Page 1 of 23
INTRODUCTION
This instruction guide contains important safety, performance and service information. Read it before you take the first ride on your new Shiv equipped with
the Specialized Carbon Aerobar with Aerostem or Hydroformed Alloy Aerobar, and keep it for reference. This instruction guide should be used in conjunction
with the Specialized Bicycle Owner’s Manual (“Owner’s Manual”). Please read the Owner’s Manual in its entirety before reading this Instruction Guide. If you do
not have a copy of the Owner’s Manual, you can download it for free at www.specialized.com, or obtain it from your nearest Authorized Specialized Dealer or
Specialized Rider Care.
Additional safety, performance and service information for specific components such as suspension or pedals on your bicycle, or for accessories such as
helmets or lights, may also be available. Make sure that your Authorized Specialized Dealer has given you all the manufacturers’ literature that was included with
your bicycle or accessories. In case of a conflict between the instructions in this instruction guide and information provided by a component manufacturer, always
follow the component manufacturer’s instructions.
This guide is not intended as a comprehensive use, service, repair or maintenance guide. Please see your Authorized Specialized Dealer for all service, repairs or
maintenance. Your Authorized Specialized Dealer may also be able to refer you to classes, clinics or books on bicycle use, service, repair, and maintenance.
Specialized recommends that installation be performed by an Authorized Specialized Dealer. If you attempt to perform the installation yourself, which
Specialized does not recommend, make sure you possess the appropriate mechanical skill, knowledge, and quality tools to do so. If you have any doubt
regarding your mechanical ability or have any questions, please consult with your Authorized Specialized Dealer.
WARNING! The combination of
this symbol and word indicates a
potentially hazardous situation which,
if not avoided, could result in serious
injury or death. Many of the Warnings
say “you may lose control and fall.”
Because any fall can result in serious
injury or even death, we do not always
repeat the warning of possible injury
or death.
CAUTION: The combination of the safety alert
symbol and the word CAUTION indicates a
potentially hazardous situation, which, if not
avoided, may result in minor or moderate
injury, or is an alert against unsafe practices.
The word CAUTION used without the safety
alert symbol indicates a situation which, if not
avoided, could result in serious damage to the
bicycle or the voiding of your warranty.
INFO: This
symbol
alerts the
reader to
information
which is
particularly
important.
GREASE:
This symbol
means that
high quality
grease
should be
applied as
illustrated.
TORQUE: This
symbol highlights
the correct torque
value for a specific
bolt. In order
to achieve the
specified torque
value, a quality
torque wrench must
be used.
TECH TIP:
Tech Tips are
useful tips
and tricks
regarding
installation
and use.
WARNING! Correct tightening force on fasteners (nuts, bolts, screws) on your bicycle is important. If too little force is applied, the
fastener may not hold securely. If too much force is applied, and the fastener can strip threads, stretch, deform or break. Either way,
incorrect tightening force can result in component failure, which can cause you to lose control and fall.
CAUTION: Ensure that all contact surfaces are clean and bolt threads are greased or have a threadlocking compound (refer to the
instructions for each bolt) prior to installation.
CAUTION: While riding, listen for any creaks, as a creak can be a sign of a problem with one or more components. Periodically examine
all surfaces in bright sunlight to check for any small hairline cracks or fatigue at stress points, such as welds, seams, holes, and points
of contact with other parts. If you hear any creaks or discovery any cracks, no matter how small, immediately stop riding the part and
have it inspected by your Authorized Specialized Dealer.
WARNING! Only use Specialized supplied hardware at all times. Using other hardware may compromise the integrity and strength of the
assembly which may result in damage to the bicycle or its components or in an accident which can cause serious injury or death.
Where indicated, ensure that each bolt is torqued to specification. After your first ride, and periodically thereafter, recheck the
tightness of each bolt to ensure secure attachment of the aerobar. The following is a summary of torque specifications in this guide:
TORQUE SPECS:
LOCATION Torque (in-lbf) Torque (Nm) LOCATION Torque (in-lbf) Torque (Nm)
Stem @ Steerer Tube 40 4.5 Control Tower 25 2.8
Stem @ Handlebar 80 9.0 Brake mounting bolts 70 7.9
Risers @ Handlebar 80 9.0 Brake cable pinch bolt 55 6.2
Extension mount @ Extension 40 4.5 Brake pad 43 4.9
Extension mount @ Pad Holder 40 4.5 Saddle rail clamp bolt 120 13.5
Bottom bracket door 25 2.8 Seat collar bolt 45 5.1
TOOLS REQUIRED
2, 2.5, 3, 4, 5, 6mm Allen keys
3, 4, 5, 6mm socket-style Allen keys
10mm wrench
Torque wrench
High-quality grease
Blue threadlocker (Loctite 242)
Cable and housing cutters
Flathead screwdriver (notched)
