Ship To Shore 66906 Manuel utilisateur

Visit our website at: http://www.harborfreight.com

Email our technical support at: [email protected]

REV 14i

Owner’s Manual & Safety Instructions

Save This Manual Keep this manual for the safety warnings and precautions, assembly,

operating, inspection, maintenance and cleaning procedures. Write the product’s serial number in the

back of the manual near the assembly diagram (or month and year of purchase if product has no number).

Keep this manual and the receipt in a safe and dry place for future reference.

When unpacking, make sure that the product is intact

and undamaged. If any parts are missing or broken,

please call 1-888-866-5797 as soon as possible.

No portion of this manual or any artwork contained herein may be reproduced in

any shape or form without the express written consent of Harbor Freight Tools.

Diagrams within this manual may not be drawn proportionally. Due to continuing

improvements, actual product may differ slightly from the product described herein.

Tools required for assembly and service may not be included.

Read this material before using this product.

Failure to do so can result in serious injury.

SAVE THIS MANUAL.

Page 2 For technical questions, please call 1-888-866-5797. Item 66906

SAFETY OPERATION MAINTENANCESETUP

SPECIFICATIONS

Electrical Requirements 120 V~, 60 Hz, 125 W

Cord Length 3’ 5" Long

Overall Dimensions 12-7/8" Dia. x 12" H

Weight 4.21 lb.

Features: 1 Vented See-Through Lid

5 Adjustable Removable Trays

HOUSEHOLD USE ONLY

IMPORTANT SAFETY INFORMATION

READ AND UNDERSTAND ALL

INSTRUCTIONS

When using electrical appliances, basic

safety precautions should always be

followed including the following:

1. Read all instructions.

2. Do not touch hot surfaces. Use handles or knobs.

3. To protect against electrical shock do not

immerse cord, plugs, or the main unit in water

or other liquid. Only the Top Lid (1), Lid (2), the

five Food Trays (3), and anything else that may

touch the food, may be immersed for cleaning.

Thoroughly clean and dry these parts prior to

first use and before every subsequent use.

4. Close supervision is necessary when any

appliance is used by or near children.

5. Unplug from outlet when not in use and

before cleaning. Allow to cool before

putting on or taking off parts.

6. Do not operate any appliance with a damaged

cord or plug or after the appliance malfunctions

or has been damaged in any manner.

7. The use of accessory attachments

not recommended by the appliance

manufacturer may cause injuries.

8. Do not use outdoors.

9. Do not let cord hang over edge of table

or counter, or touch hot surfaces.

10. Do not place on or near a hot gas or

electric burner, or in a heated oven.

11. Extreme caution must be used

when moving an appliance.

12. Do not use appliance for other

than intended use.

13. This appliance has a polarized plug (one blade

is wider than the other). This plug will fit in a

polarized outlet only one way. To reduce the

risk of electric shock, this plug is intended to

fit into a polarized outlet only one way. If the

plug does not fit fully in the outlet, reverse the

plug. If it still does not fit, contact a qualified

electrician. Do not change the plug in any way.

14. Maintain labels and nameplates on

the Dehydrator. These carry important

information. If unreadable or missing, contact

Harbor Freight Tools for a replacement.

15. Use personal safety devices, they reduce

the risk for injury. Always wear oven

mittens when handling hot cookware.

16. Maintain a safe working environment. Keep the

work area well lit. Make sure there is adequate

surrounding workspace. Always keep the work

area free of obstructions and other debris. Do

not use this product in a damp or wet location.

17. Do not use metal utensils with the Dehydrator.

They may cause fire and the risk of electric shock.

18. Do not operate the Dehydrator near draperies,

curtains, and walls. These flammable materials

may catch fire from this electric appliance.

19. Always unplug the Dehydrator from its

electrical outlet and allow the product to cool

completely before performing any inspection,

maintenance, or cleaning procedures.

20. Do not clean with metal scouring pads.

Metal pieces can break off the pads and touch

electrical parts involving risk of shock.

Page 3For technical questions, please call 1-888-866-5797.Item 66906

SAFETYOPERATIONMAINTENANCE SETUP

21. Do not store anything other than the

manufacturer’s recommended accessories

in this unit when not in use.

22. Keep bystanders and children at a distance

while operating the Dehydrator.

23. Do not immerse electrical components in water.

24. Do not use oil sprays on the trays.

25. The warnings, precautions, and instructions

discussed in this instruction manual cannot

cover all possible conditions and situations

that may occur. It must be understood by the

operator that common sense and caution are

factors which cannot be built into this product,

but must be supplied by the operator.

26. WARNING: The cord of this product contains

lead and/or di (2-ethylhexyl) phthalate (DEHP),

chemicals known to the State of California

to cause cancer, and birth defects or other

reproductive harm. Wash hands after handling.

(California Health & Safety Code § 25249.5, et seq.)

SAVE THESE INSTRUCTIONS.

Power Cord Safety

1. A short power supply cord is provided

to reduce risks resulting from becoming

entangled in or tripping over a longer cord.

2. Longer extension cords are available and may

be used if care is exercised in their use.

3. If a long extension cord is used,

a. the marked electrical rating of the

(detachable power supply cord or) extension

cord should be at least as great as the

electrical rating of the appliance,

b. if the appliance is of the grounded

type, the extension cord should be a

grounding type 3-wire cord, and

c. the longer cord should be arranged so that it will

not drape over the counter top or tabletop where

it can be pulled on by children or tripped over.

Page 4 For technical questions, please call 1-888-866-5797. Item 66906

SAFETY OPERATION MAINTENANCESETUP

OPERATING INSTRUCTIONS

Food Trays (3) Lid (2)

Bottom (8)

Power Cord (5)

Note: For additional information regarding the

parts listed in the following pages, refer to the

Assembly Diagram at the end of this manual.

Note: Before using, wash the Lid (2) and

the five Food Trays (3) in hot, soapy water,

taking care to rinse completely. Dry with a soft

cloth. Wipe the base with a soft clean cloth or

sponge. NEVER IMMERSE BASE, CORD OR

PLUG IN WATER OR ANY OTHER LIQUID.

1. Before using, make sure the

Dehydrator unit is unplugged.

2. Clean all parts before assembling. Always wash

the Food Trays (3) and Lid (2) before each

use. This will prevent food contamination.

3. Place the base assembly on a flat, smooth

surface near an electrical outlet.

4. Prepare, pre-treat, and/or pre-cook the food to

be used in the Dehydrator. Preparation depends

on the type of food to be dried. Some food will need

to have the outer layer peeled before dehydration.

Pre-treating: Fruits and Vegetables

The enzymes that are responsible for color, flavor

and texture, change during the life of the produce.

This process will continue during drying and

storage unless the activity is slowed down. The

following information offers some methods which

you may choose to use to impact this process.

a. Blanching:

Plunge the fruit or vegetables into boiling

water for one or two minutes. Place

in ice water to cool. Blot to remove

excess moisture before drying.

b. Steam Blanch:

Use steam for about four (4) minutes and

then place in ice water to cool. Blot to

remove excess moisture before drying.

c. Fruit Dip:

Plunge the fruit into lemon or pineapple juice

for two to three minutes. Blot and place

on the tray. You may also use lime

juice, orange juice, honey or gelatin.

d. Sodium Bisulfate:

Use a USP (United States Pharmacopeia)

grade of this solution. Dissolve one teaspoon

in one quart of water. This will help to

maintain the food’s natural color. Blot to

remove excess moisture before drying.

Precooking: Meat

WARNING! This unit is to be used only on meat that

has been pre-cooked properly. This unit will NOT

heat raw meats enough to kill the bacteria and other

pathogens present. Steam, roast, or otherwise heat

all pieces of meat to an internal temperature of at least

160° F (165° F for poultry). Refer to the USDA’s website

for additional food safety tips: http://www.fsis.usda.

gov/Fact_Sheets/Jerky_and_Food_Safety/index.asp

5. More than one type of food may be placed on

each tray. However, do not mix meat and fruits/

vegetables on the same tray or place a tray

with meat over a tray with fruits/vegetables.

Do not overlap food or overload trays.

Note: When the unit is plugged in, it’s warming

element will constantly be on. When you are

finished, unplug the unit to turn it off.

6. After the food is arranged on a tray, do not place

on the base yet. STACK UP AND SET ASIDE.

Page 5For technical questions, please call 1-888-866-5797.Item 66906

SAFETYOPERATIONMAINTENANCE SETUP

7. Plug the unit into an electrical wall outlet, and allow

the unit to preheat for approximately 5 minutes.

8. Place the stacked trays on the base. Cover

the top tray with the Lid (2). Allow the food to

dry for the chosen length of time. Drying time

depends on the type of food. Consult recipes for

various food drying techniques; follow beef*,

poultry*, or fish jerky* drying recipes very

carefully. Experimenting with different foods will

help you determine the length of time needed

for various foods. Purchasing recipe books (not

available at Harbor Freight Tools) or checking

on the Web for free recipes are good sources.

9. Check the food periodically before the dehydration

period is complete. Check for desired dryness.

Remove individual pieces and store in containers

or food bags. For food that is not quite done,

leave in the Dehydrator but check frequently.

10. Vents in the lid and base maintain proper circulation

while dehydrating. Do not block vents during

operation, as this will interfere with proper airflow.

11. Store all food that is not going to be eaten within

a day or two in the refrigerator or freezer. Be sure

to use freezer-proof storage containers or freezer

bags. Seal tightly. Properly home-dried jerky

can be stored 1 to 2 months without freezing.

12. When finished using the Dehydrator, unplug the unit.

13. WASH THE FOOD TRAYS (3) AND LID (2)

AFTER EACH USE. Wipe any food particles

from the base. Make sure the trays and

cover are completely dry before stacking the

trays back in the unit and storing away.

Suggested Drying Times

Drying times will change according to the humidity of the air, the temperature of the room, and the moisture content

of the food item being dried. You will need to experiment with small portions first to become familiar with the time it

will take to dry your chosen food item. Below are some general guidelines for some foods which are commonly dried.

Use this table only as a guide, as drying times will vary.

Food Done When Food Is: Estimated Drying Time

Apples Pliable 1-2 Days

Apricots Pliable 2-3 Days

Bananas Crisp 1 -1.5 Days

Orange Rind Brittle 1 -1.5 Days

Peaches Pliable and Leathery 2-3 Days

Watermelon Pliable and Sticky 2-3 Days

Artichoke Hearts Brittle 1-1.5 Days

Beets Deep Red and Brittle 1-2 Days

Carrots Leathery 1-2 Days

Corn Brittle 1-2 Days

Pumpkin Leathery 2 Days

Tomatoes Leathery 1.5-3 Days

Meat*, Poultry*, or Fish* Jerky

marinate and thoroughly precook (see page 4) first Leathery 1-2 Days

* WARNING! This unit is to be used on meat only if it has been precooked to at

least 160° F (165* F for poultry) throughout first. This unit will NOT heat raw

meats enough to kill the bacteria and other pathogens present.

Swapping the Trays

1. Swap trays every 2-4 hours as shown in

“Figure A”. Trays near the bottom are hotter

and food on them will dry more rapidly.

2. Turn each tray a 1/4 turn every

time they are swapped.

LID

BASE

START

LID

BASE

ROTATE

LID

BASE

ROTATE

Figure A

Page 6 For technical questions, please call 1-888-866-5797. Item 66906

SAFETY OPERATION MAINTENANCESETUP

INSPECTION, MAINTENANCE, AND CLEANING

1. WARNING! Make sure the Dehydrator is

unplugged from its electrical outlet and allowed

to cool before performing any inspection,

maintenance, or cleaning procedures.

2. BEFORE EACH USE, inspect the general

condition of the Dehydrator. Check for loose

screws, misalignment or binding of moving parts,

cracked or broken parts, damaged electrical

wiring, and any other condition that may affect

its safe operation. If abnormal noise or vibration

occurs, have the problem corrected before

further use. Do not use damaged equipment.

3. After each use, wash the Top Lid (2) and the

Food Trays (3) in hot, soapy water, taking care

to rinse completely. Dry with a soft cloth.

4. Clean the outside of the Dehydrator with

a clean, damp cloth. Never use abrasive

cleaners; they will damage the unit. You may

use a mild detergent. Never submerge the

outer base, or any other part not mentioned in

number 3 above, in water or any other liquid.

5. Remove residue. Then, wipe with a damp cloth.

Allow it to dry completely before reusing. You

must keep the Bottom (8) free from any foreign

objects or the Dehydrator will not operate properly.

Note: Improper cooking may cause unpleasant

odors while using the Dehydrator.

Record Product’s Serial Number Here:

Note: If product has no serial number, record month and year of purchase instead.

Note: Some parts are listed and shown for illustration purposes only,

and are not available individually as replacement parts.

Page 7For technical questions, please call 1-888-866-5797.Item 66906

SAFETYOPERATIONMAINTENANCE SETUP

Parts List and Diagram

PLEASE READ THE FOLLOWING CAREFULLY

THE MANUFACTURER AND/OR DISTRIBUTOR HAS PROVIDED THE PARTS LIST AND ASSEMBLY DIAGRAM

IN THIS MANUAL AS A REFERENCE TOOL ONLY. NEITHER THE MANUFACTURER OR DISTRIBUTOR

MAKES ANY REPRESENTATION OR WARRANTY OF ANY KIND TO THE BUYER THAT HE OR SHE IS

QUALIFIED TO MAKE ANY REPAIRS TO THE PRODUCT, OR THAT HE OR SHE IS QUALIFIED TO REPLACE

ANY PARTS OF THE PRODUCT. IN FACT, THE MANUFACTURER AND/OR DISTRIBUTOR EXPRESSLY

STATES THAT ALL REPAIRS AND PARTS REPLACEMENTS SHOULD BE UNDERTAKEN BY CERTIFIED AND

LICENSED TECHNICIANS, AND NOT BY THE BUYER. THE BUYER ASSUMES ALL RISK AND LIABILITY

ARISING OUT OF HIS OR HER REPAIRS TO THE ORIGINAL PRODUCT OR REPLACEMENT PARTS

THERETO, OR ARISING OUT OF HIS OR HER INSTALLATION OF REPLACEMENT PARTS THERETO.

Part Description Qty.

1 Top Lid 1

2 Lid 1

3Food Tray 5

4 Button 1

5 Power Cord 1

6 Support 4

7 Heating Element 1

8 Bottom 1

3491 Mission Oaks Blvd. • PO Box 6009 • Camarillo, CA 93011 • 1-888-866-5797

Limited 90 Day Warranty

Harbor Freight Tools Co. makes every effort to assure that its products meet high quality and durability standards,

and warrants to the original purchaser that this product is free from defects in materials and workmanship for the

period of 90 days from the date of purchase. This warranty does not apply to damage due directly or indirectly,

to misuse, abuse, negligence or accidents, repairs or alterations outside our facilities, criminal activity, improper

installation, normal wear and tear, or to lack of maintenance. We shall in no event be liable for death, injuries

to persons or property, or for incidental, contingent, special or consequential damages arising from the use of

our product. Some states do not allow the exclusion or limitation of incidental or consequential damages, so the

above limitation of exclusion may not apply to you. THIS WARRANTY IS EXPRESSLY IN LIEU OF ALL OTHER

WARRANTIES, EXPRESS OR IMPLIED, INCLUDING THE WARRANTIES OF MERCHANTABILITY AND FITNESS.

To take advantage of this warranty, the product or part must be returned to us with transportation charges

prepaid. Proof of purchase date and an explanation of the complaint must accompany the merchandise.

If our inspection verifies the defect, we will either repair or replace the product at our election or we may

elect to refund the purchase price if we cannot readily and quickly provide you with a replacement. We will

return repaired products at our expense, but if we determine there is no defect, or that the defect resulted

from causes not within the scope of our warranty, then you must bear the cost of returning the product.

This warranty gives you specific legal rights and you may also have other rights which vary from state to state.

Table des matières

Autres manuels Ship To Shore Appareils de cuisine

Ship To Shore

Ship To Shore 69460 Instructions de montage

Manuels Appareils de cuisine populaires d'autres marques

Tayama

Tayama TYG-35AF Manuel utilisateur

AEG

AEG 43172V-MN Manuel utilisateur

REBER

REBER Professional 40 Guide de l'utilisateur

North American

North American BB12482G / TR-F-04-B-NCT-1 Manuel utilisateur

Presto

Presto fountain popper Manuel utilisateur

Westmark

Westmark 1035 2260 Manuel utilisateur

Zanussi

Zanussi ZCG64396XA Manuel utilisateur

HOFFEN

HOFFEN SM-9302M Manuel utilisateur

Philips

Philips HD3133 Manuel utilisateur

Ronco

Ronco Beef Jerky Manuel utilisateur

Hendi

Hendi 470411 Manuel utilisateur

Livoo

Livoo MEN386 Manuel utilisateur

Vogue

Vogue D446 Manuel utilisateur

croydon

croydon WR-10313-700 Manuel utilisateur

ADE

ADE AUTOMATIC-L Manuel utilisateur

Chefman

Chefman RJ43-SQ Series Manuel utilisateur

Vacmaster

Vacmaster VP680 Manuel utilisateur

Jetmaster

Jetmaster 900HG Manuel utilisateur
