Siemens CX75 Manuel utilisateur

Local Service Organization Service Manual

BE INSPIRED

V 1.0

Version Date Department Notes to change

R 1.0 06.06.2005 COM D CCQ APAC New Document

Our innovation shapes the future

CX75 Level 2 Service Manual

COM D CCQ APAC SLI Page 2 of 42 Internal Use Only

Table of Contents

1 GPRS (GENERAL PACKET RADIO SERVICE)……………………..….3

2 K JAVA APPLICATION……………………………………………………………….4

3 KEY FEATURES……………………………………………………………………….5

4 COMPARISON WITH PERVIOUS PRODUCT...……………………………………7

5 ACCESSORIES……………………………………………………………………......8

6 UNIT DESCRIPTION CX75..………..……………………………………………….10

7 DISASSEMBLY OF CX75......……………………………………………………….12

8 REASSEMBLY OF CX75..…..………………………………………………………19

9 ASSEMBLING AND DISASSEMBLING OF CAMERA MODULE………………21

10 MOBILE SOFTWARE PROGRAMMING…………………………………………..23

11 SIEMENS SERVICE EQUIPMENT USER MANUAL……………………………..26

12 JPICS INTERNET.……………………………………………………………………27

13 INTERNATIONAL MOBILE EQUIPMENT IDENTITY, IMEI…….………………..33

14 GENERAL TESTING INFORMATION……………………………….……………..34

Annex 1……………………………………………………………………………….……….39

Annex 2…………………………………………………………………………….………….40

CX75 Level 2 Service Manual

COM D CCQ APAC SLI Page 3 of 42 Internal Use Only

1 GPRS (General Packet Radio Service)

GPRS is a new non-voice value added services that allows information to be sent

and received across a GSM mobile telephone network. It supplements today’s Circuit

Switched Data (CSD) and Short Message Services (SMS). GPRS involves overlaying

a packet based air interface on the existing circuit switched GSM network. This gives

the option to use a packet-based data service. The information is split into separated

but related “packets” before being transmitted and reassembled at the receiving end.

Theoretically, maximum speeds of up to 171.2 kilobits per second (kbps) are

achievable with GPRS using all eight timeslots at the same time. This is about 3

times as fast as the data transmission speed possible over today’s fixed

telecommunications networks and 10 times as fast as current Circuit Switched Data

services on GSM networks.

Example: Cell with 1 Frequency channel:

1 physical channel for signaling, 4 physical channels for Circuit switched and 3 physical

channels for Packet switched.

CX75 Level 2 Service Manual

COM D CCQ APAC SLI Page 4 of 42 Internal Use Only

2 K-Java Application

Java-based game system

Java Application Manager

(JAM)

Application launcher and

download manager.

Supports HTTP-based OTA

download of applications over

GPRS and CSD.

yes

RAM for Java applications Available RAM for Java

applications (i.e. Program code

and data) during application

runtime:

Minimum 100 Kbytes (Has to be

taken as working assumption

for application development).

Goal: 145 Kbytes as SL45i (not

committed)

yes

MIDP 1.0, CLDC 1.0 As SL45i, including

performance optimizations from

SL45i-Infusio.

yes

‘OEM extensions’ Proprietary API extension as

SL45i. Including ‘Siemens

Game API’

yes

HTTP API over GPRS Sl45i: only CSD yes

CX75 Level 2 Service Manual

COM D CCQ APAC SLI Page 5 of 42 Internal Use Only

3 Key Features

Bands • Triple Band E-GSM 900 / GSM 1800 / GSM 1900

• GPRS Multi Class 10

Battery • Li-Ion Battery Pack

• Nominal Voltage : 3.7V

• Nominal Capacity : 780 mAh

• GSM Capacity : 750 mAh

• Power Input : 2.0A (0.6 ms) / 0.25A (4 ms)

• Cut-off Threshold : 3.2V

Stand-by Time ≥Approx. 250 h (Best Case)

Talk Time ≥5 hrs (Best Case)

SIM Card

• Small (”Plug In”) 1.8 or 3V SIM card (Phase II)

• To insert the SIM card, the battery pack must be

removed.

Speech Codec

• Triple Rate (HR/FR/EFR) and Adaptive Multi Rate are

available as standard

Temperature

Range

• -100C to +550C (Normal operation)

• -200C to +650C (External Power Source)

• -400C to +850C (Storage capability)

Display • Type: Full Graphic

• Resolution: 132 x 176 Pixel

• Color depth: 262K

• Technology: TFT

• Active area / mm: 27.7 x 37.0

• Illumination: White LED (6 LEDs integrated)

• Frame rate: maximum 15 frames/seconds

• Pixel size per mm: 0.21mm x 0.21mm ( 1 pixel consist

of 3 sub pixels in red, green and blue)

Keypad •Plating function key + IMF number key

• 12-key-block (0-9, #, *)

• two function keys (SEND, END)

• ON/OFF key combined with the END key; the symbol (I

inside O) is used as a symbol for ON/OFF.

• 5 way-joystick with design-cap (soft material), phonebook

symbol required on navikey (Siemens standard)

• 2 soft-keys for different SW-enabled functions

• 1 dedicated hardkey (provider key), target to only have a

specific hardkey only for Vodafone and TMO

• white as illumination colour

• tactile finder on key “5“

• 6 white LEDs for keypad

Side keys • one for Pat (Push and Talk) control, one for camera activation

CX75 Level 2 Service Manual

COM D CCQ APAC SLI Page 6 of 42 Internal Use Only

Acoustics

• Three-in-one-earpiece for handset, handsfree and ringing

tones

• uni-directional microphone

• Loud signal emitter (soundringer) (>100dB(A) SPL @5cm,

'Hongkong-Spec.') only for rectangular sound signals (NOT

POSSIBLE for all Soundringer melodies)

• Polyphonic ringer tones (parallel to GPRS: 16 voices; all

other Use Cases: 40 voices)

• Hands free mode

• different selectable volume levels for handsfree, handset

and ringer mode (for the amount see SW product

description)

Memory • Approx 14MB, Slot RS-MMC, Bundled with 32MB card

Connectivity • USB

• Bluetooth®

• Infrared

Ring tones • Polyphonic 40 voices

• AAC& AAC+ Melodies and MP3

Multimedia • Video recording / encoding

• AAC, AAC+ and MP3 music support

Camera • Integrated 1.3 Mega pixel (attachable Flash accessory)

CX75 Level 2 Service Manual

COM D CCQ APAC SLI Page 7 of 42 Internal Use Only

4 Comparison with Previous Product

Feature S65 CX75 Delta

Supported Systems Triple Band

EGSM 900/GSM1800/

GSM1900 (EMEA,

APAC)

Triple Band

EGSM 900/GSM1800/

GSM1900 (EMEA,

APAC)

No GSM 850

Stand-by Time ≥250h

(approx. 3mA quiescent

current)

≥250h

(approx. 3mA quiescent

current)

Talk Time ≥5 h

(approx. 150mA

average current for

lowest TX-power level)

≥5 h

(approx. 150mA

average current for

lowest TX-power level)

Battery Technology

Battery Capacity

Li-Ion Battery Pack

NOMINAL CAP.: 780

MAH

Li-Ion Battery Pack

NOMINAL CAP.: 780

MAH

Weight Approx. 102 g approx. 102 g

Volume approx. 90.3 cm3

Length 108.9mm 111.7 mm

Width 48 mm 48 mm

Thickness 20.5 mm 19.5 mm

SIM Plug-In 1.8V/3V Plug-In 1.8V/3V

Antenna Integrated Integrated

Antenna Performance

in comparison

~28 dBm @ 900 MHz

~24,5 dBm @ 1800 MHz

~23,5 dBm @ 1900 MHz

(2,7-Band-Antenna)

~27 dBm @ 900 MHz

~24 dBm @ 1800 MHz

~23,5 dBm @ 1900 MHz

(2,7-Band-Antenna)

-1db @ 900 MHz

-0,5db @ 1800 MHz

+/-0db @ 1900 MHz

Half Rate Yes Yes

Enhanced Full Rate Yes Yes

AMR Yes Yes

Fax/Data Yes Yes

GPRS Class 10 Class 10

Keypad Illumination White LED White LED

DISPLAY /

DISPLAY

ILLUMINATION

TFT/TFD

132 x 176 Pixel

65k colour

TFT

132 x 176 Pixel

262k colour

Increased number of

colors

EXCHANGEABLE

MEMORY

Yes

(RS-MULTI-MEDIA

CARD)

Yes

(RS-MULTI-MEDIA

CARD)

CAMERA Mega pixel camera

(integrated)

Mega pixel camera

(integrated)

Improved optical

performance, socket

concept

IRDA SIR (slow Infrared) SIR

BLUETOOTH supported SUPPORTED

AAC/AAC+ Not supported Supported

Ringer volume level Min. 95 dB(A) @ 5cm

Typ. ≥98dB(A) @ 5cm

(for dedicated Siemens-

standard melodies)

Min. 100dB(A) @ 5cm

(only for rectangular

sound signals)

Min. 95 dB(A) @ 5cm

Typ. ≥98dB(A) @ 5cm

(for dedicated Siemens-

standard melodies)

Min. 100dB(A) @ 5cm

(only for rectangular

sound signals)

CX75 Level 2 Service Manual

COM D CCQ APAC SLI Page 8 of 42 Internal Use Only

5 Accessories

For CX75, the following accessories will be available.

Description Part number

Tour Case FCT-700 TBC

Belt Case FCL-710 TBC

Li-Ion Battery 750mAh EBA-660 L36880-N7101-A111

Travel Charger ETC-500 L36880-N5601-A104

Travel Charger ETC-510 L36880-N5601-A105

Car Charger Plus ECC-600 L36880-N7101-A109

Car Charger ECC-500 TBC

Headset Bluetooth® HHB-600 L36880-N7401-A100

Headset Bluetooth® HHB-610 L36880-N7401-A101

Headset Purestyle HHS-610 L36880-N7101-A500

Headset HHS-510 L36880-N5601-A108

Headset Stereo HHS-700 L36880-N7431-A101

Charger Adapter ECA-500 (for Headset Bluetooth®) L36880-N7401-A104

Car Kit Bluetooth® Portable HKW-700 TBC

Car Kit Bluetooth® HKW-600 L36880-N6551-A100

Car Kit Comfort Basic HKC-700 TBC

Car Kit Easy HKP-700 L36880-N7431-A100

Car Kit Portable HKP-500 L36880-N5601-A109

Mobile Holder Antenna HMH-700 TBC

Car Kit Upgrade HKO-700 (for Car Kit Easy) L36880-N7431-A103

Car Data Adapter HKO-690 (for Car Kit Comfort HKC-700) L36880-N7101-A800

Car Kit Upgrade HKO-650 (for Car Kit Bluetooth®) L36880-N7401-A120

Mobile Music Set IMS-700 L36880-N7431-A110

Flash IFL-600 L36880-N7101-A400

Data Cable DCA-500 L36880-N5601-A110

Data Cable USB – serial DCA-510 L36880-N5601-A111

Data Cable USB – USB DCA-540 L36880-N6501-A102

Note: Visit the Communication Market for updated accessories:

https://communication-market.siemens.de/

CX75 Level 2 Service Manual

COM D CCQ APAC SLI Page 9 of 42 Internal Use Only

5.1 CX75 Interface to Accessories

The phone has got a full compatible interface to accessories. The I/O-Connector

(Lumberg-(slim)-connector) and RF-Connector is in the same position as in the S65

Penelope. Necklace can be attached in similar way as Penelope. Interfaces for Belt-

Clip will not be necessary.

All shown interfaces are for car-cradle.

Accessory-

Interfaces

Accessory-

Interfaces

CX75 Level 2 Service Manual

COM D CCQ APAC SLI Page 10 of 42 Internal Use Only

6 Unit Description of CX75

The CX75 is designed as a two-PCB phone with removable battery cover. The upper

case, mounting frame/lower case, logo cover, antenna cover and battery cover are

plastic-parts (1-shot-molding; 1 colour), with IMD display lens, IMD UC decoration cap

and IMD camera plate and mirror.

The upper case, mounting frame/lower case, logo cover, antenna cover and battery

cover are lacquered.

Autres manuels pour CX75

Table des matières

Autres manuels Siemens Téléphone portable

Siemens

Siemens CFX65 Guide de configuration

Siemens

Siemens SIMATIC S7 CP340 Mode d'emploi

Siemens

Siemens CT56 Manuel utilisateur

Siemens

Siemens C62 Manuel utilisateur

Siemens

Siemens M65 Manuel utilisateur

Siemens

Siemens PEGASUS-DTC AX72 Manuel utilisateur

Siemens

Siemens Gigaset 4000i Micro Manuel utilisateur

Siemens

Siemens RUGGEDCOM i802 Manuel utilisateur

Siemens

Siemens Xelibri X6 Manuel utilisateur

Siemens

Siemens CF75 Manuel utilisateur

Siemens

Siemens A70 Manuel utilisateur

Siemens

Siemens CX70 Manuel utilisateur

Siemens

Siemens Gigaset S100 Manuel utilisateur

Siemens

Siemens ST55 Manuel de l'opérateur

Siemens

Siemens S6 Manuel utilisateur

Siemens

Siemens A62 Guide de configuration

Siemens

Siemens AX75 Guide de configuration

Siemens

Siemens M65 Manuel utilisateur

Siemens

Siemens Gigaset M56 Manuel utilisateur

Siemens

Siemens GSM 900, GSM 1900 Manuel utilisateur

Siemens

Siemens SXG75 Manuel utilisateur

Siemens

Siemens C62 Manuel utilisateur

Siemens

Siemens A35 Manuel utilisateur

Siemens

Siemens SXG75 Manuel utilisateur

Manuels Téléphone portable populaires d'autres marques

Zte

Zte BLADE A520 Manuel utilisateur

Nokia

Nokia Lumia 620 Manuel utilisateur

Blackbe;rry

Blackbe;rry KEYone Manuel utilisateur

Bea-fon

Bea-fon X5 Premium Manuel utilisateur

Blackbe;rry

Blackbe;rry 8707 Series Manuel utilisateur

Blackbe;rry

Blackbe;rry Storm Mode d'emploi

LG LM-X420QN Manuel utilisateur

LifeWatch

LifeWatch V Manuel utilisateur

Bea-fon

Bea-fon SILVER LINE SL860 Manuel utilisateur

IKI Mobile

IKI Mobile KF4.5i Manuel utilisateur

Hitech

Hitech HT-850 Manuel utilisateur

Yezz

Yezz Fashion F10 Manuel utilisateur

Point Mobile

Point Mobile PM60 Manuel utilisateur

Blackbe;rry

Blackbe;rry Q10 Manuel utilisateur

Blackbe;rry

Blackbe;rry Bold 9900 Manuel utilisateur

Blackbe;rry

Blackbe;rry STORM 9500 - VERSION 5.0 Manuel utilisateur

LG LM-K420EMW Manuel utilisateur

ISAFE MOBILE

ISAFE MOBILE IS655.2 Manuel utilisateur
