Showlite PBS-20 Manuel utilisateur
PBS-20 Party Ball
User Manual
Item number: 00069703
Version: 11/2020
2
Thank you for choosing this product. To ensure that you are completely satisfied with this
product, please read and understand this manual carefully.
PLEASE READ CAREFULLY
Please keep this manual in a safe place for future reference. Hand over all documents when
passing on the product to third parties. Never leave children unattended with the packaging
material. For products packed in plastic bags, there is a risk of suffocation from packaging materials.
The product should only be used under adult supervision. Only use the product if it is in
perfect condition. Do not use the product if damage is visible or suspected. We are not liable
for any damage that occurs as a result of non-observance of the safety instructions or incorrect or
improper handling.
Follow the operating instructions!
The WARNING signal word identifies hazards that, without precautions,
could result in serious injury.
The signal word NOTE indicates general precautions that should be
observed when handling the product
Images and screen images in this manual may differ slightly from the
actual product's appearance, as long as it does not adversely affect the
technical characteristics and safety of the product.
All personal phrasing in this manual should be considered gender
neutral.
This operating manual applies to responsible users and to persons who have been
supervised or instructed in the operation of the device by a person responsible for their
safety and who have proven that they are capable of handling the device.
Children should be supervised to ensure that they do not use this
device as a toy.
Never allow children to play unattendedwith the packaging material.
Risk of damage to property! We are not liable for accidents that occur
as a result of non-observance of the safety instructions or incorrect
handling.
All information in this operating manual has been checked to the best of our knowledge and belief.
However, neither the author nor the publisher can be held liablefor any damages related to the use
of thismanual.
Other product, brand and company names mentioned in this document may be the
trademarks of their respective owners. The user of this document is responsible for
compliance with all applicable copyright laws.
3
Caution
Please observe the following basic instructions in order not to endanger yourself or others
and to avoid damage to external devices.
Warnings
Do not disassemble or modify the product. This could result in injury from electric shock.
If you notice that the power cord shows obvious signs of wear, the appliance is
malfunctioning, smells burnt or smokes, immediately unplug the appliance from the wall
outlet and refer servicing, maintenance or repair to an authorised service centre or your
dealer.
Before cleaning the product, you should turn it off and disconnect it from the power supply.
Always place the product on a flat, stable surface to ensure a secure stand.
Do not use the product in a damp or wet environment.
Do not place containers filled with liquids, such as vases, glasses or bottles, on the product.
Do not place small objects on top of it that could slide in, such as hairpins, sewing needles or
coins.
Precautions
To avoid damage to the product, do not place it in places with high temperatures or a lot of
dust, do not place it directly next to an air conditioner and avoid direct sunlight.
Do not place the article near other electrical equipment to avoid interference.
Do not use force when handling the product or place heavy objects on it.
Disconnect the power supply if you are not going to use the device for a longer period of
time. To disconnect the power, pull the plug, not the cable.
Please handle the power cable with care. It should not be near radiators, do not place heavy
objects on it and lay it in such a way that no persons can step on it or fall over it.
Mains voltage
If an external power supply unit is required for use, connect it to an outlet with the correct
voltage.
Do not connect the device to a different mains voltage than that for which your product is
intended.
Unplug the power cord from the wall outlet when not using the product or when there is a
thunderstorm.
4
Installation / Hanging mounting
The installation may only be carried out by authorised specialist personnel!
In case of overhead rigging, please observe the applicable standards and regulations in your
country. In any case, a second independent suspension must be used to secure the unit.
This can be ensured by a safety net or a suitable safety rope/chain or similar.
When mounting the unit on a stand, its secure stand and compliance with its maximum load
must be ensured.
Fire hazard
Do not attach the product to flammable materials. Do not cover ventilation slots and do not
operate the product above 40°C ambient temperature. Use the attached holding device for
mounting.
Keep a safety distance of at least 50cm to all other surfaces. Maintain a minimum distance of
at least 50cm between the light emission and the illuminated area. Keep liquids, moisture
and inflammable materials away from the product.
High light intensity
High light intensity can cause visual damage. Do not look directly into the light source.
Epilepsy
Flashing light can cause epileptic seizures. People who are sensitive to flasing light should
avoid exposing themselves to flashing light and refrain from looking directly at the light
source.
Place
Do not expose the product to the following conditions to avoid deformation, discoloration or
major damage:
Direct sunlight, extreme temperature or humidity, excessively dusty or dirty place, strong
vibrations or shocks, strong magnetic fields
Cleaning
Clean the product only with a soft, dry cloth. Do not use paint thinner, solvents, cleaning
fluids or chemically impregnated wipes.
Handling
Do not exert excessive force on operating elements such as switches, knobs, buttons, and
fastening screws.
Do not insert any paper, metal or other objects inside. If this happens, unplug the AC
adapter/power cord from the wall outlet. Have the product checked by qualified service
personnel.
5
© 2020
This manual is protected by copyright. Copying or reprinting, even in extracts, is only
permitted with the consent of Musikhaus Kirstein GmbH. The same applies to the
reproduction or copying of pictures, also in modified form.
Content
1. General overview............................................................................................... 5
2. Commissioning and mounting.......................................................................... 5
3. Technical data.................................................................................................... 6
1. General overview
The PBS-20 Party-Ball is a powerful RGBAUv LED light effect that produces
constantly rotating, multicoloured light beams. The best effect you get in connection
with a fog machine. This light effect has a music control.
2. Commissioning and mounting
Please use only the supplied mains adapter.
To ensure adequate ventilation, mount the lighting effect with the bracket or holding
device. Operate the spotlight to all other sides with a minimum distance of 50cm to
surfaces. Keep a minimum distance of at least 50cm between the light emission and
the illuminated area.
This fixture is only intended for operation in dry indoor areas (protection class IP20).
Keep the fixture away from liquids, moisture and flammable materials.
Mount the fixture carefully to avoid injury by falling.
The fixture may only be mounted and secured by qualified personnel.
In case of overhead rigging, please observe the applicable standards and
regulations in your country. In any case, the installation must be secured by a
second independent suspension (e.g. safety net, safety rope, safety chain).
6
3. Technical data
Article description
PBS-20 Party Ball
Number of LEDs
6 (RGBAWUv)
Operating Modes
Automatic-Music-Control
Size in mm
180x180x150
Weight in kg
0,3
Power supply
5V/1A
Operating temperature max.
40°C
Protection class
IP20
7
WEEE declaration
(Waste of Electrical and Electronic Equipment)
Your product has been designed and manufactured with high quality materials and components that
are recyclable and can be reused.
This symbol means that electrical and electronic devices must be disposed of separately from
household waste at the end of their useful life.
Please dispose of this device at your local municipal collection point or at the recycling center.
Please help preserve the environment we live in.
Technical changes and changes in appearance are reserved.
All information corresponds to the status at the time of printing.
Musikhaus Kirstein GmbH assumes no liability for the correctness and completeness of the
descriptions, illustrations and information contained therein.
Shown colors and specifications may differ slightly from the product.
Musikhaus Kirstein GmbH - Products are only available through authorized dealers.
Distributors and dealers are not authorized representatives of Musikhaus Kirstein GmbH and have no
authorization to bind Musikhaus Kirstein GmbH legally in any way, be it expressly or through coherent
action.
Musikhaus Kirstein GmbH
Bernbeurener Str. 11
86956 Schongau –Germany
Phone: 0049-8861-909494-0
Fax: 0049-8861-909494-19
