there are no emergency

generators, battery backup power to the

system is required. Revised US Coast

Guard regulations have reduced the

SECTION II

POWER REQUIREMENTS

required battery operation time to 36 hours

for passenger ships and 18 hours for all

other types of vessels. In cases where it is a

desired option to furnish the fire detection

system with standby battery power, even

when there are main and emergency

generators supplying the system, there is no

specific battery operation time period,

although it would be recommended to be a

minimum of 18 hours.

When the smoke detection system is

furnished with battery backup power, it is

necessary to calculate the system power

requirements to determine the battery

ampere-hour capacity necessary. The

calculations can be done on the Power

Calculation Sheet (page 24) and the Battery

Curves shown on pages 26 and 27. Another

requirement involving battery power is that a

voltmeter and ammeter (MM-35) are

furnished. The voltmeter and ammeter are

not required when the batteries are used as

a third power source.

1. MODULES

CP-35 MAIN CONTROL UNIT

This control unit contains system power,

alarm and trouble indicating lamps, lamp

test/reset, trouble and subsequent alarm

silence switches, one supervised 1.5A

audible alarm circuit, and two detection

zones not to be used for US Coast Guard

approved systems because these zones do

not have alarm and trouble test switches.

(See Spec Sheet Catalog No. 3060 for

terminal identification.)

PS-35 POWER SUPPLY

This 10A power supply converts the 115

VAC, 60 or 50 Hz and supplies 24 VDC to

all modules in the System 3 Control Panel.

(See Spec Sheet Catalog No. 3061 for

additional details.)

BC-35 BATTERY CHARGER MODULE

This module is required to automatically

transfer power from normal power to battery

power and also to charge the batteries. It

can charge battery sizes up to 25 ampere-

hours, and the charging capacity can be

increased in increments of 25 AH to a limit

of more than 100 AH by use of the BE-35;

see below. (See Spec Sheet Catalog No.

3177.)

SECTION III

EQUIPMENT DESCRIPTIONS

AND FUNCTIONS

BE-35 BATTERY EXTENDER

MODULE

This extender module increases the 25 AH

charging capability of the BC-35 by another

25 AH when larger batteries are required,

based on a 48 hour recharge period, as per

ULI requirements. (See Spec Sheet Catalog

No. 3177.)

MM-35 METER MODULE

This module includes the US Coast Guard

required voltmeter and ammeter to display

battery voltage and charging current when

batteries are used as the second power

source. The meters are not required when

battery power is a third power source. (See

Spec Sheet Catalog No. 3355.)

TC-30U BATTERY TRANSFER

MODULE

This module is required to use separate

ship battery power when available. Ship

battery power would have its own charging

method.
