SICK GSE2 Flat Side Manuel utilisateur

BETRIEBSANLEITUNG

GSE2 Flat Side

Miniatur-Lichtschranke

OPERATING INSTRUCTION

GSE2 Flat Side

Miniature photoelectric sensors

Described product

G2F

GSE2F(S)

Manufacturer

SICK AG

Erwin-Sick-Str. 1

79183 Waldkirch

Germany

Production location

SICK Product Center Asia Pte. Ltd.

Singapore

www.sick.com.sg

Legal information

This work is protected by copyright. Any rights derived from the copyright shall be

reserved for SICK AG. Reproduction of this document or parts of this document is

only permissible within the limits of the legal determination of Copyright Law. Any modi‐

fication, abridgment or translation of this document is prohibited without the express

written permission of SICK AG.

The trademarks stated in this document are the property of their respective owner.

Original document

This document is an original document of SICK AG.

2006/42/EC

SAFETY

8023329.1C14/28.06.2021 | SICK O P E R A T I N G I N S T R U C T I O N | GSE2 Flat Side 3

Subject to change without notice

Contents

1 General safety notes................................................................................ 5

2 Notes on UL approval............................................................................... 5

3 Intended use............................................................................................. 5

4 Operating and status indicators.............................................................. 5

5 Mounting................................................................................................... 6

6 Electrical installation................................................................................ 6

7 Commissioning......................................................................................... 8

8 Troubleshooting........................................................................................ 10

9 Disassembly and disposal....................................................................... 10

10 Maintenance............................................................................................. 11

11 Technical specifications........................................................................... 12

11.1 Dimensional drawing............................................................... 12

11.2 Light spot diameter.................................................................. 13

CONTENTS

4O P E R A T I N G I N S T R U C T I O N | GSE2 Flat Side 8023329.1C14/28.06.2021 | SICK

Subject to change without notice

1 General safety notes

■Read the operating instructions before commissioning.

■

Connection, mounting, and configuration may only be performed by trained

specialists.

■

2006/42/EC

SAFETY

Not a safety component in accordance with the EU Machinery Directive.

■

Do not install the sensor at locations that are exposed to direct UV radiation

(sunlight) or other weather influences, unless this is expressly permitted in the

operating instructions.

■When commissioning, protect the device from moisture and contamination.

■These operating instructions contain information required during the life cycle of

the sensor.

2 Notes on UL approval

The device shall be supplied from an isolating transformer having a secondary overcur‐

rent protective device that complies with UL 248 to be installed in the field rated either:

a) max 5 amps for voltages 0 ~ 20 V (0 ~ 28.3 V peak), or

b) 100 / Vp for voltages of 20 ~ 30 V (28.3 ~ 42.4 V peak).

Alternatively, they can be supplied from a Class 2 power supply.

UL Environmental Rating: Enclosure type 1

3 Intended use

The GSE2F(S) is an opto-electronic through-beam photoelectric sensor (referred to as

“sensor” in the following) for the optical, non-contact detection of objects, animals, and

persons. A sender (GS) and a receiver (GE) are required for operation. If the product is

used for any other purpose or modified in any way, any warranty claim against SICK AG

shall become void.

4 Operating and status indicators

GENERAL SAFETY NOTES 1

8023329.1C14/28.06.2021 | SICK O P E R A T I N G I N S T R U C T I O N | GSE2 Flat Side 5

Subject to change without notice

1 2

1LED indicator green: supply voltage active

2Receiver: LED indicator yellow: status of received light beam

5 Mounting

Mount sensors (sender and receiver) using suitable mounting brackets (see the SICK

range of accessories). Align the sender and receiver with each other.

The minimum distance between sender and receiver is:

•GSE2F(S)-xxx1xx: 24 mm

•GSE2F(S)-xxx2xx: 72 mm

•GSE2F(S)-xxx5xx: 238 mm

NOTE

Swap the sender and receiver arrangement at every second through-beam photoelec‐

tric sensor and ensure that there is sufficient distance between the through-beam

photoelectric sensors.

Receiver (GE)

Sender (GS)

Receiver (GE)

Figure 1: Arrangement of several through-beam photoelectric sensors

Note the sensor's maximum permissible tightening torque of 0.1 Nm.

6 Electrical installation

The sensors must be connected in a voltage-free state (UV = 0 V). The following informa‐

tion must be observed, depending on the connection type:

4 OPERATING AND STATUS INDICATORS

6O P E R A T I N G I N S T R U C T I O N | GSE2 Flat Side 8023329.1C14/28.06.2021 | SICK

Subject to change without notice

– Plug connection: note pin assignment: when the lid is open, the male connector

can be swiveled horizontally and vertically.

– Cable: wire color

Only apply voltage/switch on the voltage supply (UV > 0 V) once all electrical connec‐

tions have been established.

Explanation of the connection diagram (Tables pin assignment):

Q = switching outputs

n. c. = not connected

DC: 10 ... 30 V DC

Table 1: Pin assignment

GE2F(S)

-X14xx

-X54xx

1BN + (L+) + (L+)

2- - -

3BU - (M) - (M)

4BK Q Q

0.127 mm2, AWG281

1Before sensor date code 5220:

Cable BK: 0.1 mm2, AWG30

Table 2: Pin assignment

GS2F(S)

-X14xx

-X54xx

1BN + (L+) + (L+)

2- - -

3BU - (M) - (M)

4BK n. c. n. c.

0.127 mm2, AWG281

1Before sensor date code 5220:

Cable BK: 0.1 mm2, AWG30

ELECTRICAL INSTALLATION 6

8023329.1C14/28.06.2021 | SICK O P E R A T I N G I N S T R U C T I O N | GSE2 Flat Side 7

Subject to change without notice

Table 3: Switching output

PNP Q

(≤ 50 mA)

+ (L+)

– (M)

+ (L+)

– (M)

(≤ 50 mA)

+ (L+)

– (M)

+ (L+)

– (M)

NPN Q

(≤ 50 mA)

+ (L+)

– (M)

+ (L+)

– (M)

(≤ 50 mA)

+ (L+)

– (M)

+ (L+)

– (M)

7 Commissioning

1Alignment

Figure 2: Alignment GSE2F

2Sensing range

Observe the application conditions: Adjust the distance between the sender and the

receiver according to the corresponding diagram [see figure 3] (x = sensing range, y =

operating reserve).

6 ELECTRICAL INSTALLATION

8O P E R A T I N G I N S T R U C T I O N | GSE2 Flat Side 8023329.1C14/28.06.2021 | SICK

Subject to change without notice

If several through-beam photoelectric sensors which are installed next to one another are

to be used, we recommend swapping the sender/receiver arrangement at every second

through-beam photoelectric sensor and ensuring that there is sufficient distance between

the through-beam photoelectric sensors. By doing this, mutual interference can be pre‐

vented [see figure 1].

Distance in mm (inch)

(0.79)

(1.57)

(2.36)

(3.15)

100

Operating reserve

Figure 3: Operating reserve 50 mm

Sensing range

Sensing range max.

Distance in mm (inch)

(0.79)

(1.57)

(3.15)

(2.36)

0 40

Figure 4: Sensing range 50 mm

(1.57)

0 80

(3.15)

120

(4.72)

160

(6.3)

200

(7.87)

100

Operating reserve

Distance in mm (inch)

Figure 5: Operating reserve 150 mm

Sensing range

0 150 200

Sensing range max.

Distance in mm (inch)

(1.57)

(3.15)

200

(7.87)

160

(6.3)

120

(4.72)

Figure 6: Sensing range 150 mm

Distance in mm (inch)

200

(7.87)

400

(15.75)

600

(23.62)

800

(31.5)

100

Operating reserve

Figure 7: Operating reserve 500 mm

Sensing range

0 500 700

Sensing range max.

Distance in mm (inch)

200

(7.87)

800

(31.5)

600

(23.62)

400

(15.75)

Figure 8: Sensing range 500 mm

COMMISSIONING 7

8023329.1C14/28.06.2021 | SICK O P E R A T I N G I N S T R U C T I O N | GSE2 Flat Side 9

Subject to change without notice

Figure 9: Sensing range area

Use see table 3, page 8 to check the function. If the switching output fails to behave in

accordance with the table, check the application conditions. See section Fault diagnosis.

3Sensitivity setting

Sensor which it is not possible to set: The sensor is adjusted and ready for operation.

8 Troubleshooting

The Troubleshooting table indicates measures to be taken if the sensor stops working.

Table 4: Troubleshooting

LED indicator/fault pattern Cause Measures

Yellow LED does not light up

even though the light beam

is aligned to the receiver and

there is no object in the path of

the beam

No voltage or voltage below

the limit values

Check the power supply,

check all electrical connec‐

tions (cables and plug connec‐

tions)

Voltage interruptions Ensure there is a stable power

supply without interruptions

Sensor is faulty If the power supply is OK,

replace the sensor

Yellow LED lights up, no object

in the path of the beam

The beam of light of a pho‐

toelectric through-beam sen‐

sor hits the receiver of

another (neighboring) photo‐

electric through-beam sensor

Swap the sender and receiver

arrangement at every sec‐

ond through-beam photoelec‐

tric sensor and ensure that

there is sufficient distance

between the through-beam

photoelectric sensors, see

figure 1, page 6

9 Disassembly and disposal

The sensor must be disposed of according to the applicable country-specific regula‐

tions. Efforts should be made during the disposal process to recycle the constituent

materials (particularly precious metals).

8 TROUBLESHOOTING

10 O P E R A T I N G I N S T R U C T I O N | GSE2 Flat Side 8023329.1C14/28.06.2021 | SICK

Subject to change without notice
