DMX 512 MERGER SERIES
1/3
User Manual
8MG3BU DMX MERGER User Manual
This DMX Merger can choose HTP Mode or BACKUP Mode to connect main
console and 2 backup consoles. All the inputs and outputs are completely isolated
by the latest electrical isolation technology. Each DMX output has super driving
ability. Each input and output has LED indicator.
1. Technical Parameter
Power input ............................................ AC88~256V /50~60HZ
Fuse(internal) .................................................................... T2A
Dimension ...................................................... 482X173X46MM
Weight ........................................................................1.75 KG
2.Safety rules
3.Contents in the package
* Keep the unit away from magnetic fields when operating.
* Do not make any inflammable liquids or metal objects enter the unit.
* Handle this product with great care, any strong shocks or vibration
may result in malfunction.
* This unit must only be operated by adults, do not allow children to tamper
or play with it.
* Should any liquid be spilled on the unit, disconnect the power supply to the
product immediately.
Before operating, please read the User Manual completely. That would be
necessary and helpful for you to use the unit more availably and effectively.
The following rules give important information regarding safety during use
and maintenance:
* Keep the unit dry, do not expose it to water or high levels of humid.
* Don’t try to dismantle or modify the product without any authorized
permission.
* DMX MERGER 1PC
* AC Adaptor 1PC
* 1PCUser Manual
