①
NO.2Instructions
NO.1 Spare par t list
Remote control 1pc AC power cable 1pc Charger 1pc Fuse 2pcs
Power
Indicator
Charger
Charging light
Fuse DC socket
(Charging Dock)
AC socket
AC/DC switch
④
Power Speed
Color Black,white,red Frequency
Voltage Weight 22KG
Capacity 150 balls Package 63.5*53*61.5cm
Remote control
battery(9V) 2pcs
Retracted pull-rod
Ball basket
Main machine
Shooting wheel
Lob feet
Shooting window
120W
AC power(100V-110V or
220V-240V selected)
DC power(12V)
1.8-6sec/ball
20-140 km/h
Parameters
Construction
1.Introduction of control panel
Please check the parts according to the following list when the machine unpacked.
AC DC
Power Plug
AC OFF DC
DC lamp
TENNIS BALL MACHINE
DC socketFUSEAC socket
Note:After checking,please fit the fuse tube on the machine and let the remote control
equipped with battery.
NO.3 Function Parameters
NO.
1
2
3
4
5
6
7One button to choose six kinds of cross-line ball.
8
9
10
11
12
13
14
15
16
17
Function Instruction
Description
Smart remote control with multi-function(speed,frequency,angle,rotate,ect.)
High performance of photoelectric sensors makes the machine runs more stably.
Humanized design,internal serve direction,more practical training.
The remote control is clear and easy to operate with LCD screen.
Standard cells, and the use time 3 to 4 hours.
Remote control with light ball or deep ball two line function(wide,middle,narrow),
three line functions.
Capacity:150pcs balls.
Random function.
Top-back spin and power adjustment.
Internal battery makes the machine more convenient.
Double S ball dividing system makes the ball shooting more smoothly.
Suitable for any tennis balls(training balls,professional balls).
Shooting wheels and the main motor with high quality materials are durable,motor
service life can be up to 10 years.
Portable telescopic rod,easy to move.
Standard accessories :remote control,charger,and cable.
Luxurious design easy to carry,can be placed in the trunk of any cars after folding.
（Red light means charging.Green light means full charge.）
（Note: The charger is only used for charging, Don’t use it as the power cord）
