Adjustable shade control between 9 and 13.
Complies to BS EN 379, BS EN 175 and DIN
standards. Features automatic switching from light to
dark on striking arc. Fitted with adjustable delay
controls for switching light to dark. Desired shade is
selected by large rotary knob on side of helmet.
Fitted with solar panel power supply - no batteries
required. Contoured design helmet with adjustable
headband for added comfort. Suitable for MIG, TIG
and arc welding.
The S0882Automatic Welding Helmet comes ready for use. Batteries are not necessary as operation is by means
of Solar cells which automatically darkens the eye shade cartridge when the arc is struck.
1. SAFETY INSTRUCTIONS
WARNING! THIS HELMET IS NOT SUITABLE FOR USE WITH LASER OR GAS WELDING/CUTTING.
3 Ensure all workshop safety rules, regulations, and conditions are complied with when using welding equipment.
7The helmet will not offer protection against mis-use of workshop tools, equipment, or accessories.
3 Maintain the helmet in good condition, and protect cartridge from liquid and dirt contact.
3 Regularly replace the protective lenses.
7 Non authorised parts may be dangerous and will invalidate the warranty.
7 DO NOT open or tamper with the shade cartridge.
3 Ensure the front cover lens and front lens frame are securely in place before use.
3 Select the shade level before use.
3 Fit the helmet and adjust the head band so the helmet will sit as low and near to your face as possible,
3 Use helmet only in temperatures ranging from -5°C to + 55°C .
7 The eye protective plate in helmet is NOT unbreakable. Helmet will not protect you against severe impact
hazards (such as, but not limited to) fragmenting abrasive discs/grinding wheels, stones and other
grinding tools, explosive devices or corrosive fluids. The helmet will only protect the eyes and face from radiation
and sparks.
3 Remove ill fitting clothing, remove ties, watches, rings, and other loose jewellery.
3 Maintain correct balance and footing. Ensure the floor is not slippery and wear non slip shoes.
3 Keep children and unauthorised persons away from the working area.
WARNING! DO NOT use the helmet if damaged or you suspect it may be faulty. (Contact Service Agent).
7 DO NOT weld when you are tired or under the influence of alcohol, drugs or intoxicating medicines.
7 DO NOT get the helmet wet or use in damp or wet locations.
7 DO NOT leave work area with helmet in lowered position, as bright light source may darken cartridge unexpectedly.
7 DO NOT place the helmet on a hot surface.
3 Clean helmet (see chapter 6) and store the helmet in a safe, dry, childproof location.
DANGER! If, at any time, the face plate in the cartridge FAILS to darken when exposed to a welding
spark, DO NOT USE. Remove cartridge and return to your dealer for service/inspection. Continued
use of the product knowing that the auto darkening feature is not functioning may damage your eyes
and cause blindness. Continued use of the helmet which is not functioning will invalidate the
warranty and could prohibit a successful claim on any insurance policy.
2. INTRODUCTION
INSTRUCTION MANUAL
WELDING HELMET
SOLAR POWERED 9 - 13 SHADES
Thank you for purchasing a Siegen Tools product. Manufactured to a high standard this product will, if used according to these
instructions
and properly maintained, give you years of trouble free performance.
IMPORTANT: PLEASE READ THESE INSTRUCTIONS CAREFULLY. NOTE THE SAFE OPERATIONAL REQUIREMENTS, WARNINGS AND
CAUTIONS. USE THIS PRODUCT CORRECTLY AND WITH CARE FOR THE PURPOSE FOR WHICH IT IS INTENDED. FAILURE TO DO SO
MAY CAUSE DAMAGE AND/OR PERSONAL INJURYAND WILL INVALIDATE THE WARRANTY. RETAIN INSTRUCTIONS FOR FUTURE USE.
MODEL NO:
S0882
fig 1
S0882 Issue No.1 01/05/11
Original Language Version
