Siemens Simodrive SIMAG H Manuel utilisateur

Planning/Installation Guide 07/2002 Edition

sensor

Measuring System for Main Spindle Drives

SIMAG H

07.02 Edition

General Information 1

Description of Components 2

Technical Data 3

Installation / Calibration 4

Assembly Drawing 5

SIMODRIVE sensor – SIMAG H

Measuring System for

Main Spindle Drives

Planning/Installation Guide

SIMODRIVEDocumentation

Printing history

Brief details of this edition and previous editions are listed below.

The status of each edition is shown by the code in the “Remarks”column.

Status code in the “Remarks” column:

ANew documentation. . . . .

BUnrevised reprint with new Order No.. . . . .

CRevised edition with new status.. . . . .

If factual changes have been made on the page since the last edition, this is indicated by a new edition

coding in the header on that page.

Edition Order No. Remarks

05.99 6SN1 197-0AB30-0BP0 A

07.02 6SN1 197-0AB30-0BP1 C

This manual is part of the documentation on CD-ROM (DOCONCD)

Edition Order No. Remarks

11.02 6FC5 298-6CA00–0BG3 C

Trademarks

SIMATICr, SIMATIC HMIr, SIMATIC NETr, SIROTECr, SINUMERIKr, SIMODRIVErand

MOTION-CONNECTrare Siemens trademarks. All other product and system names are registered

trademarks of their respective owners and must be treated accordingly.

Further information is available on the Internet under:

http://www.ad.siemens.de/simodrive

This publication was produced with Interleaf V 7

The reproduction, transmission or use of this document or its

contents is not permitted without express written authorization.

Offenders will be liable for damages. All rights, including rights

created by patent grant or registration of a utility model or design,

are reserved.

Other functions not described in this documentation might be

executable in the control. This does not, however, represent an

obligation to supply such functions with a new control or when

servicing.

We have checked that the contents of this publication agree with the

hardware and software described herein. Nonetheless, differences

might exist and therefore we cannot guarantee that they are

completely identical. The information given in this publication is

reviewed at regular intervals and any corrections that might be

necessary are made in the subsequent printings. Suggestions for

improvement are welcome at all times.

Subject to change without prior notice.

Siemens–AktiengesellschaftOrder No. 6SN1 197-0AB30-0BP1

Printed in the Federal Republic of Germany

3ls

SIMODRIVE sensor, Measuring System for Main Spindle Drives SIMAG H (PMH) –07.02 Edition

Preface

This document is part of the documentation developed for SIMODRIVE. All pu-

blications are available individually. The documentation list, which includes all

Advertising Brochures, Catalogs, Overviews, Short Descriptions, User Manuals

and Technical Descriptions can be obtained from your local Siemens office (with

Order No.).

This Guide does not purport to cover all details or variations in equipment, nor

to provide for every possible contingency to be met in connection with installa-

tion, operation or maintenance. Should further information be desired or should

particular problems arise which are not covered sufficiently for the purchaser’s

purposes, the matter should be referred to the local Siemens office. The con-

tents of this Guide shall neither become part of nor modify any prior or existing

agreement, commitment or relationship. The Sales Contract contains the entire

obligations of Siemens. The warranty contained in the contract between the

parties is the sole warranty of Siemens. Any statements contained herein do not

create new warranties or modify the existing warranty.

If you have any questions, please contact the following Hotline:

A&D Technical Support Tel: +49 (180) 50 50 222

FAX: +49 (180) 50 50 223

eMail: [email protected]

If you have any questions regarding the documentation (also suggestions, cor-

rections), please send a fax to the following number:

+49 (9131) 98–2176

Fax form: refer to the suggestion sheet the end of this brochure.

For the purpose of this Guide and product labels, a ”qualified person”is one

who is familiar with the installation, mounting, start-up and operation of the

equipment and the hazards involved. He or she must have the following

qualifications:

STrained and authorized to energize, de-energize, ground and tag circuits

and equipment in accordance with established safety procedures.

STrained in the proper care and use of protective equipment in accor-

dance with established safety procedures.

STrained in rendering first aid.

Hotline

Definition of

qualified

personnel

07.02

SIMODRIVE sensor, Measuring System for Main Spindle Drives SIMAG H (PMH) –07.02 Edition

!Danger

This symbol in the document indicates that death, severe physical injury or

substantial property damage will result if proper precautions are not taken.

!Warning

This symbol appears in the document if death, severe physical injury or

property damage can result if proper precautions are not taken.

!Caution

This symbol appears in the document indicating that minor physical injury or

property damage can result if proper precautions are not taken.

Caution

This warning (without warning triangle) indicates that material damage can

result if the proper precautions are not taken.

Notice

This warning indicates that an undesirable situation or condition can occur if

the appropriate instructions/information are not observed.

Note

We recommend that this information is observed

Explanation of the

various symbols

Preface

07.02

vii

SIMODRIVE sensor, Measuring System for Main Spindle Drives SIMAG H (PMH) –07.02 Edition

!Danger

SStart–up/commissioning is prohibited until it has been ensured that the

machine, in which the components described here are to be installed, fufills

the regulations/specifications of the Directive 98/37/EC.

SOnly appropriately qualified personnel may commission/start–up this equip-

ment.

SThis personnel must observe the technical customer documentation rele-

vant to the product and the observe the danger and warning information.

SOperational electrical equipment has parts and components which are at

hazardous voltage levels.

SHazardous axis motion can occur when working with the equipment.

SAll work should be undertaken with the system in a no–voltage condition

!Warning

SPerfect, safe and reliable operation of this equipment assumes that it has

been professionally transported, stored, mounted and installed as well as

careful operator control and service.

SThe information given in catalogs and quotations applies additionally for

special versions of machines and equipment.

SIn addition to the danger and warning information in the technical customer

documentation supplied with the equipment, all relevant national, local and

plant–specific regulations and specifications must also be taken into ac-

count.

!Caution

SFor synchronous motors, voltage is present at the motor terminals when the

rotor is turning (integrated permanent magents).

SSurface temperatures of over +100dC can occur on the motors. For this

reason, no heat–sensitive objects, such as cables or electronic compo-

nents, may be attached to or come into contact with the motor surface.

SWhen handling cables, please observe the following:

–They must not be damaged

–They must not be stressed

–They must not come into contact with rotating components.

Danger and

warning

information

Preface

07.02

SIMODRIVE sensor, Measuring System for Main Spindle Drives SIMAG H (PMH) –07.02 Edition

!Caution

Electrostatic dischargesensitive devices are individual components, integrated

circuits, or boards which when handled, tested or transported, could be des-

troyed by electrostatic fields or electrostatic discharge. These components are

designated as ESDS (ElectroStatic Discharge Sensitive Devices).

Handling ESDS boards:

SThe human body, working area and packing should be well grounded when

handling ESDS components!

SElectronic boards may only be touch by personnel in ESDS areas with con-

ductive floor surface if

–they are grounded with an ESDS bracelet

–they are wearing ESDS shoes or ESDS shoe grounding strips.

SBoards should only be touched when absolutely necessary.

SElectronic modules and boards may neither come into contact with plastic

materials nor man–made fibers

SBoards may only be placed on conductive surfaces (desk with ESDS sur-

face, conductive ESDS foam rubber, ESDS packing bag, ESDS transport

containers).

SBoards may not be brought close to data terminals, monitors or television

sets.

A minimum of 10 cm should be kept between the board and the screen.

SMeasurements may be taken on the boards only if

–the measuring equipment is grounded (e.g. via the protective conductor)

–in the case of floating measuring instruments, the probe is briefly

discharged before a measurement is taken (e.g. through contact with

bare control housing).

ESDS information

Preface

07.02

SIMODRIVE sensor, Measuring System for Main Spindle Drives SIMAG H (PMH) –07.02 Edition

Note

For technical information about the SIMODRIVE 611, please refer to the follo-

wing Guides:

SIMODRIVE 611, Planning Guide

Transistor PWM Inverters for AC Feed Drives and AC Main Spindle Drives

Order Number: 6SN1197-0AA00-0VPV

SIMODRIVE 611 Planning Guide

AC Motors for Feed and Main Spindle Drives

Order Number: 6SN1197-0AA20-0VPV

SIMODRIVE 611 Analog System, Start-Up Guide

Transistor PWM Inverters for AC Feed Drives and AC Main Spindle Drives

Order Number: 6SN1197-0AA60-0VPV

SIMODRIVE 611 Planning Guide;

AC Induction Motors for Main Spindle Drives

Order No.: 6SN1197–0AC60–0VPV

SIMODRIVE 611 Planning Guide;

AC Motors for Main Spindle Drives

1FE1 Built–In Synchronous Motors

Order No.: 6SN1197–0AC00–0VPV

Preface

07.02

SIMODRIVE sensor, Measuring System for Main Spindle Drives SIMAG H (PMH) –07.02 Edition

Preface

Space for your notes
