- q3 Magnum feature is active level 3
What is Pit Limiter mode
Before operating the pit limiter mode you have to set the RPM limit, parameter Ad/PL see
table above. Pit limiter mode when activated restricts the engine speed to a user pre-set
value and is controlled via handlebar switch provided in the kit.
What is the (Ultra Smooth) shift feature:
This option will restore the power on the next gear when using the quickshifter by firing
sequential cylinders allowing smooth transition between gears, particularly suitable for
cruise and city riding.
What is the (SC) shift sensor sensitivity control:
This option allows you to adjust the force required by the shift sensor to initiate a shift
depending on engine RPM. You can adjust 3 levels of force (A = Low, b = Med, c = High)
depending on 5 RPM ranges respectively: 1 = (3k to 5k); 2 = (5k to 7k); 3 = (7k to 9k); 4 = (9k
to 11k); 5 = (11k to red line). This option has been pre-set from factory we recommend to
test ride before changing the parameters.
Force reset of the control box
With everything connected turn the ignition key on with the engine kill switch in RUN
position, the engine must not be running then press and hold the shift lever in the direction
of upshifting all the way in –at this point the control box will display a timer hold the shift
lever until “rt” starts flashing. Module is now reset to the factory pre-set values.
Tips on adjusting your Quickshifter!
The MAGNUM Quickshifter arrives with best overall setting to your motorcycle make and
model. We strongly recommend you to test ride it before changing the St settings. Use the
following as a general guide when adjusting your Quickshifter:
If when using the Quickshifter the gearbox seems to push back the shift lever, the shift feels
rough and you have experienced missed gears - this means that the gearbox needs more
time to react –increase the St shift time.
If when using the Quickshfiter the motorcycle front dives for too long and the shift seems
slow - this means that you have to lower the shift time –decrease the St shift time. Best
results for most motorcycles are achieved with the following time settings - (60ms-70ms).
The Quickshifter has a threshold RPM which means that the engine speed must exceed the
minimum threshold in order to activate the Quickshifter function. The factory setting are
over 3000RPM and this is not adjustable.
If for some reason you're experiencing difficulties adjusting your Shift Power product, you
think it is not functioning as expected or you would like to share your opinion please feel free
to contact us to support you with a professional help.
Web: https://www.shiftpower.co.uk Email: info@ShiftPower.co.uk
This product is covered by one year warranty against malfunctions from the original date of
purchase under the following conditions –link click here.
Warranty disclaimer:
Shift Power Ltd shall not under any circumstances, be liable for any special, incidental or
consequential damaged including, person, party or property, but not limited to, damage loss
of cost of purchased or replacement goods or service, claims of customers of the purchaser,
