1-INTRODUCTION
1.1 MANUFACTURING SPECIFICATIONS
The automatic case sealing machine Mod. SM44 HS has been designed and manufactured compling with the
legal requirements in force at the date of its manufacture.
THE REFERENCE DOCUMENTS ARE:
1.2 HOW TO READ AND USE THE INSTRUCTION MANUAL
1.2.1 IMPORTANCE OF THE MANUAL
The manual is an important part of the machine; all information contained herein is intended to enable the equip-
ment to be maintained in perfect condition and operated safely. Ensure that the manual is available to all ope-
rators of this equipment and is kept up to date with all subsequent amendments. Should the equipment be sold
or disposed of, please ensure that the manual is passed on. Electrical and pneumatic diagrams are included in
the manual. Equipment using PLC controls and/or electronic components will include relevant schematics or pro-
grammes in the enclosure, and in addition the relevant documentation will be delivered separately.
1.2.2 MANUAL MAINTENANCE
Keep the manual in a clean and dry place near the machine. Do not remove, tear or rewrite parts of the manual
for any reason.
Use the manual without damaging it.
In case the manual has been lost or damaged, ask your after sale service for a new copy, quoting the code num-
ber of the document.
1.2.3 CONSULTING THE MANUAL
The manual is composed of:
- pages which identify the document and the machine;
- index of the subjects:
- instructions and notes on the machine: sections 2÷14
- enclosures, drawings and diagrams:
sections 15÷16
- spare parts: last section.
All pages and diagrams are numbered. The spare parts lists are identified by the figure identification number.
All the notes on safety measures or possible dangers are identified by the symbol:
All the important warning notes related to the operation of the machine are identified by the symbol:
The parts typed in bold refer to technical data or technical notes on a specific subject.
1.2.4 HOW TO UPDATE THE MANUAL IN CASE OF MODIFICATIONS TO THE MACHINE
Modifications to the machine are subject to manufacturer’s internal procedures.
The user receives a complete and up-to-date copy of the manual together with the machine.
Afterwards the user may receive pages or parts of the manual which contain amendments or improvements
made after its first publication.
The user must use them update this manual.
Machines guidelines 2006/42/CE
Standards applied
UNI EN 415-7
EN 415-9:2009
Guidelines EMC 2004/108/CE
Standards applied
CEI EN 60204-1:2006
EN 61000-6-2:2005
EN 61000-6-4:2007
