CX65 Level 2 Service Manual

ICM MP CCQ ASP/ASC Page 2 of 35 Internal Use Only

Table of Contents

1 GPRS (GENERAL PACKET RADIO SERVICE)……….3

2 K JAVA APPLICATION……………………………………………………………….4

3 KEY FEATURES……………………………………………………………………….5

4 COMPARISON WITH PERVIOUS PRODUCT...……………………………………7

5 ACCESSORIES……………………………………………………………………......8

6 UNIT DESCRIPTION CX65..………..……………………………………………….10

7 DISASSEMBLYOF CX65......………………………………………………………..14

8 REASSEMBLY OF CX65….………………………………………………………...17

9 MOBILE SOFTWARE PROGRAMMING…………………………………………..18

10 SIEMENS SERVICE EQUIPMENT USER MANUAL……………………………..21

11 JPICS INTERNET.……………………………………………………………………22

12 INTERNATIONAL MOBILE EQUIPMENT IDENTITY, IMEI…….………………..28

13 GENERAL TESTING INFORMATION……………………………….……………..29

Annex 1……………………………………………………………………………….……….34

Annex 2…………………………………………………………………………….………….35

SIEMENS PTE LTD

CX65 Level 2 Service Manual

ICM MP CCQ ASP/ASC Page 3 of 35 Internal Use Only

1 GPRS (General Packet Radio Service)

GPRS is a new non-voice value added services that allows information to be sent

and received across a GSM mobile telephone network. It supplements today’s Circuit

Switched Data (CSD) and Short Message Services (SMS). GPRS involves overlaying

a packet based air interface on the existing circuit switched GSM network. This gives

the option to use a packet-based data service. The information is split into separated

but related “packets” before being transmitted and reassembled at the receiving end.

Theoretically, maximum speeds of up to 171.2 kilobits per second (kbps) are

achievable with GPRS using all eight timeslots at the same time. This is about 3

times as fast as the data transmission speed possible over today’s fixed

telecommunications networks and 10 times as fast as current Circuit Switched Data

services on GSM networks.

Example: Cell with 1 Frequency channel:

1 physical channel for signaling, 4 physical channels for Circuit switched and 3 physical

channels for Packet switched.

SIEMENS PTE LTD

CX65 Level 2 Service Manual

ICM MP CCQ ASP/ASC Page 4 of 35 Internal Use Only

2 K-Java Application

Java-based game system

Java Application Manager

(JAM)

Application launcher and

download manager.

Supports HTTP-based OTA

download of applications over

GPRS and CSD.

yes

RAM for Java applications Available RAM for Java

applications (i.e. Program code

and data) during application

runtime:

Minimum 100 Kbytes (Has to be

taken as working assumption

for application development).

Goal: 145 Kbytes as SL45i (not

committed)

yes

MIDP 1.0, CLDC 1.0 As SL45i, including

performance optimizations from

SL45i-Infusio.

yes

‘OEM extensions’ Proprietary API extension as

SL45i. Including ‘Siemens

Game API’

yes

HTTP API over GPRS Sl45i: only CSD yes

3 Key Features

SIEMENS PTE LTD

CX65 Level 2 Service Manual

ICM MP CCQ ASP/ASC Page 5 of 35 Internal Use Only

Bands • Triple Band E-GSM 900 / GSM 1800 / GSM 1900

• GPRS Multi Class 10

Battery • Li-Ion Battery Pack

• Nominal Voltage : 3.7V

• Nominal Capacity : 800 mAh

• GSM Capacity : 700 mAh

• Power Input : 1.8A (0.6 ms) / (4 ms)

• Cut-off Threshold : 3.2V

Stand-by Time • Approx. 250 h / Li-Ion (measured at BSPAMFRMS = 9;

Number of neighboring cells = 0)

Talk Time • Best case approx. 5 hours (lowest output level with

DTX

• Worst case approx. : 2.0 hours (highest output level with

DTX)

Condition for DTX : 40% user talk time

SIM Card

• Small (”Plug In”) 3V SIM card (Phase II)

• To insert the SIM card, the battery pack must be

removed.

GSM Antenna

• A triple band PIFA antenna will be an integral part of the

mobile phone.

Receiver Sensitivity

• EGSM: -102 dBm (-104dBm-15.2) (Specification; static

& with fading)

• PCN : -102 dBm (Specification; static & with fading)

The reception sensitivity must comply with the corresponding

GSM recommendations in all operating conditions

(temperature,

battery level ...).

• EGSM: measurements according typical sensitivity are

not yet available.

• PCN: measurements according typical sensitivity are

not yet available

Measurement values are referred to the external antenna

connector.

Transmitter Power • EGSM: nominal 2W (Specification: Class 4 Mobile

phone)

• PCN: nominal 1W (Specification: Class 1 Mobile phone)

SIEMENS PTE LTD

CX65 Level 2 Service Manual

ICM MP CCQ ASP/ASC Page 6 of 35 Internal Use Only

Transmitter output characteristics is according to GSM 11.10

specification implying all specified operating conditions

(temperature, battery level ...).

Transmitter set points will be specified for GSM and PCN when

typical values and statistical values become available.

Speech Codec

• Triple Rate (HR/FR/EFR) and Adaptive Multi Rate are

available as standard

Temperature

Range

• -100C to +550C (Normal operation)

• -300C to +850C (Storage capability)

Display • Type: Full Graphic

• Resolution: 132 x 176 Pixel

• Color depth: 65K

• Technology: TFT

• Active area / mm: 29.5 x 20.0

• Visible area / mm: max. 33.0 x 23.2

• Illumination: White LED

• Contrast: Adjustable

• Frame rate: 15 frames/seconds

Keypad • Partially bridgeless

• 12-digit block (0-9, #, *) and two function keys (SEND,

END) in one block with small letters.

• ON/OFF key combined with the END key; the symbol _

(I inside O) is used as a symbol for ON/OFF.

• 2 soft keys

• Illumination color : White LED

• 6 white LEDs for keypad (2 white LEDs for night-design)

Acoustics

• Comfortable earpiece

• Omni-directional microphone

Internet Access • Wap 2.0 Dual stack

Camera • Integrated camera with attachable flash

• Sensor with VGA resolution: Choice of two resolutions:-

160 x 120 pixels and 640 x 480 pixels

• Photo can be viewed on the mobile’s display

Connectivity • USB, Serial, and IrDA

4 Comparison with Previous Product

Feature L55 Tuna R65 Ulysses

Supported Systems Triple Band – EGSM 900 /

1800 / 1900

Triple Band – EGSM 900 /

1800 / 1900

Stand-by Time Up to 250 H Up to 300 H

SIEMENS PTE LTD

CX65 Level 2 Service Manual

ICM MP CCQ ASP/ASC Page 7 of 35 Internal Use Only

Talk Time Up to 5 H Up to 6 H

Battery Type / Capacity Li-Ion Battery Pack

Nominal Cap. : 700 mAh

Li-Ion Battery Pack

Nominal Cap.: 800 mAh

Weight Approx. 84 g Approx. 90 g

Volume Approx. 69 cm3Approx. 80 cm3

Length 101 mm 108mm

Width 44 mm 45 mm

Thickness 18 mm 18 mm

SIM Plug-in 1.8V/3 V Plug-in 1.8V/3 V

Antenna Integrated Integrated

Full Rate Yes Yes

Half Rate Yes Yes

Enhanced Full Rate Yes Yes

AMR Yes Yes

Fax / Data Yes Yes

GPRS Yes, Class 8 Yes, Class 10

Keypad Illumination Yes Yes

Display

FSTN full dot matrix, 5 lines

graphic

TFT

Display Illumination Amber White

Ringer Volume Level Min. 95 dB(A) @ 5 cm

Typ. > 100 dB(A) @ 5 cm

Min. 95 dB(A) @ 5 cm

Typ. > 100 dB(A) @ 5 cm

5 Accessories

For CX65, the following accessories will be available.

Description Part number

Power Supply EU L36280-Z4-C404

SIEMENS PTE LTD

CX65 Level 2 Service Manual

ICM MP CCQ ASP/ASC Page 8 of 35 Internal Use Only

Travel Charger EU L36280-Z4-C410

CD ROM CX65 L36453-Z5-C281

Travel Charger (UK) ETC-500 L36880-N5601-A104

Travel Charger (UK) ETC-510 L36880-N5601-A105

Headset with PTT HHS-510 L36880-N5601-A108

Data Cable USB DCA-510 L36880-N5601-A111

Tour Case FCT-650 C60/A60/CF65/CX65/CXT65 L36880-N5601-A149

Data Cable USB DCA-540 SX1/CX65/CXT65/CXV65 L36880-N6501-A102

Note: Visit the Communication Market for updated accessories:

https://communication-market.siemens.de/

5.1 CX65 Interface to accessories

The phone has a fully compatible interface to accessories. The connectors (I/O and RF)

are identical to the L55 Family (C55, S55, A55/52, SL55, M55, and MC60).

SIEMENS PTE LTD

CX65 Level 2 Service Manual

ICM MP CCQ ASP/ASC Page 9 of 35 Internal Use Only

Mechanical interfaces are defined on the mobile phone to make sure that the accessories

are compatible across the whole L55 platform.

Slim Lumberg I/O Connector

SIEMENS PTE LTD

CX65 Level 2 Service Manual

ICM MP CCQ ASP/ASC Page 10 of 35 Internal Use Only

6 Unit Description of CX65

The CX65 Ulysses is designed as a two-PCB phone with exchangeable upper-cover,

exchangeable battery-cover and exchangeable keypad. The upper- and the battery-cover

are lacquered plastic-parts (1-shot-molding; 1 colour), Lower-Case will not be lacquered

(1-shot-molding).

6.1 Exploded View of CX65
