PULSE TYPE
HDC-AC (200Hz)
Device: Compact and lightweight with Digital controlled. High power
the output of static elimination
Advanced ionizing capability by eliminating static electricity evenly
from high-speed moving objects
Long-term stability in performance
Require less maintanenace
(50/60Hz)
Device: Heavy and large due to winding transformer
High voltage of 4-7KV is required
Minor uncleanness and abrasion of emitter needle does not impact
the result of static elimination
Unclean emitter needle may cause the current to leak out and damage
the insulator
Speed of static elimination is slightly inferior to DC type
Use sine wave, less noise generated compares to pulse type device
(DC/AC)
Frequency (kHz)
Device: extremely compact and small due to HV power
Low voltage of 2KV is required
Damage to the insulator due to current leakage is small
Abrasion of emitter needle is minimum, replacement of emitter
needle may not be required depends on the material used
Ion generated near the emitter needle can be carried away by metal
pipes and vinyl tubes,etc.
Minimum change in the ion balance
AC TYPE
S t e a d y T y p e
Positive ion charged emitter needle and Negative ion charged emitter
needle generate large amount of ions which increase static elimination
speed. Requrie additioanl device to monitor the ion balance as the
abrasions of emitter needle may differ between Positive ion charged
emitter needle and Negative ion charged emitter needle
DC TYPE
(FewHz～30Hz）
Speedy in static elimination due to various frequncies
Big Electrical noise
Applied voltage 6-10KV
Unclean emitter needle may cause the current to leak out and
damage the insulator
High Voltage Static Eliminator Types and Characters
Method and Features
AC TYPE
(With ion adjustment)
Stable and well-balanced static
elimination by SSD unique
technology
AC TYPE
（Without ion adjustment）
Ion controller is required as the
Positive and Negative ions emitted
are not even
D C T Y P E
Uneven static elimination over the
entire area as ions ejected are
seperated by different emitter
needles
About Icons
Contents
● Characters and Details
Real ESD Solutions & New Technology
P2~3
●AC HV BUILT-IN IONIZER ELIMINOSTAT characters & details P4~5
HDC-AC Bar Type Ionizer P6~8
●STATIC ELIMINATOR BLOWERS WINSTAT HDC-AC Type HV BUILT-IN P9~14
High Frequency Type P15~17
DC Type P18~19
●HIGH FREQUENCY COMPACT SIZE TRANSFORMER BUILT-IN
AC TYPE SMALL SIZE IONIZER Nozzle Type P20~23
PIEZONIZER Gun Type P24~25
Pencil Type P25
●STATIC ELIMINATOR TESTER STATIRON Static Electricity Meter P26
In-Line Static Electricity Meter P26
●DECAY TESTER Handy Type CPM P27
Charged Plate Moniter P27
STATIC HONESTMETER Half Decay Tester P28
Honest Data Analyzing System P28
●RESISTANCE METER Digital Resistance Meter P29
SHOETESTERII Antistatic Shoe Leakage Tester P30
●AC POWER SUPPLY IONIZER ELIMINOSTAT High Voltage P31~32
Bar Electrode P33
Air Electrode P34
●DC POWER SUPPLY IONIZER ELIMINOSTAT Intergrated Power Supply Ionizer P35
●EXPLOSION-PROOF IONIZER Explosion-Proof Ionizer System P35
●HEAT-RESISTANCE IONIZER
ELIMINOSTAT P36
●LIGHT IRRADIATION IONIZER IRISYS Soft X-ray irradiation Ionizer P36
●DC HV GENERATOR STATILLER P37
●DUST HALER DUST HALER P38~39
●ANTI-STATIC SPRAY STATINOL P39
3
ChargeSNS
ChargeSNS
Removable
Balancer
fixfixfixfixfixfixfix
Replaceable
Buzzer Alarm
Buzzer rings when ion alarm or fan alarm is activated
HV Alarm
LED signals when HV transformer is abnormal
HV Alarm Output
LED/ OUTPUT signals when HV transformer is abnormal
Fan Alarm
LED displays when abnormal fan activity happens
Fan Alarm Output
LED/OUTPUT signals when FAN is abnoraml
Safety Louver
Operation stops when removing louver as easy
Maintenance
Serial Connection
Multiple serial connection available inside the
device
Tungsten Emitter Needle
SSD's Original Long life Emitter Needle
Emitter Needle Automatic Cleaning
Automatic emitter needle cleaning （24H/Time）
Ion Balance Monitor
Shows Ion Balance
DC corona discharge system
The ionizer uses a DC corona discharge system
Built-in Ion Balancer
Built-in tuned ion balancer
Air Speed Adjustment
Controllable Air speed
Over Current
LED signals when there is a over current for Safety
control
Cleaning Check
Signals when emitter needle is dirty or low ion
generation
HDC-AC
SSD unique techonology
Hybrid Digitally controlled AC
Abnormal Discharge Alarm
LED signals when emitter needle is discharging
abnormally
Over Current Alarm (Value Setting)
Prevent over current with self value-setting
Over Current Alarm (FIXED)
Prevent over current with a fixed value
Over Current Alarm (3 steps)
Prevent over current with 3 stages of setting
Charged Object Sensor
Detect any approach of charged objects
Emitter Needle Missing Sensor
Remind any missing emitter needle during
replacement
Emitter Needle Replaceable
Emitter needle set and needle can be replaced by
customer
MEG102
